NXP Semiconductors LPC1311 Manual de usuario

UM10375

LPC1311/13/42/43 User manual

Rev. 3 — 14 June 2011 User manual

Document information

Info Content

Keywords ARM Cortex-M3, microcontroller, USB, LPC1311, LPC1313, LPC1342,

LPC1343, LPC1311/01, LPC1313/01

Abstract LPC1311/13/42/43 user manual

User manual Rev. 3 — 14 June 2011 2 of 368

Contact information

For more information, please visit: http://www.nxp.com

For sales office addresses, please send an email to: [email protected]

NXP Semiconductors UM10375

LPC13xx User manual

Revision history

Rev Date Description

3 20110614 LPC1311/13/42/43 user manual

Modifications:

•Parts LPC1311/01 and LPC1313/01 added.

•Modifications to the user manual applicable to parts LPC1311/01 and LPC1313/01 only:

–SSP1 added for part LPC1313FBD48/01 in Chapter 3 “LPC13xx System

configuration” and Chapter 14 “LPC13xx SSP0/1”.

–UART functions for part LPC1313FBD48/01 added in Table 128, Table 129,

Table 134, and Table 138.

–Use of IRC for entering deep power-down updated in Section 3.9.4.2.

–Enable sequence for UART clock updated in Section 12.1.

–Chapter 5 “LPC13xx Power profiles” added.

–Register IOCON_DSR_LOC (Table 140), IOCON_DCD_LOC (Table 141),

IOCON_RI_LOC (Table 142) added.

–Programmable bit OD for pseudo open-drain mode added to IOCON registers in

Chapter 7.

–Chapter 19 “LPC13xx Windowed WatchDog Timer (WWDT)” added.

•Editorial and formatting updates throughout the user manual.

•Pull-up level for internal pull-ups specified in Section 7.3.2 and Section 8.4.1 and

Section 8.4.2.

•Description WDEN bit updated in Table 290 and Table 296 (WDMOD registers).

•Section 3.7 “Start-up behavior” added.

•NVIC priority register bit description updated in Section 6.6.

•Description of GPIO data register updated in Section 9.4.1.

•LPC1342FBD48 package added.

2 20100707 LPC1311/13/42/43 user manual

1 20091106 LPC1311/13/42/43 user manual

User manual Rev. 3 — 14 June 2011 3 of 368

1.1 Introduction

The LPC13xx are ARM Cortex-M3 based microcontrollers for embedded applications

featuring a high level of integration and low power consumption. The ARM Cortex-M3 is a

next generation core that offers system enhancements such as enhanced debug features

and a higher level of support block integration.

The LPC13xx operate at CPU frequencies of up to 72 MHz. The ARM Cortex-M3 CPU

incorporates a 3-stage pipeline and uses a Harvard architecture with separate local

instruction and data buses as well as a third bus for peripherals. The ARM Cortex-M3

CPU also includes an internal prefetch unit that supports speculative branching.

The peripheral complement of the LPC13xx series includes up to 32 kB of flash memory,

up to 8 kB of data memory, USB Device, one Fast-mode Plus (FM+) I2C interface, one

UART, four general purpose timers, and up to 42 general purpose I/O pins.

1.2 How to read this manual

This user manual describes parts LPC1311, LPC1313, LPC1342, LPC1343. Part-specific

features and registers are listed at the beginning of each chapter.

Remark: The LPC13xx series consists of the LPC1300 series (parts LPC1311/13/42/43)

and the LPC1300L series (parts LPC1311/01 and LPC1313/01). The LPC1300L series

features the following enhancements over the LPC1300 series:

•Power profiles with lower power consumption in Active and Sleep modes.

•Four levels for BOD forced reset.

•Second SSP controller (LPC1313FBD48/01 only).

•Windowed Watchdog Timer (WWDT).

•Internal pull-up resistors pull up pins to full VDD level.

•Programmable pseudo open-drain mode for GPIO pins.

