Oregon Scientific RM806 Manual de usuario

RADIOCONTROLLED

CLOCK WITH HigloTM

BACKLIGHT

MODELNO.:RM806

USER’SMANUAL

www.oregonscientific.com

SNOOZE

ON/OFF ZONE

R A D I O C O N T R O L L E D

MODE

SET

24h OFF

MODEL NO. RM806

RESET

Dear RM806- Radio Controlled

Travel Alarm Clock Owner:

Congratulations on your purchase OREGON SCIENTIFIC’s radio controlled

auto-setting always-accurate alarm clock! The RM806 is a clock that automatically

sets the time and date from signals broadcast by the US Atomic Clock, one of the

world's most accurate timekeepers. This extraordinary timepiece, located outside

Boulder, Colorado, is operated by the U.S. Department of Commerce’s National

Institute of Standards and Technology. Your RM806 Clock automatically activates

its receiver immediately upon battery insertion and then six times every 24 hours

and make any necessary adjustments in its time display. The clock not only sets

itself to synchronize its digital time and date with the atomic clock’s signals, but

it also automatically adjusts for daylightsavings time!

Features

• Automatic setting of clock by radio signal from the US Atomic Clock

• Time display with Hour, Minutes, Seconds and Date

• Day of the week displayed in one of three languages (English, French or

Spanish)

• Dramatic blue HiGloTM electroluminescent backlight

• Alarm with eight-minute snooze

• Crescendo Alarm increases in volume and intensity

• Signal Reception Strength indicator

• U.S. Map icon shows user selected time zone

• Automatic adjustment for Daylight Savings time

• Low Battery indicator

Description of Function keys (Figure A)

Snooze/light (Figure A.1)

Pressing the bar on the top of The Radio Controlled Clock activates the HiGloTM

electroluminescent backlight for 5 seconds. When the alarm sounds, pressing this

Snooze/Light bar also activates the eight-minute snooze function.

+AdvanceKey(Figure A.2)

This key is used for manually setting the time, alarm time or calendar functions.

Please refer to the Manual Setting instructions in these instructions for further

information.

NOTE: Pressing once advance the setting by increments of 1: holding the

button down for more the three seconds will accelerate the setting to rapid

advance mode.

WARNING: The key also is used to reactivate the signal reception process

should it become disable. Please see the Trouble Shooting section for further

information.

ZONE(Figure A.3)

The Radio Controlled Clock is designed to automatically adjust the time signal to

the user selected North American time zone – Pacific, Mountain, Central or East-

ern. Pressing the ZONE button once advances the time zone setting (see US map

figure A.9). Once the desired time zone block is highlighted on the map, the time

will automatically adjust accordingly.

WARNING: Do not press and hold the ZONE button for more than three seconds.

Use the single press method to set the time zone. Holding the button will turn off

the automatic time signal reception. Please see the Trouble Shooting section for

further information.

[]ON/OFF(Figure A.4)

This button turns the alarm function on and off. Touching the button one time will

either turn the alarm on or off. Please refer to the Alarm Setting instructions for

furtherinformation.

NOTE: When setting the alarm time, the alarm is automatically turned on. If the

bell icon [ ] is visible, the alarm is “on”.

Touching the ON/OFF button one time will either turn the Alarm function on or

off.

If you want to stop the daily alarm white leaving the pre-set time for the follow-

ing day’s wake-up, press the ((•)) ALARM button. Pressing the ON/OFF button

to stop the wake up alarm will deactivate the alarm function.

MODE(FigureA.5)

Press the MODE key once to switch between the display of either the Day of the

Week or Seconds on the clock. Radio Controlled Clock will continue to display

the selected function (Day or Seconds) until the MODE button is pressed again.

IMPORTANT: Holding the MODE key for more than three seconds turns on the

manual mode for setting the time, date, year and language (English/French/

Spanish). Please refer to this section for specific setting instructions.

((•)) ALARM(FigureA.6)

Press the ((•)) ALARM key once to show the alarm time.

The ((•)) icon is displayed in the lower left portion of the screen to alert you that

the display is showing the time. To return to the month and date display, press the

((•)) ALARM key once. To set the alarms please refer to the section on setting the

Alarm.

NOTE: The Radio Controlled Clock will continue to display the selected function

(Alarm Time or Date) until the ((•)) ALARM button is pressed again.

Signal Strength Indicator – Figure A.7

Meaning

Your last signal reception was excellent and time Syn-

chronization with the US Atomic Clock has taken

place.

Your last signal reception was insufficient and it is

recommended that you reposition the clock.

The displayed time has been manually set and is not

synchronized by the RF signal.

Your radio reception is disabled and no signal

reception will be initiated unless it is enabled again.

