Oster FPSTSM5101 Manual de usuario

User Manual

Manual de Instrucciones

Stand Mixer

Batidora

MODELS/

MODELOS

FPSTSM5101

FPSTSM5102

Visit us at www.oster.com

P.N. 135787 Rev. E

DO NOT

RETURN

this product to place of

purchase. Questions?

Visit www.oster.com

No vuelva este producto

a lugar de compra.

¿Preguntas? Visita

www.oster.com

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USE

1. To protect against risk of electrical shock, do not put mixer in water or

other liquid. This may cause personal injury or damage to the product.

2. Close supervision is necessary when mixer is used by or near children or

incapacitated persons.

3. Unplug from outlet while not in use, before putting on or taking off

parts, and before cleaning.

4. Avoid contacting moving parts. Keep hands, hair, clothing, as well as

spatulas and other utensils away from beaters during operation to reduce

the risk of injury to persons and/or damage to the mixer.

5. To disconnect, turn off all controls and remove plug from outlet.

6. Do not operate mixer with a damaged cord or plug or after the appliance

malfunctions, or is dropped or damaged in any manner. If the mixer

becomes damaged please contact Consumer Services for assistance.

7. Do not use extension cord.

8. The use of attachments not recommended or sold by Jarden Consumer

Solutions may cause fire, electrical shock or injury.

9. Do not use outdoors or for commercial purposes.

10. Do not let cord hang over edge of table or countertop or touch hot

surfaces, including the stove.

11. Remove beaters from mixer before washing.

12. Do not place mixer or bowls on or near a hot gas or electric burner, in a

heated oven (microwave, convention, convection, etc.), or on any other

heated surface.

13. Do not use mixer for other than intended use.

14. Do not leave mixer unattended while it is operating.

English-2

English-3

15. Mixer has an internal safety to prevent overheating. If the mixer shuts

down because of overheating, reset the speed control dial to OFF and

unplug unit from wall. Wait 1 minute and plug back in. Do not plug unit

back in unless speed selection is set to OFF.

16. Any servicing, other than cleaning and user maintenance shall be

performed by an authorized service representative.

17. When mixing liquids, especially hot liquid, use a tall container or make

small quantities at a time to reduce spillage.

18. Don’t Abuse Cord. Never carry the mixer by the cord or yank it to

disconnect from an outlet; instead, grasp the plug and pull to disconnect.

SAFETY

Th I S UN I T ISF O R hO U S E h O l D US E ON l y

The motor of your Mixer is protected by a heat cured insulation. This is a

standard process. Due to the heat curing of the insulation, you may

experience an odor and possibly a slight wisp of smoke from your mixer’s

motor. This effect will disappear after the first few uses.

SPECIAL INSTRUCTIONS

FO R PR O D U c T S PU R c h A S E D IN T h E U.S. A N D cA N A D A ON l y

To reduce the risk of electrical shock, this appliance is equipped with a

3-prong plug. If you are unable to insert the plug into the outlet, contact a

qualified electrician to replace the obsolete outlet. Do not attempt to defeat

the safety purpose of the 3-prong plug by modifying it in any way. Also, do

not pull, twist or otherwise abuse the power cord; instead, grasp the plug and

pull to remove from the outlet.

SAVE ThESE INSTRUcTIONS

Welcome

Congratulations on your purchase of a Oster®Stand Mixer! To learn

more about Oster®products, please visit us at www.oster.com.

English-4

A. Attachment Eject Button – The eject button, located on the top of

the handle, releases the beaters or dough hooks for easy cleaning.

B. Variable Bowl Speed – The bowl speed increases and decreases

automatically as the beater speed is increased and decreased.

C. Off-Center Head and Beaters – The head of the Stand Mixer and

beaters are positioned off-center to the bowl to make it easier to

add ingredients during mixing.

D. Tilt Back Locking Head – The head of the Stand Mixer tilts back

and locks securely into position to allow easy removal of mixing

bowls and attachments.

Fe at u r e s o F Yo u r st a n d Mi x e r

English-5

E. Turntable – The bowl of the stand mixer ﬁts onto the turntable and

must be positioned correctly for the mixer to function properly. See

page 7 for “Positioning the Turntable”

F. Chrome Steel Dough Hooks – Heavy-duty dough hooks take the

hard work out of kneading dough and other heavy mixtures.

G. Chrome Beaters – Heavy-duty beaters

for creaming butter and sugar, plus mixing heavy cake mixes.

H. Durable Whisks – make whipping and aerating foods an ease.

(On select models only.)

