Omron CJ2M-CPU Series Manual de instrucciones

OMRON Corporation

Displacement Sensor

(ZW-7000 series)

CJ Series

EtherNet/IPTM

Connection Guide

P661-E1-01

About Intellectual Property Rights and Trademarks

Microsoft product screen shots reprinted with permission from Microsoft Corporation.

Windows is a registered trademark of Microsoft Corporation in the USA and other countries.

ODVA and EtherNet/IPTM are trademarks of ODVA.

Company names and product names in this document are the trademarks or registered

trademarks of their respective companies.

Table of Contents

1. Related Manuals........................................................................................ 1

2. Terms and Definitions............................................................................... 2

3. Precautions................................................................................................ 3

4. Overview .................................................................................................... 4

5. Applicable Devices and Device Configuration ....................................... 5

5.1. Applicable Devices............................................................................. 5

5.2. Device Configuration.......................................................................... 6

6. EtherNet/IP Settings.................................................................................. 8

6.1. Parameters ........................................................................................ 8

6.2. Tag Data Link Settings....................................................................... 9

7. EtherNet/IP Connection Procedure........................................................ 12

7.1. Work Flow........................................................................................ 12

7.2. Sensor Controller Setup................................................................... 14

7.3. PLC Setup........................................................................................ 25

7.4. Network Settings.............................................................................. 35

7.5. EtherNet/IP Communication Status Check ...................................... 48

8. Initialization method................................................................................ 55

8.1. Initializing PLC................................................................................. 55

8.2. Initializing Sensor Controller ............................................................ 56

9. Revision History...................................................................................... 57

．

Related Manuals

1. Related Manuals

To ensure system safety, make sure to always read and follow the information provided in all

Safety Precautions and Precautions for Safe Use in the manuals for each device which is

used in the system.

Cat. No. Model Manual name

W472 CJ2M-CPU[][]

CJ2H-CPU6[]

CJ2H-CPU6[]-EIP

CJ-series

CJ2 CPU Unit

Hardware USER'S MANUAL

W473 CJ2M-CPU[][]

CJ2H-CPU6[]

CJ2H-CPU6[]-EIP

CJ-series

CJ2 CPU Unit

Software USER'S MANUAL

W465 CJ1W-EIP21

CJ2M-CPU3[]

CJ2H-CPU6[]-EIP

CJ Series

EtherNet/IPTM Units

OPERATION MANUAL

W446 CXONE-AL[][]C-V4

/ AL[][]D-V4 CX-Programmer

OPERATION MANUAL

0969584-7 W4S1-05[]

W4S1-03B Switching Hub

W4S1-series

Users Manual

Z362 ZW-7000[] Displacement Sensor ZW-7000 series

Confocal Fiber Type

Displacement Sensor User’s Manual

Z363 ZW-7000[] Displacement Sensor ZW-7000 series

Confocal Fiber Type Displacement

Sensor User’s Manual for

Communications Settings

．

Terms and Definitions

2. Terms and Definitions

Term Explanation and Definition

Node A programmable controller and a device are connected to an EtherNet/IP

network via EtherNet/IP ports. EtherNet/IP recognizes each EtherNet/IP

port connected to the network as one node.

When a device with two EtherNet/IP ports is connected to the

EtherNet/IP network, EtherNet/IP recognizes this device as two nodes.

EtherNet/IP achieves the communications between programmable

controllers or the communications between a programmable controller

and a device by exchanging data between these nodes connected to the

network.

Tag A minimum unit of the data that is exchanged on the EtherNet/IP network

is called a tag. The tag is defined as a network variable or as a physical

address, and it is assigned to the memory area of each device.

Tag set In the EtherNet/IP network, a data unit that consists of two or more tags

can be exchanged. The data unit consisting of two or more tags for the

data exchange is called a tag set. Up to eight tags can be configured per

tag set for the programmable controllers produced by OMRON

Corporation.

Tag data link In EtherNet/IP, the tag and tag set can be exchanged cyclically between

nodes without using a user program.

This standard feature on EtherNet/IP is called a tag data link.

