OHAUS Valor 2000 V22PW Guía de instalación

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

Topic:

This list compiles frequently asked questions about the Valor 2000 V22PW

(plastic housing only) model:

a) How do I switch between units of measure

b) How do I select and display the active unit of measure

c) How do I calibrate my unit

d) How do I clear an Err 9 Data error?

How to switch between units of measure

With this model, you can only select one unit of measure at a time, which you need to activate from the

Service menu (see next section: How to select and display the active unit of measure).

You can also click here to view a short video on this topic.

How to select/display the active unit of measure

Enabling or disabling the units of measure can be accomplished in the SERVICE > S.UNIT sub-menu

(you can also download the user manual here –refer to Section 3.5: Unit Menu).

You can also click here to view a short video on this topic.

To enable another unit of measure, you need to disable the current active unit first (the unit displayed

when the scale is turned on).

For the following example, the current active unit is grams (g), and you want to change to pounds (lb):

1. With the scale off, press and hold [On/Zero] and [Tare]

together for up to 15 seconds –the scale will cycle through

power up and weigh mode before RAMP is displayed.

2. Release the keys after RAMP is displayed.

3. When RAMP is displayed –press [Tare] (no) repeatedly

through each succeeding sub-menus *(LIN > SPAN > CAP >

DIV5 > L.IR FL) until S.UNIT is displayed.

* DO NOT press [On/Zero] as these sub-menus are displayed.

Notes:

a) If you overshoot the S.UNIT sub-menu, just keep pressing [Tare] until S.UNIT is displayed again.

b) To abort at any time, long press [On/Zero] to turn the scale off. Repeat from Step 1.

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

4. When S.UNIT is displayed –press [On/Zero] (yes) to select.

5. UNIT KG is displayed first –press [Tare] to skip to the next

unit.

6. UNIT G is displayed –press [On/Zero] to select.

7. ON G is displayed –press [Tare] to switch to OFF G.

(pressing [Tare] switches between ON and OFF)

8. When OFF G is displayed –press [On/Zero] to select this

setting and advance to the next unit.

Note: This unit is now disabled. Another unit can now be

activated.

9. UNIT OZ is displayed –press [Tare] to advance to the next

unit.

Note: in this example, you want pounds (lb).

10. UNIT LB is displayed –press [On/Zero] to select.

11. OFF LB is displayed –press [Tare] to switch to ON LB.

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

12. When ON LB is displayed –press [On/Zero] to select this

setting and advance to the next unit.

13. UNIT LB:OZ is displayed –press [Tare] to advance to END.

14. When END is displayed –press [On/Zero] to exit the

S.UNIT sub-menu.

15. Next, E.PAND is displayed –press [Tare]

16. Next, RESET is displayed –press [Tare]

17. When END is displayed again –press [On/Zero] to exit the

service menu and enter normal weighing mode.

The activated unit of measure (lb in this example) is now

displayed.

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

How do I calibrate my unit? (user span calibration)

Before starting calibration, be sure you have the appropriate calibration masses. See below table for your

particular model:

Note: if the active unit of measure is lb or oz before initiating calibration, use lb calibration mass. If in g or kg,

use kg calibration mass.

For this example, we will use a V22PWE15T (15kg/30lb model):

1. Turn the scale on.

The weighing unit is pounds, so the required calibration mass for

this example is 30 lb.

2. Press and hold [CAL] for around 5 seconds until CAL is displayed.

When the button is released, the display will show SPAN.

3. With nothing on the pan, press [On/Zero] to initiate span

calibration.

The display will flash –C-- until the zero reading is stored, then

shows the requested calibration value.

4. Place the required calibration mass on the pan, then press

[On/Zero].

The display will flash –C-- while the reading is stored, then shows

DONE when the calibration is successful.

5. The scale returns to weighing mode and is ready for use.

Notes:

a) The message will be displayed if these calibration steps were not followed, or if the

wrong weight was used.

b) The calibration process can be aborted any time by turning the scale off.

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

How to clear Err 9 Data error (service span cal)

An Err 9 data error can occur if the internal service settings were somehow altered. This can be cleared

with a service span calibration.

Before starting calibration, be sure you have the appropriate calibration masses. See below table for your

particular model:

Note: if the active unit of measure is lb or oz before initiating calibration, use lb calibration mass. If in g or kg,

use kg calibration mass.

For this example, we will use a V22PWE15T (15kg/30lb model):

1. With the scale off, press and hold [On/Zero] and [Tare]

together for up to 15 seconds –the scale will cycle through

power up and weigh mode before RAMP is displayed.

2. Release the keys after RAMP is displayed.

3. When RAMP is displayed –press [Tare] (no) until SPAN is

displayed.

Notes:

a) If you overshoot the SPAN sub-menu, just keep pressing [Tare] until SPAN is displayed again.

b) To abort at any time, long press [On/Zero] to turn the scale off. Repeat from Step 1.

4. When SPAN is displayed:

a) Make sure there is nothing on the pan, then

b) Press [On/Zero] (yes) to initiate calibration

The display will flash –C-- until the zero reading is stored, then

shows the requested calibration value (30lb in this example)

Valor 2000 V22PW FAQ

AppNotes.v20180720_ AG

For any further questions, please e-mail us at techsupport@ohaus.com, or call us at 973-377-9000 #2 or ext. 7852 from 8AM to 5PM EST

6. Place the required calibration mass on the pan, then press

[On/Zero].

The display will flash –C-- while the reading is stored, then

shows DONE when the calibration is completed.

7. The scale will display the next sub-menu: CAP

8. When CAP is displayed –press [Tare] repeatedly through

each succeeding sub-menus (DIV5 > L.IR FL > S.UNIT >

E.PAND > RESET > END) until END is displayed*.

* If you overshoot END, just keep pressing [Tare] until END is

displayed again.

9. When END is displayed –press [On/Zero] to exit the service

menu.

10. The scale returns to weighing mode and the error is cleared.

If this still does not resolve this issue, please contact Ohaus Technical Support.
