Panasonic WV-CL920A Series Manual de usuario

(Lens : option)

WV-

CL924

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

Model No. WV-CL920A

WV-CL924A

Color CCTV Cameras

Operating Instructions

-2-

WARNING: To prevent fire or electric shock hazard, do not expose this appliance to rain or moisture. The apparatus shall not be exposed

to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

The lightning flash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the pres-

ence of uninsulated "dangerous volt-

age" within the product's enclosure that

may be of sufficient magnitude to con-

stitute a risk of electric shock to per-

sons.

The exclamation point within an equi-

lateral triangle is intended to alert the

user to the presence of important oper-

ating and maintenance (servicing)

instructions in the literature accompa-

nying the appliance.

The serial number of this product may be found on the top

of the unit.

You should note the serial number of this unit in the space

provided and retain this book as a permanent record of your

purchase to aid identification in the event of theft.

Model No. WV-CL920A/CL924A

Serial No.

Warning:

This equipment generates and uses radio frequency energy

and if not installed and used properly, i.e., in strict accor-

dance with the instruction manual, may cause harmful

interference to radio communications. It has been tested

and found to comply with the limits for a Class A computing

device pursuant to Subpart J of Part 15 of FCC Rules,

which are designed to provide reasonable protection

against such interference when operated in a commercial

environment.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER SER-

VICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PER-

SONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

SA 1965

SA 1966

For U.S.A

Power disconnection. Unit with or with-

out ON-OFF switches has power sup-

plied to the unit whenever the power

cord is inserted into the power source;

however, the unit is operational only

when the ON-OFF switch is in the ON

position. Unplug the power cord to dis-

connect the main power for all unit.

-3-

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not use near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampli-

fiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or

the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electri-

cian for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the

points where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

-4-

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-overs.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in

any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects fallen into the appa-

ratus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

S3125A

-5-

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS .......................................................................................................................... 3

PREFACE ....................................................................................................................................................................... 6

FEATURES ..................................................................................................................................................................... 7

PRECAUTIONS .............................................................................................................................................................. 8

MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS ........................................................................................ 9

CONNECTIONS ............................................................................................................................................................. 12

FOCUS OR FLANGE-BACK ADJUSTMENT .................................................................................................................. 16

INSTALLATION OF CAMERA ........................................................................................................................................ 17

SETUP ............................................................................................................................................................................ 18

1. CAMERA SETUP MENU .......................................................................................................................................... 18

2. SETUP OPERATION ................................................................................................................................................ 21

SETTING PROCEDURES ............................................................................................................................................... 23

PREVENTION OF BLOOMING AND SMEAR ................................................................................................................. 42

SPECIFICATIONS .......................................................................................................................................................... 42

STANDARD ACCESSORIES .......................................................................................................................................... 44

OPTIONAL ACCESSORIES ............................................................................................................................................ 45

-6-

PREFACE

Panasonic's WV-CL920A (WV-CL924A) series digital

color camera introduces a new level of high picture

quality and high resolution through the use of a 1/2-inch

frame interline transfer CCD image sensor having 768

horizontal pixels (picture elements), and digital signal

processing LSI's. This model offers cutting-edge tech-

nology for advanced video surveillance.

-7-

1. The following functions are built in.

(1) Auto Light Control (ALC)/Electronic Light

Control (ELC)

(2) Back Light Compensation (Auto: Factory pre-

set, Manual: Manual photometric measuring

area set)

(3) Various External Sync Functions, including

Gen-Lock

(4) Auto/Manual White Balance Function

(5) Electronic Shutter Function

2. Signal-to-noise ratio of 50 dB

3. Minimum illumination of 0.14 lx (0.014 footcandle)

with F1.4 lenses (Color mode)

4. Minimum illumination of 0.01 lx (0.001 footcandle)

with F1.4 lenses (Black and White mode)

5. 570 lines of horizontal resolution (Black and White

mode)

480 lines of horizontal resolution (Color mode)

FEATURES

6. High quality picture:

(a) 2H type vertical enhancer for greater picture

sharpness

(b) Chroma averaging circuit for better color signal

to noise ratio

(d) Expanded dynamic range by use of knee cir-

cuit

(e) Highlight aperture correction for greater picture

detail of bright objects

7. Ability to shoot indoor scenes with fixed iris lens by

use of Electronic Light Control (ELC) function.

8. Selectable electronic sensitivity enhancing modes

including: AUTO, MANUAL and OFF

9. Built in Digital Motion Detector

10. Auto Black/White mode enables the camera to

switch between C/L and B/W in response to input

lights.

-8-

1. The installation should be made by qualified

service personnel or system installers.

2. Do not attempt to disassemble the camera.

To prevent electric shock, do not remove screws or

covers.

There are no user serviceable parts inside. Ask a

qualified service person for servicing.

3. Handle the camera with care.

Do not abuse the camera. Avoid striking, shaking,

etc. The camera could be damaged by improper

handling or storage.

4. Do not use strong or abrasive detergents when

cleaning the camera body.

