Nexmosphere XN-165 XPERIENCE Manual de usuario

Xperience platform

All of Nexmosphere’s controllers are built on the same platform principles. If this is your rst time using a Nexmosphere

controller, we recommend to rst read https://nexmosphere.com/technology/xperience-platform/ to learn the basics about

our platform and its terminology.

XN-165

The XN-165 is an Xperience controller with 2 X-talk interfaces and

4 Push button interfaces:

1. X-talk interface 001

2. X-talk interface 002

3.1. Push button interface 1 (X-talk address 003)

3.2. Push button interface 2 (X-talk address 003)

3.3. Push button interface 3 (X-talk address 003)

3.4. Push button interface 4 (X-talk address 003)

USB. 5V Power input and API interface (micro-USB connector)

LED. White status LED

Hardware setup

1. Connect one or more Elements to any of the 2 X-talk interfaces. Connect push buttons to the push button interfaces.*

2. Connect the micro-USB cable to a 3rd party device (e.g. Digital Signage Player or PC).

3. Wait until the white status LED stops blinking. This lasts about 5 seconds.

*Nexmosphere oers several push buttons with pre-assembled cable and connector. The product codes for these push buttons are S-B90xxx and S-B95xxx.

Software setup for testing (Terminal)

Typically, the XN-165 controller is connected to a 3rd party device, such as a Digital Signage Player, on which CMS software is installed that has built-in

functionality for sending and receiving Serial Events. However, if you want to do a rst test on a PC or Mac, follow the instructions below:

1. Download a terminal program. For example Termite or Hercules.

2. Open the Terminal program and go to settings. Choose the COM port on which the XN-135 controller enumerated*.

In most cases this is the highest available number in the COM port drop-down setting.

3. Set the COM port settings to the following values

Baudrate 115200 Flow Control None

Parity None EOL CR+LF

Data Bits 8 Protocol ASCII

Stop Bits 1

4. Set the COM port to “Open”. The controller is now ready for use.

5. When sending consecutive API serial commands to the XN-165 controller, place a 50mS delay between each command.

*In case the XN-165 controller is not recognized as a COM port by the 3rd party device, a driver (Prolic PL2303) can be downloaded here.

Functionality

The XN-165 runs our API which provides serial output when a specic sensor Element is triggered (for example a pick-up,

or -motion sensor or touch button) and provides control over output Elements (for example controlling LED strips) via serial

input commands. These API serial commands are typically used to create interactive Xperiences for Digital Signage.

The complete API Manual and additional helpful documents can be found on https://nexmosphere.com/support-

documentation. To get you started, we’ve included some starter examples of our Elements and the corresponding API serial

commands on the following pages.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com

QUICK START GUIDE



All content contained herein is subject to change without prior notice.

1 2

3.1 3.2 3.3 3.4

USB

LED

3rd party devices and software

This Quick Start Guide oers a generic explanation of the setup and operation of the XN-165 Xperience controller. It does

not cover information on how to integrate the Controllers, Elements and their API triggers in specic 3rd party devices or

software. We have manuals available with step-by-step instructions on how to integrate Nexmosphere products with the

products of our hardware, -and software partners. You’ll nd these on the support and partner pages of our website.



Up to 4 push buttons can be connected directly to the XN-165 via Push button interface 1-4.

When a button is pressed, the following API serial commands are sent from the XN-165 to the 3rd party device:

Push button 1 is pressed X003A[3] Push button which was pressed last is released X003A[0]

Push button 2 is pressed X003A[5]

Push button 3 is pressed X003A[9]

Push button 4 is pressed X003A[17]

In case the push buttons have 3.3V LEDs, these can be set to 4 dierent states: on, o, slow blink and fast blink.

Each button LED can be set to a dierent state. However the API command for controlling the LEDs indicates and sets the

state for all LEDs simultaneously. Some example commands are provided below:

all LEDs o

LED 1 slow blink, other LEDS o

LED 1 on, other LEDS o

LED 1 fast blink, other LEDS o

all LEDs fast blink

LED 2 slow blink, other LEDS o

LED 2 on, other LEDS o

LED 2 fast blink, other LEDS o

all LEDs slow blink

LED 3 slow blink, other LEDS o

LED 3 on, other LEDS o

LED 3 fast blink, other LEDS o

all LEDs on

LED 4 slow blink, other LEDS o

An overview of the all available LED control commands is provided in Appendix A on the nal pages of the this document.

