2TechnicalSpecifications
CANICES‐3(A)/NMB‐3(A)
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept
anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferencewhentheequipmentisoperatedinacommercial
environment.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,if
notinstalledandusedinaccordancewiththeinstructionmanual,maycauseharmful
interferencetoradiocommunications.Operationofthisequipmentinaresidentialareaislikely
tocauseharmfulinterferenceinwhichcasetheuserwillberequiredtocorrecttheinterference
attheirownexpense.
ThisClassAdigitalapparatuscomplieswithCanadianICES‐003.
PursuanttoEMCDirective–Article9,thisproductisnotintendedforresidentialuse.
Table1:SystemSpecifications
SupplyVoltage(rated)12VDC
SupplyCurrent(rated)10A
HydraulicPressure(maximum)3300psi
BaudRate250kbps
ClockFrequency(maximum)96MHz
SolenoidValvePWMFrequency300Hz
UltrasonicSensorTransmitFrequency50kHz
OperatingTemperatureRange0°Cto80°C
The10Afuseonthepowercablemaybereplacedbytheoperatorifneeded.Thereplacement
fusemustberatedtoblowinlessthan120secondsat200%andbeANSI/UL248‐14orbetter.
Table2:ReplacementFuse
NORACPartNumber106676
ManufacturerPartNumberLittelfuse–0287010.PXCN
TheUC5™productlineiscoveredbymultiplepatentsincluding,butnotlimitedtothe
following:
U.S.Pat.No:US2004158381
EuropeanPat.No:EP1444894
CanadianPat.No:CA2418610
