Patton electronics 1010A Manual de usuario

USER

MANUAL

MODEL 1010A

Miniature, High Speed

Short Range Modem

with Transformer Isolation

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

Part# 07M1010A-A

Doc# 039011UA

Revised 11/8/95

APPENDIX D

BLOCK DIAGRAM

1.0 WARRANTY INFORMATION

Patton Electronics warrants all Model 1010A components to be

free from defects, and will—at our option—repair or replace the product

should it fail within one year from the first date of shipment.

This warranty is limited to defects in workmanship or materials, and

does not cover customer damage, abuse or unauthorized modification.

If this product fails or does not perform as warranted, your sole

recourse shall be repair or replacement as described above. Under no

condition shall Patton Electronics be liable for any damages incurred

by the use of this product. These damages include, but are not limited

to, the following: lost profits, lost savings, and incidental or

consequential damages arising from the use of or inability to use this

product. Patton Electronics specifically disclaims all other warranties,

expressed or implied, and the installation or use of this product shall be

deemed an acceptance of these terms by the user.

1.1 RADIO AND TV INTERFERENCE

The Model 1010A generates and uses radio frequency energy, and

if not installed and used properly—that is, in strict accordance with the

manufacturer's instructions—may cause interference to radio and

television reception. The Model 1010A has been tested and found to

comply with the limits for a Class A computing device in accordance

with the specifications in Subpart J of Part 15 of FCC rules, which are

designed to provide reasonable protection from such interference in a

commercial installation. However, there is no guarantee that

interference will not occur in a particular installation. If the Model

1010A does cause interference to radio or television reception, which

can be determined by disconnecting the RS-232 interface, the user is

encouraged to try to correct the interference by one or more of the

following measures: moving the computing equipment away from the

receiver, re-orienting the receiving antenna, and/or plugging the

receiving equipment into a different AC outlet (such that the computing

equipment and receiver are on different branches).

1.2 SERVICE

All warranty and non-warranty repairs must be returned freight

prepaid and insured to Patton Electronics. All returns must have a

Return Materials Authorization number on the outside of the shipping

container. This number may be obtained from Patton Electronics

Technical Service at (301) 975-1007.

Packages received without an

RMA number will not be accepted.

Patton Electronics' technical staff is also available to answer any

questions that might arise concerning the installation or use of your

Model 1010A. Technical Service hours: 8AM to 5PM EST, Monday

through Friday. 112

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.

This product has been thoroughly inspected and tested and is

warranted for One Year parts and labor. If any questions or problems

arise during installation or use of this product, please do not hesitate to

contact Patton Electronics Technical Support at (301) 975-1007.

2.1 FEATURES

• Transformer coupled for DC isolation between modems

• Immune to ground loops caused by ground potential differences

• Supports asynchronous RS-232 communication over 2 twisted pair

• Supports data rates to 115.2 Kbps, distances to 8.5 miles

• Loops back all handshaking signals on the RS-232 interface

• Externally accessible DCE/DTE switch makes configuration easy

• Very thin case (.75") for closely spaced computer ports

• No AC power or batteries required—draws all necessary operating

power from the RS-232 interface

• Provides surge protection of 600 Watts per wire

2.2 DESCRIPTION

The Patton Model 1010A miniature, high speed, transformer

isolated short range modem lets two asynchronous RS-232 devices

communicate between buildings, over two twisted pair. Supporting

asynchronous data rates to 115.2 Kbps, the Model 1010A derives the

necessary power for operation from the data and control voltages on

the RS-232 interface. DC transformer isolation on the line side gives

the Model 1010A immunity to ground loops that would otherwise

hamper between-building communications.

An external DCE/DTE switch lets you connect to the serial port of

either a computer/terminal (DTE) or a modem (DCE) without using a

crossover cable. The Model 1010A is available with three 4 wire

interface options: RJ-11, RJ-45 or terminal blocks with strain relief.

The Model 1010A also incorporates high speed avalanche diodes

that intercept data line transient surges and shunt them safely to

chassis ground. With surge handling capacity of 600W per wire at

1mS, the 1010A can protect itself and connected equipment from

nearby lightning strikes and other surges of electromagnetic radiation.

APPENDIX C

RS-232C PIN CONFIGURATIONS

1- (FG) Frame Ground

2- (TD) Transmit Data

3- (RD) Receive Data

4- (RTS) Request to Send

5- (CTS) Clear to Send

6- (DSR) Data Set Ready

7- (SG) Signal Ground

8- (DCD) Data Carrier Detect

Data Term Ready (DTR) - 20

RS-232C INTERFACE (DCE)

3.0 CONFIGURATION

The Model 1010A is designed to be easy to use. There are no

internal jumpers or DIP switches to set, so there is no need to open the

case to configure the unit (you may need to open the case for wire

connection—refer to section 4.0). The only configuration necessary for

operation is proper setting of the external DCE/DTE switch.

The figure below shows the location of the DCE/DTE switch on the

PC board, as well as the location of the terminal block and surge

suppressors.

