Parker SciLog DINCon Instrucciones de montaje

SciLog®DINCon®, DINPres®,

& DINTemp®Modules

Installation, Operating & Maintenance Instructions

Parker Hannifin Corporation has a continuous policy of product development and although the Company reserves the right to

change specification, it attempts to keep customers informed of any alterations. This publication is for general information only and

customers are requested to contact your local Parker Sales Representative for detailed information and advice on a product’s

suitability for specific applications. All products are sold subject to the company’s Standard conditions of sale.

SciLog®and DINCon®, DINPres®, and DINTemp®, are registered trademarks of

Parker Hannifin Corporation.

Contents

Introduction.................................................................................................................................6

Calibration ..................................................................................................................................6

Warranty.....................................................................................................................................7

Standards ...................................................................................................................................7

Installation & Start-Up.................................................................................................................7

Maintenance & Cleaning.............................................................................................................7

DIN Module Specifications..........................................................................................................8

Sensor Specifications .................................................................................................................9

SciCon Sensors..........................................................................................................................9

SciPres Sensors .........................................................................................................................9

SciTemp Sensors .....................................................................................................................10

Installation ................................................................................................................................11

Operating Instructions...............................................................................................................14

Modbus Register List................................................................................................................16

DINCon Registers.....................................................................................................................16

DINPres Registers....................................................................................................................20

DINTemp Registers ..................................................................................................................25

Reference Information ..............................................................................................................29

Precautions

READ this manual BEFORE operating or servicing this equipment.

FOLLOW these instructions carefully.

SAVE this manual for future reference.

DO NOT allow untrained personnel to operate, clean, inspect, service or tamper with

this equipment.

ALWAYS DISCONNECT this equipment from the power source before cleaning or

performing maintenance.

Contact your local Parker Division for parts, information and service.

WARNING

DISCONNECT ALL POWER TO THIS UNIT BEFORE INSTALLING,

SERVICING, CLEANING OR REMOVING THE FUSE. FAILURE TO DO

SO COULD RESULT IN BODILY HARM AND/OR PROPERTY DAMAGE.

CAUTION

OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC

SENSITIVE DEVICES.

WARNING

ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS

EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND

ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO

OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.

WARNING

FOR CONTINUED PROTECTION AGAINST SHOCK HAZARD, CONNECT

TO PROPERLY GROUNDED OUTLET ONLY. DO NOT REMOVE THE

GROUND PRONG.

CAUTION

USE ONLY CLASS 2 LISTED EXTERNAL 24 VDC POWER SUPPLY WITH

THESE DEVICES.

Précautions

LISEZ ce manual AVANT de faire fonctionner ou d’entretenir cet équipment.

SUIVEZ attentivement ces instructions.

CONSERVEZ ce manuel pour future référence.

NE LAISSEZ PAS du personnel non qualifié utiliser, nettoyer, inspecter, entretenir, réparer ou

manipuler cet équipement.

DÉBRANCHEZ TOUJOURS cet équipement de la source de courant avant de nettoyer ou

d’exécuter l’entretien.

APPELEZ PARKER pour pièces détachées, renseignements et entretien.

ATTENTION

DÉBRANCHEZ TOUT COURANT DE CETTE UNITÉ AVANT DE FAIRE

L’INSTALLATION, D’EFFECTUER L’ENTRETIEN, LE NETTOYAGE OU

AVANT DE RETIRER LE FUSIBLE. NE PAS OBSERVER CES

PRÉCAUTIONS RISQUERAIT DE CAUSER DES BLESSURES

CORPORELLES OU/ET D’ENDOMMAGER L’ÉQUIPEMENT.

PRUDENCE

SOYEZ PRUDENT LORSQUE VOUS MANIPULEZ DES APPAREILS

SENSIBLES À L’ÉLECTROSTATIQUE.

ATTENTION

ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS

EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND

ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO

OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.

ATTENTION

POUR ASSURER UNE PROTECTION CONTINUE CONTRE UNE

DÉCHARGE ÉLECTRIQUE, BRANCHEZ UNIQUEMENT SUR UNE PRISE

CORRECTEMENT RELIÉE Á LA TERRE. NE RETIREZ PAS LA FICHE DE

TERRE.

PRUDENCE

N'UTILISER QUE DE L'ALIMENTATION ÉLECTRIQUE 24 VDC

EXCLUSIVE DE CLASSE 2 AVEC CES DISPOSITIFS.

