Panasonic Projector RS-232C Control Specifications

PT-FW100NT/F100NT/F100

2/16

Using the Serial Terminals

1. Basic Format

Transmission from the computer begins with STX, then the command, parameter and ETX are sent in this

order. Add parameters according to the details of control.

Basic control command (without parameter)

Start

(STX)

Command End

(ETX)

1 byte 3 bytes 1 byte

Basic control command (with parameters)

Start

(STX)

Command Separator

(colon)

Parameters End

(ETX)

1 byte 3 bytes 1 byte Undefined length 1 byte

Response (Callback) of the basic control command

In the period when the command can be accepted

Differs according to each command.

In the period when commands cannot be accepted or the command does not exist

Hexadecimal 02h 45h 52h 34h 30h 31h 03h

Character E R 4 0 1

In case of the parameter error

Hexadecimal 02h 45h 52h 34h 30h 32h 03h

Character E R 4 0 2

Notes:

• When sending several commands, be sure to wait for a response from the projector, and send the next

command after 0.5 seconds or more pass.

• It might take time by the time the response returns because the command is processed in the projector.

Set the time-out to 10 seconds or longer.

3/16

2. Basic Control Command

Explanatory notes

Yes: Enable

No: Disable

2.1. Power ON (Lamp ON)

Hexadecimal 02h 50h 4Fh 4Eh 03h

Character P O N

Respone (Callback)

In the period when the command can be accepted (This command in power-on condition is included)

Hexadecimal 02h 50h 4Fh 4Eh 03h

Character P O N

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes Yes Yes Yes (Yes)

Note:

• When you confirm whether to have succeeded in power-on, confirm it by QPW (Query Power) command after

receiving the callback of PON command.

• When REMOTE is effective, ER401 is returned as a response (callback).

2.2. Power OFF (Standby)

Hexadecimal 02h 50h 4Fh 46h 03h

Character P O F

Response (Callback)

In the period when the command can be accepted (This command in power-off condition is included)

Hexadecimal 02h 50h 4Fh 46h 03h

Character P O F

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes Yes Yes Yes (Yes)

Notes:

• When you confirm whether to have succeeded in power-off, confirm it by QPW (Query Power) command after

receiving the callback of POF command.

• When REMOTE is effective, ER401 is returned as a response (callback).

2.3. AUTO SETUP

Hexadecimal 02h 4Fh 41h 53h 03h

Character O A S

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 41h 53h 03h

Character O A S

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Note:

• This command is acceptable only when RGB1 or RGB2 is selected and RGB PC signals are input. In other cases,

ER401 is returned.

2.4. SHUTTER key

Hexadecimal 02h 4Fh 53h 48h

3Ah

*1 03h

Character O S H : *2

Parameters (*1, *2)

Shutter OFF Shutter ON

Hexadecimal 30h 31h

Character 0 1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 48h 3Ah *1 03h

Character O S H : *2

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No Yes Yes Yes

4/16

2.5. FREEZE key

Hexadecimal 02h 4Fh 46h 5Ah

3Ah

*1 03h

Character O F Z : *2

Parameters (*1, *2)

Freeze OFF Freeze ON

Hexadecimal 30h 31h

Character 0 1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 46h 5Ah 3Ah *1 03h

Character O F Z : *2

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

2.6. Input Change

Hexadecimal 02h 49h 49h 53h 3Ah

*1 *3 *5 03h

Character I I S : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

COMPUTER 1 COMPUTER 2

Hexadecimal 52h 47h 31h 52h 47h 32h

Character R G 1 R G 2

VIDEO S-VIDEO

Hexadecimal 56h 49h 44h 53h 56h 44h

Character V I D S V D

COMPONENT NETWORK

Hexadecimal 59h 55h 56h 4Eh

57h 50h

Character Y U V N W P

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 49h 49h 53h 3Ah *1 *3 *5 03h

Character I I S : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No Yes Yes (Yes)

Notes:

• REMOTE is given to priority. Calls back ER402 if the input change by REMOTE is effective.

• Parameter NWP is available for FW100NT and F100NT only.

• STANDBY is valid when AUDIO IN STANDBY in EXT OPTION is “ON”.

2.7. MENU key

Hexadecimal 02h 4Fh 4Dh 4Eh 03h

Character O M N

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Dh 4Eh 03h

Character O M N

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

2.8. ENTER key

Hexadecimal 02h 4Fh 45h 4Eh 03h

Character O E N

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 45h 4Eh 03h

Character O E N

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

2.9. Up (K) key

Hexadecimal 02h 4Fh 43h 55h 03h

Character O C U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 55h 03h

Character O C U

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

5/16

2.10. Down () key

Hexadecimal 02h 4Fh 43h 44h 03h

Character O C D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 44h 03h

Character O C D

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

2.11. Left (I) key

Hexadecimal 02h 4Fh 43h 4Ch 03h

Character O C L

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 4Ch 03h

Character O C L

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

2.12. Right (J) key

Hexadecimal 02h 4Fh 43h 52h 03h

Character O C R

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 52h 03h

Character O C R

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes No Yes

2.13. DEFAULT key

Hexadecimal 02h 4Fh 53h 54h 03h

Character O S T

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 54h 03h

Character O S T

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No Yes No Yes

2.14. Volume + key

Hexadecimal 02h 41h 55h 55h 03h

Character A U U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 41h 55h 55h 03h

Character A U U

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• STANDBY is valid when AUDIO IN STANDBY in EXT OPTION is “ON”.