Connection A connection is used to exchange data as a unit within which data

concurrency is maintained. The connection consists of tags or tag sets.

Creating the concurrent tag data link between the specified nodes is

called a "connection establishment". When the connection is established,

the tags or tag sets that configure the connection are exchanged

between the specified nodes concurrently.

Connection type There are two kinds of connection types for the tag data link connection.

One is a multi-cast connection, and the other is a unicast (point-to-point)

connection. The multi-cast connection sends an output tag set in one

packet to more than one node. The unicast connection separately sends

one output tag set to each node. Therefore, multi-cast connections can

decrease the communications load if one output tag set is sent to more

than one node.

Originator and

Target To operate tag data links, one node requests the opening of a

communications line called a "connection".

The node that requests to open the connection is called an "originator",

and the node that receives the request is called a "target".

Tag data link

parameter

A tag data link parameter is the setting data to operate tag data links.

It includes the data to set tags, tag sets, and connections.

EDS file A file that describes the number of I/O points for the EtherNet/IP device

and the parameters that can be set via EtherNet/IP.

．

Precautions

3. Precautions

(1) Understand the specifications of devices which are used in the system. Allow some

margin for ratings and performance. Provide safety measures, such as installing a safety

circuit, in order to ensure safety and minimize the risk of abnormal occurrence.

(2) To ensure system safety, make sure to always read and follow the information provided in

all Safety Precautions and Precautions for Safe Use in the manuals for each device

which is used in the system.

(3) The user is encouraged to confirm the standards and regulations that the system must

conform to.

(4) It is prohibited to copy, to reproduce, and to distribute a part or the whole of this

document without the permission of OMRON Corporation.

(5) The information contained in this document is current as of July 2016. It is subject to

change for improvement without notice.

The following notations are used in this document.

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury or property damage.

Precautions for Correct Use

Precautions on what to do and what not to do to ensure proper operation and performance.

Additional Information

Additional information to read as required.

This information is provided to increase understanding or make operation easier.

Symbol

The triangle symbol indicates precautions (including warnings).

The specific operation is shown in the triangle and explained in the text.

This example indicates a general precaution.

．

Overview

4. Overview

This document describes the procedures for connecting Displacement Sensor (hereinafter

referred to as Sensor Controller) to CJ-series Programmable Controller + EtherNet/IP Unit

(hereinafter referred to as PLC) via EtherNet/IP, both produced by OMRON Corporation

(hereinafter referred to as OMRON), and for checking their connections.

Refer to Section 6. EtherNet/IP Settings and Section 7. EtherNet/IP Connection Procedure to

understand setting methods and key points to operate EtherNet/IP tag data links.

In this document, CJ-series EtherNet/IP Unit and the built-in EtherNet/IP port of CJ-series CJ2

CPU Unit are collectively called as "EtherNet/IP Unit''.

．

Applicable Devices and Device Configuration

5. Applicable Devices and Device Configuration

5.1. Applicable Devices

The applicable devices are as follows:

Manufacturer Name Model

OMRON CJ2 CPU Unit CJ2[]-CPU[][]

OMRON EtherNet/IP Unit CJ1W-EIP21

CJ2H-CPU6[]-EIP

CJ2M-CPU3[]

OMRON Confocal Fiber Type

Displacement Sensor

Sensor Controller

Sensor Head

ZW-7000[]

ZW-S70[][]

Precautions for Correct Use

In this document, the devices with models and versions listed in 5.2. Device Configuration are

used as examples of applicable devices to describe the procedures for connecting the

devices and checking their connections.

You cannot use devices with versions lower than the versions listed in 5.2.

To use the above devices with models not listed in 5.2. or versions higher than those listed in

5.2., check the differences in the specifications by referring to the manuals before operating

the devices.

Additional Information

This document describes the procedures for establishing the network connections.

It does not provide information on operation, installation, wiring method, device functionality,

or device operation, which is not related to the connection procedures.

Refer to the manuals or contact the device manufacturer.

