Panasonic GA-AS16T Manual de usuario

Installation Guide

 Thank you for purchasing our product.

 This document provides important information about safe and proper

operations of this Ethernet Switch.

 Please read the "Important Safety Instructions" on pages from 3 to 5.

 Any problems or damages resulting from disassembly of this Ethernet

Switch by customers are not covered by the warranty.

I0317-30222 Printed in Japan

GA-AS16T

PN25161-TH

PN25161-MY

PN25161-ID

PN25161-SG

Model No.

 The instruction manuals (Web Version), latest firmware and

SDN application (ZEQUO assist Plus) can be downloaded

from the following URL.

https://panasonic.co.jp/ew/pewnw/english/datadownload/index.html

2-12-7, Higashi-Shimbashi, Minato-ku, Tokyo Japan, 105-0021

Panasonic Electric Works Networks Co.,Ltd.

Panasonic Electric Works Networks Co.,Ltd. 2022

Contents

Important Safety Instructions

Basic Instructions for the Use of This Product

1 Product Outline

1.1 Feature

1.2 Specifications

1.3 Accessories

1.4 Basic operation

2 Part Names and Functions

3 Installation and Configuration

3.1 Grounding Cable Connection

3.2 Mounting to rack

3.3 Mounting on a wall

3.4 Configuration of IP address (Basic)

Troubleshooting

This chapter contains important safety instructions for preventing bodily injury

and/or property damage. Please read carefully, and follow them at all times.

Do not use power supply other than AC 100 - 240 V.

Deviation could lead to fire, electric shock, and/or equipment failure.

Do not handle the power cord with wet hand.

Deviation could lead to electric shock, and/or equipment failure.

Do not handle this Ethernet Switch and connection cables during a

thunderstorm.

Deviation could lead to electric shock.

Do not disassemble and/or modify this Ethernet Switch.

Deviation could lead to fire, electric shock, and/or equipment failure.

Do not damage the power cord. Do not bend too tightly, stretch, twist, bundle

with other cord, pinch, put under a heavy object and/or heat it.

Damaged power cord could lead to fire, and/or electric shock.

Do not insert, or drop foreign objects such as metal or combustible things into

Ethernet Switch from the openings or twisted pair ports.

Deviation could lead to fire, electric shock, and/or equipment failure.

Do not connect equipments other than 10BASE-T/100BASE-TX/1000BASE-T

to twisted pair port.

When connecting to a 10BASE-T device, use a Cat5 or above cable.

Deviation could lead to fire, electric shock, and/or equipment failure.

Do not place this Ethernet Switch in harsh environment (such as near water,

high humid, and/or high dust).

Deviation could lead to fire, electric shock, and/or equipment failure.

Do not place this Ethernet Switch under direct sunlight and/or high

temperature.

Deviation could lead to high internal temperature and fire.

This symbol indicates a potential hazard

that could result in serious injury or death.

 Severity of bodily injury and/or property damage, which could result from incorrect

use of the Ethernet Switch, are explained below.

 The following symbols are used to classify and describe the type of instructions to

be observed.

Important Safety Instructions

WARNING

CAUTION This symbol indicates safety instructions.

Deviation from these instructions could lead

to bodily injury and/or property damage.

This symbol is used to alert

users what they must do.

This symbol is used to alert

users what they must not do.

WARNING

Do not install this Ethernet Switch at the location with continuous vibration or

strong shock, or at the unstable location.

Deviation could lead to falling, injury and/or equipment failure.

Do not put this Ethernet Switch into fire.

Deviation could lead to explosion and/or fire.

Double pole / Neutral fusing

Use the bundled power cord (AC 100 – 240 V specifications).

Deviation could lead to electric shock, malfunction, and/or equipment failure.

Unplug the power cord in case of equipment failure.

Deviation, such as keep connecting for a long time, could lead to fire.

Connect this Ethernet Switch to ground.

Otherwise this might cause electrical shocks, misoperations and malfunctions.

Connect the Ethernet Switch via the supplied power cord to the outlet which is

connected to the ground.

