OSS EB16-Basic Manual de usuario

ExpressBox 16 - Basic

16-Slot Gen 2 PCI Express Expansion System

EB16-Basic User’s Manual

SKU: EB16-BX4 / EB16-BX8

www.onestopsystems.com

One Stop Systems

ExpressBox 16 Basic| 2

Table of Contents

Preface 5

Advisories 5

Safety Instructions 7

1Introduction 9

1.1 General Specifications 9

1.2 Basic Features 9

1.3 Specifications 10

1.4 Basic Main Components 11

1.5 Pre-Installation 12

1.6 Parts List 12

1.7 Tools Required for Installation 14

2Hardware Installation 15

2.1 Guidelines for Installation 15

2.2 Open Enclosure 16

2.3 Remove Card Holder Assembly 16

2.4 Install PCIe Cards 16

2.5 Install Host Card 19

2.5.1 x8 Interface Card 20

2.5.2 x16 Interface Card 20

2.5.3 Which slot to plug in the host card 21

2.5.4 Host mode Dipswitch Setting 22

2.5.5 Expansion mode Dipswitch Setting 23

2.6 Connect Cables 24

2.6.1 Connecting x16 Cable 24

2.6.2 Connecting x8 Cable 24

2.7 Connect Power Cables 25

2.8 Power ON Expansion chassis 25

2.9 Power ON Computer 27

2.10 Hardware Verification 27

3Software - Verify Installation 28

3.1 Windows 28

3.2 Mac OS 30

3.2.1 Expansion Slot Utility 30

3.2.2 Apple System Profiler 30

3.3 Linux 31

3.4 System Should Be Up and Running 32

4Other Technical Information 33

One Stop Systems

ExpressBox 16 Basic| 3

4.1 PCIe slot Power 33

4.2 Redundant Power Supply Option 34

4.3 Interface Cards 35

4.3.1 x16 Interface Card LEDs 35

4.3.2 x16 Card Bandwidth / Lane Settings 36

4.3.3 x8 Interface Card LEDs and Lane Settings 37

4.4 Backplane 38

4.5 Backplane Block Diagram 39

4.6 Backplane FAQs 40

4.7 Backplane Dipswitches 41

4.8 Backplane Power Supply Connectors 43

4.8.1 Backplane Aux Power Connectors 43

4.8.2 Fan Connectors & Power / LED Connectors 43

4.9 Auxiliary Power Cables 44

4.9.1 Aux Cable Installation 44

4.10 Backplane LEDs 46

4.10.1 Power Management Backplane 46

4.10.2 Backplane Power Indicator 46

4.10.3 Activity Indicator 46

5Chassis Maintenance 48

5.1 Chassis Cleaning 48

5.2 Fan Replacement 50

5.3 Power Supply Replacement 51

6Troubleshooting 53

6.1 Locate the Problem 53

6.1.1 Windows 53

6.1.2 MacOS 53

6.2 Computer Hangs During Start Up 53

6.3 Computer Doesn’t Detect the Expansion System 54

6.4 Add-in PCIe card not recognized 55

6.5 Support for 3rd Party PCIe cards 56

6.5.1 Windows Error Codes 56

6.6 Computer Hangs after Many Card Installed 57

6.7 Nothing Works 57

7How to Get More Help 58

7.1 Contacting Technical Support 58

7.2 Returning Merchandise 58

7.3 Online Support Resources 58

8Appendix A Compliance 59

8.1 FCC 59

One Stop Systems

ExpressBox 16 Basic| 4

8.2 Industry Canada 59

8.3 CE 59

8.4 ISO 9001:2008 59

8.5 RoHS 59

8.6 WEEE 59

One Stop Systems

ExpressBox 16 Basic| 5

Preface

Advisories

Five types of advisories are used throughout this manual to provide helpful information, or to alert you to the potential for hardware damage

or personal injury.

NOTE

Used to amplify or explain a comment related to procedural steps or text.

IMPORTANT

Used to indicate an important piece of information or special “tip” to help you

CAUTION

Used to indicate and prevent the following procedure or step from causing damage to the equipment.

WARNING

Used to indicate and prevent the following step from causing injury.

DANGER or STOP

Used to indicate and prevent the following step from causing serious injury or significant data loss

COMPATIBILITY ISSUE

Used to indicate a known or potential compatibility issue between OSS and non-OSS hardware that may

cause malfunction.

One Stop Systems

ExpressBox 16 Basic| 6

Disclaimer: We have attempted to identify most situations that may pose a danger, warning, or caution condition in this manual. However, OSS

does not claim to have covered all situations that might require the use of a Caution, Warning, or Danger indicator.

One Stop Systems

ExpressBox 16 Basic| 7

Safety Instructions

Always use caution when servicing any electrical component. Before handling the OSS Expansion chassis, read the following instructions and

safety guidelines to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section for advisory

conventions used in this manual, including the distinction between Danger, Warning, Caution, Important, and Note.

Always use caution when handling/operating the computer. Only qualified, experienced, authorized electronics personnel should

access the interior of the computer and expansion chassis per UL and IEC 60950-1

The power supplies produce high voltages and energy hazards, which can cause bodily harm.

Use extreme caution when installing or removing components. Refer to the installation instructions in this manual for precautions

and procedures. If you have any questions, please contact OSS Technical Support.

WARNING

Never modify or remove the radio frequency interference shielding from your workstation or expansion unit. To do so may

cause your installation to produce emissions that could interfere with other electronic equipment in the area of your

system.