LED 4 on, other LEDS

LED 4 fast blink, other LEDS o

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com

QUICK START GUIDE



All content contained herein is subject to change without prior notice.

X003A[0]

X003A[2]

X003A[3]

X003A[1]

X003A[170]

X003A[32]

X003A[48]

X003A[16]

X003A[85]

X003A[8]

X003A[12]

X003A[4]

X003A[255]

X003A[128]

X003A[192]

X003A[64]

XN-165

(Xperience controller)

USB-A to Micro-USB cable

(connect to 3rd party device)

Push bu�ons

(with LED)

1 2 3 4

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com





When a presence sensor connected to X-talk interface

001 detects a person in distance zone 4, the following API

serial command is sent from the XN-165 to the 3rd party

device: X001A[4]

When a presence sensor connected to X-talk interface

001 does not detect a person, the following API serial

command is sent from the XN-165 to the 3rd party device:

X001A[1]



When tag 2 is picked up from an antenna connected to

X-talk interface 001 the following API serial commands are

sent from the XN-165 to the 3rd party device:

XR[PU002]

X001A[1]

When tag 1 is placed on an antenna connected to X-talk

interface 001, the following API serial commands are sent

from the XN-165 to the 3rd party device:

XR[PB001]

X001A[1]

XR[PU002]

XN-165

(Xperience controller)

USB-A to Micro-USB cable

(connect to 3rd party device)

XR-C10

(RFID antenna)

XR-C10

RFID Tags

(number 1-3)

XR-DR1

(RFID antenna driver

XN-165

(Xperience controller)

XY-146

(presence sensor)

USB-A to Micro-USB cable

(connect to 3rd party device)



To initiate an X-Wave LED pattern on an X-Wave connected

to X-talk interface 002, send one of the following API

example commands from the 3rd party device to the XN-

165 controller:

40% brightness, color 0 (white), 0.5 second ramp time

Blue pulsing pattern (99% to 20%), 1.8 second ramp time

White wave pattern moving to the left

X002B[240005]

X002B[399C1801020C180018]

X002B[499018001200009]

USB-A to Micro-USB cable

(connect to 3rd party device)

XW-L96

(X-Wave LED)

XW-L9

XN-165

(Xperience controller)

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com





The XN-165 Xperience controller has 2 X-talk interfaces and 4 push button interfaces to which any combination of Elements

can be connected. For example, three of the examples in this Quick Start Guide can be combined on a single XN-165.

The API commands and operation will remain the same. When connecting multiple Elements that require a high amount of

current (LEDs or push buttons with LED ring), calculate the total required current of the Elements and check if this is within

the specication of the controller and its power supply source.

USB-A to Micro-USB cable

(connect to 3rd party device)

XW-L96

(X-Wave LED)

Push bu�ons

(with LED)

XW-L9

XR XR-C10

(RFID antenna)

XR-C10

RFID Tags

(number 1-3)

XR-DR1

(RFID antenna driver

XN-165

(Xperience controller)

