Panasonic DMCFP2 - DIGITAL STILL CAMERA Especificaciones técnicas

For Canadian assistance, please call: 1-800-99-LUMIX (1-800-995-8649) or

send e-mail to: [email protected]

VQT2K16-2

M1209KZ2030

Basic Operating Instructions

Digital Camera

Model No. DMC-FP2

DMC-FP1

Before connecting, operating or adjusting

this product, please read the instructions

completely.

Please also refer to Operating Instructions (PDF

format) contained on the CD-ROM (supplied).

You can learn about advanced operation methods and check the

Troubleshooting.

2 VQT2K16 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products

on the market today. Used properly, we’re sure it will bring you and your

family years of enjoyment. Please take the time to fill in the information

below.

The serial number is on the tag located on the underside of your Camera.

Be sure to retain this manual as your convenient Camera information

source. Please note that the actual controls and components, menu

items, etc. of your Digital Camera may look somewhat different from

those shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or

broadcast material for purposes other than your own private use may

infringe copyright laws. Even for the purpose of private use, recording

of certain material may be restricted.

Model No. Serial No.

A lithium ion battery that is recyclable powers

the product you have purchased. Please call

1-800-8-BATTERY for information on how to recycle

this battery.

Information for Your Safety

THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE

EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

This Class B digital apparatus complies with Canadian ICES-003.

(ENG) VQT2K16 3

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT

DAMAGE,

•

DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING

OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS,

SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

• USE ONLY THE RECOMMENDED ACCESSORIES.

• DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO

USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

Product Identification Marking is located on the bottom of units.

■About the battery pack

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (+ and −) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes,

wash it off thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub

the eyes. Rinse eyes thoroughly with water, and then consult a doctor.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in an automobile exposed to direct

sunlight for a long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C

(140 °F) or incinerate.

4 VQT2K16 (ENG)

■About the battery charger

CAUTION!

DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-

IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE

UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC

SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE

THAT CURTAINS AND ANY OTHER MATERIALS DO NOT

OBSTRUCT THE VENTILATION VENTS.

Battery charger

This battery charger operates on AC between 110 V and 240 V.

But

• In the U.S.A. and Canada, the battery charger must be connected to

a 120 V AC power supply only.

• When connecting to an AC supply outside of the U.S.A. or Canada,

use a plug adaptor to suit the AC outlet configuration.

■Cautions for Use

• Do not use any other AV cables except the supplied one.

• Do not use any other USB connection cables except the supplied one.

Keep the camera as far away as possible from electromagnetic equipment

(such as microwave ovens, TVs, video games etc.).

• If you use the camera on top of or near a TV, the pictures and sound on the

camera may be disrupted by electromagnetic wave radiation.

• Do not use the camera near cell phones because doing so may result in noise

adversely affecting the pictures and sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation generated by microprocessors may adversely

affect the camera, disturbing the pictures and sound.

• If the camera is adversely affected by electromagnetic equipment and stops

functioning properly, turn the camera off and remove the battery or disconnect

AC adaptor (DMW-AC5PP; optional). Then reinsert the battery or reconnect AC

adaptor and turn the camera on.

Do not use the camera near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures

and sound may be adversely affected.

(ENG) VQT2K16 5

-If you see this symbol-

Information on Disposal in other Countries outside

the European Union

This symbol is only valid in the European Union. If you

wish to discard this product, please contact your local

authorities or dealer and ask for the correct method of

disposal.

6 VQT2K16 (ENG)

Contents

Before use

Standard accessories ................7

Names of parts............................8

Cursor button ...................................9

Preparations

Charging the battery ................10

Inserting and removing the card

(optional)/the battery.................. 12

Picture save destination

(cards and built-in memory) ...........13

Setting the Clock ......................14

Setting the menu ......................15

Basics

Taking pictures with

automatic settings

[INTELLIGENT AUTO] Mode ....16

Selecting the [REC] Mode .......18

Taking motion pictures

[MOTION PICTURE] Mode........19

Viewing your pictures

[NORMAL PLAY] .......................20

Deleting pictures ......................20

Others

Reading the Operating

Instructions (PDF format) ........21

Specifications ...........................23

Optional accessories ...............26

Information for Your Safety .......2

(ENG) VQT2K16 7

Standard accessories

Check that all the accessories are included before using the camera. Part

numbers are as of January 2010.

Battery Pack

DMW-BCH7PP

• Charge the battery

before use.

Battery Pack is indicated as

battery pack or battery in the

text.

Battery Charger

DE-A75B

Battery Charger is indicated as

battery charger or charger in

the text.

Battery Case

VGQ0J54

Hand Strap

VFC4297

USB Connection

Cable

K1HA08AD0002

AV Cable

K1HA08CD0028

CD-ROM

VFF0588

• Software:

Use it to install the

software on your

PC.