Use a dry cloth to clean the camera when dirty.

In case the dirt is hard to remove, use a mild deter-

gent and wipe gently. Afterwards, wipe off the

remained part of the detergent in it with a dry cloth.

5. Clean the CCD faceplate with care.

Do not clean the CCD with strong or abrasive deter-

gents. Use lens tissue or a cotton tipped applicator

and ethanol.

6. Never face the camera towards the sun.

Do not aim the camera at bright objects. Whether

the camera is in use or not, never aim it at the sun

or other extremely bright objects. Otherwise,

blooming or smear may be caused.

7. Do not operate the camera beyond the specified

temperature, humidity or power source ratings.

Use the camera under conditions where tempera-

ture is between –10 °C - +50 °C (14 °F - 122 °F), and

humidity is below 90 %. The input power source is

120 V AC 60 Hz for WV-CL920A and 12 V DC/24 V

AC for WV-CL924A.

PRECAUTIONS

Caution:

To prevent fire or electric shock hazard, use a

UL listed cable (VW-1, style 1007) for the DC

12 V or AC 24 V Input Terminal.

-9-

<WV-CL920A>

<WV-CL924A>

WV-

CL920A

FB LOCK

Hi-Z G/L 75

Ω

WV-

CL920A

VIDEO OUT

GEN-LOCK

AC 24V

DC 12V

GND

q w

!0i y

!6 !4

VIDEO OUT

GEN-LOCK

GND

120V AC 60Hz

OUT ALARM

DAY/

NIGHT

GND

OUT ALARM

DAY/

NIGHT

GND

MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS

Slide the panel to the left until it locks.

-10-

qAuto Iris Lens Connector

This connector is used to connect the auto iris lens

with a 4-pin male connector supplied as a standard

accessory (Part No. YFE4191J100).

wFlange-back Adjusting Ring (FB)

This ring is used to adjust the back focal length or

picture focus. Rotate this ring upward or downward

for a CS-mount lens. In case of using a C-mount

lens, adjust it with the C-mount adapter.

eLens (Option)

rFocus Fixing Screw (LOCK)

tCamera Mounting Screw Hole

This hole is used to mount the camera onto a

mounting bracket.

yDown Button (K)

This button is used to move the cursor downward. It

is also used to select items in the CAM SET UP

menu.

uRight Button (M)

This button is used to move the cursor to the right.

It is also used to select the mode and can be used

to adjust some levels.

iLeft Button (L)

This button is used to move the cursor to the left. It

is also used to select the mode and can be used to

adjust some levels.

oUp Button (J)

This button is used to move the cursor upward. It is

also used to select items in the CAM SET UP menu.

!0 Set Button (I)

This button is used to activate an item selected in

the CAM SET UP menu.

!1 Gen-lock Termination Switch (Hi-Z, G/L 75Ω)

Set this switch to Hi-Z when a gen-lock video input

signal is looped through. In all other cases, set this

switch to 75 Ω.

!2 Gen-lock Input Connector (GEN-LOCK)

This connector is used to connect an external sys-

tem for synchronization.

!3 Video Output Connector (VIDEO OUT)

This connector is used to connect with the VIDEO

IN connector of the monitor.

Otros manuales para WV-CL920A Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Panasonic

Panasonic

Panasonic WV-SUD638 Manual de funcionamiento

Panasonic

Panasonic WV-CP630 Manual de usuario

Panasonic

Panasonic WVBL734 - CCTV CAMERA Manual de usuario

Panasonic

Panasonic BB-HCM381A - Network Camera Manual de usuario

Panasonic

Panasonic GPUS522HA - IND CCD CAMERA Manual de usuario

Panasonic

Panasonic WV-CS850 Manual de usuario

Panasonic

Panasonic BL-VT164W Manual de usuario

Panasonic

Panasonic WV-SPN531 Manual de usuario

Panasonic

Panasonic A-88-V Manual de usuario

Panasonic

Panasonic AWE300 - COLOR CAMERA Manual de usuario

Panasonic

Panasonic WVCP160 - COLOR CCTV CAMERA Manual de usuario

Panasonic

Panasonic WV-TW310L Manual de usuario

Panasonic

Panasonic BB-HCM527 Manual de usuario

Panasonic

Panasonic WV-CF432N1E Manual de usuario

Panasonic

Panasonic VL-WD812BX Manual técnico

Panasonic

Panasonic BL-C230 Series Manual de usuario

Panasonic

Panasonic AWE560 - COLOR VIDEO CAMERA Manual de usuario

Panasonic

Panasonic Super Dynamic III WV-CS950 Manual de usuario

Panasonic

Panasonic BL-C10A - Network Camera - Pan Manual de usuario

Panasonic

Panasonic AW-HE40HWP Manual de usuario

Panasonic

Panasonic WV-CF300L Series Manual de usuario

Panasonic

Panasonic AW-HE38HWP Manual de usuario

Panasonic

Panasonic WVNF302 - NETWORK CAMERA Manual de usuario

Panasonic

Panasonic WV-SP508 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
