USER`S MANUAL VER. 1.0

B/W CAMERA

NVC-150B

NOVUS SECURITY Sp. z o.o.

359 Pulawska Str., 02-801 Warsaw, Poland

tel: +4822-546-0-500; fax: +4822-546-0-519

[email protected]; www.novuscctv.com

NVC-150B B/W camera, User’s Manual

B/W CCD CAMERA

Operating Instructions

CAUTION

1. Please use correct power adaptor, AC230V (regulated), to operate this unit. The power tolerance of

this unit is AC 230V ± 10% (AC207V~253V), over maximum AC253V power input will damage this

unit.

2. Video output (BNC connector) of this unit can be only connected to monitor. Please check the

wiring of video output before power on. If the power is offered through video output, the unit will be

damaged.

1. Do zasilania kamery należy użyćwłaściwego zasilacza prądu stałego : AC230V (regulowane).

Tolerancja napięcia dla tej kamery wynosi: 230 VAC ± 10 % (207 -253 VAC).Przyłożenie do kamery

napięcia większego od dopuszczalnego tj. powyżej 253 VAC, może spowodowaćuszkodzenie kamery.

2. Wyjście wizyjne kamery (BNC) można połączyćwyłącznie z właściwymi wejściami urządzeńCCTV

Przed połączeniem kamery z innymi urządzeniami CCTV należy sprawdzićokablowanie. Jeśli wraz z

wizjązostanie podany inny sygnał, o napięciu większym niż1 V p-p, kamera może ulec uszkodzeniu.

1. Por favor use el correcto adaptador de energía eléctrica AC230V (regulado) para operar esta

unidad, La tolerancia de energía de esta unidad es de AC230V ± 10% (AC207V~253V). Sobrepasar el

máximo de AC253V de la potencia de entrada dañara esta unidad.

2. La potencia de salida del video (Conector BNC) de esta unidad puede solo ser conectado al

monitor. Por favor revise los cables del video antes de encenderlo. Si la energía es dada por la

potencia de salida del video, la unidad se dañara.

1. Bitte schließen Sie das Gerät an das Netzgerät (AC230V) an. Die Toleraz der Stromversorgung ist

230V AC ± 10% (AC207V~253V). Abweichende Werte können zu Beschädigungen am Gerät führen.

2. Verbinden Sie den Video-Ausgang (BNC-Anschluß) mit dem Video-Eingang des Monitors. Bevor

Sie die Spannungsversorgung einschalten, überprüfen Sie Bitte den korrekten Anschluß des Video-

Ausgangs. Falsche Anschlußbelegungen können zu Beschädigungen an den Geräten führen.

NVC-150B B/W camera, User’s Manual

Thank you for choosing this high quality camera. Before operating the camera, please read

following instructions completely and carefully.

PRECAUTIONS

• Do not install the camera in extreme temperature condition.

• Do not install the camera in an environment where the humidity is high.

• Do not install the camera under the unstable lighting condition.

• Do not disassemble the camera.

• Do not expose the camera to rain or moisture.

• Do not keep the camera face to strong light directly.

• Do not touch the front glass of the camera.

• Do not use other than specified power source.

FEATURES

• Horizontal Resolution of 380 TV Lines.

• Minimum Illumination 0.09 Lux at F1.2.

• S/N Ratio is more than 48dB (AGC off).

• Built-in Auto Electronic Shutter.

• V.D./D.D. selectable

SPECIFICATIONS

Pick up Element 1/3" Samsung B/W CCD image sensor

Number of Pixel 510(H) x 492(V) <EIA> / 500(H) x 582(V) <CCIR>

Resolution 380 TV lines

Min. Illumination 0.09 Lux at F1.2.

S/N Ratio More than 48dB (AGC off)

Electronic Shutter 1/60 (1/50) to 1/100,000 sec

Iris Mode V.D. / D.D. selectable

Video Output 1.0Vp-p composite,75 Ohm

Lens Mount C/CS mount changeable

Microphone Yes

Power Source AC230V ± 10%

Fuse 0.16A

Power Consumption 3W

Dimension (mm) 118(L) x 62(W) x 50(H)

Weight 510 g

* Design and specifications are subject to change without notice.

NVC-150B B/W camera, User`s Manual

WARNING:

TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD,DO NOT EXPOSE THIS APPLIANCE TO

RAIN OR MOISTURE.

1. Flange Back Adjustment Ring

Suitable for CS-mount lens, When use C-mount lens, please use the CS-C conversion Ring.

2. Back focal lock screw

The camera is set at the standard back focal position . Depending on types of lenses, however slight

adjustment may be necessary. Adjust the lens back-focus by turning the focusing knob.

Major Operating Control and Functions

AUTO IRIS

AC 230V

AES

LEVEL

V.D.

VIDEO

D.D.

AUDIO

AC 230V

AUTO IRIS

L H

LEVEL

AES

VIDEO

D.D.V.D.

AUDIO

Major Operating Control and Functions

NVC-150B B/W cameraUser’s Manual

3. Auto iris Lens Connector

Use for connecting auto iris lens plug. For details, see connection.

4. DC Level Adjustment V.R.

Use for adjusting video output level of DC drive auto iris lens.

5. Power LED Indicator

The Power LED Indicator indicates normal during operation.

6. Power Input Terminal

This terminal is for connecting the 230V AC regulated power supply.

7. Video Output Connector (VIDEO OUT)

This connector is for connecting with the VIDEO IN connector of the video monitor.

8. AES/AI Selector

Lets you select the mode according to the lens type that is used with this camera.

AES: Select this mode when a fixed iris lens or manual iris lens is used with this camera.

AI: Select this mode when an auto iris lens is used with this camera.

9. IRIS V.D./D.D. Selector

Lets you select the mode according to the lens type that is used with this camera.

V.D.：Select this mode when a VIDEO Drive auto iris lens is used with this camera.

D.D.：Select this mode when a Direct Drive auto iris lens is used with this camera.

10. Audio Output Connector (AUDIO OUT)

This connector is for connecting with the AUDIO IN connector of the video monitor.

CONNECTIONS

1. Mount a lens onto the camera.

2. Set the lens selection switch (AES/AI).

3. Connect a video terminal of the camera (VIDEO) and the video input terminal of the video monitor

with a 75 Ohm coaxial cable.

4. Connect a audio terminal of the camera (AUDIO) and the audio input terminal of the video monitor.

5. Connect the power terminal of the camera to a 230V AC regulated power supply.

NVC-150B B/W cameraUser’s Manual

Installation of Auto Iris Lens Connector

Install the lens connector when using a Video drive lens.

The installation should be made by qualified service personnel or system installers

Cut the iris control cable at the edge of the lens connector to remove the existing lens connector and

then remove the outer cable cover of the supplied connector as shown in the diagram .

The pin assignment of the auto iris lens connector is as follows:

VIDEO DC

Pin 1 Power source Damp -

Pin 2 Video signal Damp +

Pin 3 Not used Driver +

Pin 4 Ground, Shield Driver -

Solder the lens cable to the pins of the supplied connector

Focus or Flange-Back Adjustment

The following adjustment should be made by qualified service personnel or system installers.

1. Mount the lens by turning it clockwise on the lens mount of the camera.

2. Loosen the screws on the flange-back adjusting ring.

3. Turn the flange-back adjusting ring to the desired position.

4. Tighten the screws on the flange-back adjusting ring.

Standard Accessories

Main body and power cable *1

HEX wrench *1

C mount adaptor ring * 1

Iris header *1

Instruction manual *1

NOVUS SECURITY Sp. z o.o.