Introduction

You will find the SciLog®DINCon, DINPres and DINTemp Modules and sensors easy to use. The state-

of-the-art hardware and software design of the SciLog®DIN Module and sensor combination allows you

to measure and document the conductivity, pressure or temperature of many filtration / separation

processes. With proper maintenance, the SciLog®DIN Modules will provide many years of excellent

service and performance.

Please read the following instructions carefully!

Inspections: Remove the products carefully from the shipping container. Check the contents against

the purchase order to verify that all parts are included and undamaged.

Please do the inspection now, even if the products are not used immediately. Many carriers must

receive damage claims within seven days of delivery. Please retain all packing material so unit may be

shipped safely, if necessary.

Customer Service: Parker Bioscience customer service: If assistance is required, please contact us at:

Parker Hannifin Corporation

Bioscience & Water Filtration

2340 Eastman Avenue

Oxnard, California, USA 93030

toll free: 877 784 2234

phone: +1 805 604 3400

fax: +1 805 604 3401

email: [email protected]

www.parker.com/dhsingleuse

Parker Hannifin Manufacturing Ltd

Bioscience Engineering Filtration

Durham Road

Birtley, Co. Durham

DH3 2SF, England

phone +44 (0)191 4105121

fax +44 (0)191 4105312

email: [email protected]

www.parker.com/dhsingleuse

Parker customer service personnel will be able to serve you more efficiently if you have the following

information:

Serial number and model name of the equipment

Installation procedure being used

Concise list of symptoms

List of operating procedures and conditions in use when problem arose

Calibration

The SciLog®DIN Modules are calibrated devices, and are calibrated with test equipment that is

traceable to SI through NIST.

A Calibration Certificate is included with each unit, and has a one year expiration date.

It is highly recommended that the Module be calibrated on an annual basis or more often if your

Metrology Department deems it necessary.

Parker Bioscience provides this Calibration Service, complete with a new certificate, showing the “as

found” and “as left” data.

Contact your local Parker Bioscience representative.

Warranty

Country specific information can be found at: www.parker.com/termsandconditions

Standards

EN 61326-1:2006, Class B

EN 61010-1:2010 Ed.3+ C1; C2

Conforms to UL STD 61010-1:2012 Ed.3+ R: 29Apr2016

Certified to CSA STD C22.2 No 61010-1-12:2012 Ed.3+U1;U2

Caution: The maximum recommended pressure for the sensors is 60 psi.

If this is exceeded, problems with leakage and functionality can occur.

Installation & Start Up

Installation of the SciLog

DINCon

DINPres

, and DINTemp

Modules must be carried out only by

trained personnel in accordance with the relevant regulations and this operations manual.

Make sure that the technical specifications and input ratings of the SciLog

sensors are observed. See

the appropriate Sensor Specifications page.

The protection provided by this equipment may be impaired if the SciLog

sensors are used in a

manner inconsistent with this manual or for purposes not specified by the manufacturer.

Maintenance & Cleaning

The SciLog

DIN Modules are maintenance free. The single-use SciLog

sensors come pre-calibrated

from the factory and require no maintenance.

To remove dust, dirt and stains, the outer surfaces of the DIN Modules may be wiped using a soft, non-

fluffing cloth moistened with water. If required, you may also use a mild detergent or 2-propanol.

The single-use sensors may be sanitized with 0.1 Molar NaOH, or 2-propanol. They may be autoclaved

up to 2 times, or gamma-irradiated with exposure up to 45 kGy.

Hardware

Specifications – All Modules

Dimensions W: 0.875¨ (2.2 cm); Height 4.0¨ (10.2 cm); D: 4.75¨ (12.1 cm)

Weight 0.3 lb. (0.14 Kg)

Enclosure Molded Plastic

Electrical

Power 24 VDC, 250 mA. Use only Class 2 External Power Supply

Battery CR1632, used for internal clock, not user serviceable

I/O Port Top 8 pin Terminal Block, numbered from rear:

1: +24 VDC 2: 24 VDC Return 3: N/C 4: Signal GND (COM)

5: RS-232 RX 6: RS-232 TX 7: RS-485 A 8: RS-485 B

I/O Port – 2 RJ45, Ethernet Connection

I/O Port - 3 USB Connection

Software

I/O Port

Bottom

8 Pin Sensor Connection, DINCon has 1, DINPres and

DINTemp have 3.

