Nivona CAFEROMATICA 710 Manual de usuario
CafeRomatica
Fully automatic coffee centre
Operating Instructions and Useful Tips
710
A passion for coffee.
2
Operating Instructions and Useful Tips
Dear Customer,
Congratulations and many thanks for choosing a high-quality
NIVONA product. To get the most out of your NIVONA machine,
please read this manual carefully before use. Please start by
reading the safety notes.
Please keep this manual in a safe place. You may want to use
it as reference guide or hand it on to any further users of your
machine.
Purchase made at
Place, date
3
Equipment
Symbol display screen
AService button ‘S’
I
Height-adjustable
coffee spout
J
Drip grill
K
Drip tray
L
Grinder settings
control knob (inside)
M
Bean container
with lid
N
Pre-ground coffee
chamber
O
Steam warm-up
button
P
Steam / hot water
valve control button
Q
Document compart-
ment (on rear)
R
Mains supply
switch (on rear)
S
Steam / hot water
jet and ‘spumatore’
(milk frother)
T
Used coffee con-
tainer (inside)
U
Power cord storage
compartment
(on rear)
V
Removable water
reservoir
B
Cup warming /
holding plate
C
Water quantity
control knob
D
Coffee strength
button
E
On / Off (stand-by)
button
F
1-cup button
G
2-cup button
H
1
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
Equipment
234
5
8
6 7
9
10
aControl knob
bAir inlet valve
cAir inlet pipe
dInlet valve
eSteam / hot water jet
fLiquid inlet hose
b
c
d
e
a
f
Symbols
Number Brief description
8Coffee ready
9Coffee strength MILD
10 Coffee strength NORMAL
11 Coffee strength STRONG
12 Add coffee beans, Fill bean container
13 Fill water reservoir
14 Pre-ground coffee
15 Steam / hot water
16 Steam / hot water, open / closed
17 Empty used coffee container / drip tray
18 Descale machine
19 Clean machine
20 Change filter
21 Brewing unit incorrectly fitted or door open
Symbol
flashing
Contents
1. Security instructions
2. Set up
2.1 Preparing the machine
2.2 Getting started
2.3 Grinder settings
3. Making coffee
3.1 Select coffee strength
3.2 Select water quantity
3.3 Making one cup
3.4 Making two cups
3.5 Using pre-ground coffee
3.6 Drawing hot water
3.7 Producing steam
3.8 Frothing milk, hot milk or cappuccino
4. Programming functions
4.1 Filter
Inserting filter – Operating without a filter
4.2 Water hardness
4.3 Temperature
4.4 Automatic stand-by
5. Maintenance and care
5.1 Inserting filter
5.2 Changing filter
Changing / washing filter manually
5.3 Cleaning program
Manual cleaning
5.4 Descaling
Manual descaling
5.5 General cleaning
6. System messages
7. Troubleshooting
8. Further instructions
7
1. Safety instructions
• This machine may only be used
for the intended purpose
(domestic use) and is not for
commercial application (more
than 3000 brewing cycles per
year).
• Operating voltage must be the
same as mains voltage. Please
note the model nameplate /
sticker on the machine.
• Do not operate the machine if the
power cord or machine case is
damaged.
• Keep the power cord away from
hot parts.
• Do not unplug the machine by
pulling on the power cord.
• Observe the descaling in-
structions provided.
• Make sure to switch off and
unplug the machine before
maintenance or cleaning.
• Place the machine on a firm,
level surface and use it indoors
only.
• Do not place the machine on a
hot surface or near open flames.
• Keep the machine away from
children.
• Always unplug the machine
during extended periods of
absence.
• Do not leave the machine
switched on unnecessarily.
• Never submerge the machine
in water.
• Do not put the machine or in-
dividual parts in the dishwasher.
• Unplug immediately if there is
a defect (do not pull the cord
or machine to unplug).
• Liability for damages cannot
be accepted if the machine is
incorrectly operated, subject
to improper use or non-profes-
sional servicing. In such cases,
services will not be provided
under the guarantee.
• Use the coffee grinder for
grinding roasted coffee beans
only – do not use with other
foods. Always make sure there
is nothing but coffee beans in
the beans container – otherwise
the guarantee will not apply.
• This machine is not suitable for
individuals (including children)
with physical, sensory or mental
impairments, including indivi-
duals who do not have sufficient
8
experience or knowledge, unless
they are shown how to operate
the machine or initially super-
vised by someone responsible
for their safety.
If repair services are required, in-
cluding replacement of the power
cord, please send the machine to
the dealer from whom it was pur-
chased – or to NIVONA central
customer services.