1.3 Features

•ARM Cortex-M3 processor, running at frequencies of up to 72 MHz.

•ARM Cortex-M3 built-in Nested Vectored Interrupt Controller (NVIC).

•32 kB (LPC1343/13)/16 kB (LPC1342)/8 kB (LPC1311) on-chip flash programming

memory.

•8 kB (LPC1343/13)/4 kB (LPC1342/11) SRAM.

•In-System Programming (ISP) and In-Application Programming (IAP) via on-chip

bootloader software.

•Selectable boot-up: UART or USB (USB on LPC134x only).

•On LPC134x: USB MSC and HID on-chip drivers.

•Serial interfaces:

UM10375

Chapter 1: LPC13xx Introductory information

Rev. 3 — 14 June 2011 User manual

User manual Rev. 3 — 14 June 2011 4 of 368

NXP Semiconductors UM10375

Chapter 1: LPC13xx Introductory information

–USB 2.0 full-speed device controller with on-chip PHY for device (LPC1342/43

only).

–UART with fractional baud rate generation, modem, internal FIFO, and

RS-485/EIA-485 support.

–SSP controller with FIFO and multi-protocol capabilities.

–Additional SSP controller on LPC1313FBD48/01.

–I2C-bus interface supporting full I2C-bus specification and Fast-mode Plus with a

data rate of 1 Mbit/s with multiple address recognition and monitor mode.

•Other peripherals:

–Up to 42 General Purpose I/O (GPIO) pins with configurable pull-up/pull-down

resistors.

–Four general purpose counter/timers with a total of four capture inputs and 13

match outputs.

–Programmable WatchDog Timer (WDT).

–Programmable Windowed Watchdog Timer (WWDT) on LPC1311/01 and

LPC1313/01.

–System tick timer.

•Serial Wire Debug and Serial Wire Trace port.

•High-current output driver (20 mA) on one pin.

•High-current sink drivers (20 mA) on two I2C-bus pins in Fast-mode Plus.

•Integrated PMU (Power Management Unit) to minimize power consumption during

Sleep, Deep-sleep, and Deep power-down modes.

•Power profiles residing in boot ROM allowing to optimize performance and minimize

power consumption for any given application through one simple function call.

(LPC1300L series, on LPC1311/01 and LPC1313/01 only.)

•Three reduced power modes: Sleep, Deep-sleep, and Deep power-down.

•Single power supply (2.0 V to 3.6 V).

•10-bit ADC with input multiplexing among 8 pins.

•GPIO pins can be used as edge and level sensitive interrupt sources.

•Clock output function with divider that can reflect the system oscillator clock, IRC

clock, CPU clock, or the watchdog clock.

•Processor wake-up from Deep-sleep mode via a dedicated start logic using up to 40

of the functional pins.

•Brownout detect with four separate thresholds for interrupt and one threshold for

forced reset (four thresholds for forced reset on the LPC1311/01 and LPC1313/01

parts).

•Power-On Reset (POR).

•Integrated oscillator with an operating range of 1 MHz to 25 MHz.

•12 MHz internal RC oscillator trimmed to 1 % accuracy over the entire temperature

and voltage range that can optionally be used as a system clock.

•Programmable watchdog oscillator with a frequency range of 7.8 kHz to 1.8 MHz.

User manual Rev. 3 — 14 June 2011 5 of 368

NXP Semiconductors UM10375

Chapter 1: LPC13xx Introductory information

•System PLL allows CPU operation up to the maximum CPU rate without the need for

a high-frequency crystal. May be run from the system oscillator or the internal RC

oscillator.

•For USB (LPC1342/43), a second, dedicated PLL is provided.

•Code Read Protection (CRP) with different security levels.

•Unique device serial number for identification.

•Available as 48-pin LQFP package and 33-pin HVQFN package.

1.4 Ordering options

Table 1. Ordering information

Type number Package

Name Description Version

LPC1311FHN33 HVQFN33 HVQFN33: plastic thermal enhanced very thin quad flat package; no
