Before operating this machine, please carefully read this manual

and keep this documentation in a safe place for future reference.

(Illustration shows optional accessories that may not be installed on your machine.) English

Operating Instructions

Digital Colour Imaging Systems

(For Scanner and Email)

Model No. DP-C406 / C306 / C266

Operating Instructions

The following Operating Instruction manuals are included with this machine. Please refer to the appropriate manual and

keep all manuals in a safe place for future reference. If you lose the manual, contact the authorised Panasonic dealer.

Accessories

Quick Reference Guide

Describes the basic procedures for each function, and

introduces various settings for Copy function.

Operating Instructions (For Basic)

Describes the overview of this machine.

For a detailed explanation of functions, please refer to

the Operating Instruction manuals included on two CD-

ROMs as illustrated below.

Operating Instructions CD

Contains manuals with detailed information for

Administrator Setup, User Setup, Copy, Facsimile/

Internet Fax, Scan/Email, Print functions, Function

Parameters, User Authentication, and Maintenance.

Document Management System CD

Contains the Panasonic Document Management

System Application software, and manuals for the

Panasonic Document Management System Application

software.

Operating Instructions CD

Setup Guide For Administrator

Describes how to set up the machine.

Setup Guide For User

Describes how to install the printer driver

and application software to client PC.

Copy Function

Describes how to make a Colour Copy

with creative features.

Facsimile and Internet Fax

Function

(The Facsimile function is available when

the optional G3 Fax Communication

Board is installed.)

Describes how to send/receive a

Facsimile/Internet Fax, and describes the

course of action to take when a trouble

message appears, etc.

Scan and Email Function

Describes how to scan and how to send

Email through the machine.

Print Function

Describes how to print using the Control

Panel of the machine.

Function Parameters

Describes how to change the default

settings of each function using the Control

Panel of the machine.

User Authentication

Describes how to enable and use the

User Authentication function.

Maintenance Guide

Describes how to maintain the machine,

and the course of action to take when a

problem message appears.

Document Management System CD

Application Software

Describes how to use the application

software.

Ex: Printer Driver, Fax Driver, Quick

Image Navigator, Device Monitor/

Device Explorer, Network

Configuration and Address Book

Editor

Conventions

Icons

The following icons are used in this manual.

Notation

The following notations are used in this manual.

Icon Description

Indicates important information that must be read in detail.

Indicates reference information.

Notation Description

For Keys and Buttons Hard buttons on the Control Panel are depicted as **** key, and soft buttons on the Touch

Panel Display are depicted as “xxx”.

Ex:

Press the Start key and select “More Menus”.

Table of Contents

Chapter 1 Getting To Know Your Machine

Placing Originals.................................................................................................................. 6

How to Place Originals.................................................................................................... 6

Basic Operation Procedure ................................................................................................. 9

Sending an Email ................................................................................................................11

Chapter 2 Scan/Email Operations

Scan to the SD Memory Card..............................................................................“SD Card”13

Scan to the USB Flash Memory ..................................................................“USB Memory”16

Scan to the Internal Hard Disk Drive ................................................................................... 19

Retrieving Scanned Image from Hard Disk Drive ........................................................... 21

Scan to a Computer............................................................................................................. 22

Scan to Email .......................................................................................................... “Email”24

Searching LDAP Server for Email Address........................................................“Global”27

Adding an Email Address to the Address Book ...................................... “Add to Local”30

Sending an Email with Image File Attachment.............................................. “Attachment”32

Attaching an Image File from the SD Memory Card .......................................“SD Card”32

Attaching an Image File from the USB Flash Memory ............................“USB Memory”36

Attaching an Image File from the Internal Hard Disk Drive ............................................. 40

Receiving an Email..............................................................................................................43

Configuring to Receive Email.......................................................................................... 43

Receiving Email Automatically ........................................................................................ 43

Receiving Email Manually ............................................................................ “Get Email”44

Chapter 3 Scanner Settings

Setting the Scanning Quality ......................................................................... “Basic Menu”45

