Panasonic DMC-GH2HK Manual de usuario

DMC-GH2

Micro System Digital Camera

5 fps in 16.05-megapixel Full Resolution and Venus Engine

FHD

1920 x 1080 50i Full-HD Movies in AVCHD Format.

Intuitive Touch-control Shooting and Double Live View

3D Shooting Compatible

Artistic Images with My Color Mode, Film Mode and Variable

Movie Mode

Advanced Intelligent Resolution Technology, Intelligent D-Ran-

ge Control

LUMIX G Micro System - Interchangeable Lens Digital Camera

LUMIX G Micro System Digital Camera GH2 - Creative Machine with Full-HD Movie and High-speed

Response

TYPE

Type Digital interchangeable lens system camera

Recording media SD memory card, SDHC memory card, SDXC memory card

Image sensor size 17.3 x 13.0 mm (in 4:3 aspect ratio)

Lens Mount Micro Four Thirds mount

IMAGE SENSOR

Type Live MOS Sensor

Total pixels 18.31 Megapixels

Camera effective pixels 16.05 Megapixels

Colour filter Primary colour filter

Dust reduction system Supersonic wave filter

RECORDING SYSTEM

Recording file format Still Image: JPEG(DCF, Exif 2.3), RAW, DPOF compatible MPO (When

attaching 3D lens in Micro Four Thirds standard)

Motion Image: AVCHD / QuickTime Motion JPEG

Aspect ratio 4:3, 3:2, 16:9, 1:1 (Multi-aspect recording except 1:1)

Image quality RAW, RAW+Fine, RAW+Standard, Fine, Standard, MPO+Fine, MPO+

Standard (with 3D lens in Micro Four Thirds standard)

Color Space sRGB, Adobe RGB

899.99 GBP

File size(Pixels)

Motion Image (AVCHD : NTSC) [Full HD] 1920×1080, 24p (24H:24Mbps,24L:17Mbps)

[Full HD] 1920×1080, 60i (sensor output is 60p) (FSH:17Mbps,

FH:13Mbps/AVCHD)

[HD] 1280 x 720, 60p (sensor output is 60p)(SH:17Mbps, H:13Mbps/

AVCHD)

Motion Image (AVCHD : PAL) [Full HD] 1920×1080, 24p (24H:24Mbps,24L:17Mbps)

[Full HD] 1920×1080, 50i (sensor output is 50p) (FSH:17Mbps,

FH:13Mbps/AVCHD)

[HD] 1280 x 720, 50p (sensor output is 50p)(SH:17Mbps, H:13Mbps/

AVCHD)

Still Image [4:3] 4608x3456(L) / 3264x2448(M) / 2336x1752(S) / 1920x1440(When

attaching 3D lens in Micro Four Third System standard)

[3:2] 4752x3168(L) / 3360x2240(M) / 2400x1600(S) / 1920x1280(When

attaching 3D lens in Micro Four Third System standard)

[16:9] 4976x2800(L) / 3520x1980(M) / 1920x1080(S) / 1920x1080

(When attaching 3D lens in Micro Four Third standard)

[1:1] 3456x3456(L) / 2448x2448(M) / 1744x1744(S) / 1792x1792(When

attaching 3D lens in Micro Four Third standard)

Motion Image (Motion JPEG) [4:3] QVGA : 320 x 240, 30fps / VGA : 640 x 480, 30fps

[16:9] WVGA : 848 x 480, 30fps

[HD] 1280 x 720, 30fps

Continuous recordable time (Mo-

tion images)

AVCHD with picture quality set to [FSH]: Approx. 120 min with H-

FS014042 / Approx. 110 min with H-VS014140

Motion Jpeg with picture quality set to [FSH]: Approx. 130 min with H-

FS014042 / Approx. 120 min with H-VS014140

Actual recordable time (Motion

images)

AVCHD with picture quality set to [FSH]: Approx. 70 min with H-

FS014042 / Approx. 65 min with H-VS014140

Motion JPEG with picture quality set to [HD]: Approx. 75 min with H-

FS014042 / Approx. 70 min with H-VS014140

VIEWFINDER

Type Live View Finder (1,533,600 dots equivalent)

Field of view Approx. 100%

Magnification Approx. 1.42x / 0.71x (35mm camera equivalent) with 50mm lens at in-

finity; -1.0 m-1

Eye point Approx.17.5mm from eyepiece lens

Diopter adjustment -4.0~+4.0(dpt)

Auto eye sensor Yes

FOCUS

Type Contrast AF system

Focus mode AFS/ AFC/ MF

AF mode Face detection / AF Tracking / 23-area-focusing / 1-area-focusing

Touch (1- area-focusing in Face detection / AF Tracking / Multi-area-fo-

cusing / 1-area-focusing)