If the outlet is not connected to the ground, connect the ground cable (AWG18:

green/yellow) to the ground terminal screw.

Connect the power cord firmly to the power port.

Deviation could lead to electric shock,fire, and/or malfunction.

If the STATUS (Status) LED blinks orange, unplug the power cord since this is a

malfunction.

Deviation, such as keep connecting for a long time, could lead to fire.

Handle the Ethernet Switch carefully so that fingers or hands may not be

damaged by twisted pair port or power cord hook block.

When mounting the Ethernet Switch on a wall, mount it securely using wall

mount brackets (PN71053, optional) to prevent the Ethernet Switch from

falling due its weight and that of the connection cables.

Injuries and/or malfunctions could be caused due to the Ethernet Switch falling, etc.

This Ethernet Switch is to be periodically serviced in order to maintain its

performance.

Please assign a product administrator, and be sure to implement periodic mainte-

nance. When doing maintenance, check the inspection chart that is posted on our

website which has the requisite items listed on it.

When using this Ethernet Switch to design systems, use it after applying

appropriate measures such as setting up redundant configurations.

Communication failures might be generated due to causes such as malfunctions or

misoperations while the Ethernet Switch is being used.

WARNING

CAUTION

When using this Ethernet Switch for applications which require extremely high

reliability, be careful to expend all possible means to ensure safety and

reliability.

This Ethernet Switch was not designed or manufactured with the intention that it

be used for applications (in use with railways, aviation, and medical care, etc.

where the influence rate due to communication failures is extremely high in regard

to systems that directly affect systems and human lives) which require extremely

high reliability.

Be aware of glitches which are caused in the usage environments such as

age-related degradation, etc.

This may vary depending upon conditions such as utilisation rates and usage

environments, but performance might decrease due to the age-related

degradation, etc. of components. It is recommended that this Ethernet Switch be

replaced about five years after it has been installed.

Be careful in regards to environmental restrictions whereby the Ethernet

Switch can be used.

Please isolate the business power lines and communication lines. Isolate distribution

lines and other distribution lines, and low current power lines, optical fiber cables,

metallic water conduits, and gas conduits, etc. Noise may be generated in the

communication lines which might cause communication glitches.

CAUTION

Basic Instructions for the Use of This Product

For inspection and/or repair, consult the retailer.

Use commercial power supply from a wall socket, which is close and easily accessible to this

Ethernet Switch.

Unplug the power cord when installing or moving this Ethernet Switch.

Unplug the power cord when cleaning this Ethernet Switch.

Use this Ethernet Switch within the specifications. Deviation could lead to malfunction.

Do not touch the twisted pair cable modular metal terminals which are connected to RJ45

connectors (twisted pair ports) or the connectors, nor place them near electrically-charged

objects. Static electricity could lead to equipment failure.

Do not put the modular plug of the connected twisted pair cable on objects that can carry

static charge, such as carpet. Do not place it in the proximity. Static electricity could lead to

equipment failure.

Do not put a strong shock, including dropping, to this Ethernet Switch. Deviation could lead

to equipment failure.

Do not store and/or use this Ethernet Switch in the environment with the characteristics listed

below.

(Store and/or use this Ethernet Switch in the environment in accordance with the

specification.)

- High humidity. Possible spilled liquid (water).

- Dusty. Possible static charge (such as carpet).

- Under direct sunlight.

- Possible condensation. High/low temperature exceeding the specifications environment.

- Strong vibration and/or strong shock.

Please use this Ethernet Switch in place where ambient temperature is from 0 to 50°C.

Failure to satisfy the conditions above may result in a fire, electric shock, equipment failure,

and/or malfunction. Such events are not covered by the warranty.

Do not block the ventilator of the Ethernet Switch.

Blocked ventilator induces the heat accumulation inside, causing equipment failure and/or

malfunction.

If used at a temperature out of the operating temperature range, the protection equipment

becomes activated and the power supply stops.

When using two Ethernet Switches, do not stack them. When you place them side by side,

allow for a space of 20 mm or more between them.