Time Display (Figure A.8)

The top line of the display shows the hours, minutes and seconds (AM/PM) of the

clock. Pressing the MODE button once will switch the “Seconds” display to the

Day of the Week. The Radio controlled Clock will continue to display the selected

function (Day or Seconds) until the MODE button is pressed again.

USMAP (FigureA.9)

This map represents the four optional time-zone setting. The darkened of filled

zone block indicates the user selected time zone. NOTE: When the radio

controlled Clock is receiving a signal from the US Atomic Clock; outline of this

map will flash.

Month/Date(FigureA.10)

The Second line of the display shows the Month and the Date. Pressing the ((•))

ALARM button once will switch the “month and date” to show the “alarm time”.

The Alarm time is displayed in hours and minutes (AM/PM). NOTE: The Radio

controlled Clock will continue to display the selected function (Month/Date or

Indicators

ontheDisplay

No Indicator

Alarm Time) Until the ((•)) ALARM button is pressed again.

((•)) Alarm Display indicator (Figure A.11)

This ((•)) icon indicates the second line of the display is showing Alarm Time.

[] Alarm “ON” Indicator (Figure A.12)

This Bell [ ] icon indicates that the alarm function is activated.

[BATT] Low Battery Indicator (Figure A.13)

This [BATT] icon indicates that it is time to change batteries. Please refer to the

Battery Replacement Section of this manual.

Reset Button(Figure A.14)

To clear all user-selected settings and to cause the settings to default to their

original values, press RESET with a blunt stylus. The reset button is located

under the battery compartment door.

BATTERYINSTALLATION

Your Radio Controlled Clock is shipped with two AAA batteries. These batteries

should last for approximately one year depending on the amount of your use of the

HiGloTM backlight. Open the battery compartment, door and remove the two pro-

tective plastic strips from the batteries and slide the battery compartment door

back into place.

Radio Controlled Clock:

The RM806 will automatically synchronize current time and date with the signal

broadcast by the US Atomic Clock when the product is in reception range of the

signal.

When the unit is new and just out of the box, synchronization with the U.S. atomic

clock can take upto 72 hours. The unit will receive the most dependable and

interference free signal automatically between Midnight and 4 AM.

When the unit is receiving radio signal, the reception icon will start to blink. The

reception icon will show either strong, weak or no signal depending on the

strength of the radio signal. A complete reception generally takes about 2 to 5

minutes.

When the reception is completed the reception icon will stop blinking. The

reception icon will show [ ]for no Reception or [ ]for successfulreception. For

best signal reception, place the RM806 away from other equipment that emit RF or

microwave signals such as TV's, radios, PC's or microwave ovens. Other causes for

signal interference include electrical power transmission towers, steel reinfoced

concrete construction, and/or metal siding.

You may need to reposition the clock for maximum reception.

Radio Frequency appliances and radios, such as the Radio Controlled Alarm Clock,

perform best when placed near a window.

After receiving the initial signal, updates are accomplished with greater ease. Even

though there are areas that may have more difficulty in receiving a signal, the

RM806Alarm Clock containsvery accurate quartzmovementand willretainprecise

time even if a signal is missed on a rare occasion.

SETTINGTHEALARM

1) Press and hold the ((•)) 24h OFF button for at least three seconds. The

“Hour” Segment of the alarm time will begin Flashing.

2) While the “Hour” segment is flashing press the [+] button to set the desired

hour time (please note the AM/PM designation).

Strong

Weak

No signal

Receiving

3) When the desired hour time is reached, press the ((•)) 24h OFF button

again.

4) The “Minutes” segment of the alarm time will begin flashing.

5) While the “Minutes” segment is flashing press the [+] button to set the

desired minute time.

6) When the desired minute time is reached press the ((•)) 24h OFF button

again to exit the alarm time set mode.

NOTE: As soon as any change in the alarm time is made the alarm icon ((•)) will

automatically appear indicating that the alarm is activated.

IMPORTANT: The Radio Controlled Clock will continue to display the “ALARM”

time until the ((•)) 24h OFF button is pressed once to return to the “Month/

Date” display.

TURNINGTHEALARM ONorOFF

To turnthe alarmon oroff simply press the ON/OFF key in any mode. When the

ON/OFF button is pressed once the alarm is activated (the bell icon [ ] will

appearon thedisplay). Thealarm isdeactivated whenthe ON/OFF button is pressed

once and the bell icon [ ] disappears from the display.

When the crescendo alarm sounds, it may be turned off using one of the following

methods.

1) If the SNOOZE/LIGHT key is pressed within two minutes the Snooze is ac-

tivated and the alarm will sound again in 8 minutes.

2) If the ((•)) 24h OFF key is pressed, the alarm will not sound again until the

next day.

3) If the ON/OFF key is pressed, the alarm is deactivated and will not

sound again until it is activated.

IMFORTANT: If none of the above actions are taken, the alarm will automatically

snooze once, sound again in 8 minutes, and will not sound again until the next day.

