Reference Manual

Personal Computer

Model No. CF-31 Series

We recommend that this Reference Manual be printed.

Descriptions

• For common procedures and screens for Windows 7 and

Windows XP, this Reference Manual uses the procedures

and screens of Windows 7.

• Some menus may differ for Windows XP.

• Windows XP does not require clicking operation to of

the notification area.

Introduction

This manual explains using the Windows 7 or Windows XP default setting.

In these instructions, the names are referred as follows.

z“Genuine Windows®7 Professional 32-bit Service Pack 1” and “Genuine Windows®7 Professional 64-bit Service Pack 1”

as “Windows” or “Windows 7”

z“Genuine Microsoft®Windows®XP Professional” as “Windows” or “Windows XP”

For the users of the model with Discrete Video Controller

Your computer is equipped with two graphics processing units (GPUs).

The Intel®GPU consumes less power, but reduces the graphics display performance.

The discrete GPU consumes more power, but maintains a higher graphics display performance.

zIn this manual, refer to the sections preceded by the following descriptions, whenever they appear.

For the users of the model without Discrete Video Controller

Your computer is equipped with the Intel®graphics processing unit (GPU), which is designed to save power effectively.

zIn this manual, refer to the sections preceded by the following description, whenever it appears.

You can update to the latest patches and service packs for Windows with the following menus.

Click (Start)*1 - [All Programs] - [Windows Update].

Do not apply “Driver Updates” even if a message to update a driver appears. If a driver update is required, contact your tech-

nical support office.

*1 Windows XP: [start]

Windows Update

Introduction

Sound and video

zSound (e.g. MP3, WMA) and video (e.g. MPG, WMV) recorded in PC Cards and SD Memory Cards may be interrupted

during playback. If this happens, copy them to the hard disk drive and play back.

Depending on the processing status on Windows, sound may be interrupted at Windows startup. You can mute the sound at startup.

ARight-click the desktop and click [Personalize] - [Sounds].

BRemove the check mark from [Play Windows Startup sound], and click [OK].

When high-frequency sound occurs

If high-frequency sound occurs around keyboard while using the computer, check the settings for the USB power saving function.

A standard user needs to enter an administrator password and click [OK].

zSet [USB selective suspend setting] to [Enabled].

AClick (Start) - [Control Panel] - [System and Security] - [Power Options].

BClick [Change plan settings] of the current power plan.

CIn [Change settings for the plan], click [Change advanced power settings].

DIn [Advanced settings], double-click [USB settings].

EDouble-click the displayed [USB selective suspend setting].

FChange settings of [On battery] and [Plugged in] to [Enabled].

GClick [OK] and exit the [Advanced settings] screen.

Switching the GPU that is used

When you start up the computer for the first time after purchase, the discrete GPU is activated to maintain high performance.

You can manually change the GPU that is used.

1Log on to Windows.

2Click on the notification area, and click .

3Select [Switchable Graphics].

4To switch to the Intel®GPU, select [Power Saving Video] in [Switchable Graphics].

To switch to the discrete GPU, select [Performance Video] in [Switchable Graphics].

Regarding Windows 7

Introduction

5Click [OK].

Wait until the next [OK] screen appears.

6Click [OK].

NOTE

zYou cannot change the GPU that is used while operating graphics-related application programs.

zOnce the GPU is switched, switching to the other GPU is not possible for a certain period of time.

zWhen a digital display (such as an HDMI display) is connected, you cannot switch the GPU that is used.

zWhen an external display is connected and the GPU is switched, the video output destination may unexpectedly be

changed.

You can select the Classic view of Control Panel or the Classic Start menu. You can also change the way a user logs on or off.

This manual explains using the Windows XP default setting (not Classic view or Classic Start menu etc.).

zIf the message “Your computer might be at risk” is displayed

Select (red icon) on the notification area and make the appropriate settings. The Windows Security Center regularly gives

you notice so that you can make the optimum settings. This is not an error message and you can use the computer.

However, making appropriate measures is recommended to reduce the risk of virus and other attacks.

Regarding Windows XP

Key Combinations

NOTE

zDo not repeatedly press the keys in quick succession.

zDo not use the key combinations together with touch pad (external mouse), touchscreen (only for model with touch-

screen) or other key operations.

zDo not use the key combinations before you log on to Windows. Wait until the hard disk drive indicator turns off.

On the Setup Utility screen, you can use the key combinations of

and

zThe key combinations may not work with some applications.

zThe pop-up icon appears after logging on to Windows. It may not appear in some application conditions.