1. Please note that Panasonic shall not bear any liability whatsoever for any damages

(this shall include, but isnotlimited to,lost earnings,lost opportunities, etc.)

which were generated in relation to damages caused by operations and usage,

or the inability to use this Ethernet Switch, whereby the customer does not follow

this Installation Guide.

2. The contents described in this document may be changed without prior notice. For the

latest version, please refer to the Panasonic website.

3. For any question, please contact the retailer where you purchased the product.

Product Outline

GA-AS16T has 18 ports which are 10BASE-T/100BASE-TX/1000BASE-T compatible ports.

1.1 Feature

 Ports 1 to 18 (twisted pair ports) are 10BASE-T/100BASE-TX/1000BASE-T

corresponding to auto-negotiation.

 All of the twisted pair ports are equipped with straight/cross cable automatic

detection functions. Straight cables can be used to make interconnections without

distinctions between the terminals and network devices having to be made.

(The factory default is for ports 1 to 16 to have MDI-X be fixed.)

 If equipped with IEEE802.3az (LPI) compatible Energy Efficient Ethernet functions

(hereinafter EEE), and if data is transmitted when linked up, the energy efficient

state will be moved to, whereas each port can suppress power consumption.

Automatically detects the connection states via the equipped energy efficiency

mode, and suppresses power consumption to required levels.

VLAN function allows free grouping of up to 256 VLANs.

The IEEE802.1p compatible QoS function is supported.

Has an Internet Mansion function, which ensures security between each door.

As a factory default, IP address in this Ethernet Switch is not assigned to the device.

The address can be changed by connecting this Ethernet Switch to your PC using

twisted pair cable, if your PC has ZEQUO assist plus installed on it (ZEQUO assist plus

is downloadable from Panasonic

’

s website.)

Due to the loop detection/shutoff function, a port where loop has occurred can be

automatically shut off to prevent loop failures. Moreover, it can be referring the

history of loop on the setting screen.

1.2 Specifications

Product Outline

Interface Twisted pair port 1–18: RJ45 connector

Transmitting and receiving network system

IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE802.3ab 1000BASE-T

Energy Efficient Ethernet function

IEEE 802.3az (LPI)

Switching mode Store and Forward method: Forwarding rate

10BASE-T: Max. 14,880 pps/port

100BASE-TX: Max. 148,800 pps/port

1000BASE-T: Max. 1,488,000 pps/port

MAC Address table: Max. 8K entry/unit

Buffer: 512KByte

Link Aggregation IEEE802.3ad

Configurable up to 8 groups (Max. 8 ports per group)

VLAN IEEE802.1Q tagging VLAN protocol compatible

(Max. 256 groups including the default VLAN)

Port based VLAN, Internet Mansion function

QoS IEEE802.1p compatible, Supports 4 priority queues

Management method WEB control screen, ZEQUO assist Plus

Others Port Monitoring, Storm control

Power supply AC 100–240V, 50/60 Hz, 1.5 A

Power consumption Normally, Max. 12.8 W, Min. 6.3 W

Storage environment Temperature: -20–70°C, Humidity: 10–90% RH (no condensation)

Fan Not installed

Mass (Weight) 2,350 g

External dimensions 44 mm (Height) × 330 mm (Width) × 230 mm (Depth) (Excluding

protruding sections)

Operating environment Temperature: 0–50°C, Humidity: 20–80% RH (no condensation)

Caution: Failure to meet the above conditions may result in fire,

electric shock, breakdown, and/or malfunction.

Please take notice because such cases are not covered by

the guarantee.

Loop detection Ports 1-16: ON, Ports 17,18: OFF (default setting)

Port shut-off time: 60-86400 sec (default setting is 60 sec)

Block mode (default setting), Shutdown mode

1.3 Accessories

Please be sure to confirm the content.

Please contact our distributor if any of the contents are insufficient.

1.4 Basic operation

This Product does not have a power ON/OFF switch. Connect the supplied power

cord to this Ethernet Switch and connect the other end into an electric outlet.