DISPLAY Power Status LED, Sensor Status LED’s

Modbus Modbus RTU via RS-232

Modbus RTU via RS-485

Modbus RTU via USB

Modbus TCP via Ethernet

Environmental

Temperature 4 – 60° C

Altitude Up to 2000 Meters

IP Rating IP20, Indoor dry environments, unit is wipe-down only

Rel. Humidity 0 – 95%

Voltage Fluctuation allowed: +/- 10%

Pollution Degree: 2

Specifications – Sensors

SciCon:

Power 5 VDC provided by DINCon® Module

Fluid Connections

Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,

3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover

(‘Ladish’) Sanitary.

Wetted Materials

Polysulphone meets USP Class VI and FDA 21

CFR 177.1520, all wetted materials made with

animal-free compounds.

Sensor Type 4-Electrode Conductivity Cell, gold plated pins.

Conductivity Range 1 μS/cm to 200 mS/cm; Resolution: 0.1 μS/cm.

Accuracy High: ± 0.25 mS in the 0.1 - 200 mS range;

Low: ± 3 μS in the 0 - 100 μS range

Temperature Range 4-50° C

Temperature Accuracy +/- 0.5° C

Temperature Probe Thermistor

Pre-Calibration 0.10 M KCI Solution, 12.88 mS at 25.0° C

Sensor Microchip EPROM, Stores Sensor ID, and

Calibration Factor.

Sensor Connector & Cables Lockable and Waterproof.

SciPres:

Power 5 VDC provided by DINPres® Module

Fluid Connections

Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,

3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover

(‘Ladish’) Sanitary.

Wetted Materials

Polysulphone meets USP Class VI and FDA 21

CFR 177.1520, all wetted materials made with

animal-free compounds.

Sensor Type Medical grade, silicone piezoresistive sensing

element with on-chip temperature compensation.

Sensor Isolation

Insoluble silicone dielectric gel isolates sensing

element from process solution. The gel is a non-

toxic, non-allergenic elastomeric system.

Pressure Range -5 to 60 psi (-0.34 to 4.14 bar).

Accuracy

+/- 0.30 psi at -5 to 30 psi for 2 point calibrated

sensors (can be improved to -5 to 60 psi with 3

point calibration, also available)

Resolution 0.01 psi

Temperature Range 0 to 60 °C (32 to 140 °F).

Sensor Microchip EPROM, Stores Sensor ID, and

Calibration Factor.

Sensor Connector & Cables Lockable and Waterproof.

SciTemp:

Power 5 VDC provided by DINTemp® Module

Fluid Connections

Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,

3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover

(‘Ladish’) Sanitary.

Wetted Materials

Polysulphone meets USP Class VI and FDA 21

CFR 177.1520, all wetted materials made with

animal-free compounds.

Sensor Type Thermistor, Epoxy coated, 2252 Ω

Temperature Range -40 to +150° Celsius

Accuracy +/- 0.10° Celsius in the 4.0 to 70° Celsius range.

Resolution 0.01 ° Celsius

Sensor Microchip EPROM, Stores Sensor ID, and

Calibration Factor.

Sensor Connector & Cables Lockable and Waterproof.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Parker

Parker

Parker LINKnet TechBox Series Manual de usuario

Parker

Parker CK-6D Manual de usuario

Parker

Parker CW Series Instrucciones de funcionamiento

Parker

Parker 89-00B Guía

Parker

Parker S5A-DN Instrucciones de funcionamiento e instalación

Parker

Parker Series DFplus Manual de usuario

Parker

Parker C2 Series Instrucciones de instalación y mantenimiento

Parker

Parker PID00A-40 Series Manual de usuario

Parker

Parker RL Series Especificaciones técnicas

Parker

Parker VA01 Series Manual de usuario

Parker

Parker EBV-PR Series Guía del usuario

Parker

Parker 930 Series Guía

Parker

Parker Origa S9 Manual de usuario

Parker

Parker TDC Series Manual de usuario

Parker

Parker CK5-DN Manual de usuario

Parker

Parker DFB Series Manual de usuario

Parker

Parker AC30V Series Manual de usuario

Parker

Parker 810 Series Instrucciones de montaje

Parker

Parker D*1VW*EE Series Manual de usuario

Parker

Parker 71215 Manual de usuario

Parker

Parker S5A Guía

Parker

Parker 221 Series Manual de usuario

Parker

Parker RE06M T Series Manual de usuario

Parker

Parker PID00A-40X Series Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
