Omron CX-PROGRAMMER V9 - REV 12-2009 Manual de usuario

Cat. No. W446-E1-10

CX-Programmer Ver. 9

SYSMAC

WS02-CXPC_-V9

OPERATION MANUAL

SYSMAC

WS02-CXPC@-V9

CX-Programmer Ver. 9.@

Operation Manual

Revised December 2009

OMRON CX-Programmer – Operation Manual

CX-Programmer_Page (ii)

About this Manual (W446):

This manual describes the operation of the CX-Programmer and consists of the following three parts.

• Part 1: CX-Programmer

This part describes the CX-Programmer software that is a PLC

Programming Device, and also provides the overall precautions and the

version upgrades information.

• Part 2: CX-Server PLC Tools

This part describes the CX-Server PLC Tools software, which is a

collection of the following components:

PLC Memory, IO Table, PLC Setup, Data Trace/Time Chart Monitor, PLC

Error, Memory Card, PLC-Clock, and CX-Net Network Configuration

(including Data Link Editor and Routing Table).

• Part 3: CX-Server Runtime

This part describes the CX-Server software that is a communications

middleware.

Note: References within each part are references to the pages or chapters within that part.

Related Manual

For details on the function block functions and ST programming, refer to the CX-Programmer Operation

Manual Function Blocks and Structured Text (Cat. No. W447).

For details on the SFC programming functions, refer to the CX-Programmer Operation Manual SFC (Cat.

No. W469).

For details on procedures for installing the CX-Programmer from the CX-One FA Integrated Tool Package,

refer to the CX-One Setup Manual provided with CX-One.

Cat. No. Model Manual name Contents

W463 CXONE-AL@@C-V4/

AL@@D-V4

CX-One Setup Manual Installation and overview of CX-One FA

Integrated Tool Package.

WARNING: Failure to read and understand the information provided in this manual may

result in personal injury or death, damage to the product, or product failure.

Please read each chapter in its entirety and be sure you understand the

information provided in the chapter and related chapters before attempting

any of the procedures or operations given.

OMRON CX-Programmer – Operation Manual

CX-Programmer_Page (iv)

Read and Understand this Manual

Please read and understand this manual before using the product. Please consult your OMRON

representative if you have any questions or comments.

Warranty and Limitations of Liability

WARRANTY

(1) The warranty period for the Software is one year from either the date of purchase or the date on which

the Software is delivered to the specified location.

(2) If the User discovers a defect in the Software (i.e., substantial non-conformity with the manual), and

returns it to OMRON within the above warranty period, OMRON will replace the Software without

charge by offering media or downloading services from the Internet. And if the User discovers a defect

in the media which is attributable to OMRON and returns the Software to OMRON within the above

warranty period, OMRON will replace the defective media without charge. If OMRON is unable to

replace the defective media or correct the Software, the liability of OMRON and the User’s remedy shall

be limited to a refund of the license fee paid to OMRON for the Software.

LIMITATIONS OF LIABILITY

(1) THE ABOVE WARRANTY SHALL CONSTITUTE THE USER’S SOLE AND EXCLUSIVE REMEDIES

AGAINST OMRON AND THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED,

INCLUDING BUT NOT LIMITED TO, WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT WILL OMRON BE LIABLE FOR ANY LOST PROFITS OR

OTHER INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF

USE OF THE SOFTWARE.

(2) OMRON SHALL ASSUME NO LIABILITY FOR DEFECTS IN THE SOFTWARE BASED ON

MODIFICATION OR ALTERATION OF THE SOFTWARE BY THE USER OR ANY THIRD PARTY.

(3) OMRON SHALL ASSUME NO LIABILITY FOR SOFTWARE DEVELOPED BY THE USER OR ANY

THIRD PARTY BASED ON THE SOFTWARE OR ANY CONSEQUENCE THEREOF.

OMRON CX-Programmer – Operation Manual

CX-Programmer_Page (v)

Application Considerations

SUITABILITY FOR USE

THE USER SHALL NOT USE THE SOFTWARE FOR A PURPOSE THAT IS NOT DESCRIBED IN THE

ATTACHED USER MANUAL.

OMRON CX-Programmer – Operation Manual

CX-Programmer_Page (vi)

Disclaimers

CHANGE IN SPECIFICATIONS

The software specifications and accessories may be changed at any time based on improvements or for

other reasons.

EXTENT OF SERVICE

The license fee of the Software does not include service costs, such as dispatching technical staff.

ERRORS AND OMISSIONS

The information in this manual has been carefully checked and is believed to be accurate; however, no

responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

OMRON CX-Programmer – Operation Manual

CX-Programmer_Page (vii)

Precautions

Intended Audience

This manual is intended for the following personnel, who must also have

knowledge of electrical systems (an electrical engineer or the equivalent).

•Personnel in charge of installing FA systems.

•Personnel in charge of designing FA systems.

•Personnel in charge of managing FA systems and facilities.

General Precautions

The user must operate the product according to the performance

specifications described in the operation manuals.

Before using the product under conditions which are not described in the

manual or applying the product to nuclear control systems, railroad

systems, aviation systems, vehicles, combustion systems, medical

equipment, amusement machines, safety equipment, and other systems,

machines, and equipment that may have a serious influence on lives and

property if used improperly, consult your OMRON representative.

Make sure that the ratings and performance characteristics of the product

are sufficient for the systems, machines, and equipment, and be sure to

provide the systems, machines, and equipment with double safety

mechanisms.

This manual provides information for programming and operating the Unit.

Be sure to read this manual before attempting to use the Unit and keep this

manual close at hand for reference during operation.

WARNING It is extremely important that a PLC and all PLC Units be used for the

specified purpose and under the specified conditions, especially in

applications that can directly or indirectly affect human life. You must

consult with your OMRON representative before applying a PLC System to

the above-mentioned applications.

Safety Precautions

WARNING Confirm safety sufficiently before transferring I/O memory area status from

the CX-Programmer to the PLC. The devices connected to Output Units

may malfunction, regardless of the operating mode of the CPU Unit.

Caution is required in respect to the following functions.

•Transferring from the CX-Programmer to real I/O (CIO Area) in the CPU

Unit using the PLC Memory window.

•Transferring from file memory to real I/O (CIO Area) in the CPU Unit

using the Memory Card window.
