Nibe F2016 Manual de usuario

User manual

LEK

NIBE™ F2016

Air/water heat pump

UHB GB 1132-1

031876

Table of Contents

1 Important information 2

Installation data 2

Safety information 4

Serial number 5

Contact information 6

F2016 - An excellent choice 8

2 The heat pump – the heart of the house 9

Heat pump function 9

Contact with F2016 11

Maintenance of F2016 12

3 Disturbances in comfort 17

Troubleshooting 17

4 Technical data 20

5 Glossary 21

Item register 25

1NIBE™ F2016Table of Contents |

1Important information

Installation data

F2016Product

Serial number

Installation date

Installer

Serial number must always be given

Certification that the installation is carried out according to instructions in

NIBE's installer manual and applicable regulations.

_________________________Signed__________________Date

NIBE™ F2016Chapter 1 | Important information2

Accessories

✔

SetDefault

set-

tings

NameChan-

nel

1Communications ad-

dress

4°CConnection diff. re-

turn temp.

20 minStart interval com-

pressor

0°CBalance temperatureA5

120 minTime delay addition

relay

-15 °CStop temperatureA7

60/50

/45

Min. interval between

defrosting

+1 °CStart defrostingA9

+10 °CStop defrostingA10

7 minLongest defrostingA11

3NIBE™ F2016Chapter 1 | Important information

Safety information

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appli-

ance.

Rights to make any design or technical modifications are reserved.

©NIBE 2011.

Symbols

NOTE

This symbol indicates danger to machine or person.

Caution

This symbol indicates important information about what you should observe

when maintaining your installation.

TIP

This symbol indicates tips on how to facilitate using the product.

Marking

F2016 is CE marked and fulfils IP24.

The CE marking means that NIBE ensures that the product meets all regula-

tions that are placed on it based on relevant EU directives. The CE mark is

obligatory for most products sold in the EU, regardless where they are made.

IP24 means that the product is secure against penetration by objects with a

diameter larger than or equivalent to 12.5 mm and that the product is pro-

tected against drops from all directions.

NIBE™ F2016Chapter 1 | Important information4

Serial number

The serial number can be found on the product's foot.

LEK

6HULDO QXPEHU

Caution

Always give the product's serial number when reporting a fault.

5NIBE™ F2016Chapter 1 | Important information

Contact information

KNV Energietechnik GmbH, Gahberggasse 11, 4861 SchörflingAT

Tel: +43 (0)7662 8963-0 Fax: +43 (0)7662 8963-44 E-mail: [email protected]

www.knv.at

NIBE Wärmetechnik AG, Winterthurerstrasse 710, CH-8247 FlurlingenCH

Tel: (52) 647 00 30 Fax: (52) 647 00 31 E-mail: [email protected] www.nibe.ch

Druzstevni zavody Drazice s.r.o, Drazice 69, CZ - 294 71 Benatky nad

Jizerou

Tel: +420 326 373 801 Fax: +420 326 373 803 E-mail: [email protected]

www.nibe.cz

NIBE Systemtechnik GmbH, Am Reiherpfahl 3, 29223 CelleDE

Tel: 05141/7546-0 Fax: 05141/7546-99 E-mail: [email protected] www.nibe.de

Vølund Varmeteknik A/S, Member of the Nibe Group, Brogårdsvej 7,

6920 Videbæk

Tel: 97 17 20 33 Fax: 97 17 29 33 E-mail: [email protected] www.volund-

vt.dk

NIBE Energy Systems OY, Juurakkotie 3, 01510 VantaaFI

Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: [email protected] www.nibe.fi

NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way,

Chesterfield S41 9QG

Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: [email protected]

www.nibe.co.uk

NIBE Energietechniek B.V., Postbus 2, NL-4797 ZG WILLEMSTAD (NB)NL

Tel: 0168 477722 Fax: 0168 476998 E-mail: [email protected] www.nibenl.nl

ABK AS, Brobekkveien 80, 0582 Oslo, Postadresse: Postboks 64 Vollebekk,

0516 Oslo

Tel. sentralbord: +47 02320 E-mail: [email protected] www.nibeenergysys-

tems.no

NIBE-BIAWAR Sp. z o. o. Aleja Jana Pawła II 57, 15-703 BIAŁYSTOKPL

Tel: 085 662 84 90 Fax: 085 662 84 14 E-mail: [email protected]

www.biawar.com.pl

Tel./fax +7 831 419 57 06 E-mail: [email protected] www.nibe-evan.ru

NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 MarkarydSE

Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: [email protected]

www.nibe.se

NIBE™ F2016Chapter 1 | Important information6

For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu

for more information.

7NIBE™ F2016Chapter 1 | Important information

F2016 - An excellent choice

F2016 is an air/water heat pump specially developed for the Nordic climate,

which utilises the outside air so there is no need for bore holes or coils in the

ground.

The heat pump is intended for connection to water borne heating systems

and can both heat hot water effectively at high outdoor temperatures and

give a high output to the heating system at low outdoor temperatures.

If the outdoor temperature drops to a level below the stop temperature all

heating must then occur with external additional heat.

Excellent properties for F2016:

႑Efficient scroll compressor

Efficient scroll compressor that operates at temperatures down to -15 °C.

႑Intelligent control

Integrated intelligent control for optimum control of the heat pump.

F2016 is started by a start signal from another unit (VVM 300 for example)

or thermostat.

႑Fan

With the exception of F2016-6 kW (which only has one fan speed) F2016

has an automatic 2-step capacity control of the fan.

႑Long service life

The material has been chosen for a long service life.

႑Many possibilities

F2016 can also be used together with most electric boilers, oil boilers or

similar.

NIBE™ F2016Chapter 1 | Important information8