．

Applicable Devices and Device Configuration

5.2. Device Configuration

The hardware components to reproduce the connection procedures in this document are as

follows:

Manufacturer

Name

Model

Version

OMRON

CJ2 CPU Unit

(Built-in EtherNet/IP port)

CJ2M-CPU32

Ver.2.0

(Ver.2.12)

OMRON

Power Supply Unit

CJ1W-PA202

OMRON

Switching hub

W4S1-05C

Ver.1.00

24 VDC power supply

(for Switching hub)

OMRON

CX-One

CXONE-AL[][]C-V4

/AL[][]D-V4

Ver.4.[][]

OMRON

CX-Programmer

(Included in CX-One)

Ver.9.61

OMRON

Network Configurator

(Included in CX-One)

Ver.3.59c

Personal computer

(OS: Windows 7)

USB cable

(USB 2.0 type B connector)

LAN cable (STP (shielded,

twisted-pair) cable of Ethernet

category 5 or higher)

OMRON Sensor Controller ZW-7000 Ver.2.020

OMRON Sensor Head ZW-S7030

OMRON Calibration ROM (Supplied with Sensor Head)

OMRON

24 VDC power supply (for Sensor

Controller) (24 VDC, 2.5A, 60W）

S8VS-06024

Precautions for Correct Use

Update CX-Programmer and Network Configurator to the version specified in this Clause 5.2.

or to a higher version. If you use a version higher than the one specified, the procedures and

related screenshots described in Section 7. and subsequent sections may not be applicable.

In that case, use the equivalent procedures described in this document by referring the

CX-Programmer OPERATION MANUAL (Cat. No. W446) and Network Configurator Online

Help.

ZW-7000

24 VDC power supply

(for Sensor Controller)

Calibration ROM

CJ2M-CPU32

(Built-in EtherNet/IP port)

USB cable

Personal computer

(CX-One installed,

OS: Windows 7)

24 VDC power supply

LAN cable

W4S1-05C

．

Applicable Devices and Device Configuration

Additional Information

For specifications of 24 VDC power supply available for Switching hub, refer to the Switching

Hub W4S1-series Users Manual (Cat. No. 0969584-7).

Additional Information

For specifications of 24 VDC power supply available for Sensor Controller, refer to the

Displacement Sensor ZW-7000 series Confocal Fiber Type Displacement Sensor User’s

Manual (Cat. No. Z362).

Additional Information

The system configuration in this document uses USB for the connection between Personal

computer and PLC. For information on how to install the USB driver, refer to A-5 Installing the

USB Driver of the CJ-series CJ2 CPU Unit Hardware User's Manual (Cat. No. W472).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Omron

Omron

Omron JUSP-NS500 Manual de usuario

Omron

Omron CQM1H - 08-2005 Manual de usuario

Omron

Omron F3SP-U3P-TGR Manual de usuario

Omron

Omron G3NH Manual de usuario

Omron

Omron G3RV Manual de usuario

Omron

Omron 3G8F5-DRM21-E - V2 Manual de usuario

Omron

Omron CS1D DUPLEX SYSTEM - 10-2009 Manual de usuario

Omron

Omron SYSMAC CJ2H-CPU6@-EIP Manual de instrucciones

Omron

Omron CJ2H-CPU64 - Manual de usuario

Omron

Omron CJ Series Manual de instrucciones

Omron

Omron JUSP-NS300 Manual de usuario

Omron

Omron H7E Manual de usuario

Omron

Omron 3G3IV-PSIG Manual de usuario

Omron

Omron 3G3AX-MX2-PRT-E Manual de usuario

Omron

Omron G3NA Manual de usuario

Omron

Omron NJ501-1400 Manual de usuario

Omron

Omron CVM1 Series Manual de usuario

Omron

Omron K3TS Manual de usuario

Omron

Omron E5ZN-DRT Manual de usuario

Omron

Omron CP1L CPU UNIT - 03-2009 Manual de usuario

Omron

Omron JUSP-NS600 Guía rápida

Omron

Omron SYSMAC C200HW-PCU01 Manual de usuario

Omron

Omron SYSMAC CP Series Manual de usuario

Omron

Omron FJ-AP1 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