I. 12-Speed Control Dial – The combination of 12-speeds and a

powerful torque control motor in the mixer head ensures superior

mixing control and maintains speed regardless of the mixing load.

J. Polished Stainless Steel Mixing Bowl – 4.6 quart mixing bowl

is ideal for all your mixing needs.

K. Die-Cast Metal Body – The heavy-duty, die-cast metal body

combined with non-slip rubber feet keep the Stand Mixer stable

during operation.

at ta c h M e n t s

FG H

Ons e l e c t m O d e l s O n l y

English-6

Fe at u r e s o F Yo u r st a n d Mi x e r (c o n t .)

Pr e Pa r i n g t h e st a n d Mi x e r F o r us e

Before preparing the mixer for use, be sure the speed control dial is in

the OFF position and the electric cord is unplugged. Be sure to wash

bowls and attachments before initial use.

Po s i t i o n t h e tu r n ta b l e

Position the turntable by ﬁtting

the prongs into the right hole

with Large Bowl Icon. (Not

Center Hole) (See Figure 1).

Note: For Stand Mixer to

operate properly, Turntable

must be in the correct position.

raising a n d lo w e r i n g t h e Mixing he a d

Press the tilt release button, located at the top of the neck of the

Stand Mixer. While the button is depressed, hold the handle (1)

and ease the head of the Stand Mixer back. The head will lock into

this tilt position (2).

To lower the mixing

head, press the tilt

release button. While

the button is depressed,

hold the handle (2) and

ease the head of the

Stand Mixer down (1).

A “click” sound will

indicate when the mixer

head has locked into

position. (See Figure 2)

Figure 2

la r g e BO w l

PO s i t i O n HO l e

st a n d

mi x e r Ba s e

tu r n t a B l e

Figure 1

in s t a l l i n g t h e at ta c h M e n t s

Beaters, Dough Hooks, and Whisks

(on select models)

Select the pair of attachments best suited

for your mixing job. (See Mixing Guide for

recommendations). Take the attachment that

has a green colored band around the top –

illustrated as attachment (A).

Insert attachment (A) into the socket on the

side of the mixer nearest the side of the bowl.

The socket is identiﬁed by a green dot beside it.

Take the other attachment that has a gray

colored band around the top – illustrated as

attachment (B). Insert attachment (B) into the

socket nearest the center of the bowl.

(See Figure 3)

NO T E :Be sure both attachments click ﬁrmly

in place. You may need to twist the beater

attachment slightly to engage it in position

prior to pushing it in place.

English-7

Figure 3

cO n e

Be at e r

sq u a r e

Be at e r

English-8

Pr e Pa r a t i o n

ad d i n g t h e Mixing bo w l

Place the mixing bowl onto the turntable.

NO T E :Mixing bowls should NEVER be

used in a conventional oven, microwave

oven, on top of the range or on any other

heated surface.

Beaters must sit against the inside

of the bowl.

oP e r at i n g in s t r u c t i o n s

ab o u t t h e sP e e d co n t r o l di a l

The speed control dial is used for turning the mixer ON and OFF and

for selecting its 12 mixing speeds. (See Figure 4)

Rotate the speed control dial in a clockwise direction to increase mixing

speed, and in a counterclockwise direction to decrease mixing speed.

Rotate the speed control dial until the indicator is aligned with the

indicator line for the desired speed.

hI N T :During normal operation,

the mixer may automatically adjust

speeds as the consistency changes

of your dough or mixture: This is

for optimum performance. It is not

recommended to operate the mixer

without contents in the bowl.

Figure 4

sP e e d

cO n t r O l

di a l

English-9

Mixing gu i d e

Please keep in mind that the various mixing tasks and related speeds listed

in the following table may vary slightly from recipe to recipe.

For most recipes, it is better to begin your mixing on a slower speed until

the ingredients begin combining, then move to the appropriate speed range

for the particular task.

When mixing larger quantities you may need to increase the Stand Mixer

speed due to the amount of mixing required and the larger load on the

machine.

When building up a recipe that requires the addition of dry ingredients,

such as ﬂour, slow the speed down while these ingredients are being added

to avoid a snow storm effect. Once the extra ingredients begin combining,

slowly increase to the appropriate speed for the particular mixing task.

Sp e e d

Se t t i n g Ra n g e Mi x i n g ta S k

Re c o M M e n d e d

ac c e S S o R y

LOW

1-3

FOLDING & KNEADING

Folding

Kneading- Doughs

(pastry, bread, scones, etc.)