AF detective range EV 0-18

AF assist lamp YES

AF lock AF/AE LOCK button or Shutter button halfway pressed in AFs mode

Others Pre AF (Quick AF/Continuous AF), AF+MF, Touch shutter, Touch MF

Assist,

EXPOSURE CONTROL

ISO sensitivity (Standard Output

Sensitivity)

Auto / Intelligent ISO / 160 / 200 / 250 / 320 / 400 / 400 / 500/ 640 /

800 / 1000 / 1250 / 1600 / 2000 / 2500 / 3200 / 4000 / 5000 / 6400 /

8000 / 10000 / 12800

Light metering system 144-zone multi-pattern sensing system

Light metering mode Intelligent Multiple / Center Weighted / Spot

Metering range EV 0-18

Exposure mode Program AE, Aperture Priority AE, Shutter Priority AE, Manual, Auto

Exposure compensation 1/3EV Step ±5EV

AE lock AF/AE LOCK button or Shutter button halfway pressed

AE bracket 3,5,7 frame, in 1/3, 2/3 or 1 EV Step, ±3 EV

WHITE BALANCE

White balance Auto / Daylight / Cloudy / Shade / Halogen / Flash / White Set 1, 2, 3,

4 / Color temperature setting

White balance adjustment Blue/amber bias, Magenta/green bias

Color temperature setting 2500-10000K in 100K

White balance bracket 3 exposures in blue/amber axis or in magenta/green axis

SHUTTER SYSTEM

Type Focal-plane shutter

Shutter speed Still Images: 1/4000 ~ 60 and Bulb (up to approx. 2 minutes)

Self timer 10sec, 3 images/ 2sec / 10sec

Remote control Remote control with bulb function by DMW-RSL1 (Optional)

SCENE MODE

Still Image SCN mode Portrait (Normal/Soft Skin/Outdoor/Indoor/Creative) / Scenery (Normal/

Nature/Architecture/Creative) / Close-up (Flower/Food/Objects/Creati-

ve) / SCN (Peripheral Defocus/Night Portrait/Night Scenery/Sunset/Par-

ty/Sports/Baby 1,2/Pet)

Movie SCN mode Portrait (Normal/Soft Skin/Outdoor/Indoor/Creative) / Scenery (Normal/

Nature/Architecture/Creative) / Close-up (Flower/Food/Objects/Creati-

ve) / SCN (Peripheral Defocus/Night Portrait/Night Scenery/Sunset/Par-

ty/Sports/Baby 1,2/Pet)

(Activated by selecting Still Image SCN mode then pressing Movie But-

ton. Still Image SCN modes without corresponding Movie SCN mode is

recorded in mode suitable for the recording situation.)

MY COLOR MODE (Still image & Movie) Expressive/Retro/Pure/Elegant/Monochrome/Dy-

namic Art/Silhouette/Custom (Color/Brightness/Saturation/ adjustable)

BURST SHOOTING

Burst speed SH: 40 frames/sec(4M), H: 5 frames/sec, M: 3 frames/sec, L: 2 frames/

sec

Number of recordable images 7 images (when there are RAW files with the particular speed)

Unlimited consecutive shooting (when there are no RAW files)

(depending on memory card size, battery power, picture size, and com-

pression)

BUILT-IN-FLASH

Type TTL Built-in-Flash, GN13.9 equivalent (ISO 160 ·m), Built-in Pop-up

Flash Mode Auto, Auto/Red-eye Reduction, Forced On, Forced On/Red-eye Reduc-

tion, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off

Synchronization speed Less than 1/160 second

Flash output adjustment 1/3EV Step ±2EV

Flash synchronization 1st. Curtain Sync, 2nd Curtain Sync.

Hot shoe TTL Auto with FL220/FL360/FL500(Optional)

LCD MONITOR

Type TFT LCD with Touch panel

Monitor size Free-angle 3.0inch / 3:2 Aspect / Wide viewing angle

Pixels 460K dots

Filed of view Approx. 100%

Monitor adjustment Brightness (7 levels), Color (7 levels)

LIVE VIEW

Extra Tele Conversion Still image: Max.2x, Motion image: Max.4.8x

(Not effective with L size recording. Magnification ratio depends on the

recording pixels and aspect ratio.)

Digital zoom 2x, 4x

Other functions Guide Lines (3 patterns)

Real-time Histogram

FILM MODE

Colour Standard / Dynamic / Smooth / Nature / Nostalgic / Vibrant

Black and white Standard / Dynamic / Smooth

Others My Film1 / My Film2 / Multi Film / Cinema

PLAYBACK

Playback mode Normal playback

30-thumbnail display

12-thumbnail display

Calendar display

Zoomed playback (16x Max.)