3.1 SETTING THE DTE/DCE SWITCH

For your convenience, the Model 1010A has an externally

accessible DCE/DTE switch (see figure below). If the device connected

to the Model 1010A is a modem or multiplexer (or is wired like one), set

the switch to "DTE". This setting causes the Model 1010A to behave

like Data Terminal Equipment and transmit data on pin 2.

If the device connected to the Model 1010A is a PC, terminal or

host computer (or is wired like one), set the switch to "DCE". This

setting causes the Model 1010A to behave like Data Communications

Equipment and transmit data on pin 3.

DCE DTE

DCE/DTE

Switch Surge

Suppressors

DCE DTE

Terminal

Block

Transformers

APPENDIX B

SPECIFICATIONS

Transmission Format: Asynchronous, full duplex

Transmission Line: Two unconditioned twisted pair 19 - 26 AWG

Range: (See table below)

Interfaces: EIA RS-232, CCITT V.24

Data Rates: 50 - 115.2 Kbps

Isolation: Minimum 1500 V RMS via custom transformers

Surge Protection: 600W power dissipation at 1 mS;

component response time of 1 pS; installed response time of 2 µs

Dimensions: 2.66" x 2.10" x 0.73"

Factory Switch Setting: DCE (transmits from RS-232 on pin 3)

Control Signals: DSR and DCD follow DTR from the terminal

(DTE); CTS follows RTS from the terminal (DTE)

Connectors: DB-25 male or female on RS-232 side;

RJ-11, RJ-45 or terminal block with strain relief on

line side

Power Supply: None required; uses power from EIA data and

control signals

Temperature Range: 0-60°C (32-140°F)

Altitude: 0-15,000 feet

Humidity: Up to 95% non-condensing

Weight: 2 oz.

Data

Rate

115,200 0.6 0.45 0.3

57,600 2.0 1.5 1.0

38,400 2.4 1.8 1.2

19,200 2.6 2.0 1.2

9,600 4.0 2.5 1.6

4,800 5.0 3.5 2.2

2,400 6.8 4.7 3.2

1,200 8.5 5.7 3.8

Model 1010A Distance Table (miles)

Wire Gauge

19 24 26

4.0 INSTALLATION

Once you have properly configured the DTE/DCE switch, you are

ready to connect the Model 1010A to your system. This section tells

you how to properly connect the Model 1010A to the twisted pair and

RS-232 interfaces, and how to operate the Model 1010A.

4.1 CONNECTION TO THE TWISTED PAIR INTERFACE

The Model 1010A supports data-only communication between two

RS-232 devices at distances to 8.5 miles and data rates to 115.2 Kbps.

There are two essential requirements for installing the Model 1010A:

1) These units work in

pairs

. Therefore, you must have one Model

1010A at each end of a two twisted pair interface.

2) To function properly, the Model 1010A needs two twisted pairs of

metallic wire. These pairs must be

unconditioned

, dry metallic wire,

between 19 and 26 AWG (the higher number gauges may limit distance

somewhat). Standard dial-up telephone circuits, or leased circuits that

run through signal equalization equipment, are

not acceptable

For your convenience, the Model 1010A is available with three

different twisted pair interfaces: RJ-11 jack, RJ-45 jack and terminal

blocks with strain relief.

4.1.1 TWISTED PAIR CONNECTION USING RJ-11 OR RJ-45

The RJ-11 and RJ-45 connectors on the Model 1010A's twisted pair

interface are pre-wired for a standard TELCO wiring environment. The

signal/pin relationships are shown below:

RJ-1

1 SIGNAL RJ-45 SIGNAL

1...................GND* 1 .................N/C

2...................RCV- 2 .................GND*

3...................XMT+ 3 .................RCV-

4...................XMT- 4 .................XMT+

5...................RCV+ 5 .................XMT-

6...................GND 6 .................RCV+

7 .................GND

8 .................N/C

10. BEND the top half of the case as necessary to place it over the

strain relief assembly. Do not snap the case together yet.

11. Insert one captive screw through a saddle washer, then insert

the captive screw with the washer on it through the hole in the DB-25

end of the case. Snap that side of the case closed. Repeat the

process for the other side. This completes cable installation.

4.2 CONNECTION TO THE RS-232 INTERFACE

Once you have configured the Model 1010A for DTE or DCE and

connected the twisted pair wires correctly, all that remains is to plug the

1010A directly into the DB-25 port of the RS-232 device. After doing

so, remember to insert and tighten the two captive connector screws.

(Note: If you must use a cable to connect the Model 1010A to the

RS-232 device, make sure it is a

straight through

cable of the shortest

possible length—we recommend 6 feet or less).

4.3 OPERATING THE MODEL 1010A

Once the Model 1010A is properly installed, it should operate

transparently—as if it were a standard cable connection. Operating

power is derived from the RS-232 data and control signals; there is no

"ON/OFF" switch. All data signals from the RS-232 interface are

passed straight through. All control signals from the RS-232 interface

are looped back.

