Philips HPL-N Manual de usuario

H.I.D. lamps HPL (-N)(-R) Comfort

∅A

Type A B

max. max.

Cap/base E27

HPL Comfort 50W 56.00 130.00

HPL Comfort 80W 71.00 155.00

HPL Comfort 125W (HG) 76.00 173.00

HPL-N 50W/542 56.00 130.00

HPL-N 80W/542 71.00 155.00

HPL-N 125W HG/542 76.00 173.00

40 max.

187 max.

∅127 max.

colour quality and luminous

efficacy.

The HPL-R has a cone-shaped

hard-glass bulb with an internal

reflector directing the light to

where it is needed.

Applications

- HPL Comfort and HPL-N:

pedestrian and residential areas,

commercial and public buildings,

factories, railway stations,

schools, shops and petrol

stations.

- HPL-R: high-bay in heavy

industry e.g. iron foundries,

paper mills, mines and quarries;

also sign boards and decorative

floodlighting.

High-pressure mercury vapour

lamps consist of a glass bulb,

containing a gas for maintaining a

constant temperature, and a

quartz mercury vapour discharge

tube.The lamps are equipped

with a standard screw or bayonet

base and one or two auxiliary

electrodes to ensure quick and

reliable ignition. Apart from a

ballast, no special control gear is

required.

The HPL-N has an internally

coated ovoid outer bulb,

providing a cool, bluish white light

with reasonable colour qualities.

The HPL Comfort has a special

internal coating, providing a

pleasant white light with increased

HPL-R

Dimensions in mm

HPL(-N) (Comfort)

HPL-R 125 W HG E27

H.I.D. lamps HPL (-N)(-R) Comfort

∅A

Type A B C

max. max. max.

Cap/base E40

HPL-R 250W HG 162.50 259.00 50.00

HPL-R 400W HG 178.50 299.00 50.00

∅A

Type A B

max. max.

Cap/base E40

HPL Comfort 250W HG 91.00 228.00

HPL Comfort 400W HG 121.50 290.00

HPL-N 125W 76.00 184.00

HPL-N 250W HG 91.00 228.00

HPL-N 400W HG 121.50 290.00

HPL-N 700W HG 141.50 328.00

HPL-N 1000W HG 166.50 399.00

Dimensions in mm

Burning position

Commercial Wattage Cap/ Lamp Lamp Lamp Lumen Correlated Chrom. Chrom. Colour Maximum Maximum Nett EOC

name base wattage voltage current output colour coord. coord. rendering permissible permissible weight

temp. index base/pinch bulb

temp. temp.

WWVA lm K x y degr.C degr.C g

HPL Comfort

HPL Comfort 250 HG E40 250 135 2.13 14200 3300 419 392 51 250 350 185 181022

HPL Comfort 400 HG E40 400 140 3.25 24200 3500 413 392 47 250 350 260 181053

HPL-N

HPL-N 50 E27 50 95 0.61 1800 4200 371 370 49 200 350 46 179913

HPL-N 125 E27 125 125 1.15 6200 4100 374 373 46 200 350 76 180124

HPL-N 125 E40 125 125 1.15 6200 4100 374 373 46 200 350 110 180308

HPL-N 125 HG E27 125 125 1.15 6200 4100 374 373 46 200 350 90 180155

HPL-N 250 HG E40 250 135 2.10 12700 4100 381 383 45 250 350 184 180605

HPL-N 400 HG E40 400 140 3.25 22000 3900 384 384 45 250 350 26 180452

HPL-N 700 HG E40 700 145 5.40 38500 3900 390 390 45 250 350 344 183910

HPL-N 1000 HG E40 1000 145 7.50 58500 3900 390 395 36 250 350 520 184030

HPL-R

HPL-R 125 HG E27 125 125 1.15 5700 4200 371 387 43 200 350 147 183880

HPL-R 250 HG E40 250 135 2.10 12000 4100 381 394 37 250 350 323 183941

HPL-R 400 HG E40 400 140 3.20 20500 3900 382 402 36 250 350 360 183972

Mercury HP

HG = Hard glass outer bulb

H.I.D. lamps HPL (-N)(-R) Comfort

300 400 500 600 700 800

100

200

300

400

500

600 HPL-N 250 W, HPL-R 250 W

Wavelength in nm

mW per m2per 5 nm

per 1000 lux

246810

200

160

120

HPL-N, HPL Comfort, HPL-R

Time in min.

lamp current

lamp wattage

luminous flux

lamp voltage

Lamp performance during run-up

92 96 100 104 108

125

115

105

HPL-N, HPL Comfort, HPL-R

Relative supply voltage in %

lamp current

lamp wattage

luminous flux

lamp voltage

Effects of mains voltage variations

180°

90°

60°

30°

90°

60°

30°

(cd)

HPL-R

2000

4000

6000

8000

125 W

250 W

400 W

Polar light distributions

180°

90°

60°

30°

90°

60°

30°

(cd)

HPL-R

3500

7000

10500

14000

700 W

1000 W

300 400 500 600 700 800

100

200

300

400

500

600 HPL Comfort 250 W

Wavelength in nm

mW per m2per 5 nm

per 1000 lux

Spectral power distributions
