SPECIFICATION SHEET

Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)

REFERENCE QTY. REMARKS Project

Location

Architect

Engineer

Contractor

Submitted by Date

Model 655 — Heater/Fan/Light

Model 659 — Heater/Fan/Light

Model 656 — Heater/Light

Model 657 — Fan/Light

Model 658 — Heater/Fan

FEATURES

GRILLE:

•White polymeric grille

•Directional vanes for heat and exhaust

•Snap-in light diffusing lens for 100W bulb (not included)

VENTILATOR (except Model 656):

•Resilient anti-vibration mounts

•Plug-in, permanently lubricated motor

•Low sound, high performance blower wheel

HEATER (except Model 657):

•1300 watts, with metal blower wheel for efficient, even

heating

•Plug-in, permanently lubricated motor - functions

independent of ventilator

HOUSING:

•Adjustable mounting brackets span up to 24"

•Polymeric damper/duct connector with 2" long tapered

sleeve and no metallic clatter

•Compact 23 gage steel housing finished with electrically-

bonded epoxy paint

NOTE: For installation in ceilings up to 12/12 pitch

•Suitable for use in insulated ceilings (Type I.C.).

•For all models shown above, except Model 658, use

supply wiring rated for at least 90°C.

•Models 655 and 659: Use Model 66V (Ivory) / 66W

(White) Three Function Control

•Models 656, 657, and 658: Use Model 68V (Ivory) / 68W

(White) Two Function Control

•Model 657 U.L. listed for use in tub/shower enclosure with

GFCI branch wiring

Model 654H: Rough-in housing for Models 655F, 656F,

657F, 658F, 659F finish assemblies. 654H packed (4) per

carton, 655F thru 659F packed (1) per carton

COMBINATION

UNITS

70E 99041093R

TYPICAL SPECIFICATION

Combination unit shall be Broan Model 655 (Model 659)

(Model 656) (Model 657) (Model 658).

Unit shall have steel housing finished in electrically-bonded

epoxy paint and adjustable mounting brackets.

Unit shall have directional vanes for heat and exhaust and

must be rated to handle a 100W bulb.

Fan, heater and light shall be separately controllable. Motors

shall be permanently lubricated. RPM not to exceed number

listed for each model.

Air delivery shall be no less and sound levels no greater than

listed for each model. All air and sound ratings shall be

certified by HVI.

Units shall be U.L. listed.

Models 655, 656, 657, 658 and 659 suitable for use in

insulated ceilings. (Type I. C.)

PERFORMANCE RATINGS - MODELS 655, 656, 657, 658, 659

Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)

MODEL DESCRIPTION VOLTS AMPS WATTS* SONES CFM DUCT

655 Heater/Fan/Light 120 12.8 1536 4.0 70 4" Round

656 Heater/Light 120 11.9 1428 --- ---- -----------

657 Fan/Light 120 2.0 N/A 4.0 70 4" Round

658 Heater/Fan 120 11.9 1428 4.0 70 4" Round

659 Heater/Fan/Light 120 12.0 1440 2.5 50 4" Round

*Total connected load

MODEL 658MODELS 655,

656, 657 & 659

HVI-2100 CERTIFIED RATINGS comply with new testing

technologies and procedures prescribed by the Home Ventilating

Institute, for off-the-shelf products, as they are available to

consumers. Product performance is rated at 0.1 in. static pressure,

based on tests conducted in AMCA’s state-of-the-art test laboratory.

Sones are a measure of humanly-perceived loudness, based on

laboratory measurements.