Key Function Pop-up icon

LCD brightness

(

= down /

= up)

Key Combinations

Display mode switching (Îpage 49)

When an external display (a projector etc.) is connected, you can change the dis-

play mode.

APress

BClick the display mode. (Computer only/Duplicate/Extend/Projector only)

The change you made may not be effective until

Enter

is pressed.

You can also change the operating mode by pressing +

Computer only Duplicate Extend Projector only

CAUTION

zDo not press any keys until the display has finished switching.

zDo not use this function:

• When playing motion video such as DVD or MPEG.

• When an extended monitor is not connected.

• When showing a game screen such as pinball.

• When using the extended desktop.

*1 Speaker on/off

OFF

(MUTE)

Key Function Pop-up icon

LCD LCD + HDMI display (port replicator side)*2 HDMI display (port

replicator side)*2 LCD + HDMI display (computer side) HDMI display

(computer side) LCD + analog display analog display HDMI dis-

play (port replicator side)*2 + HDMI display (computer side) HDMI display

(port replicator side)*2 + analog display HDMI display (computer side) +

analog display

Key Combinations

*1 These key combinations are disabled when [Concealed Mode] is enabled.

*2 Only when a port replicator having an HDMI port is connected.

*3 Even if [Sound] is set to [OFF] on the [Concealed Mode Configuration] menu, icon on the notification area and [Volume] do not

show mute state.

However, audio from the speaker is not heard.

*4 Windows XP: standby

When [Fan] is set to [OFF] on the [Concealed Mode Configuration] menu, a message of Fan Status does not appear even if the fan is stopped.

Volume

(

= down /

= up)

NOTE

zWhen fine-tuning the sound volume, press and hold

, and press

intermittently.

zThis does not work on beeps or speakers connected to the USB port.

Activate sleep*4 (Îpage 17)

Concealed Mode on/off

You can select on/off of LCD Backlight, LED, Sound*3, Wireless Radio, Backlit

Keyboard and Fan*5.

NOTE

zYou have to set [Concealed Mode] to [Enabled] in Setup Utility.

(Îpage 98)

zYou can set the devices turned off in [Concealed Mode] with Setup Utility

(Îpage 98).

zIf you press

in succession, the Concealed Mode may not be

switched. More than 4 minutes interval is necessary to switch on/off.

Remaining battery charge (Îpage 27)

F10

Activate hibernation (Îpage 17)

Key Function Pop-up icon

Key Combinations

You can make 2 settings:

•Fn key lock

When you press

, the key is locked (pressed-down) until you press another key. Use this when pressing difficult key

combinations.

• Pop-up icon on/off

1Start up the Hotkey Settings.

Click (Start)*6 - [All Programs] - [Panasonic] - [Hotkey Settings].

2Make the settings.

[Use Fn key lock]

zWhen using an

key combination

APress

once. (Locked)

BPress another key. (Lock released)

zWhen using successive

key combinations

APress

twice. (Locked)

BPress another key.

Fn key remains locked until you press

again.

[Notification]

[Make sounds when Fn key is pressed]*7

[Show status on screen]: Displays the Fn key status when on the notification area is clicked.

•:

is locked.

•:

is not locked.

[Disable popup]

The pop-up icon will not be displayed.

[Display status bar while Fn Key is held down]

[Status bar position]: Select [TOP] or [Bottom].

3Click [OK].

NOTE

zYou can have different settings for each user.

*6 Windows XP: [start]

*7 If the speaker is muted or [Sound] is turned off in [Concealed Mode Configuration], beeps do not sound.

Hotkey Settings

Touchscreen

You can use the touchscreen function to perform the same operation as the touch pad and mouse. Touch the screen surface

with the stylus (included).

For further information, click (Start) - [Control Panel] - [Hardware and Sound] - [Pen and Touch] - [Flicks] - [Practice using

flicks].

zTo right-click

ATouch and hold with the stylus, or touch and select the right button of “touch pointer”.

AClick on the notification area.

changes to .

BClick the object you want to right-click.

returns to .

NOTE

zThe touchscreen function does not work in the Setup Utility.

zYou need to make the following setting for each user.

AClick [start] - [All Programs] - [Fujitsu Touch Panel (USB)] - [Touch Panel Configuration].

BSelect the settings, and then click [OK].

• Do not add a check mark to [Delete Cursor] since the display may be distorted.

zIf you add a check mark for [Use] in [Hold [Ctrl] key down + Touch the screen] of [Touch Panel Configuration], touching

the screen may always be recognized as a right-click. To return to the normal operation, press

Ctrl

on the keyboard.

zThe touchscreen function does not work in the Setup Utility, in the full screen of [Command Prompt].