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 0]o o o o

X003A[ 1] fast blink o o o

X003A[ 2] slow blink o o o

X003A[ 3] on o o o

X003A[ 4]o fast blink o o

X003A[ 5] fast blink fast blink o o

X003A[ 6] slow blink fast blink o o

X003A[ 7] on fast blink o o

X003A[ 8]o slow blink o o

X003A[ 9] fast blink slow blink o o

X003A[ 10] slow blink slow blink o o

X003A[ 11] on slow blink o o

X003A[ 12]o on o o

X003A[ 13] fast blink on o o

X003A[ 14] slow blink on o o

X003A[ 15] on on o o

X003A[ 16]o o fast blink o

X003A[ 17] fast blink o fast blink o

X003A[ 18] slow blink o fast blink o

X003A[ 19] on o fast blink o

X003A[ 20]o fast blink fast blink o

X003A[ 21] fast blink fast blink fast blink o

X003A[ 22] slow blink fast blink fast blink o

X003A[ 23] on fast blink fast blink o

X003A[ 24]o slow blink fast blink o

X003A[ 25] fast blink slow blink fast blink o

X003A[ 26] slow blink slow blink fast blink o

X003A[ 27] on slow blink fast blink o

X003A[ 28]o on fast blink o

X003A[ 29] fast blink on fast blink o

X003A[ 30] slow blink on fast blink o

X003A[ 31] on on fast blink o

X003A[ 32]o o slow blink o

X003A[ 33] fast blink o slow blink o

X003A[ 34] slow blink o slow blink o

X003A[ 35] on o slow blink o

X003A[ 36]o fast blink slow blink o

X003A[ 37] fast blink fast blink slow blink o

X003A[ 38] slow blink fast blink slow blink o

X003A[ 39] on fast blink slow blink o

X003A[ 40]o slow blink slow blink o

X003A[ 41] fast blink slow blink slow blink o

X003A[ 42] slow blink slow blink slow blink o

X003A[ 43] on slow blink slow blink o

X003A[ 44]o on slow blink o

7. Appendix A

All available combinations of button

LED control commands

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 45] fast blink on slow blink o

X003A[ 46] slow blink on slow blink o

X003A[ 47] on on slow blink o

X003A[ 48]o o on o

X003A[ 49] fast blink o on o

X003A[ 50] slow blink o on o

X003A[ 51] on o on o

X003A[ 52]o fast blink on o

X003A[ 53] fast blink fast blink on o

X003A[ 54] slow blink fast blink on o

X003A[ 55] on fast blink on o

X003A[ 56]o slow blink on o

X003A[ 57] fast blink slow blink on o

X003A[ 58] slow blink slow blink on o

X003A[ 59] on slow blink on o

X003A[ 60]o on on o

X003A[ 61] fast blink on on o

X003A[ 62] slow blink on on o

X003A[ 63] on on on o

X003A[ 64]o o o fast blink

X003A[ 65] fast blink o o fast blink

X003A[ 66] slow blink o o fast blink

X003A[ 67] on o o fast blink

X003A[ 68]o fast blink o fast blink

X003A[ 69] fast blink fast blink o fast blink

X003A[ 70] slow blink fast blink o fast blink

X003A[ 71] on fast blink o fast blink

X003A[ 72]o slow blink o fast blink

X003A[ 73] fast blink slow blink o fast blink

X003A[ 74] slow blink slow blink o fast blink

X003A[ 75] on slow blink o fast blink

X003A[ 76]o on o fast blink

X003A[ 77] fast blink on o fast blink

X003A[ 78] slow blink on o fast blink

X003A[ 79] on on o fast blink

X003A[ 80]o o fast blink fast blink

X003A[ 81] fast blink o fast blink fast blink

X003A[ 82] slow blink o fast blink fast blink

X003A[ 83] on o fast blink fast blink

X003A[ 84]o fast blink fast blink fast blink

X003A[ 85] fast blink fast blink fast blink fast blink

X003A[ 86] slow blink fast blink fast blink fast blink

X003A[ 87] on fast blink fast blink fast blink

X003A[ 88]o slow blink fast blink fast blink

X003A[ 89] fast blink slow blink fast blink fast blink

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 90] slow blink slow blink fast blink fast blink

