Nikon D7000 Manual de usuario

Page1

Nikon D7000 Camera Kit

-Checklist and Operations Manual-

February 2, 2012

SRQ Composite Squadron, Civil Air Patrol

Page2

1.0 Equipment Pre-Mission Check

1.1 Open the camera case and verify the following items are enclosed:

Nikon D7000 camera, MB-D11 Battery Grip, 18-105mm Nikkor lens,

50mm Nikkor lens, UV filters and lens caps.

2 rechargeable camera batteries (one stored in the battery grip)

Nikon GP-1 GPS attachment with attached cable

Charger for camera batteries

Instruction manuals for D7000, GP-1

Page3

D7000 Camera

Battery Grip

Lens Cover & Lens Shield

(lens Shield not used)

SD Memory Card

Battery Charger and Battery

Battery

Page4

Adapter for 4 AA Batteries

(use when rechargeable

batteries are discharged)

GP1 GPS Adapter

USB Cable

50mm F1.8 Lens

1.2 Charge Camera Batteries

To remove the battery pack from the camera body, open the door on the bottom of the

camera by moving the release lever. When the battery access door opens, move the

yellow release lever until the battery pack pops free. There is one battery pack in the

battery grip. To remove the battery pack from the battery grip, pull the release ring out

and turn counter-clockwise to open the battery grip. Slide the insert out and remove

the battery by pressing the button marked “push” and slide the battery free. Charge

each battery pack, one at a time, and bring the batteries to full charge. The indicator

light will flash during charging. When fully charged, the light will illuminate

continuously.

Page5

Battery Compartment Release

Battery release lever

Battery Grip Release Tab

Battery Pack Tab Marked “push”

Page6

1.4 Nikon D7000 Camera Pre-mission Initiation

Verify the Camera is turned off

Mode Selector On/Off Switch

Install memory cards

(cards may already be in the camera) by moving the door located on the right side of the camera and

pushing it slightly toward the rear of the camera to open the memory card access cover. The cards are

installed by gently pushing the card in until it clicks in place. A light located on the back-right of the

camera will briefly illuminate to confirm the card is seated. The card can be removed by pushing the

card in and it will pop out. Two 32 GB cards are furnished with the system.

SD Memory Cards Memory card access cover

Page7

Set the lens autofocus switch to AF Set the camera autofocus switch to AF

Just to the left of the camera AF switch is the lens optical

stabilizer switch (OS). Place this switch to ON.

Rotate mode switch to "auto-no-flash".

The Mode switch is located on the top-left side of the camera. "auto-no-flash" is

reached by setting the Mode between the "Auto" (green camera symbol) and the

“scene” setting. If the green auto setting is used, the camera flash will pop up and

contact the GP1

Page8

Install the Nikon GP1 GPS

If the cable is not attached to the GP-1, insert the smaller connector into the GP-

1 while lining up the arrows on the GP-1 and cable. Push it in until it snaps in

place hiding the arrows.

The other end of the cable goes into the GPS port on the camera. The arrow on

the connector should face the back of the camera. Slide the connector all the

way in. It does not snap in place.

Page9

Insert camera batteries

The D7000 body holds one battery. The MB-D11 holds one battery. The D700

will operate properly without the MB-D11. The MB-D11 extends operation

time. If the MB-D11 Battery grip is attached, it must be removed before

replacing the battery in the camera body. At the back of the MB-D11 is a wheel

labeled “lock”.

To remove the MB-D11 turn the wheel to the left and the battery grip will

separate from the camera body.

With the MB-D11 removed, the battery compartment on the D7000 is located

on the bottom of the camera. Move the battery compartment release toward the

middle of the camera and the battery door will open. With the door open, move

the yellow release until the battery pops up.

To install a battery, with the battery door open push the battery in until it snaps

in place. Close the battery door, and attach the MB-D11.

The MB-D11 holds one battery. To access the battery compartment pull the

release tab located on the side of the MB-D11. With the tab straight out turn the

tab in direction of the green arrow. The battery compartment will slide out and

expose the battery. To release the battery, push on the tab labeled “push” and

the battery will slide free. To install a battery, slide the battery with the

contacts down until it snaps into place. Then slide the compartment into the

MB-D11 and turn the release tab to lock in place.

The MS-D11 also has a accessory that replaces the rechargeable battery

compartment with one that holds 4 AA batteries. Observe proper polarity when

installing batteries. The compartment slides in place in the same manner as the

standard rechargeable one. Photos on page 5

Page10

Remove Lens Cap

Turn on the camera

Check Batteries

Note: the battery symbol above shows the status of the battery in use. When two batteries

are installed it is better to follow the procedure below to check battery status.

Press the "Info" button to turn on the Monitor.

The following will show on the Monitor. Both batteries are shown;

the active battery (chosen by the camera) and the standby battery.
