Nikon Coolpix S640 Manual de usuario

Take the Camera Out of the Box 3

First Steps 4

Shooting and Playback 9

Installing the Supplied Software Applications

Transferring Pictures to a Computer 17

Quick Start Guide

Thank you for your purchase of a Nikon COOLPIX S640 digital camera.

This guide introduces the procedures necessary in using this camera for the first

time.

For more detailed information, please refer to the supplied User’s Manual.

Technical support information is available online at the following sites:

•For users in the USA: http://www.nikonusa.com/

•For users in Europe and Africa: http://www.europe-nikon.com/support/

•For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

An Important Notice about Accessories

Nikon COOLPIX digital camera is designed to the highest standards and

includes complex electronic circuitry. Only Nikon accessories, such as chargers,

batteries, Charging AC Adapters and AC adapters, are certified by Nikon

specifically for your Nikon COOLPIX digital camera and are engineered and

tested to operate within the requirements of the electronic circuitry of our

cameras.

Take the Camera Out of the Box 3

Take the Camera Out of the Box

Remove the camera and accessories from the box and confirm that you have all the

items listed below.

* Plug adapter supplied only in countries or regions where required and its shape varies with

country or region of purchase. The shape of the Charging AC Adapter EH-68P (AR) supplied

in Argentina differs from that supplied in other countries (A6).

NOTE: A Secure Digital (SD) card, hereafter referred to as a “memory card”, is not provided.

See page 138 of the User’s Manual for a list of approved memory cards.

Parts of the Camera

COOLPIX S640

Digital Camera

Camera Strap Rechargeable Li-ion

Battery EN-EL12

(with terminal cover)

Charging AC Adapter

EH-68P/EH-68P (AR)*

USB Cable

UC-E6

Audio Video Cable

EG-CP14

Software Suite

installer CD

•Quick Start Guide (this guide) • User’s Manual •Warranty

A: This icon indicates that more information is available elsewhere in this guide.

1Power switch/Power-on lamp

2Zoom control

3Shutter-release button

4Charge lamp/Flash lamp

5A(shooting mode) button

6c(playback) button

7Rotary multi selector

8k(apply selection) button

9l(delete) button

10 dbutton

11 Battery-chamber/memory card slot cover

12 Monitor

First Steps

Step 1Attach the Strap

Step

Insert the Battery and the Memory Card

*Data will be recorded onto the camera’s internal memory

(approximately 45 MB) even if there is no memory card. If recording

data to the camera’s internal memory, you do not have to insert a

memory card in step 2.3.

. 1 Open the battery-chamber/

memory card slot cover.

Slide the cover latch toward Y(1)

and open the battery-chamber/

memory card slot cover (2).

.2 Insert the battery.

•Insert the Rechargeable Li-ion Battery EN-EL12

(supplied) into the battery chamber.

•Use the edge of the battery to push the orange battery

latch in the direction indicated by the arrow (1) and

fully insert the battery (2). When the battery is fully

inserted, the battery latch will lock it in place.

Inserting the Battery Correctly

Inserting the battery upside down or backwards

could damage the camera. Be sure to check the battery

is in the correct orientation.

Battery chamber

Memory card slot

Battery latch

First Steps 5

. 3 Insert the memory card.

Make sure that the orientation of the memory

card is correct, and slide it in until it clicks into

place.

Inserting the Memory Card Correctly

Inserting the memory card upside down or

backwards could damage the camera or the memory

card. Be sure to check the memory card is in the correct

orientation.

. 4 Close the battery-chamber/memory card slot cover.

Close the battery-chamber/memory card slot cover (1), and

slide the cover latch to the Zposition (2).

BRemoving the Battery and Memory Card

Turn the camera off and confirm that the power-on lamp and the monitor are off before

opening the battery-chamber/memory card slot cover.

Removing the Battery

•To eject the battery, open the battery-chamber/memory card

slot cover and slide the orange battery latch in the direction

shown (1). The battery can then be removed by hand (2).

