One Forall URC-7560 Manual de usuario

Retain For Future Reference

USER GUIDE & CODE BOOK

Universal Remote

URC-7560

QUICK SET-UP

QUICK SEARCH

INSTALLING THE BATTERIES

THE KEYPAD

INSTALLATION

Setting up your TV 7

Setting up your other devices 8

The Search Method 9

SET-UP CODES

Quick Code Reference 11 Home Automation 21

Televisions 11 Amplifiers 21

Video Recorders 16 Amp/Tuners 21

Satellite Receivers 18 Cassette Players 21

Cable Converters 20 Laser Disc 21

CD/Mini Disc 20 Digital Audio Tape 21

Miscellaneous Audio 21 DVD 21

BSKYB AND ON DIGITAL INFORMATION

ADVANCED FEATURES

Controlling Colour and Brightness 23

Volume Punch-Through 23

Changing the Device Keys 24

Menu 25

Auto scan 26

Macros 28

Learning Feature 30

Home Theater 32

Key Magic 34

Telephone Upgradable Technology 35

TROUBLE-SHOOTING

Helpful Hints 36

Consumer Help-Line 37

Table of Contents

About Your ONE FOR ALL 6

Your ONE FOR ALL 6 Package contains:

Your ONE FOR ALL 6 Remote

Your ONE FOR ALL 6 Manual

Your manual is divided into two parts: set-up instructions and

device codes. You may need this guide again in the

future, so please be sure to keep it.

Your ONE FOR ALL 6 needs 2 new “AA/LR6” batteries.

Your ONE FOR ALL 6 is designed to let you use one remote to

operate your Video and Audio equipment; any device

designed to be operated by an infrared signal. This also

includes those devices which operate over 100 kHz. You can

choose any combination of six devices you would like to

operate. Also, what makes the ONE FOR ALL 6 even more

unique is the "Learning" feature which allows you to

customise any of the special functions of your original remote

control onto the keypad of your new ONE FOR ALL.

The following pages explain in simple steps how

to customize the ONE FOR ALL 6 to your home

entertainment needs.

WWW.ONEFORALL.COM 1

Backlit

Device

Keys

Volume(-)

Menu down

Menu left

Rewind/

Text on

SP/LP/Red Record/Yellow

Stop/Green

Pause/Hold

Fast Forward/

Expand

Programme(-)

Programme(+)

Menu up

Power

Home

Theater Key

Number

Keys

Custom

Keys

Teletext Keys

Auto/Blue

Play/Text off

Menu right

Volume(+)

Mute/OK

Magic

Quick Set-Up

The instructions below and on the next page

can be used to quickly install your new ONE

FOR ALL.

You can use the Quick Set-Up below with the

codes listed on pages 11-21. If this doesn’t

work, try the Quick Search on the next page.

The Quick Search can also be used even if

your brand is not listed at all.

Make sure you install the batteries in

your ONE FOR ALL before following the

instructions below.

Make sure your device is switched on

(not in standby).

Press device key:

Press and hold

until the device key blinks

twice (the device key will

blink once and then twice).

Then release

Enter

(4-digit code). See pages

11-21. The device key

will blink twice.

Aim remote at your

device and press

(or PLAY).

3. ____

NOTES:

- The instructions above are a “Quick”

set-up guide. For further explanation,

please refer to the pages within.

- Make sure you write your Set-Up codes

in the boxes provided on page 11 and

inside the battery compartment for

easy future reference.

VCR

AUD

SAT

DVD

Quick Search

Aim your ONE FOR ALL at

your device and press a

device key:

Press and hold

until the device key blinks

twice. (The device key

will blink once then twice).

Press

Slowly alternate between

the device key ( )

and until your

device turns off.

When your device turns

off, press . The

device key will blink

twice. Your device is

set up.

NOTES:

- During step 4, you may have to press

these keys many times, so please be

patient.

- If the original remote control does not

have a power key, press PLAY instead

of POWER during step 4.

ie:

Make sure your device is switched on

(not in standby).

Make sure you aim your ONE FOR ALL

at your device during “Quick Search”.

VCR

AUD

SAT

DVD

4WWW.ONEFORALL.COM

Installing the Batteries

Important notes:

-On the inside of the battery compartment door you will

find a label on which to write your Set-Up codes after

your ONE FOR ALL 6 is set up for your device. Please

write down your codes for easy, future reference.

-Do not use rechargable batteries

-Upon changing the batteries, your set-up codes and

advanced programming will be retained.

Your ONE FOR ALL 6 needs 2 new “AA/LR6” alkaline batteries.

Remove the battery cover from the

back of your ONE FOR ALL 6 by

pressing down on the tab.

Match the batteries to the + and -

marks inside the battery case, then

insert the batteries.

Press the battery cover back into

place.

Function

Magic Key

The Magic key is used to set up your ONE

FOR ALL 6 and to access special functions.

Menu Key

The Menu key (see page 25) controls the

same function as it did on your original

remote. If available on your original remote

control, this key will allow you to access the

Surround mode of your device.

Power Key

The Power key controls the same function as

it did on your original remote.

