Reference Manual

Personal Computer

Model No. CF-F8 Series

CF-W8 Series

CF-T8 Series

We recommend that this Reference Manual be printed.

Read Me First

z“Windows Vista®Business with Service Pack1” is indicated as “Windows” or “Windows Vista”.

z<Only for CF-F8/CF-W8 Series>

The following software package is described as follow:

• “WinDVD™ 8 (OEM Version)” as “WinDVD”

User Account Control is a new security component of Windows Vista to stop unauthorized changes to your computer.

The User Account Control message will pop up every time you try making an important change to your computer.

The Windows Sidebar does not appear in the default setting. To display it, click (Start) - [All Programs] - [Accessories] -

[Windows Sidebar].

zTo always display the sidebar:

ARight-click the sidebar icon on the notification area, and click [Properties].

BAdd a check mark for [Start Sidebar when Windows starts] and click [OK].

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in minor or moderate injury.

Enter

This illustration means to press the

Enter

key.

This illustration means to press and hold the

key, then press the

key.

When using with the

key and the

Ctrl

key functions interchanged, read with the

key and the

Ctrl

key reversed.

(Start) - [All Programs] This illustration means to click (Start), then to click [All Programs].

Îor ⇒These symbols indicate related pages.

Î: If this is clicked, it will jump to the page corresponding Reference Manual.

⇒: Refer to the Operating Instructions.

xxxx*1 If *1 is clicked, it will jump to a related topic.

User Account Control

Windows Sidebar

Read Me First

zSound (e.g. MP3, WMA) and video (e.g. MPG, WMV) recorded in PC Cards and SD Memory Cards may be interrupted

during playback. If this happens, copy them to the hard disk drive and play back.

zSound and video in AVI files may be interrupted or produce a time-lag during playback. If this happens, click or on

the notification area, and click [High performance]. This may remedy the problem.

zDepending on the processing status on Windows, sound may be interrupted at Windows startup. You can mute the sound

at startup.

ARight-click the desktop and click [Personalize] - [Sounds].

BRemove the check mark from [Play Windows Startup sound], and click [OK].

The thermal control may set the computer to hibernation if you use the computer in a high ambient temperature and use an

application that uses a lot of CPU power.

Wait a few minutes (at least 5) before turning the computer on again if this occurs.

Sound and Video

Entering hibernation suddenly

Using the Touch Pad

Use the Touch Pad to move the cursor on the screen and perform computer operations.

A. Work Surface (Touch Pad)

B. Left Button

C. Right Button

Function Operation

Moving the Cursor <CF-F8 Series>

<CF-W8/CF-T8 Series>

Move the tip of your finger lightly over the work surface.

Tapping/Clicking <CF-F8 Series>

<CF-W8/CF-T8 Series>

tapping or clicking

To right-click: Can only be performed by clicking the right

button.

CF-F8 Series

CF-W8/CF-T8 Series

Using the Touch Pad

NOTE

zYou can change the speed of the double-click or the operations of mouse buttons by clicking (Start) - [Control

Panel] - [Mouse].

Double-Tapping/

Double-Clicking

<CF-F8 Series>

<CF-W8/CF-T8 Series>

double-tapping or double-clicking

Dragging <CF-F8 Series>

<CF-W8/CF-T8 Series>

Two quick taps, but on the second tap leaving your finger

down (applying pressure) and moving it on the work surface.

While holding down the button, moving your finger on the work

surface.

Scroll Trace a circle around the Touch Pad. (Îpage 6)

Function Operation

Using the Touch Pad

There are two ways of scrolling with the Touch Pad: the Touch Pad utility, and the Virtual Scrolling Function. You cannot use

both functions at the same time.

The Touch Pad utility is enabled in the default setting.

zThe Touch Pad utility (below)

You can scroll continuously by tracing a circle on the Touch Pad.

zThe Virtual Scrolling function (Îpage 11)

You can scroll vertically (or horizontally) by tracing repeatedly in the desired direction.

You can use separate settings for each account regarding whether to use the Touch Pad utility or the Virtual Scrolling func-

tion.

Using the Touch Pad Utility

You can scroll easily by tracing a circle on the Touch Pad.

NOTE

zExternal mouse drivers cannot be used at the same time as the Touch Pad utility. (Îpage 80)

1Make the following settings to use the horizontal scroll.

Once the settings have been made, it is not necessary to make the same settings the next time.

Scroll

Vertical scroll It can be used in the default setting.

