Reference Manual

Personal Computer

Model No. CF-19 Series

We recommend that this Reference Manual be printed.

Descriptions

• For common procedures and screens for Windows 7 and

Windows XP, this Reference Manual uses the procedures

and screens of Windows 7.

• Some menus may differ for Windows XP.

• Windows XP does not require clicking operation to of

the notification area.

Introduction

This manual explains using the Windows 7 or Windows XP default setting.

indicates “Genuine Windows®7 Professional”

indicates “Genuine Microsoft®Windows®XP Professional” or “Genuine Microsoft®Windows®XP Tablet

PC Edition”

indicates “Genuine Microsoft®Windows®XP Professional”

indicates “Genuine Microsoft®Windows®XP Tablet PC Edition”

In these instructions, the names are referred as follows.

“Genuine Windows®7 Professional” as “Windows” or “Windows 7”

“Genuine Microsoft®Windows®XP Professional” or “Genuine Microsoft®Windows®XP Tablet PC Edition” as “Windows”

or “Windows XP”

You can update to the latest patches and service packs for Windows with the following menus.

Click (Start)*1 - [All Programs] - [Windows Update].

Do not apply “Driver Updates” even if a message to update a driver appears. If a driver update is required, contact your tech-

nical support office.

*1 Windows XP: [start]

Sound and video

Sound (e.g. MP3, WMA) and video (e.g. MPG, WMV) recorded in PC Cards and SD Memory Cards may be interrupted

during playback. If this happens, copy them to the hard disk drive and play back.



Depending on the processing status on Windows, sound may be interrupted at Windows startup. You can mute the sound at startup.

ARight-click the desktop and click [Personalize] - [Sounds].

BRemove the check mark from [Play Windows Startup sound], and click [OK].

When high-frequency sound occurs

If high-frequency sound occurs around keyboard while using the computer, check the settings for the USB power saving function.

A standard user needs to enter an administrator password and click [OK].

Set [USB selective suspend setting] to [Enabled].

AClick (Start) - [Control Panel] - [System and Security] - [Power Options].

BClick [Change plan settings] of the current power plan.

Windows Update

Regarding Windows 7

Introduction

CIn [Change settings for the plan], click [Change advanced power settings].

DIn [Advanced settings], double-click [USB settings].

EDouble-click the displayed [USB selective suspend setting].

FChange settings of [On battery] and [Plugged in] to [Enabled].

GClick [OK] and exit the [Advanced settings] screen.

You can select the Classic view of Control Panel or the Classic Start menu. You can also change the way a user logs on or off.

This manual explains using the Windows XP default setting (not Classic view or Classic Start menu etc.).

If the message “Your computer might be at risk” is displayed

Select (red icon) on the notification area and make the appropriate settings. The Windows Security Center regularly gives

you notice so that you can make the optimum settings. This is not an error message and you can use the computer.

However, making appropriate measures is recommended to reduce the risk of virus and other attacks.

Regarding Windows XP

Key Combinations

NOTE

Do not repeatedly press the keys in quick succession.

Do not use the key combinations together with touch pad (external mouse), touchscreen (only for model with touch-

screen), dual touch (only for model with dual touch), tablet buttons, or other key operations.

Do not use the key combinations before you log on to Windows. Wait until the hard disk drive indicator turns off.

On the Setup Utility screen, you can use the key combinations of

and

The key combinations may not work with some applications.

The pop-up icon appears after logging on to Windows. It may not appear in some application conditions.

Key Function Pop-up icon

LCD brightness

(

= down /

= up)

Display mode switching (page 56)

When an external display (a projector etc.) is connected, you can change the dis-

play mode.

APress

BClick the display mode. (Computer only/Duplicate/Extend/Projector only)

The change you made may not be effective until

Enter

is pressed.

You can also change the operating mode by pressing +

Internal LCD Simultaneous display External display

CAUTION

Do not press any keys until the display has finished switching.

