CaseIH(20,30&40Series)

ActiveWingRoll

UC7BoomHeightControlSystem

InstallationManual



PrintedinCanada

ReorderP/N:UC7‐BC‐CS05A‐INSTRevA(CaseIH20,30&40SeriesActiveWingRoll)



NOTICE:NORACSystemsInternationalInc.reservestherighttoimproveproductsandtheirspecificationswithoutnoticeandwithouttherequirementto

updateproductssoldpreviously.Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Thetechnicalinformationin

thismanualwasreviewedatthetimeofapprovalforpublication.



WWW.NORAC.CA

PRECISIONDEFINED



Contents



Introduction..........................................................................................................................1



TechnicalSpecifications........................................................................................................2



PartsOverview......................................................................................................................3



Pre‐InstallationChecklist.......................................................................................................8



HydraulicInstallation.............................................................................................................9



UltrasonicSensorInstallation..............................................................................................16



ElectronicInstallation..........................................................................................................23



WingRollCylinderAirBleedProcedure..............................................................................28



SoftwareSetup....................................................................................................................29



CableSchematics.................................................................................................................30



AppendixA:MainLiftValveInstallation.............................................................................35





WWW.NORAC.CA

PRECISIONDEFINED





Page1

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

1Introduction

CongratulationsonyourpurchaseoftheNORACBoomHeightControlSystem.Thissystemismanufactured

withtopqualitycomponentsandisengineeredusingthelatesttechnologytoprovideoperatingreliability

unmatchedforyearstocome.

Whenproperlyusedthesystemcanprovideprotectionfromsprayerboomdamage,improvesprayer

efficiency,andensurechemicalsareappliedcorrectly.

Pleasetakethetimetoreadthismanualcompletelybeforeattemptingtoinstallthesystem.Athorough

understandingofthismanualwillensurethatyoureceivethemaximumbenefitfromthesystem.

Yourinputcanhelpmakeusbetter!Ifyoufindissuesorhavesuggestionsregardingthepartslistorthe

installationprocedure,pleasedon’thesitatetocontactus.



Everyefforthasbeenmadetoensuretheaccuracyoftheinformationcontainedinthismanual.Allparts

suppliedareselectedtospeciallyfitthesprayertofacilitateacompleteinstallation.However,NORAC

cannotguaranteeallpartsfitasintendedduetothevariationsofthesprayerbythemanufacturer.

Pleasereadthismanualinitsentiretybeforeattemptinginstallation.

WWW.NORAC.CA

PRECISIONDEFINED





Page2

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

2TechnicalSpecifications

 

CANICES‐3(A)/NMB‐3(A)



ThisClassAdigitalapparatuscomplieswithCanadianICES‐003.

PursuanttoEMCDirective–Article9,thisproductisnotintendedforresidentialuse.

Table1:SystemSpecifications

SupplyVoltage(rated) 12VDC

SupplyCurrent(rated) 10A

HydraulicPressure(maximum) 3300psi

BaudRate 250kbps

OperatingTemperatureRange 0°Cto80°C





WWW.NORAC.CA

PRECISIONDEFINED





Page3

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3PartsOverview

3.1. ElectronicInstallationOverview



Figure1:ElectronicInstallationOverview



WWW.NORAC.CA

PRECISIONDEFINED





Page4

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.2. HydraulicPlumbingSchematic



