Philips MCM177/12 Manual de usuario

CR2025

Quick Start Guide

Step B

Step A

Enjoy

Setup

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

FM antenna

Quick Start Guide

Pull out the insulation

plastic sheet.

User Manual

User manual

Remote Control

MCM177

MCM177_12_QSG_Eng 1/11/08, 10:271

Step A Setup

Connection

Setting the clock

For radio reception, connect the supplied FM antenna to the

FM ANTENNA terminal.

Connect the speaker wires to the SPEAKERS terminals.

Connect the power cord of the system to the AC power outlet.

In standby mode, press and hold DISPLAY/CLOCK

(CLOCK on the remote control) for 2 seconds.

Press TUNING ¡1 / 2™ (¡1 / 2™ on the remote control ) to

set the hours.

Press í/

ëon the set (ALBUM/PRESET +/- on the remote control )

to set the minutes.

Press DISPLAY/CLOCK (CLOCK on the remote control) to confirm the time.

speaker

(right)

speaker

(left)

FM wire antenna

Power adaptor

2Press PROG to select between 12 hour and 24 hour display.

The clock digits for flash.

MCM177_12_QSG_Eng 1/11/08, 10:272

Tip:

Detailed playback features and

additional functions are described in

the accompanied owner's manual.

Step B Enjoy

Playing a disc

Select FM source.

Press PROG on the remote control for more than two seconds to program all available stations

in order of waveband.

Pressí/

ëon the set (ALBUM/PRESET +/- on the remote control ) until the desired preset station is

displayed

Programming and tuning to radio stations

Select CD source.

Press OPEN/CLOSE on the top of the system to open the CD door.

Insert a disc with the printed side facing up and press down

on OPEN/CLOSE to close the CD door.

PressÉÅto start playback.

Press 9to stop playback.

Notes for the remote control:

– First, select the source you wish to

control by pressing one of the source select

keys on the remote control (CDor AUX, for

example).

–Then select the desired function ( 2;,

í, ëfor example).

MCM177_12_QSG_Eng 1/11/08, 10:273

Step B Enjoy

2008 CKoninklijie Philips Electronics

http://www.philips.com PDCC-ZYL-0802

Playing a USB mass storage device

Make sure that your MCM177 is being powered on.

Press SOURCE repeatedly (or USB on the remote) to enter USB mode.

The LCD display shows USB.

Plug a compatible USB mass storage device to MCM177’s USB port marked .

If needed, use a suitable USB cable to connect between the device and MCM177’s USB port.

The device will automatically power on.

PressÉÅon your MCM177 to start playback.

Press 9to stop playback.

Tip:

Refer to the user manual supplied for

the description about compatibility of

USB mass storage device, and

playability of the files stored on the

USB device.

INFORMATION REGARDING USB DIRECT:

1. Compatibility of the USB connection on this micro system:

a) This micro system supports most USB Mass storage devices (MSD) that these devices are compliant

to the USB MSD standards.

i) Most common Mass storage class devices are flash drives, memory sticks, jump drives and etc.

ii) If you see a "Disc Drive" showing up on your computer after you have plugged the mass storage

device into your computer, most likely it is MSD compliant and it will work with this micro system.

b) If your Mass storage device requires a battery/power source, please make sure you have a fresh

battery in it or charge the USB device first and then plug it into the micro system again.

2) Supported Music type:

a) This device only supports unprotected music with file extension: .mp3 .wma

b) Music bought from on-line music stores are not supported because they are secured by Digital Rights

Management protection (DRM).

c) File name extensions that ended with the following are not supported: .wav; .m4a; .m4p; .mp4; .aac and

etc.

3) No Direct connection can be made from a Computer USB port to the micro system even you have either

or both mp3 or wma file in your computer.

MCM177_12_QSG_Eng 1/11/08, 10:274
