Norcold DC-351D Manual de usuario

PARTS LIST

DC351D

DC351 SERIES

PART#619719

NORCOLD 10/24/2002

DC351F

DC351SERIESPARTSLIST-PAGE2

DC351SERIESPARTSLIST-PAGE3

REFRIGERATOR ASSEMBLY - DC351 SERIES

(CONTINUED ON PAGE 4)

NO. PART # DESCRIPTION DC351D DC351F

2 161212400 BLIND PLATE XX

3 439010400 HEAT INSULATOR XX

4 430307100 PLATE-"I" (1 PER REFRIGERATOR) X X

5 416004200 BUSHING-FOR BLIND PLATE X X

6 80830441210 SCREW-TRUSS TAPPING/M4x12 X X

7 645100510 FASTENER-PLASTIC RIVET X X

8 8050050104 SCREW XX

9 83400500010 WASHER-TEETH LOCK X X

10 160924300 HOLDER ASSY-TRAVEL LATCH X X

11 505502330 HINGEPIN-0.625" XX

12 304111000 PLATE-HINGE(USE304111020) X X

13 8300087001 WASHER XX

15 323008600 CABINET FRAME-BLACK/SIDES (USE160925800) X

16 323008500 CABINET FRAME-BLACK/TOP/BOTTOM (USE160925800) X

NS 160925800 CABINET FRAMEASSY-FOURSIDES X X

17 160203000 ICECUBETRAY XX

18 433001401 DRAINAGEPAN XX

19 523003210 SHELF XX

20 645109400 HOLDER-SHELF/REAR X X

21 80830441210 SCREW-TRUSS TAPPING/M4x12 X X

22 603200921 THERMOSTAT (USE603200910) X X

603200910 THERMOSTAT XX

23 603604000 CIRCUIT BREAKER XX

24 191214910 CORD ASSY (AT THERMOSTAT) X X

25 191212940 CORDASSY (AT CIRCUIT BREAKER) X X

26 422501700 COVER-THERMOSTAT X X

27 545020730 MARK-THERMOSTAT HOLDER X X

28 160203200 KNOB-THERMOSTAT/BLACK X X

29 160102990 POWER SUPPLY (USE 16011395008) X

160104370 POWER SUPPLY (USE16011395008) X

30 163007430 OSCILLATOR & TRANSFORMER (USE16000395008) X X

31 196008720 TRANSFORMER ASSY (USE16011395008) X X

32 163008500 OSCILLATOR ONLY XX

33 163204100 CASEASSY XX

34 322119100 COVER-DC WIRES XX

35 546017100 CAUTIONPLATE(ONDC COVER) X X

36 546028011 CAUTION PLATE(ONPOWERSUPPLY) X X

37 80840430810 SCREW-TRUSS TAPPING/M4x8 X X

38 83400400010 WASHER-TEETHLOCK X X

DC351SERIESPARTSLIST-PAGE4

REFRIGERATOR ASSEMBLY - DC351 SERIES (CONTINUED FROM PAGE 3)

NO. PART # DESCRIPTION DC351D DC351F

39 80830441210 SCREW-TRUSS TAPPING/M4x12 X X

40 8073044121 SCREW-TAPPING/WITHTEETHLOCKWASHER X X

41 161008220 COOLING UNIT XX

42 80800441620 SCREW-TAPPING/M4x16 X X

43 320200001 HOLDER-THERMOSTAT BULB X X

44 8080043082 SCREW-TAPPING XX

45 500800400 SCREW-TAPPING XX

46 321105900 HOLDER-COOLING UNIT X X

47 322005310 HOLDER-CONDENSER WASHER X X

48 8071043163 SCREW-TAPPING XX

49 80830431210 SCREW-TAPPING/M4x12 X X

50 422006700 CLIP-EVAPORATOR HOLDER/U SHAPED X X

51 8073044121 SCREW-TAPPING/WITHTEETHLOCKWASHER X X

54 83400400010 WASHER-TEETHLOCK X X

55 160027600 DOORASSY-WITHOUT POCKETS X X

56 302311620 DOORPANEL-BLACK XX

57 160923710 DOORFRAMEASSY-FOAMED LINER X X

58 422508800 DOORPOCKET-DOOR SHELF BIN X X

59 422508600 PARTITION-DOOR POCKET X X

60 427602700 DOORFRAME-BOTTOM/GRAY X X

61 412006670 CUSHION-DOORPANEL X X

62 422107800 COVER PLATE-HINGEHOLE X X

NS 422101510 CAP-BLACK/INSTALLATIONHOLES (NOT SHOWN) X X

NS 16092493007 FAN KIT ASSY (NOT SHOWN) X X

NS 16011395008 KIT-POWER SUPPLY (NOT SHOWN) X X