(Note: If your system requires

hardware

flow control, you will need the

Patton Model 1012 or Model 1060 Short Range Modem. Call Patton

Customer Service at 301-975-1007 for more information).

+RCV- G -XMT+ +RCV- G -XMT+

+RCV- G -XMT+

When connecting two Model 1010As, it is necessary to use a

"cross over" cable. The diagram below shows how a cross over cable

should be constructed for an environment where both Model 1010As

use a 6-wire RJ-11 connector. Similar logic should be followed when

using RJ-45 connectors or a combination of the two.

RJ-1

1 Cable (4-Wire)

SIGNAL PIN# PIN# SIGNAL

GND†1-----------------------6 GND†

RCV- 2-----------------------4 XMT-

XMT+ 3-----------------------5 RCV+

XMT- 4-----------------------2 RCV-

RCV+ 5-----------------------3 XMT+

GND†6-----------------------1 GND†

†Connection to ground is optional

4.1.2 TWISTED PAIR CONNECTION USING TERMINAL BLOCKS

If your RS-422 application requires you to connect two pairs of

bare wires to the Model 1010A, you will need to open the case to

access the terminal blocks. The following instructions will tell you how

to open the case, connect the bare wires to the terminal blocks, and

fasten the strain relief collar in place so that the wires won't pull loose.

(continued)

8. Place the 2 halves of the strain relief assembly on either side of

the telephone wire and press together very lightly. Slide the assembly

so that it is about 2 inches from the terminal posts and press together

firmly. If your cable diameter is too small or too large for our strain

relief, please contact our technical support. We have strain relief

assemblies to accommodate most cable diameters.

9. Insert the strain relief assembly with the wire going through it

into the slot in the bottom half of the modem case and set it into the

recess in the case.

DCE DTE

+RCV- G -XMT+

DCE DTE

+RCV- G -XMT+

1. Open the unit by gently inserting a screw driver between the DB-25

connector and the lip of the plastic case (see below). You don't have to

worry about breaking the plastic, but be careful not to bend the D-sub

connector.

Once the unit has been opened, you will be able to see the

terminal blocks located at the rear of the PC board.

2. Strip the outer insulation from the twisted pairs about one inch

from the end.

3. Strip back the insulation on each of the 2 twisted pair wires

about .25".

+RCV- G -XMT+ +RCV- G -XMT+

+RCV- G -XMT+

+RCV- G -XMT+ +RCV- G -XMT+

+RCV- G -XMT+

4. Connect

one pair

of wires to XMT+ and XMT- (transmit positive

and negative) on the terminal block, making careful note of which color

is positive, and which color is negative.

5. Connect the

other pair

of wires to RCV+ and RCV- (receive

positive and negative) on the terminal block, again making careful note

of which color is positive, and which color is negative.

Ultimately, you will want to construct a two pair cross over cable that

makes a connection with the RS-422 device as shown below:

6. If there is a shield around the telephone cable, it may be

connected to "G" on the terminal block. To avoid ground loops, we

recommend connecting the shield at the computer end only. A ground

wire is

not necessary

for proper operation of the Model 1010A.

7. When you finish connecting the wires to the terminal block, the

assembly should resemble the diagram below:

DCE DTE

+RCV- G -XMT+

XMT + RCV+

XMT - RCV -

G G

RCV - XMT -

RCV + XMT +

To Shield (Optional) }One Pair

}One Pair

Tabla de contenidos

Otros manuales de Módem de Patton electronics

Patton electronics

Patton electronics RocketLink 3202 Manual de usuario

Patton electronics

Patton electronics 1092 Manual de usuario

Patton electronics

Patton electronics NetLink 1082/144 Manual de usuario

Patton electronics

Patton electronics ParaLink 1225 Manual de usuario

Patton electronics

Patton electronics 1006 Manual de usuario

Patton electronics

Patton electronics 1110ARC Manual de usuario

Patton electronics

Patton electronics 1045 Manual de usuario

Patton electronics

Patton electronics 1002S Manual de usuario

Patton electronics

Patton electronics 3010 Manual de usuario

Patton electronics

Patton electronics 1017 Manual de usuario

Patton electronics

Patton electronics 1004ABRC Manual de usuario

Patton electronics

Patton electronics 1050patton Manual de usuario

Patton electronics

Patton electronics 1094 Manual de usuario

Patton electronics

Patton electronics 1004A Manual de usuario

Patton electronics

Patton electronics 1203 Manual de usuario

Patton electronics

Patton electronics 1080A Manual de usuario

Patton electronics

Patton electronics 2703-X21 Manual de usuario

Patton electronics

Patton electronics 1140 Manual de usuario

Patton electronics

Patton electronics 2190 Manual de usuario

Patton electronics

Patton electronics 1004 Manual de usuario

Patton electronics

Patton electronics 2703 Manual de usuario

Patton electronics

Patton electronics RocketLink-G 3088 Series Manual de usuario

Patton electronics

Patton electronics DIAMONDLINK 3201 Manual de usuario

Patton electronics

Patton electronics SMARTNODE 1200 Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