MANUALLYSETTING:TIME,YEAR,MONTH,

DATE&LANGUAGE

NOTE: It is highly unlikely you should ever have the desire (or need) to manually

set the clock time, year, month or date of the Radio Controlled Clock. However,

in the event this becomes necessary please review the following.

Setting the Time

1) Press and hold MODE button for at least three seconds. The “Hour” segment

of the time will begin flashing.

2) While the “Hour” segment is flashing press the [+] button to set the desired

hour time is reached hour time (Please note the AM/PM designation).

3) When the desired hour time is reached press the MODE button again. The

“Minutes” segment of the clock time begin flashing.

4) While the “Minuted” segment is flashing press the [+] button to set the de-

sired minutes time.

5) When the desired minutes time is reached, briefly press the MODE button five

more times to exit the clock time set mode.

IMPORTANT : As soon as any manual change in the clock time is mode, there is

a loss of the signal strength indicator from the display.

NOTE : The next successful reception of a radio signal will override all manual

settings.

Settingthe YearMonthand Date

1) Press and hold MODE button for at least three seconds. The “Hour” segment

of the clock time will begin flashing.

2) Briefly press the MODE button and the “Minutes” segment will begin flashing.

3) Briefly press the MODE button once more. The clock time will disappear and

be replaced by a flashing year (Ex. 1995). This is the year set mode.

4) While the “Year” segment is flashing press the [+] button to set the desired

year.

5) When the desired year is reached briefly press the MODE button and the

"Month" digit will start flashing.

6) Press [ + ] button until the desired month appears on the display.

7) Press the Mode button to confirm the "month" and the "date" digits will flash

8) Press [+ ] until the desired date appears on the display.

9) Press Mode button to confirm the "Date" and the Language display will flash".

10)Press [+ ] button until the desired language indicator appears on the display

(“E” for English, “F” for French and “S” for Spanish).

11)Press MODE button one moretime toexit theset modeand resumenormal time

keeping.

TROUBLESHOOTING

Problem Remedy

No Display • Check battery compartment.

• Confirm that batteries are of good quality, and are

installed correctly

• Be certain the plastic protective tabs have been re-

moved.

• If the units are new and just out of the box ,allow60-

72 hours cycle for the clock to automatically seek a

signal between midnight and 4 a.m.

• May be caused by too much interference. Relocate

the clock or the antenna to position near a window.

• Becertain theantenna cordis fullyextended andlook

for low battery indicator.

• May be caused by interference.

• If the problem persists, move the clock or antenna to

a new location. The ExactSetTM is equipped with a

high quality clock mechanism, which insures accu-

racy between signals.

Other • Call Oregon Scientific at 800-853-8883 or through

Problem the internet at [email protected]

Loss of

signal

Did not

receive A

time signal

Tabla de contenidos

Otros manuales de Reloj de Oregon Scientific

Oregon Scientific

Oregon Scientific TR119 Manual de usuario

Oregon Scientific

Oregon Scientific RM932 Manual de usuario

Oregon Scientific

Oregon Scientific BAR332ES Manual de usuario

Oregon Scientific

Oregon Scientific DP100 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA G RRM222PA Manual de usuario

Oregon Scientific

Oregon Scientific RRM320P Manual de usuario

Oregon Scientific

Oregon Scientific Slim Projection Clock RA368P Manual de usuario

Oregon Scientific

Oregon Scientific CIR100 Manual de usuario

Oregon Scientific

Oregon Scientific WL388 Manual de usuario

Oregon Scientific

Oregon Scientific BAR339P Manual de usuario

Oregon Scientific

Oregon Scientific DP100 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA B Manual de usuario

Oregon Scientific

Oregon Scientific RM998PS Manual de usuario

Oregon Scientific

Oregon Scientific IWA-80055 Manual de usuario

Oregon Scientific

Oregon Scientific RM313PA Manual de usuario

Oregon Scientific

Oregon Scientific RM913TCN Manual de usuario

Oregon Scientific

Oregon Scientific RM822 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA G RRM222P Instrucciones de instalación

Oregon Scientific

Oregon Scientific RM308P Manual de usuario

Oregon Scientific

Oregon Scientific BC100U Manual de usuario

Oregon Scientific

Oregon Scientific BAR339P Manual de usuario

Oregon Scientific

Oregon Scientific JM828CD Manual de usuario

Oregon Scientific

Oregon Scientific RM329P Manual de usuario

Oregon Scientific

Oregon Scientific JM889N Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

La Crosse Technology

La Crosse Technology WS-8256-AL Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

La Crosse Technology

La Crosse Technology WT-3141b Manual

La Crosse Technology

La Crosse Technology W86531 Manual de usuario

Sharp

Sharp SPC900 Manual de usuario

La Crosse Technology

La Crosse Technology 404-50447 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario
