Olympus CAMEDIA C-3020 Zoom Guía de instalación

ENGLISH

DIGITAL CAMERA/APPAREIL PHOTO NUMÉRIQUE

DIGITALKAMERA/CÁMARA DIGITAL

BASIC MANUAL

ENGLISH

Before using your camera, read this manual carefully to ensure correct use.

We recommend that you take test shots to get accustomed to your camera

before taking important photographs.

These instructions are only for quick reference. For more details on the

functions described here, refer to the camera reference manual on the CD-

ROM included with the camera.

C-3020ZOOM

MANUEL DE BASE

Avant d’utiliser votre appareil photo, veuillez lire attentivement ce mode

d’emploi, de manière à obtenir les meilleurs résultats possibles.

Avant d’effectuer des prises de vues importantes, nous vous conseillons par

ailleurs de faire quelques essais afin de vous familiariser avec le maniement

de l’appareil photo.

Ces instructions ne sont que pour une référence rapide. Pour plus de détails sur

les fonctions décrites ici, se référer aux instructions du CD logiciel sur le CD-ROM.

FRANÇAIS

EINFACHE ANLEITUNG

DEUTSCH

Bitte lesen Sie vor Gebrauch dieser Kamera sorgfältig diese

Bedienungsanleitung, um optimale Ergebnisse beim Fotografieren zu erzielen.

Wir empfehlen, vor wichtigen Aufnahmen Probeaufnahmen durchzuführen,

um sich mit der Bedienung und den Funktionen der Kamera vertraut zu

machen.

Diese Kurzanleitung dient dem ersten Kennenlernen Ihrer Kamera. Eine

ausführliche Beschreibung der hier aufgeführten Funktionen finden Sie in der

Bildschirmbedienungsanleitung der CD-ROM.

MANUAL BÁSICO

ESPAÑOL

Antes de usar su cámara lea este manual detalladamente para asegurar el

uso correcto.

Nosotros le recomendamos que tome fotografías de prueba para

familiarizarse con su cámara antes de tomar fotografías importantes.

Estas instrucciones son sólo de referencia rápida. Para más detalles acerca

de las funciones aquí descritas, refiérase a las instrucciones del CD del

software en el CD-ROM.

ENGLISH

For customers in Europe

“CE” mark indicates that this product complies with the European

requirements for safety, health, environment and customer

protection. “CE” mark cameras are intended for sales in Europe.

Trademarks

• IBM is a registered trademark of International Business Machines

Corporation.

• Microsoft and Windows are registered trademarks of Microsoft Corporation.

• Macintosh is a trademark of Apple Computer Inc.

• All other company and product names are registered trademarks and/or

trademarks of their respective owners.

•

The standards for camera file systems referred to in this manual are the

“Design Rule for Camera File System/DCF” standards stipulated by the

Japan Electronics and Information Technology Industries Association (JEITA).

For customers in North and South America

For customers in USA

Declaration of Conformity

Model Number : C-3020ZOOM

Trade Name : OLYMPUS

Responsible Party : Olympus America Inc.

Address : 2 Corporate Center Drive, Melville, New York

11747-3157 U.S.A.

Telephone Number : 631-844-5000

Tested To Comply With FCC Standards

FOR HOME OR OFFICE USE

This device complies with Part 15 of the FCC rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including

interference that may cause undesired operation.

For customers in Canada

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Thank you for purchasing an Olympus digital camera. Before you start to use

your new camera, please read these instructions carefully to enjoy optimum

performance and a longer service life. Keep this manual in a safe place for

future reference.

CONTENTS/TABLE DES MATIÉ/INHALT/CONTENIDO

ENGLISH ..............................................................................2

FRANÇAIS ........................................................................46

DEUTSCH ..........................................................................90

ESPAÑOL ........................................................................134

NAMES OF PARTS 4

HOW TO USE THIS MANUAL 14

GETTING STARTED 15

SHOOTING BASICS 19

ADVANCED SHOOTING 33

PLAYBACK 35

PRINT SETTINGS 38

TRANSFERRING PICTURES TO A COMPUTER 39

OPTIONAL ACCESSORIES 41

ERROR CODES 42

SPECIFICATIONS 44

CONTENTS

These instructions are only for quick reference. For more

details on the functions described here, refer to the

camera reference manual on the CD-ROM included with

the camera.

