Panasonic AW-RP50 Manual de usuario

★ AW-RP50 controller can control up to five AW-HE40 cameras via the serial connection.

1. Connection

Connect one of AW-RP50 “T PAN/TILT HEAD” ports [1] – [5] and AW-HE40 “RS-422” port using a LAN cable

(Category 5 or higher, Straight cable, Up to 1,000m).

2. Setting Up AW-RP50

Example: Connection to AW-RP50 “T PAN/TILT HEAD” port [1]

① Press MENU button. – (Fig.3-A)

② Press [10] SYSTEM button. – (Fig.3-B) * “[1] CAMERA CTL” will be displayed on the LCD Panel. – (Fig.4)

* If it is not displayed, turn F1 dial – (Fig.3-C) to make “[1] CAMERA CTL” appear.

③ While “[1] CAMERA CTL” is displayed on the LCD, press F1 dial.

* “[1] CAM1” will be displayed on the upper half, and the connection method (default: [NoAsign]) on the lower

half of the LCD Panel. – (Fig.4)

④ Turn F2 dial – (Fig.3-D) to select [Serial], and then press F2 dial to determine the setting.

<Note>

・ Camera numbers CAM1 – CAM5 correspond to “T PAN/TILT HEAD” ports [1] – [5] on the Rear Panel,

respectively.

For example, if “T PAN/TILT HEAD” port [5] is used for serial connection, set [1] CAMERA CTL > 5. CAM5

to [Serial].

③Press F1

(LAN Cable)

Controlling AW-HE40 with AW-RP50 (vi Seri l Connection)

(Figure 4: LCD Panel)

（A）

（B）

（C）

（D）

(Figure 3: AW-RP50 Control Panel)

(Figure 1: AW-RP50 Rear Panel) (Figure 2: AW-HE40 Rear Panel)

［1］CAMERA CTL

①MENU N => ②Select [10]

④Turn F2 to select

=> Press F2 to set

1．CAM1

NoAsign

1．CAM1

Seri l

・ The [Serial] setting for serial connection cannot be set for camera numbers CAM6 – CAM100.

3. Turning On AW-HE40

★ After the setting-up is completed, LED button 1 at AW-RP50 CAMERA STATUS / SELECTI N Area – (Fig.5) lights

up according to the camera’s power status. If the camera is in STANDBY mode (power FF: factory default), it

lights up in orange. If in P WER N mode (power N), it lights up in green.

★ When the camera is in STANBY mode, follow the procedure below to turn on the camera.

Example: Switching over to P WER N mode (power N) on AW-HE40 connected to CAM1

① Hold down LED button 1 at CAMERA STATUS/SELECTI N. – (Fig.6-A)

* While the button is held down, the selected camera and its power status will be displayed on the LCD Panel. –

(Fig.7)

② Keeping the button held down, turn F2 dial – (Fig.6-B) to select “ N”. Then press F2 dial to determine it.

* By this operation, AW-HE40 will be switched over to P WER N mode after its default setting motion.

(The status lamp will light up in green and the LED on AW-RP50 will also light up in green.)

* In P WER N mode, if you follow the same procedure and select [P WER: FF], AW-HE40 will be switched

over to STANBY mode.

CAM1＜AW-HE40 ＞

POWER

：

OFF

CAM1＜AW-HE40 ＞

POWER

：

“C

AM1”

is held down

Select “ N” => Press F2 to determine

Turn F2

After setting up, this lights up

according to the camera’s

power status.

* If it does not light up, please check the following points.

（A）

(Figure 6: AW-RP50 Control Panel)

(Figure 7: LCD Panel)

（B）

① Check the connection state of LAN cable or whether you are using a cable that meets the specifications.

② Check that the LAN cable is connected to “RS-422 port”, not to “LAN port”.

③ Double-check that there is no error in setting up the connection.

(Figure 5: AW-RP50 CAMERA STATUS/SELECTI N Area)
