Philips 42TA2800S Manual de usuario

Philips

widescreen flat TV with

Digital Crystal Clear

107cm (42")

LCD HD Ready

42TA2800S

Turn up your viewing experience

with Digital Crystal Clear

Tuned for picture-perfect quality, the Philips 42TA2800 HDTV delivers optimal high

definition display and increased picture depth plus virtual surround sound, eye-catching

design, smart audio/video presets and even doubles as a PC monitor.

Vivid, natural and razor sharp images

• HD LCD WXGA display, with a 1366 x 768p resolution

• HD Ready for the highest quality display of HD signals

• Digital Crystal Clear provides vivid cinema-like images

• Progressive Scan component video for optimized image quality

Crisp and Clear sound

• Virtual Surround Sound for enhanced sound

Stylish design

• Compact and slim design that fits in every room

Designed for your convenience

• Smart Picture and Smart Sound to personalize your viewing

• PC input lets you also use your TV as a PC monitor

For advanced performance

• HDMI input for full digital HD connection in one cable

42TA2800S/93

Highlights

Widescreen flat TV with Digital Crystal Clear

107cm (42") LCD HD Ready

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

HD Ready

Enjoy the exceptional picture quality of High

Definition pictures and be fully prepared for

HD sources like HDTV settop box or Blu-ray

disc. HD Ready is a protected label that offers

picture quality beyond that of progressive scan.

It conforms to strict standards laid out by

EICTA to offer a HD screen that displays the

benefits of resolution and picture quality of a

High Definition signal. It has a universal

connection for both analog YPbPr and

uncompressed Digital connection of DVI or

HDMI, supporting HDCP. It can display 720p,

and 1080i signals at 50 and 60Hz.

Digital Crystal Clear

Digital Crystal Clear is a package of picture

innovations that digitally adjusts and optimizes

picture quality to optimal contrast, color and

sharpness levels. It's like watching vivid cinema-

like images.

Progressive Scan

Progressive Scan doubles the vertical

resolution of the image resulting in a noticeably

sharper picture. Instead of sending a field

comprising the odd lines to the screen first,

followed by the field with the even lines, both

fields are written at one time. A full image is

created instantaneously, using the maximum

resolution. At such a speed, your eye perceives

a sharper picture with no line structure.

Virtual surround sound

Virtual surround sound creates additional

audio channels for a theater-like audio

experience.

Smart Picture and Smart Sound

Philips preset modes for Smart Picture and

Smart Sound provide you with direct access via

a single key on the remote control. You can

select optimized picture and sound settings for

the various picture and sound modes.

HDMI input

HDMI makes an uncompressed digital RGB

connection from the source to the screen. By

eliminating conversion to an analog signal, it

delivers an unblemished image. The non-

degraded signal reduces flicker and leads to a

clearer picture. HDMI intelligently

communicates the highest output resolution

with the source device. The HDMI input is fully

backward compatible with DVI sources but

includes digital audio. HDMI uses HDCP copy

protection.

PC input

With PC input you can connect your TV to a

computer and use the TV as a PC monitor.

Issue date 2011-06-07

Version: 2.0.3

12 NC: 8670 000 35655

EAN: 87 12581 38416 6

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

42TA2800S/93

Specifications

Widescreen flat TV with Digital Crystal Clear

107cm (42") LCD HD Ready

Picture/Display

• Color cabinet: black, high gloss black strip

• Aspect ratio: Widescreen

• Display screen type: LCD WXGA Active Matrix

TFT

•Panel resolution: 1366 x 768p

• Picture enhancement: Digital Crystal Clear, 3/2 - 2/

2 motion pull down, 3D Combfilter, 3D MA

deinterlacing, Blue stretch, Black stretch, White

stretch, Green enhancement, Progressive scan,

Smart Picture, Automatic skin tone correction

• Screen enhancement: Anti-Reflection coated

screen

Supported Display Resolution

•Computer formats

Resolution Refresh rate

640 x 480 60Hz

800 x 600 56, 60Hz

1024 x 768 60Hz

1280 x 720 60Hz

1280 x 768 60Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

576i 50Hz

576p 50Hz

720p 60Hz

1080i 60Hz

Sound

• Output power (RMS): 2 x 10 W

• Sound Enhancement: Virtual Surround Sound

• Sound System: Mono, Nicam Stereo, Stereo

Loudspeakers

• Loudspeaker types: detachable

Convenience

• Child Protection: Child Lock+Parental Control

• Clock: Sleep Timer

• Ease of Installation: Autostore, Fine Tuning, PLL

Digital Tuning, Sorting

• Ease of Use: Auto Volume Leveller (AVL), On

Screen Display, Program List, Smart Picture, Smart

Sound, Top Controls

• Remote Control: TV

• Remote control type: RC2023611/01B

• Screen Format Adjustments: 4:3, Subtitle Zoom,

Superwide, Widescreen, Zoom 14:9, Zoom 16:9

• Picture in Picture: Picture in graphics

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• TV system: PAL D/K

• Video Playback: NTSC, PAL

• Tuner bands: Hyperband, S-Channel, UHF, VHF

Connectivity

• AV 1: Audio L/R in, YPbPr

• AV 2: Audio L/R in, YPbPr

• AV 3: Audio L/R in, CVBS in, S-Video in

•AV4:HDMI

•Front/Sideconnections:Audio L/R in, CVBS in,

Headphone out, S-video in

• Other connections: Analog audio Left/Right out,

Composite video (CVBS) out, PC Audio in, PC-In

VGA, S/PDIF out (coaxial)

Power

• Ambient temperature: 0 °C to 40 °C

• Mains power: 90-264 VAC, 50/60 Hz

• Power consumption: < 275 W

• Standby power consumption: < 2 W

Accessories

• Included accessories: Power cord, Quick start

guide, User Manual, Warranty certificate, Remote

Control, Batteries for remote control

Dimensions

•Setdimensions(Wx H x D):

1039 x 700 x 102 mm

• Set dimensions with stand (W x H x D):

1039 x 759 x 256 mm

• Product weight: 21 kg

• Product weight (+stand): 28 kg

•Boxdimensions(Wx H x D):

1182 x 767 x 363 mm

• Weight incl. Packaging: 36 kg

• VESA wall mount compatible: 400 x 200 mm

•