ENGLISH

NAMES OF PARTS

Camera

ENGLISH

Self-timer lamp

Diopter adjustment dial

Zoom lever (T/W)

Index display/Close-up

playback lever ( / )

Shutter button

Control panel

Flash

Card cover

Strap eyelet

Lens

Connector cover

USB connector

DC-IN jack

ENGLISH

AE lock button (AEL)

Custom button ( )

Protect button ( )

Erase button ( )

Flash mode button ( )

Macro/Spot button ( )

Print button ( )

Mode dial

(S-Prg, A/S/M/ , P, OFF, )

Viewfinder

Monitor

OK/Menu button

Manual focus button

()

Monitor button

()

Card access lamp

Arrow pad (ÑñÉí)

Battery compartment lock

Tripod socket

Battery compartment

cover

NAMES OF PARTS

Viewfinder indications

ENGLISH

1Orange lamp

●In some situations, this lamp lights up when you press the shutter button

halfway. This indicates that the flash will fire when the picture is taken.

●Lights when you start movie recording and remains lit while movie

recording is in progress.

●Blinks if the flash is required for a particular shot and the flash is turned

off.

●If this lamp blinks just after you change from the flash override mode to

another mode or after you shoot with the flash, it means that the flash is

recharging. Wait until the lamp stops blinking, then press the shutter

button.

2Green lamp

●When you press the shutter button down halfway to lock focus and

exposure, this lamp lights. If the subject is out of focus, the lamp blinks.

●Blinks when shutter button will not release, such as when there is no

memory left to store the image.

●Blinks when there is a problem with the SmartMedia card.

3AF target mark

●Place this on the subject in order to focus on it.

Control panel indications

ENGLISH

1Flash mode

●Displayed when the flash mode is selected by pressing the (flash

mode) button.

No indication: Auto-flash, : Red-eye reduction flash, : Fill-in flash,

SLOW: Slow synchronization flash, : Off (flash override)

2Manual Focus

●Displayed when locking focus using the Manual focus function.

3Flash intensity control

●Displayed when the amount of the light emitted by the flash is adjusted.

4Battery check

●When remaining battery power is low, the battery check indication

changes as follows:

●Be aware that the amount of power remaining when the battery check

indication appears varies depending on the type of batteries used.

134

$% ^

5Card error

●When the power is turned on, the camera checks the removable

memory card. If there is a problem with the card, this indication appears.

6White balance

●Displayed when the White balance is set to any mode except AUTO.

Fully charged Low power

No power

Blinks, then turns off.

NAMES OF PARTS

Control panel indications (Cont.)

ENGLISH

7ISO

●Displayed when the ISO is set to any mode except AUTO.

8Exposure compensation

●Displayed when exposure compensation is set to any value except 0.

9Auto-bracket

●Displayed when the drive mode is set to the Auto-bracket mode.

0Macro mode

●Displayed when the macro mode is engaged.

!Spot metering mode

●Displayed when the Spot metering mode is set.

@Sequential shooting

●Displayed when the drive mode is set to Sequential shooting or AF

Sequential shooting.

#Self-timer mode

●Displayed when self-timer mode is set.

$Record mode (TIFF, SHQ, HQ, SQ)

●Displays the mode in which images will be recorded.

%Card writing

●Displayed when images are being written to a removable memory card.

^Number of storable still pictures

●Displays the number of still pictures you can shoot.

Seconds remaining ( Movie mode only)

●Displays available movie recording time.

Card error

●Displayed if there is a problem with the removable memory card.

TSee “Error codes”.

134

$% ^

Monitor indications — Shooting information

ENGLISH

The indications vary depending on the shooting mode.