Figure2:HydraulicPlumbingSchematic



WWW.NORAC.CA

PRECISIONDEFINED





Page5

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3. ListofParts

ItemPartNumberNameQuantity

B0544706‐01KITCABLETIEBLACK10PCS21IN150PCS7.5IN1

B0744746BRACKETWRCCS1

B1744972SENSORMOUNTINGBRACKETLOWPROFILERAINFLAP16GA2

B2044971SENSORMOUNTINGBRACKETLOWPROFILE16GA2

B2144973SENSORMOUNTINGBRACKETLOWPROFILE16GALARGEFLANGE1

C0143220‐01CABLENETWORK14AWG1M1

C0243220‐03CABLENETWORK14AWG3M1

C0543210‐20CABLENETWORK18AWG20M2

C1050130‐01CABLEVALVE4‐PINDTTO2‐PINDT4

C1150120‐01CABLETEMPERATUREPROBE1

C2050140‐03CABLEINTERFACEDT(280"ML)1

C3043250‐04CABLEBATTERYAMPFUSED1

E0150000HCM1MODULE1

E0543750ULTRASONICSENSOR1

E0750100ULTRASONICMAXSENSOR2

E1143765NETWORKCOUPLER8‐WAY1

E1243764NETWORKCOUPLER2‐WAY1

E2043764TNETWORKCOUPLER2‐WAYWITHTERMINATOR2

H0144862‐08HOSEASSEMBLY122R2‐0436INL6FORX6FORX4

H0244863‐10HOSEASSEMBLY122R2‐0660INL6FJX8FORX2

H0344863‐25HOSEASSEMBLY122R2‐06136INL6FORX6FORX1

H0444863‐31HOSEASSEMBLY122R2‐06106INL6FORX6FORX1

H0544863‐38HOSEASSEMBLY122R2‐06156INL6FORX6FORX902

H0644863‐23HOSEASSEMBLY122R2‐0632INL6FORX6FORX4

H0744863‐53HOSEASSEMBLY122R2‐0666INL6FORX6FORX1

H1044865‐06HYDRAULICSFITTINGKIT‐CS31

H1144865‐48HYDRAULICSFITTINGKIT‐CS41

H1244865‐75HYDRAULICSFITTINGKIT‐AWR11

H2044978WINGROLLCYLINDERW/POSITIONSENSOR 1

M02UC7‐BC‐CS05A‐INSTMANUALINSTALLATIONUC7CASEIH(20,30&40SERIES)ACTIVEWINGROLL1

M05106706MOUNTINGCLIPHCM12

P01106705NETWORK4PINCAVITYPLUG1

P03105882NETWORK6PINPLUG3

V0144960DVALVEBLOCKASSEM3STATIONCC/LSPROPDT4BOLT1

V0244962DVALVEASSEMBLYEXPANSIONDPOCPROPDT4BOLT1



WWW.NORAC.CA

PRECISIONDEFINED





Page6

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3.1. HydraulicFittingKitDetails(P/N:44865‐06)

ItemPartNumberNameQuantityPicture

F02103312MALEADAPTER‐6MB6MJ2



F03104586TEEADAPTER‐6FORXR6MORT4



F04104886MALEADAPTER‐8MOR8MB2



F0544917MALEADAPTER‐6MB‐6MOR8



F06104885TEEADAPTER‐8FORXR8MORT2



F0710459090DEGADAPTER‐6MOR6FORX904



F08104369PLUG‐6MBP2



F0944928ONEWAYORIFICEINSERT‐0.0474



F10104592O‐RINGHYD3.8INFLATFACE2



F11105184ORIFICEINLINE6FLATFACE2



Notallfittingsareusedforthisinstallation.





6 M B - 6 M OR X 90

SIZE IN

1/16TH'S

GENDER: MALE

OR FEMALE

90° ANGLE

SWIVEL

TYPE

GENDER

SIZE

TYPE:

B - ORB

J - JIC

OR - FLAT

FACE

P - PIPE

Fitting Name

Example:

WWW.NORAC.CA

PRECISIONDEFINED





Page7

Visitwww.solutions.norac.caformoresystem

installationandtroubleshootinginfo.

3.3.2. HydraulicFittingKitDetails(P/N:44865‐48)

Thefollowingfittingsareusedforconnectingthemainlifthydraulics.

ItemPartNumberNameQuantityPicture

*F03104586TEEADAPTER‐6FORXR6MORT2



*F0444917MALEADAPTER‐6MB6MOR2



3.3.3. HydraulicFittingKitDetails(P/N:44865‐75)

Thefollowingfittingsareusedforconnectingtheactivewingrollhydraulics.

ItemPartNumberNameQuantityPicture

F1244917MALEADAPTER‐6MB6MOR6



F13104586TEEADAPTER‐6FORXR6MORT4



F1410459090DEGADAPTER‐6MOR6FORX909



Notallfittingsareusedforthisinstallation.



Donotusehighspeedpowertools/drillswheninstallinghardware.



TheuseofdielectricgreaseisnotrecommendedonanyNORACelectricalconnections.



ToensureallstainlesssteelhardwaredoesnotgallorseizeapplyalightcoatingofthesuppliedPermatex

Anti‐seizegreasetoallthreadedpartsuponinstallation.PermatexAnti‐seizelubricantispreferred,but

othersimilaranti‐seizeproductsmaybeused.
