Parrot Disco Manual de usuario

USER GUIDE

GUIDE UTILISATEUR

GUÍA DEL USUARIO

BENUTZERHANDBUCH

GUIDA UTENTE

HANDLEIDING

GUIA DO USUÁRIO



English��4

Français �� 29

Español�� 53

Deutsch �� 77

Italiano �� 101

Nederlands�� 125

Português�� 149

�� 173

PRESENTATION

OF THE PARROT DISCO

GENERAL

Flap

Servomotor

Propeller Flap

Servomotor

Cowling

Fisheye camera

On/off button, warning light and pitot tube

ENGLISH

CHUCK AUTOPILOT UNIT

Micro USB port

RC remote port

Battery connector

Servomotor

connectors

Central engine connector

BEFORE GETTING STARTED

DOWNLOAD THE FREEFLIGHT PRO

APPLICATION

FreeFlight Pro application to your smartphone or tablet.

CHARGING THE PARROT DISCO’S BATTERY

The battery must be disconnected from the Parrot Disco.

1.Select the plug for your country and put it on the charger.

2.Connect the cable to the charger.

3.Connect the battery to the charger’s cable, and then plug the

charger into the mains.

The warning light is red while charging and then turns green when

the battery is charged.

The battery charge time is approximately 55 minutes.

The ﬂight time is approximately 45 minutes.

ENGLISH

FITTING THE BATTERY

1. Remove the Parrot Disco’s cowling.

2. Place the battery in the

slot provided for this

purpose.

3. Plug the battery into the

Parrot Disco.

4. Close the Parrot Disco’s

cowling.

Attach the wings to either side of

the Parrot Disco.

Make sure the wings are properly secured

in the servomotors.

ATTACHING THE WINGS

To remove the wings, pull on them.

Do not move the servomotors with your hand to avoid damaging them.

ENGLISH

PRE-FLIGHT CHECKS

Before each ﬂight with Parrot Disco, make the following checks:

REGULATIONS

Make sure that the use of Parrot Disco is allowed where you are

going to ﬂy.

Check the restrictions regarding the use of Wi-Fi®frequencies in

the place where you are going to ﬂy.

Check the regulations on the use of FPV goggles when ﬂying a

drone where you are going to ﬂy.

FLIGHT CONDITIONS

Make sure you have at least 80 meters in diameter of clear space

for your Parrot Disco to take off and land. Make sure the airﬁeld

has no obstacles that may hinder piloting or prevent visual ﬂight.

Do not ﬂy the Parrot Disco at night.

Do not ﬂy the Parrot Disco over an urban area or in certain places

in the public domain (for example: train stations, airports, etc.).

Check weather conditions. Do not ﬂy the Parrot Disco in rain,

fog, snow or wind over 12 meters per second or 43 km/h.

PARROT DISCO

Make sure the Parrot Disco’s wings are properly secured (see the

Attaching the wings section).

Make sure the Parrot Disco’s battery and your remote control’s

battery are charged (see the Fitting the battery section).

Make sure the Parrot Disco’s cowling is properly closed.

Make sure the Parrot Disco’s warning light is green. This means

the Parrot Disco has acquired the GPS signal.

PILOTING CONFIGURATIONS

There are three piloting conﬁgurations.

Familiarise yourself with no. 1 and no. 2 before using no. 3.

Parrot Skycontroller 2

alone

Parrot Skycontroller 2 and

Parrot Cockpitglasses

TAKEOFF

GPS 97%

0m/s

EMERGENCY

Parrot Skycontroller 2

and smartphone

1 2