Horizontal scroll A setting is required to use the horizontal scroll.

Vertical scroll The Virtual Scrolling function must be set to enable.

Horizontal scroll

Using the Touch Pad

AClick on the notification area, and click [Settings].

When is not displayed:

Click (Start) - [All Programs] - [Panasonic] - [Touch Pad Utility settings].

If a message appears indicating that the Touch Pad utility is not running, click

(Start) - [All Programs] - [Panasonic] - [Touch Pad Utility], and display .

BAdd a check mark for [Activate horizontal scroll function] in the [General

settings] screen, and click [OK].

2Display the scrollable screen.

3Place the cursor over the area that you want to scroll, and tap (click).

4Remove your finger from the pad, then place your finger in the appropriate area to begin

scrolling.

The finger position on the Touch Pad can be changed using the Touch Pad utility. (Îpage 9) This explanation

assumes in the default setting.

*1 If the horizontal scroll function has not been enabled, the segment shown in the figure above (A) is also included in the area

to begin vertical scrolling.

Vertical scroll*1 Horizontal scroll

Position where finger is

placed

<CF-F8 Series>

<CF-W8/CF-T8 Series>

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Icon on the notification area When you place your finger on the Touch Pad, the icon changes.

Using the Touch Pad

5Trace a circle around the Touch Pad without lifting your finger from the pad.

The scroll direction can be changed using [Reverse vertical scrolling] or [Reverse horizontal scrolling] in the Touch

Pad utility. (Îpage 9)

*2 When the horizontal scroll function has not been enabled, any scrolling will be vertical scrolling.

zThe screen will not scroll if you trace toward the center of the Touch Pad.

zOn screens that cannot be scrolled (e.g., desktop screen), if you scroll, the computer may try to scroll the screen,

causing the cursor to freeze. If this happens, remove your finger from the Touch Pad and begin again, this time

starting from the center of the Touch Pad.

zFor example, on a screen that will only scroll horizontally, even if you execute a vertical scroll, the screen will

scroll horizontally.

Vertical scroll Horizontal scroll*2

Trace clockwise To scroll down

<CF-F8 Series>

<CF-W8/CF-T8 Series>

To scroll right

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Trace counter-clockwise To scroll up

<CF-F8 Series>

<CF-W8/CF-T8 Series>

To scroll left

<CF-F8 Series>

<CF-W8/CF-T8 Series>

Using the Touch Pad

6Once scrolling has begun, continue to trace a circle on the Touch Pad without removing

your finger from the pad.

zAs long as you are tracing a circle, you can continue scrolling using any position on the Touch Pad.

zTo scroll in the opposite direction, trace a circle in the opposite direction without removing your finger from the

Touch Pad.

7When you finish scrolling, remove your finger from the Touch Pad.

Change the settings for the Touch Pad utility

1Click on the notification area, and then click [Settings].

When is not displayed:Îpage 7, step1-A

Using the Touch Pad

2Change the settings.

zGeneral settings

Activate Touch Pad

function (On/Off)

If you add a check mark, you can use the Touch Pad

function (screen scroll). If you remove the check mark,

the Touch Pad function will be disabled, and will be

displayed on the notification area.

Show icon in task tray

(On/Off)

If you add a check mark, the icon will be displayed in the

notification area.

Show scroll direction

(On/Off)

If you add a check mark, the icon will change while

scrolling and the finger located within the region which

starts scrolling.

Activate scroll direction

with animate scroll (On/

Off)

If you add a check mark, the icon will rotate while you

are scrolling.

Scroll window under

mouse cursor (On/Off)

If you add a check mark, scroll the region where the

mouse cursor is located within the active window.

If you remove the check mark, scroll the selected region

within the active window. In either case, if the mouse

cursor is outside the active window, scroll the selected

region.

Reverse vertical scroll-

ing (On/Off)

You can change the direction in which the screen scrolls

when you trace the Touch Pad clockwise.

• When check mark is added: Upwards

• When check mark is removed: Downwards

Activate horizontal

scroll function (On/Off)

If you add a check mark, you can use the horizontal

scroll.

Reverse horizontal

scrolling (On/Off)

When you add a check mark for [Activate horizontal

scroll function], you can change the direction in which

the screen scrolls when you trace the Touch Pad clock-

wise.

• When check mark is added: Scroll left

• When check mark is removed: Scroll right

Set scroll speed You can change the scroll speed.
