Basic Operating Instructions

Digital Camera

Model No. DMC-FH20

DMC-FH3

DMC-FH1

Before connecting, operating or adjusting this product,

please read the instructions completely.

Please also refer to Operating

Instructions (PDF format)

recorded on the CD-ROM

containing the Operating Instructions

(supplied).

You can learn about advanced operation methods

and check the Troubleshooting.

until

2010/1/30

For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,

VQT2K50

DMC-FH1&FH3&FH20-VQT2K50_eng.book 1 ページ２００９年１２月２２日　火曜日　午後５時８分

VQT2K50 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products on

the market today. Used properly, we’re sure it will bring you and your family

years of enjoyment. Please take time to fill in the information on the below.

The serial number is on the tag located on the underside of your Camera. Be

sure to retain this manual as your convenient Camera information source.

Please note that the actual controls and components, menu items, etc. of

your Digital Camera may look somewhat different from those shown in the

illustrations in these Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may be

restricted.

A lithium ion battery that is recyclable powers the product

you have purchased. Please call 1-800-8-BATTERY for

information on how to recycle this battery.

Model No.

Serial No.

DMC-FH1&FH3&FH20-VQT2K50_eng.book 2 ページ２００９年１２月１１日　金曜日　午後１時２８分

(ENG) VQT2K50

Information for Your Safety

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT

DAMAGE,

•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING

OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH

AS VASES, SHALL BE PLACED ON THE APPARATUS.

•USE ONLY THE RECOMMENDED ACCESSORIES.

•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE

EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

Product Identification Marking is located on the bottom of units.

DMC-FH3

DMC-FH1

DMC-FH20

DMC-FH1&FH3&FH20-VQT2K50_eng.book 3 ページ２００９年１２月１６日　水曜日　午後６時１２分

VQT2K50 (ENG)

FCC Note:

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:To assure continued compliance, follow the attached

installation instructions and use only shielded interface

cables with ferrite core when connecting to computer or

peripheral devices.

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this

equipment.

Declaration of Conformity

Trade Name: Panasonic

Model No.: DMC-FH20

DMC-FH3

DMC-FH1

Responsible party: Panasonic Corporation of North America One

Panasonic Way, Secaucus, NJ 07094

Support Contact: Panasonic Consumer Electronics Company

1-800-211-PANA (7262)

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

DMC-FH1&FH3&FH20-VQT2K50_eng.book 4 ページ２００９年１２月１６日　水曜日　午後６時１２分

(ENG) VQT2K50

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a

long period of time with doors and windows closed.

∫About the battery charger

CAUTION

Battery pack (Lithium ion battery pack)

•Use the specified unit to recharge the battery pack.

•Do not use the battery pack with equipment other than the specified unit.

•Do not get dirt, sand, liquids, or other foreign matter on the terminals.

•Do not touch the plug terminals (iand j) with metal objects.

•Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes,

wash it off thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub the

eyes. Rinse eyes thoroughly with water, and then consult a doctor.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dispose

of used batteries according to the manufacturer’s instructions.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC

(140 oF) or incinerate.

CAUTION!

DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN

CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT

IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK

OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT

CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE

VENTILATION VENTS.

DMC-FH1&FH3&FH20-VQT2K50_eng.book 5 ページ２００９年１２月１１日　金曜日　午後１時２８分

VQT2K50 (ENG)

∫Cautions for Use

•Always use a genuine Panasonic AC adaptor (DMW-AC5PP; optional).

•Do not use any other AV cables except the supplied one.

•Do not use any other USB connection cables except the supplied one.

Keep the camera as far away as possible from electromagnetic

equipment (such as microwave ovens, TVs, video games etc.).

•If you use the camera on top of or near a TV, the pictures and sound on the

camera may be disrupted by electromagnetic wave radiation.

•Do not use the camera near cell phones because doing so may result in noise

adversely affecting the pictures and sound.

•Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely

affect the camera, disturbing the pictures and sound.

•If the camera is adversely affected by electromagnetic equipment and stops

functioning properly, turn the camera off and remove the battery or disconnect

AC adaptor (DMW-AC5PP; optional). Then reinsert the battery or reconnect AC

adaptor and turn the camera on.

Do not use the camera near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures

and sound may be adversely affected.

Battery charger

This battery charger operates on AC between 110 V and 240 V.

But

•In the U.S.A. and Canada, the battery charger must be connected to a 120 V

AC power supply only.

•When connecting to an AC supply outside of the U.S.A. or Canada, use a

plug adaptor to suit the AC outlet configuration.

DMC-FH1&FH3&FH20-VQT2K50_eng.book 6 ページ２００９年１２月１１日　金曜日　午後１時２８分

(ENG) VQT2K50

-If you see this symbol-

Information on Disposal in other Countries outside

the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your

local authorities or dealer and ask for the correct

method of disposal.