Caution: Electrical appliances
must be repaired by qualified per-
sonnel! Non-professional repairs
can expose the user to significant
dangers. Liability for damages
cannot be accepted if the machine
is used for any other than the
intended purpose, incorrectly
maintained or serviced.
Caution: Using the mains switch
(fig. 1/S) during brewing can
damage the machine! Only switch
off at the mains when the On / Off
switch is switched to Off (stand-
by).
Caution: Risk of scalding!
• Then you draw steam or hot
water, watch out for splashes
from the jet / frother (fig. 1/T):
risk of scalding!
• Only touch the plastic parts of
the steam jet (fig. 1/T) and never
point it at people.
• The steam jet (fig. 1/T) becomes
VERY HOT during use. Prefer-
ably leave to cool for a few
minutes before touching.
CE – This machine conforms to
the following EC guidelines:
• 73/23/EWG dated 19/02/1973
“Low Voltage Directive”,
including amendment
93/68/EWG.
• 89/336/EWG dated 03/05/1989
“EMV Directive”, including
amendment 92/31/EWG.
Specifications
Mains voltage: 220 - 240 V
Power input: 1350 W
Note: Your fully automatic coffee
centre has a cord storage compart-
ment – if the power cord is too
long, any surplus can be accom-
modated in the storage area on
the rear of the machine (fig. 1/V).
... 1. Safety instructions
9
2. Set up
2.1 Preparing the machine
➔ Carefully remove the machine
and all parts from the packaging.
Note: If you need to return your
machine for servicing, it can be
sent by post in the original pack-
aging. Please keep all packaging
and protective material for this
purpose.
➔ Remove the water reservoir
(fig. 1/B and 2) and wash it out
with cold, clean tap water.
➔ Then fill the reservoir up to the
max. mark and replace it in the
machine. Make sure that it clicks
into place.
Note: Only fill the reservoir with
fresh, cold water. Do not use car-
bonated water or other liquids.
➔ Open the lid of the coffee con-
tainer (fig. 1/N) and add coffee
beans.
Note: Do not use beans which have
been treated with supplements,
such as sugar, during or after the
roasting. Supplements can damage
the grinding mechanism and any
repair costs arising as a result are
not covered by the guarantee.
Please make sure the steam / hot
water valve control knob (fig. 1/Q
and 7) is turned to ‘0’!
2.2 Getting started
➔ Remove the plug from the
power cord compartment (fig. 1/V)
and plug the machine in.
➔ Switch the mains supply on
(fig. 1/S). The On / Off button (fig.
1/F) lights up.
➔ Press the On / Off button (fig.
1/F). The ‘cup’ symbol (Symbol 8)
starts to flash in the display.
➔ After the machine has warmed
up, the Service button (fig. 1/I)
flashes.
➔ Now place a cup under the
height-adjustable coffee spout
(fig. 1/J and 5). Press the Service
button (fig. 1/I).
10
➔ The system is then filled with
water and completely rinsed out
via the height- adjustable coffee
spout (fig. 1/J and 5).
➔ The machine is now operat-
ional.
Note: For manufacturing reasons,
the machine pipes may still be
empty when the machine is first
operated. The machine indicates
this as follows:
➔ After the machine has been
switched on using the On / Off
button (fig. 1/F), the ‘water /
steam open / closed’ symbol
(Symbol 16) starts to flash.
➔ Open the steam / hot water
control valve (fig. 1/Q and 7) by
turning to the right. The system
now fills up and some water may
come out of the jet (fig. 1/T).
➔ As soon as the ‘water / steam
open / closed’ symbol (Symbol 16)
starts flashing again, you can turn
the valve control knob (fig. 1/Q
and 7) back to the left to
close.
➔ After the machine has warmed
up, the Service button (fig. 1/I)
flashes.
➔ Press the Service button (fig.
1/I) and the system is rinsed
out via the coffee spout (fig. 1/J
and 5).
➔ The machine is now operational.
2.3 Grinder settings
Caution: Grinder settings can only
be adjusted when the grinder is in
operation. You can adjust the
grinder to suit the roast of your
coffee beans. We recommend that
you leave the grinder on a medium
setting.
➔ Open the lid of the bean con-
tainer (fig. 1/N).
➔ Turn the control knob (fig. 1/M
and 3) to the desired position
while the grinder is running. The
smaller the dot, the finer the
coffee is ground. Remember:
· a light roast requires a finer
grind
· a dark roast requires a coarser
grind
Try out the different settings to
find the one that best meets your
personal preferences.
... 2. Set up