Operate the touchscreen with your finger or with an approved stylus

When using the touchscreen function, use only your finger or an approved stylus on the surface.

Operating the touchscreen with an object other than your fingertip or the stylus (a fingernail or metal object, or other hard

or sharp objects that may leave a mark) may scar or stain the surface, causing the touchscreen to malfunction.

Do not apply too much pressure when operating the touchscreen

Only a light touch is required to operate the touchscreen. Applying too much pressure may damage the surface.

Operation of the touchscreen

Touchscreen

When the touchscreen becomes dirty, wipe it with an approved soft cloth

The touchscreen is specially treated to prevent dirt from adhering to the surface, so dirt can be removed easily using a dry

cloth (use only the approved soft cloth). If the dirt does not come off easily, breathe on the surface and try again.

Do not apply water or solvents to the soft cloth.

Suggestions About Cleaning the LCD Surface

To improve the outdoor visibility of the display, a low reflection coating has been added. In order to avoid scratches and

peeling of this coating, an approved soft cloth has been included to wipe the LCD surface of the computer. Before using

the computer, be sure to read the instructions provided below.

• Use the soft cloth when it is dry. Do not apply water or solvents to the soft cloth.

• First, lightly wipe foreign particles and dust adhering to the LCD display on one side of the soft cloth. Do not use force,

since the LCD surface may be damaged with the foreign particles or dust.

Next, wipe off fingerprint, etc., with the other side of the soft cloth.

After wiping off foreign particles and dust, wash the soft cloth (refer to the following) to remove the foreign particles and

dust from the soft cloth.

• When the soft cloth becomes dirty, wash it with neutral detergent. Do not use bleach or a fabric conditioner (softener), or

carry out sterilization by boiling.

• If the LCD gets wet, wipe the surface lightly with the soft cloth.

• While wiping the LCD display, the computer must be turned off.

Clean the touchscreen while the computer is powered off

Cleaning the screen while the power is on may cause the computer to malfunction. Also, dirt on the touchscreen is easier

to see when the computer is powered off, and so is easier to clean.

Wash the soft cloth when it becomes dirty

When the soft cloth becomes dirty, wash it with mild detergent. Do not use bleach or fabric conditioner (softener), or try to

sterilize the cloth by boiling.

If the soft cloth is dirty, it may be ineffective in cleaning the touchscreen, and in fact may cause dirt to adhere to the touch-

screen.

Maintaining the performance of the touchscreen

• Be sure to wipe the LCD display to remove fingerprints, etc., with the soft cloth.

• Do not wipe areas other than the LCD display with the soft cloth.

Otros manuales para Toughbook CF-31AAA7J1M

Este manual sirve para los siguientes modelos

395

Tabla de contenidos

Otros manuales de Computadora portátil de Panasonic

Panasonic

Panasonic Toughbook CF-28 Series Manual de usuario

Panasonic

Panasonic Toughbook 19 Manual de usuario

Panasonic

Panasonic CF-W2 Series XP Manual de usuario

Panasonic

Panasonic CF-71 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-M33W5M Manual de usuario

Panasonic

Panasonic CF-AX2 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-W4HWEZZBM Manual de usuario

Panasonic

Panasonic Toughbook CF-F8EWAZZJM Manual de usuario

Panasonic

Panasonic CF-33 series Manual de usuario

Panasonic

Panasonic Toughbook CF-U1GQG6L2M Manual de usuario

Panasonic

Panasonic Toughbook CF-29F3K15KK Manual de usuario

Panasonic

Panasonic Toughbook CF-18BCAGCMM Manual de usuario

Panasonic

Panasonic Toughbook CF-W7BWAZZAM Manual de usuario

Panasonic

Panasonic CF-Y5 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-52CCABCBM Manual de usuario

Panasonic

Panasonic Toughbook CF-18 mk3 Diagrama de cableado

Panasonic

Panasonic CF48X4KHUQM - PERSONAL COMPUTER Manual de usuario

Panasonic

Panasonic Toughbook CF-72N3FCZEM Manual de usuario

Panasonic

Panasonic Toughbook CF-30F3SAXAM Manual de usuario

Panasonic

Panasonic CF-1000 Manual de usuario

Panasonic

Panasonic Toughbook CF-52GGNBP2B Manual de usuario

Panasonic

Panasonic CF-18KHH6512 Manual de usuario

Panasonic

Panasonic FX-55 Series Manual de usuario

Panasonic

Panasonic CF-M34 Series Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