• Operating

Instructions

• Cards are optional. You can record or play back pictures on the built-in

memory when you are not using a card.

• If any accessories are lost, customers should contact 1 800 99-LUMIX

(1-800-995-8649) for further information about obtaining replacement

parts.

• Please dispose of all packaging appropriately.

8 VQT2K16 (ENG)

Names of parts

Release lever

Tripod receptacle

• Ensure that the tripod is stable.

Card/Battery door

Zoom lever

Shutter button

Flash

Lens

Self-timer indicator/

AF Assist Lamp

Lens cover

•Fully peel off the strip of tape from the

lens cover before using the camera.

•When opening and closing the lens

cover, make sure that liquid or foreign

objects such as sand do not enter.

LCD monitor

[MODE] button

Cursor button

[DISPLAY] button

[Q.MENU]/Delete button

Microphone

Power button

Playback button

Speaker

button

●We recommend you use a battery with sufficient battery power or the

AC adaptor when recording motion pictures.

(ENG) VQT2K16 9

Hand strap eyelet

Cursor button

[AV OUT/DIGITAL] socket

[DC IN] socket

②

①We recommend using the

supplied hand strap to avoid

dropping the camera.

[MENU/SET]

(menu display/set/finish)

Left cursor button (◄)

• Self-timer

Down cursor button (▼)

• Macro mode

Up cursor button (▲)

• Exposure compensation

Right cursor button (►)

• Flash

●In this manual, the button that is used is shaded or indicated

by▲▼◄►.

●Always use a genuine Panasonic AC adaptor (DMW-AC5PP: optional).

●If while recording motion pictures using the AC adaptor the power

supply is cut off due to a power cut or if the AC adaptor is disconnected

etc., the motion picture being recorded will not be recorded.

The illustrations and screens in this manual may differ from the actual

product. This manual uses the screens from DMC-FP1 as examples in

its explanations.

10 VQT2K16 (ENG)

Charging the battery

■About batteries that you can use with this unit

The battery that can be used with this unit is DMW-BCH7PP.

It has been found that counterfeit battery packs which look very

similar to the genuine products are made available to purchase

in some markets. Some of these battery packs are not adequately

protected with internal protection to meet the requirements of

appropriate safety standards. There is a possibility that these

battery packs may lead to fire or explosion. Please be advised

that we are not liable for any accident or failure occurring as a

result of use of a counterfeit battery pack. To ensure that safe

products are used we recommend that a genuine Panasonic

battery pack is used.

•Use the dedicated charger and battery.

•The camera has a function for distinguishing batteries which can

be used safely. The dedicated battery (DMW-BCH7PP) supports

this function. The only batteries suitable for use with this unit

are genuine Panasonic products and batteries manufactured by

other companies and certified by Panasonic. (Batteries which do

not support this function cannot be used). Panasonic cannot in

any way guarantee the quality, performance or safety of batteries

which have been manufactured by other companies and are not

genuine Panasonic products.

•The battery is not charged when the camera is shipped. Charge

the battery and set the clock before use.

•Charge the battery with the charger indoors (10 °C - 35 °C)

(50 °F - 95 °F).

Insert the battery terminals and attach

the battery to the charger

Ensure [LUMIX] faces outwards.

Otros manuales para DMCFP2 - DIGITAL STILL CAMERA

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic DMC-FX30A - Lumix Digital Camera Manual de instrucciones

Panasonic

Panasonic Lumix DMC-G3KPP Manual de usuario

Panasonic

Panasonic LUMIX DC-GH6 Manual de usuario

Panasonic

Panasonic DCGH5SGNK Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-GX8 Manual de usuario

Panasonic

Panasonic DMC-GH1K - Lumix Digital Camera Manual de usuario

Panasonic

Panasonic Lumix DC-FZ10002 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-ZS9 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX01W Manual de usuario

Panasonic

Panasonic Lumix DMC-FX30 Manual de usuario

Panasonic

Panasonic DMC-TZ25GW Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ300 Manual de usuario

Panasonic

Panasonic Lumix DMC-ZS8 Guía

Panasonic

Panasonic AW-HE145WP Manual de usuario

Panasonic

Panasonic Lumix DMC-FS15 Manual de usuario

Panasonic

Panasonic Lumix DMC-LS1PP Manual de usuario

Panasonic

Panasonic Lumix DMC-SZ7P Manual de usuario

Panasonic

Panasonic Lumix DMC-GF1 C Manual de usuario

Panasonic

Panasonic LUMIX DMC-LS1EB Manual de usuario

Panasonic

Panasonic DMCFZ30PP - DIGITAL STILL CAMERA Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ70 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FT25 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX700 Manual de usuario

Panasonic

Panasonic Lumix DMC-GX8WC Especificaciones técnicas

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