When Working Inside a Computer

1. Before taking covers off a computer, perform the following steps:

2. Turn off the computer and any peripheral devices.

3. Disconnect the computer and peripheral power cords from their AC outlets or inlets in order to prevent electric shock or system

board damage.

In addition, take note of these safety guidelines when appropriate:

To help avoid possible damage to systems boards, wait five seconds after turning off the computer before removing a component,

removing a system board, or disconnecting a peripheral device from the computer.

When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable itself. Some cables have a connector

with locking tabs. If you are disconnecting this type of cable, press in on the locking tabs before disconnecting the cable. As you pull

connectors apart, keep them evenly aligned to avoid bending any connector pins. Also, before connecting a cable, make sure both

connectors are correctly oriented and aligned.

CAUTION

Do not attempt to service the system yourself except as explained in this manual. Follow installation instructions closely.

Protecting Against Electrostatic Discharge

Electrostatic Discharge (ESD) Warning

Electrostatic Discharge (ESD) is the enemy of semiconductor devices. You should always take precautions to eliminate any

electrostatic charge from your body and clothing before touching any semiconductor device or card by using an

electrostatic wrist strap and/or rubber mat.

One Stop Systems

ExpressBox 16 Basic| 8

Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedures to reduce the risk of

damage to components. OSS strongly encourages you to follow proper ESD procedures, which can include wrist straps and smocks, when

servicing equipment.

You can also take the following steps to prevent damage from electrostatic discharge (ESD):

When unpacking a static-sensitive component from its shipping carton, do not remove the component’s anti-static packaging

material until you are ready to install the component in a computer. Just before unwrapping the anti-static packaging, be sure you

are at an ESD workstation or are grounded.

When transporting a sensitive component, first place it in an anti-static container or packaging.

Handle all sensitive components at an ESD workstation. If possible, use anti-static floor pads and workbench pads.

Handle components and boards with care. Do not touch the components or contacts on a board. Hold a board by its edges or by its

metal mounting bracket.

One Stop Systems

ExpressBox 16 Basic| 9

1Introduction

1.1 General Specifications

OSS ExpressBox 16 Basic is a 16-Slot PCI Express® Expansion System. The expansion system consists of a PCIe® host interface card, an iPass

cable, a 4U rack-mount chassis containing a 16 Slot backplane and an expansion interface card, a standard or redundant power supply, and high

volume cooling fans.

ExpressBox 16 Basic

A choice of two backplane configurations:

EB16-BX4: provides (16) x4 PCIe Gen 2 slots

EB16-BX8: provides (2) x16 PCIe Gen 2 slots and (14) x8 PCIe

Gen 2 slots.

EB16 BASIC

Sixteen PCIe slots

Card Retainers

4 Cooling Fans (Replaceable)

Expansion Backplane

1 Power Supply Module

1 Expansion Interface Card

No Netburner

Single Power Switch

No LED Locator & Reset Button

1iPass Connectors to Host

16 Card slots

2 Thumb Screws

Two Front Handles

Front Power Button (On & OFF)

No Front LED Indicators

1 Link Cable

1 Host Interface card

No Express IO Manager / WEB GUI

1.2 Basic Features

Easy “Plug and Play” installation

PCI Express Gen 2 x16 or x8 interconnection

All slots support full-length cards

Status LEDs on backplane indicate active link, speed (Gen 1 or Gen 2), partial or complete lane training

Automatic power-up control by computer

Four hot-swappable cooling fans

Multiple power supply options with auxiliary power connectors to support cards requiring more than 75 Watts

Industrial 4U rack-mount enclosure

Card retainers keep cards in place and are adjustable to fit any size card

Chassis provides superior EMI control, vibration, shock and moisture resistance

One Stop Systems

ExpressBox 16 Basic| 10

1.3 Specifications

Item

Description

Technology

PCI Express Bus Specification Revision 2.0

PCI Local Bus Specification Revision 2.3

PCI Bridge Architecture Revision 1.2

Backplane

EB16-BX4 - 16 slots x4 PCIe

EB16-BX8 - 14 slots x8 PCIe and 2 slots x16 PCIe

Interface Cards

Low Profile

PCIe x8 Gen 2

Dimensions: 2.70”H x 4.70” L x 0.62”W

Power Consumption: 1.2A @ +3.3V (3.96 watts)

PCIe x16 Gen 2

Dimensions: 2.75” H x 6.95” L x 0.75”W

Power Consumption: 1.5A @ +3.3V (5 watts)

Interconnect Bandwidth

40Gbps (x8 Link)

80Gbps (x16 Link)

Interface Card

Power Consumption

x8 PCIe: 1.2A @ +3.3V (3.96 watts)

x16 PCIe: 1.5A @ +3.3V (5 watts)

Enclosure

4U Rack-mount

19”W x, 7”H x 20”D

Removable/cleanable air filter

34 lbs / 15.5 Kg

System Cooling

(4) 77 CFM Fans - Hot Swappable

Power Supply Options

850 Watt, 1700 Watt or 850 Watt Redundant (Optional)

100-240 VAC, 47-63 Hz Power Input

12V @ 60Amps

3.3V @ 33 Amps

Environmental

Ambient Temperature 0° to 50° C

Storage Temperature -55° to 125° C

Relative Humidity 0% to 90% non-condensing

MTBF

850W standard power supply - 185,600 hours

1700W dual standard power supply - 106,600 hours

850W redundant power supply - 720,000 hours (Optional)

Regulatory Compliance

FCC Class A Verified

RoHS Compliant

Supported Operating Systems

Windows

MacOS

Linux

Warranty

30 day money back guarantee

1 year return to factory
