Introduction LCB Compact Linear Actuator
8 192-510014 N04 March 2010
1.2.5. Safety Instructions for the Company Using the System
Supervisors must also become familiar with the entire chapter entitled "Safety" and
handling required on the linear actuator.
Supervisors must ensure that installation and operating personnel have read and
understand the chapter entitled "Safety" and the description of how to work with the
machine, and that they observe the instructions.
The manual must be available close to the linear module during the performance of
all tasks.
It is impermissible to operate the liner module if it is not in perfectly functional
condition.
1.2.6. Safety Instructions for Operating Personnel
Any work step that has a negative effect on the operating safety of the linear
actuator must be omitted.
Operating and supervisory personnel are required to check the linear actuator or
machine at least once per shift for externally visible damage or defects. Changes
that have occurred (including the operating behaviour) that could have a negative
effect on the operating safety must be reported immediately.
Components and accessories are designed especially for this product. When
purchasing spare and wearing parts, use only original Parker parts. We note here
explicitly that we are unable to check or release spare parts or accessories that
were not provided by us. Installing and/or using such products may cause negative
changes in the required design properties in some circumstances, which in turn
could negatively effect the active and/or passive operating safety of the product.
The manufacturer is unable to accept any liability for damage caused by using non-
original parts and accessories.
Safety and protection devices are strictly NOT to be removed or bypassed or set
out of order.
Applicable requirements and national accident prevention regulations must always
be observed when installing and operating our linear motor module.
1.2.7. Transport
Never step under overhead loads – danger of being injured!
Moving parts must always be secured against slipping or moving.
*By wrapping several turns of strong adhesive tape around the sliding carriage, which if possible is in
the centre of the profile, for example.
Hint
Danger when transporting long actuators. Because the actuator bends under its own weight,
guiding accuracy may deteriorate significantly. In addition, the shape of the profile may
change and the travel behaviour of the sliding carriage may be negatively affected.
In general no means of transport are needed for the LCB. The linear actuator can
be carried, depending on the size, by one or two persons.