•Note that the battery may become hot during use; observe

due caution when removing the battery.

Removing Memory Cards

Open the battery-chamber/memory card slot cover and press

the card in (1) gently to partially eject the card. The card can

then be removed by hand (2).

Pages 14, 15, 22 and 23 of the User’s Manual

First Steps

Step 3Charge the Battery

Use the supplied Charging AC Adapter EH-68P and USB Cable UC-E6 to charge the

battery inserted into the camera.

.1 Prepare the Charging AC Adapter EH-68P.

If a plug adapter* is included, attach the plug adapter to the plug on

the Charging AC Adapter. Push the plug adapter firmly until it is

securely held in place. Once the two are connected, attempting to

forcibly remove the plug adapter could damage the product.

* The shape of the plug adapter varies according to the country or

region in which the camera was purchased.

For Customers in Argentina

If the camera was purchased in Argentina, a plug adapter is not

supplied. Proceed to step 3.2.

. 2 Be sure that the power-on lamp and the monitor are off.

Be sure to insert the battery into the camera and turn off the camera.

.3 Use the supplied USB

cable to connect the

Charging AC Adapter to

the camera.

. 4 Plug the Charging AC Adapter into an

electrical outlet.

The camera’s charge lamp slowly blinks

green to indicate that the battery is charging.

Charging is complete when the charge lamp

turns off.

About 4 hours are required to charge a

fully exhausted battery.

.5 Disconnect the Charging AC Adapter from the electrical outlet and then

disconnect the USB cable.

Pages 16-19 of the User’s Manual

EH-68P (AR)

USB cable

First Steps 7

Step 4Turn On the Camera

CAuto Power Off in Shooting Mode (Standby Mode)

If no operations are performed for about a minute (default setting), the monitor will turn off

automatically and the camera will enter standby mode. If no operations are performed for another three

minutes, the camera will turn off automatically (the auto off function). If the monitor is off in standby

mode (power-on lamp is flashing), press the power switch or the shutter-release button to reactivate it.

Step 5Choose a Language and Set the Camera Clock

A language-selection dialog is displayed the first time the camera is turned on.

Follow the steps below to choose a language and set the time and date.

Press the power switch to turn on the

camera. The power-on lamp (green) will

light for a moment and the monitor will

turn on.

. 1

Choose the desired language and press

the kbutton.

. 2

Choose Yes and press the kbutton.

•The time zone selection screen is

displayed.

The Rotary Multi Selector

Use the rotary multi selector to choose and apply settings. Operate

the rotary multi selector by pressing it up, down, left, right and by

pressing the

button.

Advance to the next screen

Move the highlight up.

Move the highlight down.

Apply selection.

(move the highlight to the right).

Return to the previous screen

(move the highlight to the left).

Items can also be highlighted by

rotating the rotary multi selector.

Rotary multi selector operations

used are indicated with U.

Date

Set time and date?

Yes

Cancel

First Steps

The next procedure explains basic shooting operations using A(auto) mode.

. 3

Select your home time zone (city

name) and press the kbutton.

•The Date screen is displayed.

. 4

Press the rotary multi selector up or

down to edit the highlighted item.

•

Press right to move the highlight in the

following order.

(day)

➝

(month)

➝

(year)

➝

hour

➝

minute

➝

DMY

(the order in which the day,

month, and year are displayed).

•Press the rotary multi selector left to

return to the previous item.

. 5

Choose the order in which DMY are

displayed and press the kbutton.

•The settings are applied and monitor

display exits to shooting mode.

•The lens will extend at this time.

CChanging the Language, Date and Time

Select Language or Date from the ztab (setup menu) to change the settings.

•Press the dbutton and choose the ztab to display the setup menu.

•Choose Language to change the language.

•Choose Date to change the date and time. Choose Time zone from the Date option in the

setup menu to change the home time zone (city name) and daylight saving time settings.

Pages 116 and 120 of the User’s Manual

CImprinting the Date on Pictures

After setting the date and time, set the

Date imprint

setting in the setup menu. Once

Date imprint

is set, the shooting date and time can be imprinted on the image data when taking pictures.