DMC-FH1&FH3&FH20-VQT2K50_eng.book 7 ページ２００９年１２月１１日　金曜日　午後１時２８分

VQT2K50 (ENG)

Contents

Information for Your Safety ................................................................... 3

Standard Accessories........................................................................... 9

Names of the Components ................................................................. 10

Charging the Battery........................................................................... 12

About the Built-in Memory/the Card.................................................... 14

Inserting and Removing the Card (optional)/the Battery.....................15

Setting Date/Time (Clock Set)............................................................. 16

• Changing the clock setting............................................................ 16

Setting the Menu................................................................................. 17

Selecting the [REC] Mode................................................................... 18

Taking pictures using the automatic function

(ñ:Intelligent Auto Mode).................................................................. 19

• Scene detection ............................................................................ 20

Motion Picture Mode........................................................................... 21

Playing back Pictures ([NORMAL PLAY])........................................... 22

Deleting Pictures................................................................................. 22

Reading the Operating Instructions

(PDF format) ....................................................................................... 23

Specifications...................................................................................... 25

Digital Camera Accessory System...................................................... 28

Digital Camera Accessory Order Form............................................... 29

Limited Warranty

(ONLY FOR U.S.A. AND PUERTO RICO) ......................................... 30

∫About illustrations in these operating instructions

The procedure is described for DMC-FH1 as an example.

DMC-FH1&FH3&FH20-VQT2K50_engTOC.fm 8 ページ２００９年１２月１１日　金曜日　午後１時４２分

(ENG) VQT2K50

Standard Accessories

Check that all the accessories are included before using the camera.

Product numbers correct as of January 2010. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or

battery in the text)

Charge the battery before use.

2 Battery Charger

(Indicated as battery charger or

charger in the text)

3 USB Connection Cable

4AVCable

5 CD-ROM

•Software:

Use it to install the software to your

PC.

•Operating Instructions

6 Hand Strap

7 Battery Case

•SD Memory Card, SDHC Memory Card

and SDXC Memory Card are indicated

as card in the text.

•The card is optional.

You can record or play back pictures

on the built-in memory when you are

not using a card.

•For information about optional

accessories, refer to the “Digital

Camera Accessory System”.

•If any accessories are lost, customers

should contact Panasonic’s parts

department at 1 800 833-9626 for

further information about obtaining

replacement parts.

5 6

CGA-S/106B

K1HA08CD0027

VFC4297

DE-A59B

VFF0554

VGQ0D56

K1HA08AD0001

DMC-FH1&FH3&FH20-VQT2K50_eng.book 9 ページ２００９年１２月１１日　金曜日　午後１時２８分

VQT2K50 (ENG)

Names of the Components

1Flash

2 Lens

3 Self-timer indicator

AF assist lamp

4LCDmonitor

5 [MENU/SET] button

6 [DISPLAY] button

7 [Q.MENU]/Delete button

8 [MODE] button

9 [REC]/[PLAYBACK] selector switch

10 Cursor buttons

A: 3/Exposure compensation

B: 4/Macro Mode

C: 2/Self-timer button

D: 1/Flash setting button

In these operating instructions, the cursor buttons are described as shown

in the figure below or described with 3/4/2/1.

e.g.: When you press the 4(down) button

or Press 4

1 2 3

4109

DMC-FH1&FH3&FH20-VQT2K50_eng.book 10 ページ２００９年１２月１１日　金曜日　午後１時２８分

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic Lumix DMC-FX80 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FS3 Manual de instrucciones

Panasonic

Panasonic Lumix DMC-FH25 Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-LZ20E Manual de usuario

Panasonic

Panasonic Lumix DMC-FZ50 Manual de usuario

Panasonic

Panasonic Lumix DMC-GH2HPP Manual de usuario

Panasonic

Panasonic LUMIX S5IIX Manual de usuario

Panasonic

Panasonic Lumix DMC-FH22 Especificaciones técnicas

Panasonic

Panasonic DMC-GH3KBODY Manual de usuario

Panasonic

Panasonic DMCFS12 - DIGITAL STILL CAMERA Manual de instrucciones

Panasonic

Panasonic LUMIX DMC-FX60 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FP1 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-GX80 Manual de usuario

Panasonic

Panasonic Lumix DMC-LX5 Manual de usuario

Panasonic

Panasonic DC-S5M2 Instrucciones de montaje

Panasonic

Panasonic Lumix DMC-FS35 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FH27 Manual de usuario

Panasonic

Panasonic lumix DC-TZ90 Manual del propietario

Panasonic

Panasonic LUMIX DMC-FS12 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-FS11EB Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ40 Manual de instrucciones

Panasonic

Panasonic LUMIX DMC-FZ30EB Manual de usuario

Panasonic

Panasonic Lumix DMC-TS1 Manual de usuario

Panasonic

Panasonic HX-A500 Instrucciones de instalación y servicio

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