Standard Beaters

Dough Hooks

MEDIUM

4-6

LIGHT MIXING

Kneading- Heavy Doughs

(large quantities)

Beating- Packaged Mixes

Beating- creaming sugar and butter

Standard Beaters

Dough Hooks

HIGH

7-9

CREAMING & BEATING

Whisking- Light Batters

Beating- Cake Mixes, Heavy Batters,

Icings, etc.

Standard Beaters

Whisks

VERY HIGH

10-12

WHIPPING & AERATING

Whisking- Egg Whites, Cream, etc.

Standard Beaters

Whisks

English-10

ca r i n g Fo r Yo u r Mi x e r

cl e a n i n g Yo u r Mi x e r

To clean the mixer, turn off and unplug from outlet, wipe the mixer

head, stand and turntable with a damp cloth, then dry. DO NOT

IMMERSE THE STAND MIXER IN WATER. Avoid the use of

abrasive cleaners, as they may damage the ﬁnish of the mixer. Wash the

beaters and bowls in hot, soapy water after each use. Rinse thoroughly

and dry. Beaters and bowls may also be washed in an automatic

dishwasher.

st o r i n g Yo u r Mi x e r

Store the mixer in a dry location, such as on a countertop or table top, or

in a closet or cupboard. Insert the beaters into the proper sockets. Place

the dough hooks and other attachments in the mixing bowl. Store the

bowl(s) on the turntable. Wind the electric cord into a coil, then secure it

with a twist fastener.

Ma i n t e n a n c e

The motor of your stand mixer has been carefully lubricated at the

factory and does not require any additional lubricant. Other than

the recommended cleaning, no further user maintenance should be

necessary.

For servicing or repairs please contact Consumer Services for assistance.

(1-800-334-0759 in the U.S. or 1-800-667-8623 in Canada)

Otros manuales para FPSTSM5101

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Mezclador de Oster

Oster

Oster Planetary Stand Mixer Manual de usuario

Oster

Oster 2600 SERIES Manual de usuario

Oster

Oster 2612 Manual de usuario

Oster

Oster FPSTHB6600 Manual de usuario

Oster

Oster FPSTSMPL4W Manual de usuario

Oster

Oster FPSTHS2612W Manual de usuario

Oster

Oster FPSTSM3711 Manual de usuario

Oster

Oster 2612 Manual de usuario

Oster

Oster MIXMASTER 2700 Manual de usuario

Oster

Oster 2610-049 Manual de usuario

Oster

Oster 2610 Manual de usuario

Oster

Oster BLSTPB220 Manual de usuario

Oster

Oster 2381 Guía del producto

Oster

Oster 6627 Manual de usuario

Oster

Oster 2604 Manual de usuario

Oster

Oster FPSTHS3610 Manual de usuario

Oster

Oster FPSTSMPL1 Manual de usuario

Oster

Oster FPSTSMPL2 Manual de usuario

Oster

Oster MCPR06-WSO-049 Manual de usuario

Oster

Oster MGSTSL7500-449 Manual de usuario

Oster

Oster Kitchen Center Manual de usuario

Oster

Oster FPSTSM2710 Manual de usuario

Oster

Oster MGSTSL7500-449 Manual de usuario

Oster

Oster MGSTSL5010-449 Manual de usuario

Manuales populares de Mezclador de otras marcas

Bosch

Bosch GRW 9 Manual de usuario

MULTIQUIP

MULTIQUIP Whiteman WM45E Guía

KitchenAid

KitchenAid KSM7581BZ0 Guía rápida

Jay-Lor

Jay-Lor 5050 Manual de usuario

Sunbeam

Sunbeam FPSBSM210X Manual de usuario

MULTIQUIP

MULTIQUIP Whiteman MC94S Guía

Thinky

Thinky ARE-250 Manual de usuario

Midas

Midas XL4 Manual de usuario

bianco

bianco PURO 4 Manual de usuario

Paso

Paso DAG9200 Manual de usuario

Sima

Sima SFX-9A Manual de usuario

better chef

better chef IM-815WC Instrucciones de instalación

ALLEN & HEATH

ALLEN & HEATH GR1 Manual de usuario

Lacor

Lacor 69083 Hoja de especificaciones

M-Audio

M-Audio Midiman SAM Manual de usuario

Buffalo

Buffalo CP921 Manual de usuario

Pentair

Pentair HYPRO Cleanload 3376-0870 Instrucciones de operación

Cuisinart

Cuisinart SM50WHE Manual de usuario