2.15. Volume −key

Hexadecimal 02h 41h 55h 44h 03h

Character A U D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 41h 55h 44h 03h

Character A U D

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• STANDBY is valid when AUDIO IN STANDBY in EXT OPTION is “ON”.

6/16

2.16. INDEX WINDOW key

Hexadecimal 02h 4Fh 49h 58h 03h

Character O I X

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 49h 58h 03h

Character O I X

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• It is invalid during SIDE BY SIDE with the PT-FW100NT.

2.17. DIGITAL ZOOM + key

Hexadecimal 02h 44h 5Ah 55h 03h

Character D Z U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 44h 5Ah 55h 03h

Character D Z U

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• It is invalid during SIDE BY SIDE with the PT-FW100NT.

2.18. DIGITAL ZOOM −key

Hexadecimal 02h 44h 5Ah 44h 03h

Character D Z D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 44h 5Ah 44h 03h

Character D Z D

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• It is invalid during SIDE BY SIDE with the PT-FW100NT.

2.19. Picture Mode

Hexadecimal 02h 56h 50h 4Dh

3Ah

*1 *3 *5 03h

Character V P M : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

DYNAMIC NATURAL STANDARD BLACKBOARD

Hexadecimal 44h 59h 4Eh 4Eh

41h

54h

53h

54h

44h 42h 42h

44h

Character D Y N N A T S T D B B D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 50h 4Dh 3Ah *1 *3 *5 03h

Character V P M : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

7/16

2.20. Audio Volume Level

Hexadecimal 02h 41h 56h 4Ch

3Ah

*1 *3 *5 03h

Character A V L : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

0 1 2

Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h

Character 0 0 0 0 0 1 0 0 2

61 62 63

Hexadecimal 30h 36h 31h 30h 36h 32h 30h 36h 33h

Character 0 6 1 0 6 2 0 6 3

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 41h 56h 4Ch 3Ah *1 *3 *5 03h

Character A V L : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No No No No Yes

Notes:

• STANDBY is valid when AUDIO IN STANDBY in EXT OPTION is “ON”.

2.21. Set Date

Hexadecimal 02h 54h 53h 44h

3Ah

*y1 *y2 *y3

Character T S D :

Hexadecimal *y4 *m1 *m2 *d1 *D2

*w 03h

Character

Parameters

*y1 - *y4: Year (4 digits)

*m1, *m2: Month (2 digits)

*d1, *d2: Day (2 digits)

*w: Day of the week (Mon = 1, Tue = 2, Wed = 3, Thu = 4, Fri = 5, Sat = 6, Sun = 7)

Set it by UTC (Coordinated Universal Time).

Example: Thursday, June 29, 2006

*y1 *y2 *y3 *y4 *m1 *m2 *d1 *D2 *w

Hexadecimal 32h 30h 30h 36h 30h 36h 32h 39h 34h

Character 2 0 0 6 0 6 2 9 4

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 54h 53h 44h 3Ah *y1 *y2 *y3

Character T S D :

Hexadecimal *y4 *m1 *m2 *d1 *d2 *w 03h

Character

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No Yes Yes Yes Yes

2.22. Set Time

Hexadecimal 02h 54h 53h 54h

3Ah

*h1

Character T S T :

Hexadecimal *h2 *m1 *m2 *s1 *s2 03h

Character

Parameters

*h1, *h2: Hour (2 digits)

*m1, *m2: Minute (2 digits)

*s1, *s2: Second (2 digits)

Set it by UTC (Coordinated Universal Time).

Example: 3 seconds at 3:45 p.m.