This Ethernet Switch operates at AC 100 - 240 V (50/60 Hz).

When power is supplied, all the LEDs are turned ON.

Subsequently, the POWER (power) LED lights up green, and the STATUS (status) LED

lights up orange and the hardware runs a self-diagnostic.

When it is finished, both the the POWER (power) LED and STATUS (status) LED light

up green, and it operates as a Ethernet Switch.

As this Ethernet Switch succeeds in communicating with a terminal connected to

each port, LED of the port lights up.

When the terminal is not operating normally, for example when power is not

supplied to the terminal, LED is not lighted.

Quantity

[Power Cord]

The following power cords are supplied as per the intended nation of delivery.

Locale

Thailand 250 VAC 6 A TIS166-2549-

Indonesia 250 VAC 10 A

250 VAC 10 A

250 VAC 5 A

CEE7/7

BS1363

13 A

5 A

Malaysia

Singapore

Product Number

PN25161-TH

PN25161-ID

PN25161-MY

PN25161-SG

Power Cord Rating FUSE Rated Current

Plug Type

* For the configuration and management methods, please see the PDF

version of the Operating Instructions on Panasonic’s website.

Installation Guide (this document) 1 (*)

Rubber foot 4

Mounting bracket (for 19-inch rack) 2

Screw (for 19-inch rack) 4

Screw (for fixing the main unit and 19-inch rack mount bracket) 8

Power cord 1

* Just the PN25161-TH has 1 Installation Guide in Thai (a total of 2 guides).

Part Names and Functions

Power port

MAC Address label

Serial number label Power cord hook block

10BASE-T/100BASE-TX/1000BASE-T port

Back panel

Power port

Connect the supplied power cord to this port and connect the other end into an

electric outlet.

Power cord hook block

If the supplied power cord is hanged to this block, the cord becomes hard to pull

out from the power port.

Ground terminal

Connect the ground cable (AWG18: green/yellow) to the ground terminal screw.

10BASE-T/100BASE-TX/1000BASE-T port (ports 1–18)

Connect 10BASE-T/100BASE-TX/1000BASE-T terminals, hubs, repeaters, bridges,

and Ethernet Switches.

Install the device so that the length of the twisted pair cables (CAT5e or above) will

be 100 m or less.

Ground terminal

Front panel

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Panasonic

Panasonic

Panasonic AVHS400N - MULTI FORMAT LIVE SWITCHER Manual de usuario

Panasonic

Panasonic CATU7000U - AV CTRL AMP Manual de usuario

Panasonic

Panasonic PN25168-NZ Manual de usuario

Panasonic

Panasonic PN28080i-TH Manual de usuario

Panasonic

Panasonic KX-T206E Especificaciones técnicas

Panasonic

Panasonic GA-AS10T Series Manual de usuario

Panasonic

Panasonic AW-HS50N Manual de usuario

Panasonic

Panasonic AK-HC1500 Manual de usuario

Panasonic

Panasonic AW-HS50N Manual de usuario

Panasonic

Panasonic WJMP204C - DATA MULTIPLEX UNIT Manual de usuario

Panasonic

Panasonic WJ-220 Manual de usuario

Panasonic

Panasonic GA-ML4TPoE+ Series Manual de usuario

Panasonic

Panasonic Switch-M8eGi Series Manual del propietario

Panasonic

Panasonic MAS3132D Manual de usuario

Panasonic

Panasonic AW-HS50 Series Manual de usuario

Panasonic

Panasonic ZEQUO 2210 Series Manual de usuario

Panasonic

Panasonic Swtich-M48eG Series Manual de usuario

Panasonic

Panasonic WJ410 - BW QUAD SYSTEM Manual de usuario

Panasonic

Panasonic GA-ML8TPoE+ Manual de usuario

Panasonic

Panasonic ZEQUO 6700RE Manual de usuario

Panasonic

Panasonic WH-0M1101A Manual de usuario

Panasonic

Panasonic PN28248 Manual de usuario

Panasonic

Panasonic M16eG Manual de usuario

Panasonic

Panasonic PN28160A Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