Quality Adjustment .......................................................................................................... 46

Setting Original Type and Scanning Density....................................................................... 47

Selecting Original Type ................................................................................................... 47

Adjusting Scanning Density ............................................................................................ 47

Scanning Resolution............................................................................................................ 48

Advanced Colour Quality Settings................................................................. “Adjustment”49

Compression (Full Colour) ...............................................“Compression (Full Colour)”49

Compression (Grey Scale).................................................“Compression (Greyscale)”51

Compression (Black)................................................................. “Compression (Black)”52

Background Removal ...............................................................“Background Removal”53

Bleed-Through Prevention................................................“Bleed-Through Prevention”54

Contrast.......................................................................................................... “Contrast”55

Sharpness .................................................................................................. “Sharpness”56

Setting the File Type and/or File Name ........................................... “File Type and Name”57

Scanning Special Originals.................................................................................................. 59

Scanning 2-Sided Originals ............................................................. “2-Sided Originals”59

Scanning Special Originals (Thin Paper, etc.) from ADF ........... “Job Build and SDAF”62

Chapter 4 Adding to the Address Book

Adding an Email Address to Address Book......................................................................... 64

Editing the Address Book .................................................................................................... 66

Editing an Email Address ................................................................................................ 66

Deleting an Email Address .............................................................................................. 68

Editing Image Box Name ..................................................................................................... 69

Chapter 5 Appendix

Specifications....................................................................................................................... 71

Chapter 1 Getting To Know Your Machine

1Getting To Know Your Machine

Placing Originals

How to Place Originals

On the ADF

Acceptable Paper Type

Notice for ADF

Do not use the following type / flawed originals.

• Drawing papers, Transparencies, Labeling paper, Heavy weight papers, Thin Art papers, Film,

Thermal papers.

• Papers which are curled, ripped, creased, folded, punched, glued, stapled, or self-adhesive.

• Pressure sensitive or carbon backed papers.

• Paper which is still wet with colour ink or white-out.

Original Size: A3, B4, A4, A4-R, A5, A5-R, FLS1, FLS2

Paper Weight: 1 sided : 50-105 g/m2

2 sided : 64-105 g/m2

Face up. Up to 100 sheets

(80 g/m2/ A4)

Originals can be set up to the

Upper Limit Indicator.

Original Guides

Adjust the Original

Guides to the original’s

width.

Upper Guide Upper Limit Indicator

Chapter 1 Getting To Know Your Machine

On the Platen Glass

Ex: Book Original

Ex: Sheet Original

Face down.

Align with top left corner.

Face down.

Align with top left corner.

Chapter 1 Getting To Know Your Machine

Notice for Platen Glass

Align the original to the top left corner mark ( ).

• If the original is not positioned properly, a portion of the

original may not be scanned.

• For originals smaller than A5 size, position the original

within the A5 area and select A5.

Original Orientation

Ex: A5

Scanning a thick booklet

• After scanning a thick booklet, open the ADF and verify that the ADF Hinge was returned to original

position in order to prevent the rear of the ADF from being raised.

• When scanning with the ADF open, do not look directly at the exposure lamp.

Direct eye exposure can cause eye fatigue or eye injury.

• When scanning a thick original, do not use excessive force to press it against the Platen Glass.

The Glass may break and cause injuries.

For Portrait Orientation

Original Guides

For Landscape Orientation

Original Guides

A4A5R

A4R

A5 A5R

CAUTION

Chapter 1 Getting To Know Your Machine

Basic Operation Procedure

This section describes the workflow of Scan/Email operations. For the detailed description of each

setup item involved, refer to the relevant suggested section.

Place original(s).

zWhen using the Scan/Email function, the

created images are rotated by 90 degrees.

Place originals with their top edges aligned

with the left side of the scanner to create

upright scan data.

zRefer to Placing Originals (See page 6).

Press the Scan/Email key.