The Keypad

WWW.ONEFORALL.COM 5

Function

Backlit Device Keys

The TV, VCR, SAT, CD, AUD and DVD keys

select the home entertainment device to be

controlled. For example pressing the TV key

allows the remote to control the functions

of your Television, after pressing VCR you

can operate your Video Cassette Recorder,

etc. For more detailed information, please

refer to the chart on page 6. During

operation of the ONE FOR ALL the device

key will light up to indicate the mode you

are using.

Home Theater Key

This key is used to select the Home Theater

mode of the ONE FOR ALL remote control.

See page 32 for more information.

Volume, Programme Keys

The Volume and Programme keys control

the two most frequently used functions of

your devices. They operate just as the keys

on your original remote. These keys are also

used to adjust colour and brightness (see

page 23 for further explanation)

Directional Keys

If available on your original remote, these

keys will allow you to navigate through the

Menu (see page 25) and the Surround Sound

mode of your device.

Mute Key

The Mute key operates the same function it

did on your orginal remote control. It is also

used to activate the Scan feature (see page

26). Also, if your original remote control

required that you press an “OK” or “ENTER”

key during Menu operation, the Mute key

can be used for this function.

Number Keys

The Number keys (0-9, 10, 20) provide

functions just like your original remote, such

as direct access programme selection. If your

original remote uses one/two digit input

switching (-/-- symbol), this function can be

obtained by pressing the -/-- key, which is the

same as the 10 key. If your original remote

has a 20 key this function can be found

under the AV key.

The AV key operates the same function it

did on your original remote control. Also, if

your original remote control required that

you press an “EXIT” key during Menu

operation, the AV key can be used for this

function. In VCR mode it obtains the TV/VCR

function.

The Keypad

-/-- 20

VCR

AUD

DVD

SAT

Function

Video Recorder Keys

After pressing the VCR key, the Video Recorder

keys operate the functions of your Video

Recorder. To prevent accidental recordings, the

Record key must be pressed twice to start

recording.

The SP/LP key controls the tape speed function,

the AUTO key controls the auto tracking

function just like on your original remote.

Teletext and Fastext Keys

After pressing the TV key, the top row of

the VCR keys is used to operate the main

Teletext functions. The symbols below the

keys are for Teletext. The text keys are used

to access the Teletext functions of your

television. Of course, your television must have

Teletext capability.

TEXT ON Puts the television in the Teletext mode.

TEXT OFF Switches the television back to regular viewing

mode. On some televisions, this may be done

by pressing the TEXT ON key several times.

HOLD/STOP

Stops changing pages.

EXPAND Shows the top half of the Teletext page in

larger letters. By pressing again, you can see

the bottom half of the Teletext page enlarged.

To return to regular Teletext viewing, press the

EXPAND key again, or press the TEXT ON key,

depending on your television.

After pressing the TV key and accessing the

text mode, the bottom row of the Video

Recorder keys marked red, green, yellow

and blue, allow you to access the Fastext

functions of your television. Again, your

television must have fastext capability to

operate these functions. If on your original

remote control these keys are used for

Menu navigation, the ONE FOR ALL Fastext

keys may operate the same.

Custom Keys

The Custom Keys are spare keys which give you

the possibility to customize the ONE FOR ALL

remote using the Learning and Key Magic®

features (page 30 and 34). These keys can also

be used to program Macros (see page 28).

For your convenience, the ONE FOR ALL 6 comes with an

adhesive overlay to label the “custom keys”. To use the overlay:

1. Remove the label from under the door.

2. Peel off the transparent protective cover from the front.

3. Write down the appropriate functions in the white area

next to the appropriate key you have customized.

4. Peel off the backing sheet.

5. Stick the label back in place.

6WWW.ONEFORALL.COM

The Keypad

(red)

(blue)

(yellow)

(green)

SP/LP

AUTO

SP/LP

AUTO

Important note: For a more detailed explanation of Teletext and

Fastext, please refer to the manual of your television. Remember,

different televisions control Teletext and Fastext features in

different ways. Not all of the Teletext functions may be available

for your particular model.

Setting Up Your Television

To set up the ONE FOR ALL 6 for your TV, follow the

instructions below.

Find your 4-digit Television code in the

Set-Up Code section (starting on page

11). Codes are listed by brand name. The

most popular code is listed first. Make

sure your Television is switched on

(not in standby).

Press and release your ONE FOR ALL 6’s

TV key.

Press and hold down the MAGIC key

until the TV key blinks twice (the TV key

will blink once then twice).

Enter your four-digit TV code using the

number keys. The TV key will blink twice.

Now, aim the ONE FOR ALL 6 at your

Television and press POWER. If your

Television switches off, your ONE FOR ALL 6

should be ready to run your Television.

Turn your device back on and try all the

remote’s functions to ensure they are

working properly (you may need to press

a number key instead of power). If the

functions do not work properly, repeat

steps 1-5 using another code listed under

your brand.

Write your code in the boxes

provided in the battery compartment

and on page 11 for easy future

reference.