The information below is displayed

for about 3 seconds after operating

the buttons/mode dial or closing the

menus.

The information below is always

displayed in the shooting mode.

* These illustrations show examples of

indications displayed when the mode

dial is set to P.

1Shooting mode

●Displays the shooting mode.

S-Prg: Scene program mode ( : Portrait mode, : Sports mode,

: Landscape-Portrait mode, : Night-scene mode, : Movie

mode), P: Program mode, A: Aperture priority mode, S: Shutter priority

mode, M: Manual mode, : My mode

2Aperture value

●Displays the current aperture value.

3Shutter speed

●Displays the current shutter speed.

4Exposure compensation

●Displays the current exposure (brightness) compensation value.

Exposure differential (M mode only)

●Displays the difference between the exposure determined by the

currently selected combination of the aperture and shutter speed and

that considered optimal by the camera.

5Exposure lock

AEL : AE lock

●The exposure is locked until single-frame shooting is performed. After

you shoot an image, the indication disappears.

AEL

SLOW1

AEL

NAMES OF PARTS

Monitor indications — Shooting information (Cont.)

ENGLISH

MEMO : AE memory

●The exposure is locked and retained in memory even after shooting.

This indicator is displayed until the AE memory is turned off.

6AF target mark

●Place this on the subject in order to focus on it.

7Record mode (TIFF, SHQ, HQ, SQ)

●Displays the record mode that was selected on the menus.

8Manual Focus

●Displayed when locking focus using the Manual focus function.

9Number of storable still pictures

●Displays the number of still pictures you can shoot.

Seconds remaining ( Movie mode only)

●Displays available movie recording time for one-time shutter operation.

0Memory gauge

●Displays the amount of space used by the pictures stored in the built-in

memory as the images are being written to the SmartMedia card. If you

take pictures continuously, the indication changes as shown below.

The memory gauge changes depending on the number of storable

pictures or seconds remaining.

AEL

Otros manuales para CAMEDIA C-3020 Zoom

Tabla de contenidos

Idiomas:

Otros manuales de Cámara digital de Olympus

Olympus

Olympus E-PL2 Manual de usuario

Olympus

Olympus Sigital Vision D-620L Manual de usuario

Olympus

Olympus Stylus 7030 Manual de usuario

Olympus

Olympus S701 - Pearlcorder Microcassette Dictaphone Guía de configuración

Olympus

Olympus C-2000 - Zoom 2.1MP Digital Camera Manual de usuario

Olympus

Olympus SP-565 UZ Manual de usuario

Olympus

Olympus E-P1 - Digital Camera - Prosumer Instrucciones de montaje

Olympus

Olympus Stylus Verve - Stylus Verve 4MP Digital... Manual de usuario

Olympus

Olympus CAMEDIA C-7070 Wide Zoom Instrucciones de funcionamiento

Olympus

Olympus OM77AF Manual de usuario

Olympus

Olympus Stylus Verve - Stylus Verve 4MP Digital... Guía de configuración

Olympus

Olympus Stylus Tough 8000 Blue - Stylus Tough 8000 12MP 2.7 LCD Digital... Instrucciones de montaje

Olympus

Olympus CAMEDIA C-5050 Zoom Guía de configuración

Olympus

Olympus FE 100 - 4MP Digital Camera Manual de usuario

Olympus

Olympus CAMEDIA D-490 Zoom Manual de usuario

Olympus

Olympus SP590UZ - 12MP Digital Camera Instrucciones de montaje

Olympus

Olympus E-PM2 Manual de usuario

Olympus

Olympus FE-210/X-775 Guía de configuración

Olympus

Olympus XA Instrucciones de funcionamiento

Olympus

Olympus 35 ECR Manual de usuario

Olympus

Olympus D630 - CAMEDIA D 630 Zoom Digital Camera Manual de usuario

Olympus

Olympus DP23 Manual de usuario

Olympus

Olympus TG-4 Manual de usuario

Olympus

Olympus FE-47 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
