oticon RITE Manual de usuario
INSTRUCTIONS FOR USE RITE
Thank you
Thank you for choosing our product as your means to better hearing. To support your
eorts, we have put great care and attention into making sure that your new hearing
instrument is of the highest quality and is easy to use and maintain.
We recommend that you read this manual carefully to achieve the full benet of your new
hearing instrument.
To meet your needs, various functions may be congured to your hearing instrument.
The actual conguration of your instrument is marked (ticked o) by your Hearing
Care Professional in relevant sections of this manual. Also see last page for a complete
overview of all functions congured to your hearing instrument(s).
The hearing instrument amplication is uniquely adjusted and optimised to your personal
hearing capabilities by the prescription performed by your Hearing Care Professional.
If you have any questions on the use or maintenance of the hearing instrument, please
contact your Hearing Care Professional.
Indications for Use
The hearing instrument is intended to amplify and transmit sound to the ear and thereby
compensate for mild to severe hearing loss.
Instrument view RITE with speaker type “60” 7a
Instrument view RITE with speaker type “85” 7b
Instrument view RITE with speaker type ”100” 7c
Instrument view RITE with Power mould 7d
Warnings 9
Activating the hearing instrument for the rst time 15
Replacing the battery 16
Turning your instrument ON and OFF 18
Left/Right ear marking 19
Putting on your instrument 20
Push-button 21
Programs (optional) 23
Volume control (optional) 26
Mute (optional) 27
Tamper-resistant battery door (optional) 28
Telecoil (optional) 31
Continues on next page
IMPORTANT NOTICE
Please familiarise yourself with the entire content of this booklet before using your
hearing instrument. It contains instructions and important information about the use
and handling of your hearing instrument and batteries.
CAUTION
The RITE Power is a powerful hearing instrument. If you are tted with RITE Power,
you should never allow others to wear your hearing instrument as incorrect usage
could cause permanent damage to their hearing.
Contents
7a
Instrument view RITE with speaker type “60”
Autophone (optional) 32
DAI direct audio input (optional accessory) 34
FM (optional accessory) 36
Audible and visual indicator summary table 38
Caring for your hearing instrument 40
Cleaning the instrument 42
Maintenance with mould 44
Maintenance with dome 46
Avoiding heat and chemicals 49
Water resistance 50
Eight easy steps to better hearing 52
Common problems and their solutions 58
Wireless accessories 60
International warranty 62
Warranty certicate 63
Mobile phone 64
Technical information 66
Settings overview for your hearing instrument 7
Speaker
Microphone openings
Push-button
LED indicator
Battery door
Sound outlet
Wax protection
Your ear piece
Micro mould
LiteTip (mould)
Domes:
Type Size
Open 6 mm
Power 8 mm
Bass, single vent 10 mm
Bass, double vent 12 mm
Battery size: 312
7b
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, particularly overnight.
Instrument view RITE with speaker type “85”
Speaker
Microphone openings
Battery doorSound outlet
Wax protection
Your ear piece
Micro mould
LiteTip (mould)
Domes:
Type Size
Open 6 mm
Power 8 mm
Bass, single vent 10 mm
Bass, double vent 12 mm
Battery size: 312
Push-button
LED indicator
7c
Instrument view RITE with speaker type ”100”
Power
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, particularly overnight.
Microphone openings
Your ear piece
Domes:
Type Size
Power 6 mm
Bass, single vent 8 mm
Bass, double vent 10 mm
12 mm
Speaker
Battery door
Sound outlet
Wax protection
Battery size: 312
Push-button
LED indicator
7d
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, particularly overnight.
Sound outlet
+ wax protection system
Ventilations openings Battery door
Microphone openings
Customised
mould
Instrument view RITE with Power mould
Battery size: 312
Push-button
LED indicator
9
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, particularly overnight.
You should familiarise yourself fully with the following general warnings and the entire
content of this booklet before using your hearing instrument.
Usage of hearing instruments
• Hearing instruments should be used only as directed and adjusted by your Hearing Care
Professional. Misuse can result in sudden and permanent hearing loss.
• Never allow others to wear your hearing instrument as incorrect usage could cause
permanent damage to their hearing.
Choking hazards
• Hearing instruments, their parts, and batteries are not toys and should be kept out of
reach of children and anyone who might swallow these items or otherwise cause injury
to themselves.
• Never replace the battery or adjust the controls of the hearing instrument in front of
infants, small children or people with learning diculties.
• Discard batteries carefully in a place where infants, small children or people with
learning diculties cannot reach them.
Warnings
10 11
• Batteries have occasionally been mistaken for pills. Therefore check your medicine
carefully before swallowing any pills.
• Never put your hearing instrument or batteries in your mouth for any reason, as they
are slippery and could be swallowed by accident.
• Most hearing instruments can be supplied with a tamper-resistant battery
compartment upon request. This is strongly recommended for infants, small children,
and people with learning diculties.
If a battery or hearing instrument is swallowed, see a doctor immediately.
Battery use
• Always use batteries recommended by your Hearing Care Professional. Batteries of low
quality may leak and cause bodily harm.
• Never attempt to recharge your batteries. They may explode and cause serious injury.
• Never dispose of batteries by burning them. There is a risk that they will explode and
cause serious injury.
Dysfunction in hearing instruments
• Hearing instruments may stop functioning, for instance if the batteries have expired or
if the speaker is blocked by moisture or ear wax. You should be aware of this possibility,
in particular when you are in trac or otherwise dependent on warning sounds.
Active implants
Caution must be shown with active implants. General advice is to follow the guideline as
recommended by manufacturers of implantable debrillators and pacemakers regarding
use with mobile phones:
• If you wear an active implant, then keep the hearing instrument more than 15 cm away
from the implant e.g. do not carry them in a breast pocket.
• If you have an active brain implant, please contact the manufacturer of your
implantable device for information about the risk of disturbance.
Warnings Warnings
12 13
• The included case for instrument storage may have a built-in magnet. If so, and you
have an implantable device, such as pacemakers or debrillators, the instrument case
should not be carried in a chest pocket or near to the chest.
If you are in doubt of details of your instrument case, contact your Hearing Care
Professional.
• The MultiTool has a built-in magnet. If you have an implantable device, such as
pacemakers or debrillators, the MultiTool should not be carried in a breast pocket or
near the chest.
Explosives
• The power source in your hearing instrument has insucient energy to cause re in
normal conditions of use. The hearing instrument has not been tested for compliance
with international standards concerning explosive atmospheres. It is recommended not
to use your hearing instrument in areas where there is a danger of explosions.
X-ray, CT, MR, PET scanning and electrotherapy
• Remove your hearing instrument for example during X-ray, CT / MR / PET scanning
electrotherapy or surgery as your hearing instrument may be damaged when exposed
to strong elds.
Power instrument
• Special care should be exercised in selecting, tting and using a hearing instrument
where maximum sound pressure capability exceeds 132 dB SPL (IEC 711), as there may
be risk of impairing the remaining hearing of the hearing instrument user.
Possible side eects
• Hearing instruments, moulds or domes may cause an accelerated accumulation of ear
wax.
• The otherwise non-allergenic materials used in hearing instruments may in rare cases
cause a skin irritation or any other unusual condition.
Please seek consultation with a physician if these conditions occur.
Warnings Warnings