Do not use this function:

• When playing motion video such as DVD or MPEG.

• When an extended monitor is not connected.

• When showing a game screen such as pinball.

• When using the extended desktop.

Key Combinations

*1 These key combinations are disabled when [Concealed Mode] is enabled.

*2 Even if [Sound] is set to [OFF] on the [Concealed Mode Configuration] menu, or icon on the notification area and [Volume] in

[SoundMAX] display do not show mute state.

However, audio from the speaker is not heard.

*3 Windows XP: standby

*1 Speaker on/off

NOTE

Beeps do not sound if you turn off the speaker sound.*2

OFF

(MUTE)

Volume

(

= down /

= up)

NOTE

When fine-tuning the sound volume, press and hold

, and press

intermittently.

This does not work on beeps or speakers connected to the USB port.

Activate sleep*3 (page 27)

Concealed Mode on/off

You can select on/off of LCD Backlight, LED, Sound*2, Wireless Radio, Camera

Light and Backlit Keyboard.

NOTE

You have to set [Concealed Mode] to [Enabled] in Setup Utility.

(page 108)

You can set the devices turned off in [Concealed Mode] with Setup Utility

(page 108).

If you press

in succession, the Concealed Mode may not be

switched. More than 4 minutes interval is necessary to switch on/off.

Remaining battery charge (page 36)

F10

Activate hibernation (page 27)

Key Function Pop-up icon

Key Combinations

You can make 2 settings:

•Fn key lock

When you press

, the key is locked (pressed-down) until you press another key. Use this when pressing difficult key

combinations.

• Pop-up icon on/off

1Start up the Hotkey Settings.

Click (Start)*4 - [All Programs] - [Panasonic] - [Hotkey Settings].

2Make the settings.

[Use Fn key lock]

When using an

key combination

APress

once. (Locked)

BPress another key. (Lock released)

When using successive

key combinations

APress

twice. (Locked)

BPress another key.

Fn key remains locked until you press

again.

[Notification]

[Make sounds when Fn key is pressed]*5

[Show status on screen]: Displays the Fn key status when on the notification area is clicked.

•:

is locked.

•:

is not locked.

[Disable popup]

The pop-up icon will not be displayed.

3Click [OK].

NOTE

You can have different settings for each user.

*4 Windows XP: [start]

*5 If the speaker is muted or [Sound] is turned off in [Concealed Mode Configuration], beeps do not sound.

Hotkey Settings

Tablet Buttons

NOTE

The Tablet buttons work when the Windows screen is displayed.

The Tablet buttons may not work immediately after Windows is started up or the Windows logon screen (or the Wel-

come screen) is displayed.

If you set password input for resuming from screensaver, the Input Panel, Enter and Rotation buttons do not work on

screensaver.

Button Function

LCD Brightness

: down / : up

Input Panel

Tablet PC Input Panel on/off

Software keyboard on/off (page 20)

This button does not work on the Welcome screen.

Enter

Works as

Enter

Rotation

Rotates the display. (page 23)

Do not press the button again until the display rotation is completed.

Security

Works as

Ctrl

Alt

Del

Locks the computer.

On the Windows logon screen and the Welcome screen, this button work as

Ctrl

Alt

Del

This button does not work on screensaver.

Tablet Buttons

NOTE

You can have different settings for each user.

On the Windows logon screen and Welcome screen, the tablet buttons are enabled and work in default irrespective of

the settings you made.

To change the tablet button functions

You can change the functions of the Input Panel ( )/Enter ( )/Rotation ( ) buttons.

1Open the setting screen.

Click (start) - [Control Panel] - [Hardware and Sound] - [Set tablet buttons to perform certain tasks].

Click [start] - [All Programs] - [Panasonic] - [Tablet Buttons Settings].

Click [start] - [Control Panel] - [Printers and Other Hardware] - [Tablet and Pen Settings] - [Tablet Buttons].

2Click the tablet button and click [Change].

Select the function in [Press] and [Press and hold].