Select “Basic Menu”, and then set the

desired scanning mode if necessary.

zFor more detailed instructions, refer to

Scanner Settings (See pages 45 to 63).

zWhen addresses are selected, the

“Addresses:###” button turns yellow (###:

the number of selected addresses).

Face up.

Up to 100 sheets (80 g/m2/ A4)

Face down. Align with top left corner.

Close the ADF.

ABC

Original. Scan Data.

Chapter 1 Getting To Know Your Machine

Select the location or destination.

Scan to SD Memory Card/USB Flash

Memory/Internal Hard Disk Drive

zThe scanned image(s) cannot be saved to

the SD Memory Card or USB Flash Memory

if the setting of Function Parameter “70 SD/

USB Memory Function” (General Settings

> Key Operator Mode) is set to “No”.

For more details on this setting, refer to

General Settings in the Operating

Instructions (For Function Parameters) of

provided CD-ROM.

zThe scanned image(s) cannot be saved to

the internal Hard Disk Drive if the setting of

Function Parameter “02 Scan to HD

Function” (Scanner Settings > Key

Operator Mode) is set to “No”.

For more details on this setting, refer to

Scanner Settings in the Operating

Instructions (For Function Parameters) of

provided CD-ROM.

Transfer Scanned Image to:

Press the Start key.

zWhen scanning from the Platen Glass, place

the next original, and then follow the

instructions described on the Touch Panel

Display.

The scanned image(s) is transferred to the SD

Memory Card, USB Flash Memory, PC, or

Email.

zWhen cancelling the operation, press the Stop key

on the Control Panel, and then follow the

instructions described on the Touch Panel Display.

SD Memory

Card or USB

Flash Memory

Select “SD Card / Hard Drive”,

and then select “SD Card” or

“USB Flash Memory”.

zRefer to Scan to the SD

Memory Card (see page 13).

zRefer to Scan to the USB

Flash Memory (see page

16).

Internal Hard

Disk Drive

Select “SD Card / Hard Drive”,

and then select an Image Box.

zRefer to Scan to the Internal

Hard Disk Drive (see page

19).

Scan to a

Computer

When a desired destination is

selected from the Address

Book, a reception notice

appears on the destination.

zRefer to Scan to a Computer

(see page 22).

Scan to Email Select “Email”, and then select

the desired destination.

zRefer to Scan to Email (see

page 24).

Otros manuales para DP-C406

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Panasonic

Panasonic

Panasonic KX-MB2010FR Manual de usuario

Panasonic

Panasonic DP-MB251CX Manual de usuario

Panasonic

Panasonic KX-FLB811 - FLAT BED FAX Manual de lista de piezas

Panasonic

Panasonic KX-FLB882CX Manual de usuario

Panasonic

Panasonic DP-180 Manual de usuario

Panasonic

Panasonic Workio DP-3030 Manual de usuario

Panasonic

Panasonic Workio DP-C401 Manual de usuario

Panasonic

Panasonic WORKIO DP-C106 Manual del operador

Panasonic

Panasonic KX-PS8000 Manual de usuario

Panasonic

Panasonic Workio DP-C262 Manual de usuario

Panasonic

Panasonic Workio DP-2310 Manual de usuario

Panasonic

Panasonic Workio DP-8016P Manual de usuario

Panasonic

Panasonic KX-MB2010BL Manual de funcionamiento

Panasonic

Panasonic DP-MB310 Manual de usuario

Panasonic

Panasonic KX-MB778TW Manual de usuario

Panasonic

Panasonic DP-2330 Manual de usuario

Panasonic

Panasonic Workio DP-C262 Manual de instrucciones y seguridad

Panasonic

Panasonic Workio DP-C305 Manual de usuario

Panasonic

Panasonic DP-80116P Manual de usuario

Panasonic

Panasonic DP-8020E Manual de usuario

Panasonic

Panasonic FP-D355 Manual de usuario

Panasonic

Panasonic Workio DP-C262 Manual de usuario

Panasonic

Panasonic KX-PS8000 Manual de usuario

Panasonic

Panasonic Workio DP-C262 Manual de usuario

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
