Opticron Aurora BGA Manual de usuario

Aurora BGA

User Instructions and

30 Year Guarantee

Models

8x42

10x42

Features & Speciﬁcations

ADioptre adjustment ring (click stop)

BLugs for connecting binocular lanyard

CWide band focusing (inﬁnity to

1.8 metres close focus) with 500°

range for accurate focusing

DMulti-stage locking rotating retractable

eyecup assembly

ETextured rubber armouring for positive

handling with or without gloves

FIntegral tripod adapter socket -

unscrew to ﬁt 31012 Binocular Tripod

Mount

Speciﬁcations 8x42 10x42

Product Code Bl 30490 30491

Product Code Gr 30492 30493

Product Code Bl/Gm 30494 30495

Field (m) 126 113

Min Focus (m) 1.8 1.8

Eyerelief (mm) 20 19

IPD (mm) 58~76 58~76

HxW (mm) 140x126 140x126

Weight (g) 654 663

Model featured: Black

Accessories (included)

Accessories (optional)

Leather Case 31020 Rainguard Removable Objective Lens Covers 31002 Neoprene Bungee Lanyard

31012 Binocular

Tripod Mount

BGA roof prism

models

40940 2.5x Universal Tele-Adapter (UTA) with 40941 connection ring

The Opticron UTA enables you to increase the magniﬁcation of your Aurora BGA binocular

by a factor of 2.5x using a simple push ﬁt connection. Features include: ‘B’ speciﬁcation

eyepiece for use with or without spectacles, twist type eyecup assembly and fully multi-

coated optics.

8x Binocular 8x Binocular with 2.5x UTA

giving 20x magniﬁcation

Naked eye

Binoculars can open up a whole range of new and exciting impressions

when travelling on holiday, taken to sporting and leisure events or used as

part of a hobby such as birdwatching or astronomy. To help you get the best

results from your equipment please read the following instructions carefully.

Adjusting to obtain a single picture. To adjust to the spacing of your eyes

simply rotate the two sides of the binocular around the centre hinge until a

single rounded picture is obtained when looking through both eyepieces.

Adjusting for maximum sharpness. Many people have slightly different

vision between their eyes. When using binoculars, this difference can be

compensated for by turning the dioptre adjustment ring located on the right

eyepiece tube.

To set the binoculars correctly, close your right eye and look through the

left eyepiece with your left eye and using the centre focus wheel - focus on

an object of your choice until it is clear and sharp. Next, close your left eye

and look through the right eyepiece with your right eye. You may ﬁnd the

object being viewed is not absolutely sharp and this can be corrected by

rotating the dioptre adjustment ring (but without turning the centre focus

wheel) until the object being viewed becomes sharp. The binoculars are

now set and a perfectly clear and sharp image should be attainable when

using both eyes together. To focus at different distances simply turn the

centre focus wheel.

User Instructions

Retractable rubber eyecups and wearing glasses. Opticron Aurora BGA

binoculars provide the full ﬁeld of view when wearing glasses. To get

the maximum ﬁeld of view with glasses on, turn the eyecup clockwise

into the ‘down’ position. Remember to return them to the upright

position if you or anybody else wants to use them without glasses.

Care and cleaning. Binoculars require little maintenance but

occasionally the outside surfaces of the eyepieces and objective lenses

will need cleaning. To avoid damaging these surfaces please read the following carefully.

(i) Gently remove excess dirt and dust using compressed air or blower brush.

Caution: Hard and persistent rubbing of dirty surfaces can cause abrasive scratches on the surface of the glass

which may distort viewing.

(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth (code 30277) in a circular motion

until the surface is clean again.

Do not attempt to dismantle the instrument as this will invalidate the guarantee.

Cold weather. In cold weather the external lens surfaces may steam up when moving the instrument from cooler air

outside to warmer air inside. If this happens, leave the instrument to stand for a few minutes until any condensation

evaporates.

WARNING Never under any circumstances use a binocular to view the Sun. Doing so may cause serious damage to

your eyes.

We hope you will get a great deal of pleasure from your Opticron Aurora BGA binocular. If you have any problems or

damage the instrument in any way please contact our Service Department.

User Instructions

Multi-stage locking rotating retractable eyecup

assembly

Opticron Aurora BGA binoculars are of a very high quality

both in their performance and construction.

We guarantee some parts in these instruments for up to 30

years under the following conditions:

(i) In the case of defects attributable to faulty processing

or materials, we will assume responsibility for the

labour and material costs during the ﬁrst 10 years

after purchase. We reserve the right to decide whether

defective parts should be repaired or replaced.

(ii) During the next 20 years we will assume responsibility

for material costs only, charging corresponding labour

costs.

(iii) We will accept no liability for damage caused by

incorrect use, or for any repairs or actions which have

been carried out outside our ﬁrm.

(iv) Parts such as carrying straps, rubber eyecups, rubberised

coatings etc. are excluded from the guarantee.

This guarantee is in addition and does not affect your

statutory rights.

Please keep this Guarantee Card in a safe place

Guarantee

Registration

If you would like to register your purchase with us please complete the online Product Registration Form at

www.opticron.co.uk/Forms/registration_form.htm

Alternatively please telephone us during normal working hours on the numbers given. We will need the product

name and serial number (if applicable), purchase date and outlet, your name and postcode.

Registration is voluntary and failure to register will not diminish your rights under the guarantee.

Privacy

Opticron takes your privacy seriously and we do not share personal information with other companies.

AURORA30YR14

Address: Opticron, Unit 21, Titan Court, Laporte Way, Luton, Bedfordshire, LU4 8EF, UK

Phone: +44 (0)1582 726522 Fax: +44 (0)1582 723559 Email: [email protected]
