Care Instructions
Care Instructions
2EXEC™care instructions
DO NOT use bleach or other harsh chemicals
to clean any part of the seat.
DO NOT attempt to iron the covers or pads.
Cleaning and Maintenance
Cleaning the Seat Cover, Slip Cover,
Harness Pads, and Infant Insert
Seat cover, slip cover, harness pads, and infant
insert can be cleaned according to the instructions
on the tag attached to the seat cover. Infant insert
support wedge should be spot cleaned only.
Cleaning the Harness
The child restraint harness system cannot be
removed. DO NOT attempt to remove the harness
system.
When required, harness may be cleaned with a
sponge and warm soapy water.
Towel dry excess water and allow to air dry.
Cleaning the Shell
Shell may be cleaned with a damp sponge.
Towel dry.
Cleaning the Buckle
BUCKLE CANNOT BE REMOVED.
To clean buckle, wipe with damp cloth.
DO NOT use abrasive cleansers on the shell.
Seat Cover Removal
Removing the seat cover involves removing the
cover from the head support, the leg rest, and the
entire child restraint.
Checklist Before Removing Seat Cover
Raise head support to highest position (p.34)
Loosen/unbuckle harness and chest clip (p.26).
Remove harness pads, head insert, and infant
insert (p.32–34).
Unhook tether from back of seat (p.50).
Remove Head Support Cover
1 - Undo the snaps on the bottom of the head
support cover.
2 - Undo the upper and lower snaps (location
indicated by the four arrows) in the center of
the head support cover.
3 - Gently pull the cover out of the retaining
channel along the edge of the head support.
4 - Undo the snaps around the harness straps (1).
Slide the straps out to remove the head
support cover (2).
Take care when removing head support
cover so as not to damage the energy
absorbing foam underneath.
WARNING: Do not attempt to disassemble
the child restraint. Only perform steps shown in
this manual.
1
2
3
4
1
2
3EXEC™care instructions 4EXEC™care instructions
Remove Cover from Leg Rest
1 - Position leg rest with the bottom visible to
you. Locate the four tabs on the bottom of
the leg rest. Pushing each tab in the direction
indicated releases a corner of the fabric-
covered leg rest frame (detailed in step 2).
2 - While pushing in one of the four tabs (1), pull
on the fabric-covered leg rest frame at the
corner connected to that tab (2).
Tip: Start with one of the bottom corners and
use the fabric to tug the leg rest frame until it
pops out. A gentle force is necessary, so pull
straight back from the leg rest so as not to
bend or break the plastic tab.
Repeat for the other three corners. All four
corners of the leg rest frame need to be pulled
out so that the frame completely detaches from
the leg rest.
3 - Take the removable leg rest frame out of the
fabric cover and store it until you are ready to
put the seat cover back on.
Tip: The easiest way to store the frame is to put
it back into the leg rest without the fabric for
now. Align the tabs and pop it back into place.
4 - Undo black hook and loop strip under leg rest.
5EXEC™care instructions 6EXEC™care instructions
2
3
4
1
2
1
1
Remove Cover from Child Restraint
1 - Undo the snaps on the front of the seat, being
careful not to damage the hidden white plastic
tabs.
2 - Gently begin pulling the seat cover out of the
retaining channel along the edge of the child
restraint.
3 - Unsnap the lower back seat cover from the
sides.
4 - On both sides, near the booster lap belt path,
undo the snap that secures the seat cover to
the inside of the seat.
Be careful not to damage the white plastic tab
tucked into the retaining channel at the booster
lap belt path.
5 - Unhook the white plastic tab from the button
on the edge of the seat, near the magnetic
buckle holder area.
Finish pulling the entire seat cover out of the
retaining channel.
6 - Lower the head support to the lowest position
and slide the tether strap out to completely
remove the seat cover from the child restraint.
7EXEC™care instructions 8EXEC™care instructions
4
5
6
6
6
6
2
1
6
4
5
3
Seat Cover Assembly
Reverse steps of seat cover removal.
Assembly Checklist
Leg rest cover is secured around the leg rest
frame, and the frame is secured back inside the
leg rest.
The hook and loop closure under the leg rest
is attached.
All snaps are attached.
The harness buckle, harness adjustment strap,
and tether strap are routed through the seat
cover.
The white plastic tabs on either side of the seat
cover are folded under the fabric before the
fabric is tucked into the retaining channel.
The edge of the seat cover is tucked into the
retaining channel along the edge of the seat.
The edge of the head support cover is tucked
into the retaining channel along the edge of the
head support.
©2019 Nuna Baby Essentials, Inc. Nuna and all associated logos
are trademarks.
9EXEC™care instructions
IM-0298A