Slideshow (duration & effect is selectable)

Playback Mode (Normal/Picture/AVCHD/Motion JPEG/3D Play/Catego-

ry/Favorite)

Title Edit

Text Stamp

Video Divide

Resize

Cropping

Aspect Conversion

Rotate

Rotate Display

Favorite

Print Set

Protect

Face Rec Edit

IMAGE PROTECTION / ERASE

Protection Single / Multi or Cancel

Erase Single / Multi / All / Except Favorite

Direct Print PictBridge compatible(Print size, Layout, Date setting is selectable )

INTERFACE

Microphone Stereo, Wind-cut: Off / Low / Standard / High

USB USB 2.0 High Speed

HDMI miniHDMI TypeC

Video: Auto / 1080i / 720p / 480p (576p in PAL system)

Audio: Dolby® Digital Stereo Creator

Audio video output Stereo Type, NTSC/PAL, NTSC only for North America

*Check the website of the Panasonic sales company in your country or

region for details on the products that are available in your market.

Remote / External microphone

input

φ2.5mm. stereo mini jack

Speaker Monaural

LANGUAGE

OSD language Japanese, English, German, French, Italian, Spanish

GENERAL

Colour Black

Power

Battery life (CIPA standard) Approx. 330 images (LCD), Approx. 340 images (LVF) with H-

FS014042

Approx. 320 images (LCD), Approx. 330 images (LVF) with H-

VS014140

Battery ID-Security Li-ion Battery Pack (7.2V, 1200mAh) (Included)

Battery Charger

Dimensions (W x H x D) 124 x 89.6 x 75.8mm / 4.88 x 3.53 x 2.98 in (excluding protrusions)

Weight Approx.609g / 21.48 oz (SD card, Battery, 14-42mm lens included)

Approx. 904g / 31.88 oz (SD card, Battery, 14-140mm lens included)

Approx. 392g / 13.82 oz (Body only)

Operating Environment

Operating temperature 0 to 40 (32°F to 104°F)

Operating humidity 10% to 80%

Standard Accessories

Software PHOTOfunSTUDIO 6.0 BD Edition

SILKYPIX® Developer Studio 3.1 SE

Super Loilo Scope (trial version)

USB Driver

Standard accessories Battery Charger

Battery Pack

Body Cap

AV Cable

USB Connection Cable

Shoulder Strap

Stylus pen

CD-ROM

INTERCHANGEABLE LENS-1

Lens Name LUMIX G VARIO 14-42mm / F3.5-5.6 ASPH. / MEGA O.I.S.

Lens Construction 12 elements in 9 groups (1 Aspherical lens)

Mount Micro Four Thirds mount

Optical Image Stabilizer Yes

Focal Length f=14mm to 42mm (35mm camera equivalent 28mm to 84mm)

Aperture Type 7 diaphragm blades / Circular aperture diaphragm

Aperture F3.5(Wide) - F5.6(Tele)

Minimum Aperture F22

Closest Focusing Distance 0.3m / 1ft

Maximum magnification Approx. 0.16x / 0.32x (35mm camera equivalent)

Diagonal Angle of View 75°(W) - 29°(T)

General

Filter Size φ52mm / 2.05 in

Max. Diameter φ60.6mm / 2.39 in

Overall Length Approx. 63.6mm / 2.50 in (from the tip of the lens to the base side of the

lens mount)

Weight [g] Approx. 165g

Weight [oz] Approx. 5.82oz

Standard Accessories Lens Cap

Lens Hood

Lens Rear Cap

Lens Storage Bag

NOTE *1 Use a card with SD Speed Class with "Class6" or higher

*2 Use a card with SD Speed Class with "Class4" or higher

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic Lumix DMC-GF7K Especificaciones técnicas

Panasonic

Panasonic Lumix S1H Manual de usuario

Panasonic

Panasonic DMCFX33 - DIGITAL STILL CAMERA Manual de instrucciones

Panasonic

Panasonic DMCFH3 - DIGITAL STILL CAMERA Manual de usuario

Panasonic

Panasonic Lumix DMC-FX700 Manual de usuario

Panasonic

Panasonic Lumix DMC-ZS19 Manual de usuario

Panasonic

Panasonic DMC-FX550EB Manual de usuario

Panasonic

Panasonic Lumix DMC-FX78 Instrucciones de instalación y servicio

Panasonic

Panasonic PalmCam PV-SD4090 Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ5GN Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ60 Especificaciones técnicas

Panasonic

Panasonic lumix VQT0W41 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FX520 Manual de usuario

Panasonic

Panasonic LUMIX DMC-LF1 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FX150 Manual de usuario

Panasonic

Panasonic Lumix DMC-FX12 Manual de usuario

Panasonic

Panasonic Lumix DMC-LC20 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FS25 Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ330 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FT25 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-ZX3 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FZ18 Manual de usuario

Panasonic

Panasonic DMC-FX48K - Lumix Digital Camera Manual de instrucciones

Panasonic

Panasonic AW-UE80WP Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
