Optronis CamPerform CP80-25-M Manual de usuario

CamPerform

CP80-25-M/C-72

CoaxPress Camera

User Manual

Ref. 1889-SU-01-D

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 1

Contents

Revision 3

General 4

Declaration of conformity 4

RoHS compliance 4

Scope of delivery 5

Optronis customer service 5

Remark, Attention 6

Precautions 6

Camera Power 6

Environmental Conditions 6

General Precautions 7

Camera 8

Electrical Interface 9

Auxiliary (Aux.) connector pinout 9

Camera Power 11

Indicator Lamp (LED) 12

CoaxPress Data Channels 12

Lens mount and handling 13

Nikon F-Mount adapter 13

C-Mount adapter 15

Important features 15

Frame format 15

Minimum Frame rate (@ internal synchronisation) 15

Maximum Frame rate (@ internal synchronisation) 15

Max. Frame Rate Examples: 17

Calculation of Exposure Time 17

Frame Rate (@ external synchronisation) 18

Technical Data 19

General 19

Spectral Response / Transmittance 20

Mechanical Dimensions 21

F-Mount Lens (/CM) 21

Synchronisation Input schematics 23

Synchronisation Output schematics 23

Internal Synchronisation Timing 24

Synchronisation Output 24

External Synchronisation Timing 25

Synchronisation Input “level detection” 25

Synchronisation Output “level detection” 25

Focal Length Calculation 26

Full Sensor Resolution 26

Reduced Sensor Resolution 26

Distance Washer 27

Camera firmware update 29

Camera mapping 31

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 2

Gen<i>Cam 36

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 3

Revision

Cameramodel Date Description

CP80-25-M/C-72

SNr. 1889-ST-xxx 30.04.2013 Firmware 6.01

CP80-25-M/C-72

SNr. 1889-ST-xxx 23.05.2013 Firmware 6.02

Gain = 1,39; Offset < 10

CP80-25-M/C-72

SNr. 1889-ST-xxx 11.11.2013 Firmware 8.0

- Add offset and gain calibration menu in xml file

- Add 'Rolling shutter' mode in the xml file

-Add of 'Granularity' mode which allows to set

exposure time through register when using external

synchronisation of trigger over CoaxPress

CP80-25-M/C-72

SNr. 1889-ST-xxx 28.11.2013 Firmware 8.1

- Add flash configuration in xml file (see

FlashSaveWithAutoStart,

FlashSaveWithoutAutoStart, DisableFlashLoad)

- Add Pixel Format saving in the flash configuration

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 4

General

Declaration of conformity

Manufacturer: Optronis GmbH

Address: Ludwigstr. 2, 77694 Kehl, Germany

We certify and declare under our sole responsibility that the

following apparatus

Product: CP80-25-M-72

CP80-25-C-72

conform with the essential requirements of the EMC Directive

2004/108/EC, based on the following specifications applied:

Specifications: EN 61000-6-3 Emission

EN 61000-6-1 Immunity

Kehl, 23.05.2013

Optronis GmbH

Dr. Patrick Summ

Managing Director

RoHS compliance

CamPerform CP80-25-M/C-72 cameras are Pb free manufactured.

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 5

Scope of delivery

CP80-25-M/C-72 CoaxPress camera

Options: /C: Color sensor (Bayer Pattern)

(IR Cutoff Filter, Specification: 1830-SS-10)

/M: Monochrome sensor

Lens mount: /CM: CMount

/FM: FMount

/FMG: FMount for Nikon G-Lens series

CoaxPress: up to 6,25GBit/channel, 4 channels

Synchronisation Adapter cable

Programming cable (USB2) for firmware update

User Manual (CD-ROM)

Optronis customer service

Optronis GmbH

Ludwigstr 2

77694 Kehl

Germany

Tel: +49 (0) 7851 9126 0

Fax: +49 (0) 7851 9126 10

E-mail: [email protected]

For any questions or problems, please do not hesitate to ask our customer

service. Please prepare the following information:

•Camera type: CP80-25-M-72 or CP80-25-C-72

•Serial-Number: see label at the bottom side of the camera

•Frame Grabber

•Operating System (Windows XP/Vista/32bit/64bit …)

•Short description of the problem

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 6

Remark, Attention

This user manual is compliant with the firmware version v.6.02 of the camera.

The following signs are used in the user manual

Remarks and additional information

Attention

Precautions

Camera Power

Please use Power over CoaxPress or as an option the CP80-25-M/C-72

camera power supply (not included in shipment).

Environmental Conditions

Temperature range during operation: < + 45°C (housing temperature)

> 0°C (ambient temperature)

Humidity during operation < 80% non-condensed

At high ambient or housing temperatures the camera lifetime will

be reduced. Avoid camera operation beyond temperature limits.

Please ensure, that the housing temperature will be kept as low as

possible by additional heatsinks.

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 7

General Precautions

Read the user manual carefully before using the camera.

Do not orientate the optical input of the camera to direct sunlight.

Keep the camera free protected from dirt, dust, grease and water.

Make sure that all the connecting cables are in good condition. Defective

cables have to be replaced.

Always unplug the camera before cleaning it. Do not use cleaning liquids or

sprays. Instead, use a dry and soft duster.

There are no serviceable parts inside the camera. Do not open the

housing of the camera.

Warranty becomes void if the camera housing is opened.

CP80-25-M/C-72 Ref. 1889-SU-01-D Page 8

Camera

1: Camera housing 2: Mounting holes 2x M4x6mm 1x ¼ ``x6mm

3: Lens mount (Nikon-F) 4: Nikon lens

5: electrical interface (right side) 6: Mounting holes 4x M4x6mm

3 4
