Pepperl+Fuchs Vibracon LVL-M2C Manual de usuario

ISO9001

LVL-M2C

Vibration Level Switch

ATEX, IEXEx

Ex ia IIC Ga/Gb

Instruction Manual

With regard to the supply of products, the current issue of the following document is applicable:

The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central

Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most

recent version as well as the supplementary clause: "Expanded reservation of proprietorship"

Worldwide

Pepperl+Fuchs Group

Lilienthalstr. 200

68307 Mannheim

Germany

Phone: +49 621 776 - 0

E-mail: [email protected]hs.com

North American Headquarters

Pepperl+Fuchs Inc.

1600 Enterprise Parkway

Twinsburg, Ohio 44087

USA

Phone: +1 330 425-3555

E-mail: [email protected]

Asia Headquarters

Pepperl+Fuchs Pte. Ltd.

P+F Building

18 Ayer Rajah Crescent

Singapore 139942

Phone: +65 6779-9091

E-mail: [email protected]erl-fuchs.com

https://www.pepperl-fuchs.com

Vibration Level Switch LVL-M2C

SI00113O-G

2022-03

Vibration Level Switch

Vibracon LVL-M2C

Table of Contents

Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Supplementary Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Manufacturer's Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Manufacturer Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Other Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Extended Order Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Safety Instructions: General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Safety Instructions: Special Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Safety Instructions: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Temperature Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Connection Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

2022-03

Vibration Level Switch LVL-M2C

SI00113O-G

1 Associated Documentation

This document is an integral part of the following documents:

•KA00162O (LVL-M2C)

The documents which are supplied and correspond to the device type apply.

2 Supplementary Documentation

Electrical explosion protection literature:

The literature can be found on the Internet at www.pepperl-fuchs.com.

3 Manufacturer's Certificates

EU Declaration of Conformity

The EU Declaration of Conformity can be found on the product detail page of the devices

on the Internet at www.pepperl-fuchs.com.

Enter the order designation in the search field → Select the appropriate product →

Open the product detail page → Open the Approvals+Certificates tab.

EU Type-Examination Certificate

Certificate number: KEMA 01 ATEX 1089 X

List of applied standards: see EU Declaration of Conformity

IEC Declaration of Conformity

Certificate number: IECEx DEK 16.0077X

Affixing the certificate number certifies conformity with the following standards

(depending on the device version).

•IEC 60079-0:2017

•IEC 60079-11:2011

•IEC 60079-26:2021

4 Manufacturer Address

Pepperl+Fuchs Group

Lilienthalstraße 200, 68307 Mannheim, Germany

Internet: www.pepperl-fuchs.com

5 Other Standards

Among other things, the following standards shall be observed in their current version

for proper installation:

•IEC/EN 60079-14: "Explosive atmospheres - Part 14: Electrical installations design,

selection and erection"

•EN 1127-1: "Explosive atmospheres - Explosion prevention and protection - Part 1:

Basic concepts and methodology"

Vibration Level Switch LVL-M2C

SI00113O-G

2022-03

6 Extended Order Code

The extended order code is indicated on the nameplate, which is affixed to the device

in such a way that it is clearly visible. Additional information about the nameplate is provided

in the associated manual.

Structure of the Extended Order Code

Table 1

Basic Specifications

The features that are absolutely essential for the device (mandatory features) are specified

in the basic specifications. The number of positions depends on the number of features

available. The selected option of a feature can consist of several positions.

Optional Specifications

The optional specifications describe additional features for the device (optional features).

The number of positions depends on the number of features available.

More detailed information about the device is provided in the following tables.

These tables describe the individual positions and IDs in the extended order code

which are relevant to hazardous locations.

Device type Basic specifications Probe length

LVL-M2C – XXXXXX-XXXXXX-XX . XXXX

X = Placeholder

At this position, an option (number or letter) selected from the specification is displayed instead

of the placeholders.

2022-03

Vibration Level Switch LVL-M2C

SI00113O-G

Extended Order Code: Vibration Level Switch

Device type

LVL-M2C

Basic specifications

Table 2

Optional specifications

No options specific to hazardous locations are available.

Note

The following specifications reproduce an extract from the product structure and are used

to assign:

•This documentation to the device (using the extended order code on the nameplate).

•The device options cited in the document.

Probe version, probe length

Position Option Description

LVL-M2C-XXXXXX-XXXXXX-XX.XXXXX BK, CK, DK with ECTFE coating

Temperature spacer, gastight spacer

Position Option Description

LVL-M2C-XXXXXXX-XXXXXX-XX.XXXXX A without

BTemperature spacer

CGastight spacer

Housing

Position Option Description

LVL-M2C-XXXXXXX-XXXXXX-XX.XXXXX AX Aluminum housing

EX Stainless steel housing, hygienic version

Electrical connection

Position Option Description

LVL-M2C-XXXXXXX-XXXXXX-XX.XXXXX PA FEL50A, PROFIBUS PA

SI FEL55, 8/16 mA, 11 V to 36 V DC

N1 FEL56, NAMUR, L-H edge

N2 FEL58, NAMUR with push button, H-L edge

Approval

Position Option Description

LVL-M2C-XXXXXX-XXXXXX-XX.XXXXX EI ATEX II 1/2G Ex ia IIC T6...T1 Ga/Gb

IECEx Ex ia IIC T6...T1 Ga/Gb

Vibration Level Switch LVL-M2C

SI00113O-G

2022-03

7 Safety Instructions: General

•The device is intended to be used in explosive atmospheres as defined in the scope

of IEC 60079-0 or equivalent national standards. If no potentially explosive atmospheres

are present or if additional protective measures have been taken:

The device may be operated according to the manufacturer's specifications.

