Parkside PAS 4 C4 Manual de usuario

AKKU-SCHRAUBER

Originalbetriebsanleitung

CORDLESS SCREWDRIVER /

AKKU-SCHRAUBER / VISSEUSE SANS FIL PAS 4 C4

IAN 351834_2007

VISSEUSE SANS FIL

Traduction des instructions d’origine

CORDLESS SCREWDRIVER

Translation of the original instructions

MULTIFUNKČNÍ AKU

ŠROUBOVÁK

Překlad originálního provozního návodu

AKU SKRUTKOVAČ

Preklad originálneho návodu na obsluhu

BATTERIDREVEN SKRUETRÆKKER

Oversættelse af den originale driftsvejledning

ACCU-SCHROEFMACHINE

Vertaling van de originele gebruiksaanwijzing

WKRĘTARKA

AKUMULATOROWA

Tłumaczenie oryginalnej instrukcji obsługi

ATORNILLADORA RECARGABLE

Traducción del manual de instrucciones original

GB Translation of the original instructions Page 1

DE Originalbetriebsanleitung Seite 25

FR Traduction des instructions d’origine Page 51

NL Vertaling van de originele gebruiksaanwijzing Pagina 81

CZ Překlad originálního provozního návodu Strana 107

PL Tłumaczenie oryginalnej instrukcji obsługi Strona 131

SK Preklad originálneho návodu na obsluhu Strana 157

ES Traducción del manual de instrucciones original Página 181

DK Oversættelse af den originale driftsvejledning Side 207

9a 9b

PAS 4 C4 GB│IE │ 1 ■

Contents

Introduction...................................3

Intended use..........................................3

Notes on trademarks ...................................3

Features .............................................4

Package contents ......................................4

Technical data ........................................5

General power tool safetywarnings ..............7

1. Work area safety....................................7

2. Electrical safety .....................................7

3. Personal safety......................................8

4. Power tool use and care ..............................9

5. Battery tool use and care.............................10

6. Service ...........................................12

Safety guidelines for screw drivers........................12

Safety guidelines for battery chargers .....................12

Before use ...................................13

Charging the appliance battery (seeﬁg.A).................13

Changing bits/screw driver bits (seeﬁg.B) .................14

Operation ...................................14

Switching the cordless screwdriver on/oﬀ ..................14

Changing the direction of rotation ........................15

Tips and tricks........................................15

PAS 4 C4

■ 2 │ GB│IE

Maintenance, storage and cleaning ..............16

Disposal.....................................17

Kompernass Handels GmbH warranty ...........19

Service ......................................22

Importer ....................................22

Translation of the original Conformity Declaration . .23

PAS 4 C4 GB│IE │ 3 ■

CORDLESS SCREWDRIVER PAS 4 C4

Introduction

Congratulations on the purchase of your new appliance. You have

chosen a high-quality product. The operating instructions are part of

this product. They contain important information about safety, usage

and disposal. Before using the product, please familiarise yourself

with all operating and safety instructions. Use the product only as

described and for the range of applications speciﬁed. Please also pass

these operating instructions on to any future owner.

Intended use

This appliance is designed for screwing into wood, plastic and metal.

Use this product only as described and for the areas of applications

speciﬁed. The appliance is not intended for commercial use. Any

other usage or modiﬁcation of the appliance is deemed to be

improper and carries a signiﬁcant risk of accidents. The manufacturer

accepts no responsibility for damage(s) attributable to misuse.

Notes on trademarks

USB®is a registered trademark of USB Implementers Forum, Inc.

All other names and products may be trademarks or registered

trademarks of their respective owner.

PAS 4 C4

■ 4 │ GB│IE

Features

1Rotation direction switch/safety lock-out

2Motor direction indicator for clockwise rotation

3Battery charge level indicator

4Motor direction indicator for anticlockwise rotation

5Charging socket (appliance)

6ON/OFF switch

7LED lamps

8Tool holder

9Charger

9a USB plug of the charging cable

9b USB-C plug on charging cable

0Bits

Package contents

1 cordless Screwdriver

1 charger

1 charging cable

30 bits x 25mm

1 set of operating instructions

PAS 4 C4 GB│IE │ 5 ■

Technical data

Cordless Screwdriver PAS 4 C4

Nominal voltage 4 V (DC)

Battery (integrated) (1 cell)

Battery capacity 1500 mAh

Rated idle speed n0200rpm

Torque max. 10 Nm

Tool holder 6.35 mm (¼")

Use only the following charger to charge

the cordless tool PAS 4 C4-1

Average active eﬃciency 78.17%

No-load power consumption 0.07 W

INPUT

Rated voltage 100–240V ∼,

50/60Hz (AC)

Rated current 0.3 A

Safety transformer

Switching power supply

OUTPUT

Rated voltage 5.0 V (DC)

Rated current 1700 mA

Charging time approx. 1 hr

Protection class II/ (double insulation)

Rated power 8.5 W

PAS 4 C4

■ 6 │ GB│IE

Noise and vibration data

The measured values have been determined in accordance with

EN62841. The A-rated noise level of the tool is typically:

Sound pressure level LpA= 68.2 dB (A)

Sound power level LWA = 79.2 dB (A)

Uncertainty K KpA/WA = 3 dB

Vibration values (vector total of three directions) determined in

accordance with EN 62841:

Screws

Vibration emission value ah= 0.86 m/s2

Uncertainty K = 1.5 m/s2

NOTE

► The vibration emission values and the noise emission values

given in these instructions have been measured in accord-

ance with a standardised test procedure and can be used for

comparison of the power tool with another tool.

► The speciﬁed total vibration values and the noise emission

values can also be used to make a provisional load estimate.

WARNING!

► Depending on the manner in which the power tool is being

used, and in particular the kind of workpiece that is being

worked, the vibration and noise emission values can deviate

from the values given in these instructions during actual use of

the power tool.

► Try to keep the load as low as possible. Measures to reduce

the vibration load are, e.g. wearing gloves and limiting the

working time. Wherein all states of operation must be included

(e.g. times when the power tool is switched oﬀ and times where

the power tool is switched on but running without load).
