Patton electronics 1058 Manual de usuario

Product Model Model 1058 12.5 Mbps VDSL Modem

Product Name 12.5 Mbps VDSL Modem

Product Manager John Grant Contact Jgrant@patton.com

Who are the customers for the Model 1058?

The Patton Model 1058DV Variable Rate VDSL Modem

enables the utilization of existing copper infrastructure

for the delivery of high-speed broadband services. The

1058DV includes seven asymmetrical and symmetrical

settings, which include an option for line rates up to

16.67 Mbps!

The Model 1058DV’s built in POTS/ISDN splitter allows

users to simultaneo

usly talk on the phone while surfing

the web, downloading files, or receiving emails. This

incredible bandwidth and line sharing capabilities are

provided over a single twisted pair of voice-grade wire.

The Model 1058DV solution is targeted to users or

service providers that need high-speed Ethernet data and voice links over their existing copper

infrastructure. These organizations include but are not limited to CLEC’s, ISP’s, Educational Facilities

(Campus), MTU/MDU’s, and corporate/government offices. Popular applications for symmetrical VDSL

include Ethernet extension, medical imaging, video-conferencing, Ethernet Bridging, and connecting

remote devices or networks to a central LAN. The variable symmetrical data rates ensure the highest

possible data rate is achieved over various lengths and types of copper wire and environments.

Variable asymmetrical line rates make the Model 1058 ideal for service providers who want to

differentiate their services and extend the reach of their customer base using VDSL services. The

Model 1058DV allows service providers to offer unparalleled performance for applications such as:

always on Internet access, real time bi-directional video streaming, and various multimedia

applications.

Typical applications include:

LAN-to-LAN Bridging: The Model 1058 connects remote LANs over a high-speed, symmetrical or

asymmetrical link. The 1058 CP unit is placed at the remote location and the 1058 CO unit is placed at

the central site to provide a LAN-to-LAN connection over a voice-grade wire. This application will

generally be made over a symmetrical link.

Ethernet Extension: The Model 1058 overcomes the 328 ft (100m) limitations of Ethernet with a

symmetrical or asymmetrical data link at distances up to 6,656 ft (2.03 km) and speeds up to 16.67

Mbps. The Model 1058 point-to-point solution does not use or require Ethernet repeaters. This

application will generally be made over a symmetrical link.

oCard

oCardoCard

oCard

Dedicated Internet and Voice Services: The Model 1058 VDSL technology enables ISP’s to deliver

dedicated high-speed Internet access and voice services from a Point-of-Presence (POP) to a

customer premise. A 1058CO is used at the POP and a 1058CP is used at the customer premise. The

Model 1058DV’s built-in POTS/ISDN splitter allows users to simultaneously use the phone or fax

machine, while surfing the web, downloading files or receiving e-mails. The variable rates and

asymmetrical and symmetrical settings allow the ISP’s to sell differentiated services as well as

increase the typical distances of their VDSL services. This application generally will be made over an

asymmetrical link.

MTU/MDU Services: Using the Model 1058 rack chassis and the standalone solution, data and voice

services can be extended to the hotel guest, apartment resident, and housing resident, etc. Patton’s

Model 1058 VDSL modems allow service providers to avoid the cost and trouble of wiring the

individual hotel rooms with 4-wire twisted pair or Ethernet cabling by using the existing voice-grade 2-

wire infrastructure. The service provider would place the 1001R rack system with multiple

1058RCDV/CO rack cards and an Ethernet switch in the basement or closet and the standalone

1058DV/CP in the individual hotel rooms. Once connected, the Model 1058 will automatically

establish a high-speed Point-to-Point voice and data link. Bandwidth can be limited or distance

increased by choosing various asymmetrical /symmetrical data rates on the CO and CP VDSL

modems. This application generally will be made over an asymmetrical link.

Model 1058 Features and Benefits

High-Speed line rates up to 12.5 Mbps. Fast and reliable data transmission.

Extends Ethernet beyond its current 328 ft

(100m) limitation.

Inexpensively links remote devices or extends LANs up

to 6,652 ft (2.03 km).

Full service integration (voice, video, and data)

services over voice-grade telephone wire.

Eliminates the need to install/upgrade to new LAN-grade

cable or expensive fiber.

Built-in POTS/ISDN Splitter Provides “life-line” telephone services.

Operation transparent to high-layer protocols. Lets higher-layer broadcast, cast and uni-cast data

frames pass through, and supports VLAN tagged frames.

Auto-sensing 10 or 100Base-T and full or half-

duplex Ethernet.

No configuration necessary, just Plug your Ethernet

connections in and play.

Auto MDI-X Automatically detects DCE/DTE eliminating the concern

of which type of cable straight-through or crossover.