WWW.ONEFORALL.COM 7

ONE FOR ALL

Acura

Admiral

Adyson

Agazi

AGB

Agef

Aiko

0009

0087, 0093, 0363, 041

0217, 0216

0264

0516

0087

0216, 0009, 0037, 0

0037, 0274

0361, 0208, 0371,

Installation

Important notes:

- Some codes are quite similar. If your device does not respond or

is not functioning properly with one of the codes, try another

code listed under your brand.

- If your television does not respond, follow steps 1 through 6 with

each code listed for your brand. If none of the codes listed for

your brand operate your device or if your brand is not listed at

all, try the search method described on page 9.

- Remember, to control your television after the ONE FOR ALL is

set up, you must press the TV key.

4____

Setting Up Your Other Devices

To set up the ONE FOR ALL 6 for your other devices:

Find the code for your device in the Set-Up

Code section (starting on page 11). Codes are

listed by device type and brand name. The most

popular code is listed first. Make sure your

device is switched on (not in standby).

Press the device key on the ONE FOR ALL 6 for the

device you wish to control. Devices can be found under

the following key:

Device Device Key

Television TV key

Video Recorder VCR key

Satellite Receiver / Cable Converter SAT key

CD Player / Mini Disk Player CD key

Audio Amplifier AUD key

Tuner AUD key

Miscellaneous Audio AUD key

Phonographs AUD key

Digital Versatile Disc (DVD) DVD key

Laser Disc Player DVD key

Audio Cassette Player DVD key

Digital Audio Tape DVD key

Press and hold down the MAGIC key

until the device key blinks twice. (The

device key will blink once and then twice.)

Enter your four-digit device code using

the number keys. The device key will

blink twice.

Now, aim the ONE FOR ALL 6 at your

device and press POWER. If your device

switches off, the ONE FOR ALL 6 is ready

to operate your device.

Write your code in the four boxes

provided in the battery compartment

and on page 11 for easy future reference.

Installation

8WWW.ONEFORALL.COM

Important notes:

- If your device’s original remote control does not have

a power key, press PLAY instead of POWER when

setting up your device.

- Remember to press the correct device key before

operating your device. Only one device (CD, amplifier,

cassette, etc.) can be assigned to a device key. If your

original remote operates more than one device (for

example, a receiver, CD player and cassette player in one

remote), you need to set up each device separately.

- If your device does not respond, follow steps 1 through 5

with each code listed for your brand. If none of the

codes listed for your brand operate your device, or if

your brand is not listed at all, try the search method

described on page 9.

ONE FOR ALL

Fernseher

Admiral 087 093 264

163

Agazi 264

AGB 075

Aiko 216 009

Akai 208 351 037

____

Tabla de contenidos

Otros manuales de Control remoto universal de One Forall

One Forall

One Forall URC-7525 Manual de usuario

One Forall

One Forall ONE FOR ALL Manual de usuario

One Forall

One Forall URC 4700 Access 4 Manual de usuario

One Forall

One Forall URC-6211 Manual de usuario

One Forall

One Forall KAMELEON URC-8308 Manual de usuario

One Forall

One Forall URC-2981 Hoja de información del producto

One Forall

One Forall URC-3445 Manual de usuario

One Forall

One Forall URC-7930 Manual de usuario

One Forall

One Forall SMART CONTROL PRO Manual de usuario

One Forall

One Forall URC 7120 Manual de usuario

One Forall

One Forall URC-7240 Manual de usuario

One Forall

One Forall URC-6210 Manual de usuario

One Forall

One Forall ZAPPER URC-6010 Manual de usuario

One Forall

One Forall SAMSUNG URC-4910 Manual de usuario

One Forall

One Forall URC-7740 Manual de usuario

One Forall

One Forall URC-9966 Manual de usuario

One Forall

One Forall Home Producer URC 9800 Manual de usuario

One Forall

One Forall URC-6210 Manual de usuario

One Forall

One Forall Zapper URC-6512 Manual de usuario

One Forall

One Forall URC-44 Manual de usuario

One Forall

One Forall Little Easy Manual de usuario

One Forall

One Forall URC-7730 Manual de usuario

One Forall

One Forall URC-7556 Manual de usuario

One Forall

One Forall OARC05G Manual de usuario

Manuales populares de Control remoto universal de otras marcas

Pronto

Pronto Peel Manual de usuario

GE 24929 Manual de usuario

Radio Shack

Radio Shack Wireless Remote Control System Manual de usuario

AUVIO

AUVIO Universal Home Theater Remote Manual de usuario

Philips

Philips Icon SRU4106 Manual de usuario

THOMSON

THOMSON ROC4309 Manual de usuario

Philips

Philips pm625S Manual de usuario

GE RM94931 Manual de usuario

RCA

RCA RCU600WMS - Universal Remote Control Manual de usuario

Blackweb

Blackweb BWB17AV002 Manual de usuario

Marmitek

Marmitek DoorGuard 300 Manual de usuario

Chunghop

Chunghop RM-L618 Manual de usuario

GE RM24965 Manual de usuario

Anderic

Anderic KTN828 Manual de usuario

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manual de usuario

Medion

Medion E74023 Manual de usuario

intensity

intensity RM02A Manual de usuario

GE RM24950 Manual de usuario
