NGM Vanity Manual de usuario
1
Rev.1.0 - 20100805
Contents
1. FOR YOUR SAFETY .......................5
2. MOBILE PHONE PROFILE .............7
3. PREPARATION BEFORE USE .......10
Install SIM Card..............................................10
Install Memory card.......................................12
Install Battery ................................................13
Charge Battery...............................................13
Notices on using the battery..........................15
PIN code ........................................................16
4. GENERAL INSTRUCTIONS...........17
Dial key ..........................................................17
Switch-on/off key /End key............................18
Standard keypad ............................................18
AM/FM function key......................................19
Keypad lock....................................................19
Icons in Standby State ...................................20
Language and Input Mode.............................20
Services..........................................................21
2
Callers’ group.................................................21
5. TERMS DESCRIPTION....................21
Dial domestic calls .........................................21
Dial international calls ...................................22
Dial extension ................................................22
Emergency calls .............................................23
IMEI ...............................................................23
6. BASIC OPERATION .....................24
Switch on .......................................................24
Switch off.......................................................25
Dial a Call .......................................................25
Auto Redial ....................................................26
Adjust Receiver Volume.................................26
Answer a Call .................................................26
Background sound .........................................27
Send DTMF Signal..........................................27
Dial Hold ........................................................27
Fast Read SMS................................................28
Missed Calls ...................................................29
Connect to Voice mail....................................29
Sound recorder..............................................29
7. USE OF MENU FUNCTIONS ...........29
3
7.1 Multimedia...............................................29
7.2 Phonebook ...............................................41
7.3 Call logs ....................................................45
7.4 Services ....................................................49
7.5 IM ............................................................54
7.6 Messaging ................................................55
7.7 Facebook ..................................................65
7.8 Google......................................................65
7.9 Organizer..................................................65
Applications ...................................................68
7.11 Twitter....................................................73
7.12 Settings ..................................................73
8. COFFER FUNCTION .......................79
9. EDITOR OPERATION...................83
Basic letter input............................................83
Number input ................................................83
Symbol input .................................................84
10. USE OF USB .............................84
11. MAINTENANCE & SAFETY...........85
After sales service..........................................85
Charger and Adapter Safety...........................85
Battery Information and Care ........................85
5
1. For your Safety
For your safety and proper use of the
mobile phone, please read the following
guidelines carefully: Do not switch the mobile
phone on when close to chemical factory, gas
station or other explosive objects.
During driving, please use headset for safety
purpose; unless otherwise in emergency,
always stop the car on roadside to have a call
conversation.
Because the use of the mobile phone can
cause interference in the aircraft, never use
the mobile phone in aircraft. The use of the
mobile phone is dangerous and illegal; do
switch off the mobile phone before boarding.
Pay special attention to the use of the mobile
phone near heart pacemaker, deaf-aid and
some other medical equipments, because
the mobile phone can cause interference
with them.
None-original factory’s accessories and parts
will lose guarantee.
Do not dismantle the mobile phone without
permission. In case of failure, please contract
the supplier as soon as possible.
Do not plug the charger into the mobile
6
phone and charge without battery. Always
power off the mobile phone when taking out
the battery; otherwise the memory of the
phone may be damaged.
When charging the mobile phone, always
keep it in the place with good ventilation,
heat sink and away from flammable and
explosive objects.
In order to avoid demagnetization, always
keep the mobile phone away from magnetic
objects such as CD, credit card etc.
Ensure the mobile phone not to contact any
liquid; once such case occurs, remove the
battery and contact the supplier
immediately.
Do not use the mobile phone in the
environment at too high or too low
temperature, never expose the mobile
phone under strong sunshine or too wet
environment. The suitable temperature for
the phone and accessories is 0℃-40℃. The
height to use the phone shall be less than
2,000m.
Do not use liquid or wet cloth with strong
cleanser to clean the mobile phone.
This mobile phone has shooting, videoing
7
and audio recording functions, which shall be
used as per the related laws and regulations.
Always keep the mobile phone out of
children’s reach. Do not throw or vibrate the
mobile phone because violent treatment to
the mobile phone may damage the inner
circuits and precise structures.
Please do not discard the waste battery into
general household garbage. Please deal with
the waste battery according to provisions
where they are definitely made.
2. Mobile Phone Profile
The mobile phone has qwerty keys, including
single screen，one vibration motor, one charger/
data common transmission port. (Below is the
front of the mobile phone).
8
1
2
3
4
9
10
5
6
7
8
9
7
6
1.
Speaker
7.
QWERTY keypad
2.
LCD
8.
Phonebook
3.
Main menu keys
9.
Retreat key
4.
Message Shortcuts
10.
End key
5.
SEND 1 key(SIM-1)
11.
Speaker
6.
SEND 2 key(SIM-2)
12.
Camera
9
11
12
10
3. Preparation before Use
Install SIM Card
When registering mobile phone number,
you can apply for two different phone numbers,
two different mobile phone network service
providers and thus obtain two SIM (Subscriber
Identification Module) cards.
With these two SIM cards, you can use all
functions of your mobile phone. The SIM cards
save the parameters needed for communications
and personal data, including PIN (Personal
Identification Number) code, phonebook, short
message and other extra system services.
Warning: Do not distort or scratch the SIM card
nor let it contact static, dust or moisture. If it is
lost, please contact immediately your network
operator for help.
Before SIM card installation, please switch off
the mobile phone. The SIM card is installed on
the back of the mobile phone.
Follow the following diagram to install the
SIM card. Please insert the host SIM card into the
SIM1 slot and the slave SIM card into the SIM2
