SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

SNMP MIB manual

for i-PRO camera

Ver. 3

Panasonic i-PRO Sensing Solutions Co., Ltd.

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

Change history

Version

Date

Chapter #

Comment

Trigger

6/10/2020

Added MIB explanation for Trap

Trap function added

2.1

10/18/2019

First release

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

This document is copyright protected and Panasonic i-PRO Sensing Solutions Co., Ltd. reserves

all titles and rights in the document. Nobody can copy, reproduce, distribute, or modify this

document in any way without the prior written consent of Panasonic i-PRO Sensing Solutions

Co., Ltd..

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

Table of contents

1. Introduction ......................................................................................................... 5

Definition........................................................................................................ 6

Target devices................................................................................................. 7

2. Overview of SNMP support for i-PRO cameras............................................................ 8

SNMP version.................................................................................................. 9

PDU-type........................................................................................................ 9

3. MIBs supported by i-PRO cameras ......................................................................... 10

Standard MIB................................................................................................ 11

Extended MIB of Panasonic Corporation ............................................................ 12

PANASONIC-MIB...................................................................................... 12

PANA-NCE-SEC........................................................................................ 13

PANA-SECURITY-MIB................................................................................ 15

PANA-CAM-MIB........................................................................................ 15

PANA-CAMTRAP-MIB ................................................................................ 42

4. Trap format ........................................................................................................ 45

SNMP general trap ......................................................................................... 46

trap native events.......................................................................................... 48

I. Appendix............................................................................................................ 50

A) extended MIB tree structure............................................................................ 50

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

1. Introduction

This document describes the setting information necessary for the network monitoring system

to monitor the camera using the SNMP protocol, and tips for the network administrator to

perform camera maintenance.

This document does not provide detailed descriptions of SNMP specifications or standard MIBs.

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

Definition

Word

definition

SNMP

Simple Network Management Protocol

SNMP agent

In this document, it is a network camera.

SNMP manager

An SNMP client that can monitor an SNMP agent.

Network

monitoring

system

A system for monitoring devices connected to a network. Although the

status of network devices can be obtained not only by SNMP but also by

other methods, in this document, what has a function as an SNMP

manager is expressed as a network monitoring system.

Network

administrator

An administrator who receives network device error notifications issued

by the network monitoring system and performs maintenance according

to each device.

Native event

Event notification function that already exists in i-PRO cameras. The

settings can be changed by setting screen accessed and displayed by a

web browser, CGI, or a dedicated setting tool. Existing events include

terminal alarms, motion detection alarms, and command alarms.

MIB

Management Information Base

Standard MIB

MIB as defined in RFC

Extended MIB

Object ID .iso (1) .org (3) .dod (6) .internet (1) .private (4) .enterprises

(1). A MIB that defines: MIBs extended for i-PRO cameras can be

downloaded from the web page.

Object

What is uniquely defined in the MIB.

Object Name

The name of the Object.

Object ID (OID)

An ID that uniquely defines an Object when communicating with SNMP.

Index

A row heading in an SNMP table.

Version

This document refers to SNMP Version.

PDU-Type

How to get the value using SNMP. There are Get, get-next, get-response,

set, trap, inform, etc.

Panasonic

(Corporation)

Company name.

PANASONIC(-

MIB)

Name of the MIB that defines the object ID that Panasonic Corporation

applied for in the extended MIB

Panasonic

Object name defined in the PANASONIC-MIB.

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

Target devices

The devices mentioned in this document are i-PRO EXTREME series and WV-SUD638.

This document describes the features in the latest firmware version.

The differences in functions for each model will be explained in the next chapter.

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

2. Overview of SNMP support for i-PRO cameras

Below is a summary of the SNMP Version and PDU type support status for each model.

WV-SUD638

I-PRO EXTREME series

Version

PDU-Type:Get

PDU-Type:Set

PDU-Type:Trap

Available

Not supported

V2c

Available

Not supported

Notifiable*1

Available

Not supported

The following models do not support Trap : WV-U1113, WV-U1114, WV-U1130, WV-

U1132, WV-U1133, WV-U1134, WV-U1142, WV-U1532L, WV-U1533, WV-U1542L, WV-

U2114, WV-U2130L, WV-U2132L, WV-U2134, WV-U2140L, WV-U2142L, WV-U2530L, WV-

U2532L, WV-U2540L, WV-U2542L

Version

PDU-Type:Get

PDU-Type:Set

PDU-Type:Trap

Available

Not supported

V2c

Available

Not supported

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

SNMP version

i-PRO EXTREME series supports v1, v2c, v3 GET. It also supports v2c Trap.

WV-SUD638 and WV-SUD638B support GET of v1 and v2c.

PDU-type

The PDU-Types supported by i-PRO cameras are shown below.

Get, Get-next, Gret-bulk:

For i-PRO camera, you can get the value of SNMP object by GET request using SNMP v1,

v2c. The i-PRO EXTREME series also supports GET of SNMPv3.

i-PRO cameras can return get-response to Get, get-next and get-bulk requests.

Trap:

You can configure the i-PRO camera to use SNMP v2c for TRAP notification. You can get the

value of the SNMP object by receiving the TRAP notification.

SNMP MIB manual for i-PRO camera

Panasonic i-PRO Sensing Solutions Co., Ltd.

3. MIBs supported by i-PRO cameras

The i-PRO camera responds with standard MIB (mainly mib-2) and extended MIB (panasonic).

This chapter describes the response contents of the standard MIB supported by the camera

and the OID of the extended MIB.

Overview of SNMP responses that i-PRO cameras respond to:

+ iso(1)

| + org(3)

| | + dod(6)

| | | + internet(1)

| | | | + mgmt(2)

| | | | | + mib-2(1)

| | | | | | + ip(4)

| | | | | | + tcp(6)

| | | | | | + udp(7)

| | | | + snmpV2(6)