Page 124 of the User’s Manual

Back

London

Casablanca

If daylight saving time is in effect, press the

rotary multi selector up to turn on the

daylight saving time option.

When the daylight saving time option is

enabled, Wis displayed at the top of the

monitor.

To turn off the daylight saving time option,

press the rotary multi selector down.

200901

00 00

Date

DMY

Edit

15 10

2009

DMY

Edit

Date

Shooting and Playback 9

Shooting and Playback

Step 1Check Indicators in the Monitor

Check the battery level and number of exposures remaining.

Pages 24-25 of the User’s Manual

Step 2Frame the picture

Position the main subject near the center of the monitor.

Pages 26-27 of the User’s Manual

1313

Number of exposures remaining*

Battery level indicator

Display Description

NO INDICATOR Battery fully charged.

BBattery low. Prepare to replace or charge

the battery.

Battery

exhausted.

Cannot shoot. Recharge or replace with a

fully charged battery.

*When data are recorded to the internal memory, Cis displayed.

1313

Zoom control

Rotate towards gto zoom in and

enlarge the subject, or rotate

towards fto zoom out, increasing

the area visible in the frame.

Shooting and Playback

Step 3Focus and Shoot

.1 Press the shutter-release button halfway, stopping

when you feel resistance.

•Camera automatically selects the

focus area (up to nine areas)

containing the subject closest to

the camera. When the subject is

in focus, the focus area (active

focus area) glows green.

•When the camera is unable to

focus, the focus area blinks in red.

Change the composition and

press the shutter-release button

halfway again.

Flash lamp

The status of the flash can be checked by pressing the shutter-release button halfway.

*If the battery is low, the monitor display will turn off while the flash is charging.

. 2 Smoothly press the shutter-release button the rest of the way

down to take the picture.

Do not use force when pressing the shutter-release button, as this may

cause camera shake, resulting in blurred pictures.

Pages 28-29 of the User’s Manual

On Flash will fire when picture is taken.

Blinks Flash charging.*

Off Flash off or not required.

1/250

F2.7

Flash lamp

Shutter speed Aperture

Focus area

Otros manuales para Coolpix S640

Tabla de contenidos

Otros manuales de Cámara digital de Nikon

Nikon

Nikon 16 Manual de usuario

Nikon

Nikon DXM1200C Instrucciones de montaje

Nikon

Nikon Coolpix P5100 Manual de usuario

Nikon

Nikon COOLPIX L105 Manual de usuario

Nikon

Nikon Coolpix S200 Guía del usuario

Nikon

Nikon D90 - Digital Camera SLR Manual de usuario

Nikon

Nikon D2X - D2X SLR 12.4 Megapixel Digital Camera Manual de usuario

Nikon

Nikon COOLPIX L110 Manual de usuario

Nikon

Nikon Coolpix P300 Manual de usuario

Nikon

Nikon 25587 - Coolpix L14 Digital Camera Guía del usuario

Nikon

Nikon CoolPix S3 Manual de usuario

Nikon

Nikon D-40 - D40 6.1MP The Smallest Digital SLR... Manual de usuario

Nikon

Nikon Pronea 6i Manual de usuario

Nikon

Nikon Coolpix S6100 Manual de usuario

Nikon

Nikon 25492 Manual de usuario

Nikon

Nikon 26175 - Coolpix S70 Digital Camera Guía del usuario

Nikon

Nikon COOLPIX P4 Manual de usuario

Nikon

Nikon Coolpix S50c Manual de usuario

Nikon

Nikon Coolpix S6900 Manual de usuario

Nikon

Nikon COOLPIX S4 Manual de usuario

Nikon

Nikon Coolpix L31 Manual de usuario

Nikon

Nikon Coolpix L12 Manual de usuario

Nikon

Nikon CoolPix P500 Manual de usuario

Nikon

Nikon Coolpix L31 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario

Samsung

Samsung SCC-C4253 Manual de usuario