You cannot select

for [Press a key or key combination].

Click [Browse] to select the application if you select [Start a program].

Select the function in [Action].

You cannot select

for [Press a key or key combination].

Click [Browse] to select the application if you select [Launch an application].

4Click [OK].

5Click [OK].

Setting the Tablet Buttons

Tablet Buttons

To disable the tablet buttons

You can disable the Security ( )/Input Panel ( )/Enter ( )/Rotation ( ) buttons.

1Click [start] - [All Programs] - [Panasonic] - [Tablet Buttons Settings].

2Remove the check mark from [Enable Security, Input Panel, Enter, Rotation Button.]

3Click [OK].

Touchscreen

You can use the touchscreen function to perform the same operation as the touch pad and mouse. Touch the screen surface

with the stylus (included).

For further information, click (Start) - [Control Panel] - [Hardware and Sound] - [Pen and Touch] - [Flicks] - [Practice using

flicks].

To right-click

ATouch and hold with the stylus, or touch and select the right button of “touch pointer”.

AClick on the notification area.

changes to .

BClick the object you want to right-click.

returns to .

NOTE

The touchscreen function does not work in the Setup Utility.

You need to make the following setting for each user.

AClick [start] - [All Programs] - [Fujitsu Touch Panel (USB)] - [Touch Panel Configuration].

BSelect the settings, and then click [OK].

• Do not add a check mark to [Delete Cursor] since the display may be distorted.

If you add a check mark for [Use] in [Hold [Ctrl] key down + Touch the screen] of [Touch Panel Configuration], touching

the screen may always be recognized as a right-click. To return to the normal operation, press

Ctrl

on the keyboard.

The touchscreen function does not work in the Setup Utility, in the full screen of [Command Prompt].

Operate the touchscreen with your finger or with an approved stylus

When using the touchscreen function, use only your finger or an approved stylus on the surface.

Operating the touchscreen with an object other than your fingertip or the stylus (a fingernail or metal object, or other hard

or sharp objects that may leave a mark) may scar or stain the surface, causing the touchscreen to malfunction.

Do not apply too much pressure when operating the touchscreen

Only a light touch is required to operate the touchscreen. Applying too much pressure may damage the surface.

Operation of the touchscreen

Otros manuales para CF-19RDRAX6M

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Computadora portátil de Panasonic

Panasonic

Panasonic Toughbook CF-52ELNBD2M Manual de usuario

Panasonic

Panasonic Toughbook F9 Manual de usuario

Panasonic

Panasonic Toughbook CF-F8EWAZZJM Manual de usuario

Panasonic

Panasonic CF-27 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-W7BWAZAAM Manual de usuario

Panasonic

Panasonic CF-74 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-W8EWDZZ2M Manual de usuario

Panasonic

Panasonic CF-31JEGAXDM Manual de usuario

Panasonic

Panasonic Toughbook CF-52GGNHE2B Manual de usuario

Panasonic

Panasonic CF-U1G Diagrama de cableado

Panasonic

Panasonic Toughbook CF-30CAQCXBM Manual de usuario

Panasonic

Panasonic CF-C2 series Manual de usuario

Panasonic

Panasonic CF-20 series Hoja de especificaciones

Panasonic

Panasonic CF-72X3UUBDM - Toughbook 72 - Pentium 4-M 1.8... Manual de usuario

Panasonic

Panasonic CF-07 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-18BHKZXDM Manual de usuario

Panasonic

Panasonic CF-AX3 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-29CTKGZKM Manual de usuario

Panasonic

Panasonic Toughbook CF-29F3K15KK Manual de usuario

Panasonic

Panasonic Toughbook CF-52EKMxDxM Manual de usuario

Panasonic

Panasonic Toughbook CF-48 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-27FCCKFAM Manual de usuario

Panasonic

Panasonic Toughbook CF-28 Series Manual de usuario

Panasonic

Panasonic Toughbook CF-50LB2UDKM Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