•Staff must meet the following conditions for mounting, electrical installation,

commissioning and maintenance of the device:

•Be suitably qualified for their role and the tasks they perform

•Be trained in explosion protection

•Be familiar with national regulations

•Install the device according to the manufacturer's instructions and national regulations.

•Do not operate the device outside the specified electrical, thermal and mechanical

parameters.

•Only use the device in media to which the wetted materials have sufficient durability.

•Avoid electrostatic charging:

•Of plastic surfaces (e. g. housing, sensor element, special varnishing,

attached additional plates, ...)

•Of isolated capacities (e. g. isolated metallic plates)

•Refer to the temperature tables for the relationship between the permitted ambient

temperature for the sensor and/or transmitter, depending on the range of application

and the temperature class.

•Modifications to the device can affect the explosion protection and must be carried

out by staff authorized to perform such work by Pepperl+Fuchs.

•The probe is made of stainless steel or high corrosion-resistant alloy of thickness ≥ 1 mm.

8 Safety Instructions: Special Conditions

•Limitations of the maximum ambient temperature at the electronics housing

may be required dependent on device configuration, process temperatures

and temperature classification.

•Details of limitations: See section 10 for temperature tables.

•To avoid electrostatic charging: Do not rub surfaces with a dry cloth.

•In the event of additional or alternative special varnishing on the enclosure or other metal

parts or for adhesive plates:

•Observe the danger of electrostatic charging and discharge.

•Do not install in the vicinity of processes ( 0.5 m) generating strong electrostatic

charges.

Basic specification, feature Housing, option AX

Avoid sparks caused by impact and friction.

Device group IIC

•Sensors coated with non-conductive material can be used if avoiding electrostatic

charging (e. g. through friction, cleaning, maintenance, strong medium flow).

•Marked with warning sign: Avoid electrostatic charging.

2022-03

Vibration Level Switch LVL-M2C

SI00113O-G

9 Safety Instructions: Installation

Basic specification, feature Electrical connection, options SI, N1, N2

Figure 1

AZone 1

1Tank; Zone 0

2Electronic insert

3Housing

4Basic specification, feature Electrical connection, options SI, N1, N2:

associated intrinsically safe power supply units

Vibration Level Switch LVL-M2C

SI00113O-G

2022-03

Basic specification, feature Electrical connection, option PA

Figure 2

•Connect the device using suitable cable and wire entries of protection type

Intrinsic safety (Ex i).

•Continuous service temperature of the connecting cable: ≥ Tamb + 5 K.

•Perform the following to achieve the degree of protection IP66/67:

•Screw the cover tight.

•Mount the cable entry correctly.

•Seal unused entry glands with approved sealing plugs that correspond to the type

of protection.

•Observe the pertinent guidelines when interconnecting intrinsically safe circuits.

•Connection of intrinsically safe PROFIBUS devices: 10 devices.

•Observe the maximum process conditions according to the manufacturer's

documentation.

•At high medium temperatures, note flange pressure load capacity as a factor

of temperature.

AZone 1

1Tank; Zone 0

2Electronic insert

3Housing

4Permitted terminating resistor Ex ia IIC

5Certified associated apparatus

6Power supply

7Tank; Zone 1

8Potential equalization

2022-03

Vibration Level Switch LVL-M2C

SI00113O-G

•Install the device to exclude any mechanical damage or friction during the application.

Pay particular attention to flow conditions and tank fittings.

•Support extension tube of the device if a dynamic load is expected.

Intrinsic safety

•The device is only suitable for connection to certified, intrinsically safe equipment with

explosion protection Ex ia.

•The intrinsically safe input power circuit of the device is isolated from ground.

The dielectric strength is at least 500 Vrms.

Potential equalization

•Integrate the device into the local potential equalization.

•Grounding the screen, see the following figure.

Basic specification, feature Electrical connection, option PA

Figure 3

AVersion 1:

Use small capacitors (e. g. 1 nF, 1500 V, dielectric strength, ceramic).

Total capacitance connected to the screen may not exceed 10 nF.

BVersion 2

1Terminating resistor

2Distributor/terminal box

3Screen insulated

4Supply unit/segment coupler

5Potential equalization (secured in high degree)

6Field device

221

6 6

Otros manuales para Vibracon LVL-M2C

Tabla de contenidos

Otros manuales de Cambiar de Pepperl+Fuchs

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL2-U-8RJ45-DIN Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs SIL LVL-M4 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs VISOLUX ML7-55 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manual

Pepperl+Fuchs

Pepperl+Fuchs LKL-P1 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs HD2-GTR-4PA Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-A7 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL2-U-5RJ45-DIN Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs VISOLUX LD28/76a Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs SI00113O-F Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M1 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs RocketLinx ICRL2-U-16RJ45-G-DIN Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-B1 Manual

Pepperl+Fuchs

Pepperl+Fuchs ARS B2 IC Series Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs KFD0-SD2-Ex2.1045 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-B1 Guía de referencia

Pepperl+Fuchs

Pepperl+Fuchs LVL-M3 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs LCL2 Guía de referencia

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M1 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs LCL2 Guía de referencia

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs Vibracon LVL-M H Series Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manual de usuario

Pepperl+Fuchs

Pepperl+Fuchs LVL-M4 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
