PASCO ME-9495A Manual de usuario

Instruction Manual

012-10860C

Angle Indicator

ME-9495A

800-772-8700 www.pasco.com

Introduction

The PASCO ME-9495A Angle Indicator is an accessory

used for measuring angles from 0° to 90° in two directions.

There are four different methods of using the Angle Indica-

tor:

• hand-held, by suspending the device over a string.

• attached to a PASCO Cart by sliding the device into

the slots on the top of the cart.

• attached to the side of a PASCO Track.

ANGLE INDICATOR

Square Nut

Thumbscrew

Plunger Cart

012-10860C

• slipped over the platform on the PASCO Rotary

Motion Sensor.

Maintenance

The thread that supports the spherical weight is attached to

the back of the Angle Indicator with a hex screw.

Loosen the hex screw in order to replace the thread.

Technical Support

For assistance with any PASCO product, contact PASCO

at:

Replacement Parts

Check with Technical Support about possible replacement

parts:

More Information

For more information about the latest revision of this

Instruction Manual, visit:

www.pasco.com/manuals

and enter the Product Number.

For information about any PASCO product, what software

to use, and what other accessories are available, check the

PASCO web site.

Warranty, Copyright, and Trademarks

Limited Warranty For a description of the product warranty, see the

PASCO catalog. Copyright The PASCO scientific 012-10860C

Instruction Manual

granted to non-profit educational institutions for reproduction of any part of

this manual, providing the reproductions are used only in their laboratories

and classrooms, and are not sold for profit. Reproduction under any other

circumstances, without the written consent of PASCO scientific, is

prohibited. Trademarks PASCO and PASCO scientific are trademarks

or registered trademarks of PASCO scientific, in the United States and/or

in other countries. All other brands, products, or service names are or may

be trademarks or service marks of, and are used to identify, products or

services of, their respective owners. For more information visit

www.pasco.com/legal.

Address: PASCO scientific

10101 Foothills Blvd.

Roseville, CA 95747-7100

Phone: 916-462-8384 (worldwide)

800-772-8700 (U.S.)

Web: www.pasco.com

Email: [email protected]

ANGLE INDICATOR

Thread

Hex

Screw

Item

Brass weight Hex screw

Thumbscrew Nylon thread

Square nut
