Opticron 7x50 BIF.GA Manual de usuario

Marine Pro Series II

User Instructions and Warranty

North America

Models

7x50 BIF.GA

7x50 BIF.GA/C

Main Features

AFitting point for removable objective lens

covers (supplied)

BIntegral tripod adapter socket - unscrew to

fit 31005 large L mount (optional extra - visit

www.opticron.co.uk for more information)

CIntegrated compass and distance scale for

use in the northern hemisphere (Model 7x50

BIF.GA/C only). Compasses for other world

regions can be fitted to order

DNatural rubber armoring with contoured ribs

to maximize comfort and handling with or

without gloves

ELong eyerelief 26mm diameter eyepieces for

viewing comfort

FFold down rubber eyecups

Models supplied in multi-purpose soft case with

neoprene neck strap, rainguard and integral

objective lens covers.

Model Illustrated

7x50 BIF.GA/C

User Instructions

Multi-purpose case.

Semi-rigid carrying case manufactured in padded

waterproof material. Designed to be carried, stowed, or

fixed to a wall for easy access to instrument.

AZip fastener

BRetaining curtain

CAdjustable carrying strap

DD-rings for mounting case to wall (hooks not supplied)

Care and cleaning. Marine PSII binoculars require little

maintenance but occasionally the outside surfaces of the

eyepieces and objective lenses will need cleaning. To

avoid damaging these surfaces please read the following carefully.

(i) Gently remove excess dirt and dust using a compressed air device or blower brush. Caution: Hard and persistent

rubbing of dirty surfaces can cause abrasive scratches on the surface of the glass which may distort viewing.

(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth (code 30277) in a circular

motion until the surface is clean again.

Do not attempt to dismantle the instrument as this will invalidate the warranty.

WARNING. Never under any circumstances use a binocular to view the sun. Doing so will cause serious damage

to your eyes.

We hope you will get a great deal of pleasure from your new Opticron binocular. If you have any problems or

damage the instrument in any way our Service Department is on hand to help you.

User Instructions

To help you get the best results from your equipment, please read the following instructions carefully.

Adjusting to obtain a single picture. To adjust the binoculars to match the spacing of your eyes simply rotate

the two sides of the instrument around the center hinge until a single rounded picture is obtained when looking

through both eyepieces.

Adjusting for maximum sharpness (focusing). Marine PSII binoculars feature individual eyepiece focusing but the

large depth of field generated by the 7x50 specification means they deliver ‘in focus’ images from approximately

50 yards to infinity distance. As a rule for general observation over 50 yards, the binoculars can be ‘set’ with the

white vertical marks on the eyepiece tubes positioned directly above the rubber dots on the main body.

Focusing at close range (below 50 yards) is facilitated by turning the left and right eyepieces simultaneously.

Adjusting for differences in visual acuity. Some people have differences in strength or visual acuity between their

eyes. To compensate for this the eyepiece tubes can be rotated to different positions (usually within a few degrees

of each other) for any given distance.

Wearing glasses. Marine PSII binoculars deliver full field of view with or without glasses. To ensure the maximum

available field of view is obtained, the fold down rubber eyecups fitted to each eyepiece housing should be in the

‘down’ position when viewing with glasses. Be sure to return the eyecups to the ‘up’ position if you or anybody

else wants to view without glasses.

Distance Scale (7x50 BIF.GA/C)

The scale allows you to measure either the distance

of an object if the height is known, or the height of an

object if the distance is known.

The unit ‘mil’ is used on the scale. One scale

division is 5 mils and equivalent to an object of height

5m being viewed at a distance of 1000m.

To calculate either the distance or height of an object:

Distance [m] = Height[m] x1000 / No. of mils

Height [m] = Distance[m] x no. of mils / 1000

Compass (7x50 BIF.GA/C)

Model 7x50 BIF.GA/C is fitted with a ø30mm graduated

compass in degrees suitable for use in the northern

hemisphere. N =360º, S =180º, E=90º and W=270º.

To use, simply hold the binoculars in the viewing

position [horizontal] and focus on an object.

250 260 270

5 mils

Please keep this Warranty Card in a safe place

Warranty

Model:........................................................................................................................................................................

Serial No: ................................................................. Purchase Date:...................................................................

Dealer: .......................................................................................................................................................................

Opticron Marine Pro Series II binoculars are of a very high quality both in their performance and construction and

for your peace of mind we offer them with a Premier Plus Limited Lifetime Warranty.

The Premier Plus Limited Lifetime Warranty covers all the optical and mechanical components as well as the outer

protective armor, but not accessories such as neck straps, rainguards, dust caps, objective lens covers etc. which

are covered by our Standard Warranty.

In the case of accidental damage or defects attributable to faulty parts or assembly we will assume responsibility

for the full costs of repair up to 5 years from the date of purchase. We reserve the right to decide whether defective

parts or products should be repaired or replaced.

For the next 15 years your product is covered for defects attributable to faulty parts or assembly and we will assume

responsibility for those costs only, charging labor costs to carry out the repair.

The Premier Plus Limited Lifetime Warranty does not cover loss, theft or deliberate damage to the instrument.

MARINEPSIIUSA0714

Registration

It is important you register your new purchase to activate your Premier Plus Limited Lifetime Warranty. To register

your product and activate the warranty please visit www.opticronusa.com and complete the online Product

Registration Form.

Premier Plus Limited Lifetime Warranties are available on new instruments purchased from participating dealers in

North America and are transferable. If you part with your instrument please make sure the new owner has a copy

of your original proof of purchase and re-registers their ownership at www.opticronusa.com.

Privacy

Opticron takes your privacy seriously and we do not share personal information with other companies.

Address: Opticron LLC, 16501-D Northcross Drive, Huntersville, NC 28078

Tel: (704) 895 3046 Fax: (704) 895 3047 Email: sales@opticronusa.com