Seven status LEDs. Monitoring your connection and operational status is

made simple.

ard

ardard

ard

Optional parts for the Model 1058

•DC Power Supplies

•Rack cards are compatible with Patton’s Model 1001R High-Density Telco Rack Chassis and Cluster

Boxes.

•Model 3324/DV/GE/UI 24 Port VDSL Concentrator

Optional DC Power Supplies for Standalone Units

Part Number Description

48V-PSM -48 VDC power supply, 5VDC, 1A (optional)

24V-PSM -24 VDC power supply, 5VDC, 1A (optional)

12V-PSM -12 VDC power supply, 5VDC, 1A (optional)

If you require a DC power supply with the Model 2168, you must order the 2168 without power supplies and add

the DC power supply as a separate line item.

EXAMPLE ORDER:

1 X 1058DV/E-2PK 16 Mbps Multi-VDSL Set (Central Office and Customer Premise); No Power Supply

2 x 48V-PSM -48 VDC power supply, 5VDC, 1A

Shipping/Export Information

ECCN export number: 8517.50.1000

Country of origin: United States of America, NAFTA

Total weight boxed: .96lbs (.44kg) without power supply

Individual unit: .4lbs (.18kg); without power supply

MTBF/ Repair Information

MTBF: 126,000 Hrs. Calculation based on MIL-HDBK-217F, Notice 2 - "Parts Count Reliability Prediction"

Mean time to repair: 7–10 days

Warranty: 1-year parts and labor

Out of warranty repair rate: $150, flat rate – contact Patton’s Tech Support for details.

ard

ardard

ard

Physical Specifications

Dimensions: Standalone: 1.5” H x 4.13” W x 3.75” D (3.81 H x 10.5 W x 9.53 D cm)

Rack Card: 3.00” H x 0.83” W x 7.84” D (7.6 H x 2.1 W x 19.9 D cm)

Color: Standalone: Case: Black Front and Back Panel: Black with white letters

Rack Card: Front and Back Panel: White with black letters

Case material: Standalone: Plastic, Fire retardant Rack Card: Iridite Aluminum

Environmental

Operating Temp: 32 to 122°F (0 to 50°C) Storage Temp: -40 to 185°F (-40 to +85°C)

Relative Humidity: Up to 90% RH, non-condensing

Altitude: 0 –15,000 feet (3,048 meters)

Ventilation requirements: None, units do not require cooling fans.

Approvals

Safety Emissions Telecommunications

FCC part 15, Class ACE Marked per EMC directive

89/336/EEC and low voltage

directive 72/23/EEC.

ESD EN61000-4-2

EN55022 Class A, conducted

and radiated emissions

Power Supplies

Standalone Units Only

AC: 120VAC, 50-60Hz, external or Universal input, 100-240VAC, 50-60Hz, external

DC: -48VDC, -24VDC, or -12VDC external (optional)

ard

ardard

ard

Ordering Information-Model 1058

Model Description

1058DV/CO/E

12.5 Mbps VSDL Modem; Central Office (RJ45); No Power Supply

1058DV/CP/E

12.5 Mbps VSDL Modem; Customer Premise (RJ45); No Power Supply

1058DV/E-2PK

12.5 Mbps VSDL Modem Kit; Central Office and Customer Premise (RJ45); No Power Supply

1058DV/CO/EUI *

12.5 Mbps VSDL Modem; Central Office (RJ45); 100-240VAC

1058DV/CP/EUI*

12.5 Mbps VSDL Modem; Customer Premise (RJ45); 100-240VAC

1058DV/EUI-2PK*

12.5 Mbps VSDL Modem Kit; Central Office and Customer Premise (RJ45); 100-240VAC

1058DVRC/CO

Central Office 12.5 Mbps VSDL Modem Rack Card

1058DVRC/CP

Customer Premise 12.5 Mbps VSDL Modem Rack Card

•When ordering standalone units, it is recommended that the 1058DV be ordered in sets: one 1058DV/CO/E

(Central Office) and one 1058DV/CP/E (Customer Premise). When ordering rack cards it is required to match a

standalone CO (Central Office) with an CP(Customer Premise) rack card and if you order the standalone CO

(Central Office), you must match it with an CP (Customer Premise) rack card.

•* =You must specify a country specific power cord

Environmentally Hardened Models

Model Description

ET1058DV/CP/UI

Extended Temperature 16Mbps EnviroNET VDSL Modem; 100-240VAC; -40 to 85C; NEMA4

EC1058DV/CP/UI

Environmentally Controlled 16Mbps EnviroNET VDSL Modem; 100-240VAC; 0 to 85C; NEMA4

EH1058DV/CP/UI

Environmentally Hardened 16Mbps EnvrioNET VDSL Modem; 100-240VAC; 0 to 50C; NEMA4

ard

ardard

ard