*h1 *h2 *m1 *m2 *s1 *s2

Hexadecimal 31h 35h 34h 35h 30h 33h

Character 1 5 4 5 0 3

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 54h 53h 54h 3Ah *h1

Character T S T :

Hexadecimal *h2 *m1 *m2 *s1 *s2 03h

Character

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

No Yes Yes Yes Yes

2.23. Query Power

Hexadecimal 02h 51h 50h 57h

03h

8/16

Character Q P W

Response (Callback)

OFF

Hexadecimal 02h 30h 30h 31h 03h

Character 0 0 0

Hexadecimal 02h 30h 30h 31h 03h

Character 0 0 1

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes Yes Yes Yes Yes

2.24. Query Lamp Status

Hexadecimal 02h 51h 24h 53h

03h

Character Q $ S

Response (Callback)

Lamp OFF

Hexadecimal 02h 30h 03h

Character 0

In turning ON

Hexadecimal 02h 31h 03h

Character 1

Lamp ON

Hexadecimal 02h 32h 03h

Character 2

In turning OFF

Hexadecimal 02h 33h 03h

Character 3

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes Yes Yes Yes Yes

2.25. Query Input Change

Hexadecimal 02h 51h 49h 4Eh

03h

Character Q I N

Response (Callback)

COMPUTER 1

Hexadecimal 02h 52h 47h 31h 03h

Character R G 1

COMPUTER 2

Hexadecimal 02h 52h 47h 32h 03h

Character R G 2

VIDEO

Hexadecimal 02h 56h 49h 44h 03h

Character V I D

S-VIDEO

Hexadecimal 02h 53h 56h 44h 03h

Character S V D

COMPONENT

Hexadecimal 02h 59h 55h 56h 03h

Character Y U V

NETWORK

Hexadecimal 02h 4Eh 57h 50h 03h

Character N W P

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes Yes Yes

9/16

2.26. Query Audio Volume Level

Hexadecimal 02h 51h 41h 56h

03h

Character Q A V

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No Yes Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

0 1 2

Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h

Character 0 0 0 0 0 1 0 0 2

61 62 63

Hexadecimal 30h 36h 31h 30h 36h 32h 30h 36h 33h

Character 0 6 1 0 6 2 0 6 3

2.27. Query Color

Hexadecimal 02h 51h 56h 43h

03h

Character Q V C

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−32 −31 −30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

2.28. Query Tint

Hexadecimal 02h 51h 56h 54h

03h

Character Q V T

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−32 −31 −30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

2.29. Query Brightness

Hexadecimal 02h 51h 56h 42h

03h

Character Q V B

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−32 −31 −30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

10/16

2.30. Query Contrast

Hexadecimal 02h 51h 56h 52h

03h

Character Q V R

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−32 −31 −30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

2.31. Query Sharpness

Hexadecimal 02h 51h 56h 53h

03h

Character Q V S

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−08 −07 −06

Hexadecimal 2Dh 30h 38h 2Dh

30h 37h 2Dh

30h 36h

Character −0 8 −0 7 −0 6

13 14 015

Hexadecimal 30h 31h 33h 30h 31h 34h 30h 31h 35h

Character 0 1 3 0 1 4 0 1 5

2.32. Query White Balance - R

Hexadecimal 02h 51h 57h 52h

03h

Character Q W R

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

-32 -31 -30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

2.33. Query White Balance - G

Hexadecimal 02h 51h 57h 47h

03h

Character Q W G

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h *1 *3 *5 03h

Character *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

SHUTTER

REMOTE

Yes No No Yes Yes

Parameters (*1, *2, *3, *4, *5, *6)

−32 −31 −30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character −3 2 −3 1 −3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

Otros manuales para PT-F100

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de Panasonic

Panasonic

Panasonic FP7 Series Manual de usuario

Panasonic

Panasonic CZ-256ESMC2 Manual de usuario

Panasonic

Panasonic FP7 Series Manual de usuario

Panasonic

Panasonic CZ-256ESMC1U Manual de usuario

Panasonic

Panasonic AKHRP900P - CAMERA CONTROLLER HC Manual de usuario

Panasonic

Panasonic AAD03011 Manual de usuario

Panasonic

Panasonic DPC-L100 Series Manual de usuario

Panasonic

Panasonic FP7 Series Manual de usuario

Panasonic

Panasonic FP3 Manual de usuario

Panasonic

Panasonic AK-HRP1015 Manual de uso y cuidado

Panasonic

Panasonic WVCU950 - CONTROLLER - ADDENDUM Manual de usuario

Panasonic

Panasonic WVCU550C - SYSTEM CONTROLLER UNIT Manual de usuario

Panasonic

Panasonic FP E Series Manual de usuario

Panasonic

Panasonic MINAS S-series Manual de usuario

Panasonic

Panasonic CZ-256ESMC2 Manual de usuario

Panasonic

Panasonic FP0R Series Manual de usuario

Panasonic

Panasonic FP-I4C Manual de usuario

Panasonic

Panasonic FP7 Series Manual de usuario

Panasonic

Panasonic FP0H Series Manual de usuario

Panasonic

Panasonic CZ-TACG1 Manual de usuario

Panasonic

Panasonic AWRP605 - CCU & PAN/TILT CONTR Manual de usuario

Panasonic

Panasonic FP0 RTD Unit Manual de usuario

Panasonic

Panasonic AW-RP605AN Manual de usuario

Panasonic

Panasonic FP Web-Server2 Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

3M MicroTouch EX113 Manual de usuario

KUHN

KUHN TKS Manual de usuario