X003A[ 91] on slow blink fast blink fast blink

X003A[ 92]o on fast blink fast blink

X003A[ 93] fast blink on fast blink fast blink

X003A[ 94] slow blink on fast blink fast blink

X003A[ 95] on on fast blink fast blink

X003A[ 96]o o slow blink fast blink

X003A[ 97] fast blink o slow blink fast blink

X003A[ 98] slow blink o slow blink fast blink

X003A[ 99] on o slow blink fast blink

X003A[ 100]o fast blink slow blink fast blink

X003A[ 101] fast blink fast blink slow blink fast blink

X003A[ 102] slow blink fast blink slow blink fast blink

X003A[ 103] on fast blink slow blink fast blink

X003A[ 104]o slow blink slow blink fast blink

X003A[ 105] fast blink slow blink slow blink fast blink

X003A[ 106] slow blink slow blink slow blink fast blink

X003A[ 107] on slow blink slow blink fast blink

X003A[ 108]o on slow blink fast blink

X003A[ 109] fast blink on slow blink fast blink

X003A[ 110] slow blink on slow blink fast blink

X003A[ 111] on on slow blink fast blink

X003A[ 112]o o on fast blink

X003A[ 113] fast blink o on fast blink

X003A[ 114] slow blink o on fast blink

X003A[ 115] on o on fast blink

X003A[ 116]o fast blink on fast blink

X003A[ 117] fast blink fast blink on fast blink

X003A[ 118] slow blink fast blink on fast blink

X003A[ 119] on fast blink on fast blink

X003A[ 120]o slow blink on fast blink

X003A[ 121] fast blink slow blink on fast blink

X003A[ 122] slow blink slow blink on fast blink

X003A[ 123] on slow blink on fast blink

X003A[ 124]o on on fast blink

X003A[ 125] fast blink on on fast blink

X003A[ 126] slow blink on on fast blink

X003A[ 127] on on on fast blink

X003A[ 128]o o o slow blink

X003A[ 129] fast blink o o slow blink

X003A[ 130] slow blink o o slow blink

X003A[ 131] on o o slow blink

X003A[ 132]o fast blink o slow blink

X003A[ 133] fast blink fast blink o slow blink

X003A[ 134] slow blink fast blink o slow blink

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 135] on fast blink o slow blink

X003A[ 136]o slow blink o slow blink

X003A[ 137] fast blink slow blink o slow blink

X003A[ 138] slow blink slow blink o slow blink

X003A[ 139] on slow blink o slow blink

X003A[ 140]o on o slow blink

X003A[ 141] fast blink on o slow blink

X003A[ 142] slow blink on o slow blink

X003A[ 143] on on o slow blink

X003A[ 144]o o fast blink slow blink

X003A[ 145] fast blink o fast blink slow blink

X003A[ 146] slow blink o fast blink slow blink

X003A[ 147] on o fast blink slow blink

X003A[ 148]o fast blink fast blink slow blink

X003A[ 149] fast blink fast blink fast blink slow blink

X003A[ 150] slow blink fast blink fast blink slow blink

X003A[ 151] on fast blink fast blink slow blink

X003A[ 152]o slow blink fast blink slow blink

X003A[ 153] fast blink slow blink fast blink slow blink

X003A[ 154] slow blink slow blink fast blink slow blink

X003A[ 155] on slow blink fast blink slow blink

X003A[ 156]o on fast blink slow blink

X003A[ 157] fast blink on fast blink slow blink

X003A[ 158] slow blink on fast blink slow blink

X003A[ 159] on on fast blink slow blink

X003A[ 160]o o slow blink slow blink

X003A[ 161] fast blink o slow blink slow blink

X003A[ 162] slow blink o slow blink slow blink

X003A[ 163] on o slow blink slow blink

X003A[ 164]o fast blink slow blink slow blink

X003A[ 165] fast blink fast blink slow blink slow blink

X003A[ 166] slow blink fast blink slow blink slow blink

X003A[ 167] on fast blink slow blink slow blink

X003A[ 168]o slow blink slow blink slow blink

X003A[ 169] fast blink slow blink slow blink slow blink

X003A[ 170] slow blink slow blink slow blink slow blink

X003A[ 171] on slow blink slow blink slow blink

X003A[ 172]o on slow blink slow blink

X003A[ 173] fast blink on slow blink slow blink

X003A[ 174] slow blink on slow blink slow blink

X003A[ 175] on on slow blink slow blink

X003A[ 176]o o on slow blink

X003A[ 177] fast blink o on slow blink

X003A[ 178] slow blink o on slow blink

X003A[ 179] on o on slow blink

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 180]o fast blink on slow blink

X003A[ 181] fast blink fast blink on slow blink

X003A[ 182] slow blink fast blink on slow blink

X003A[ 183] on fast blink on slow blink

X003A[ 184]o slow blink on slow blink

X003A[ 185] fast blink slow blink on slow blink

X003A[ 186] slow blink slow blink on slow blink

X003A[ 187] on slow blink on slow blink

X003A[ 188]o on on slow blink

X003A[ 189] fast blink on on slow blink

X003A[ 190] slow blink on on slow blink

X003A[ 191] on on on slow blink

X003A[ 192]o o o on

X003A[ 193] fast blink o o on

X003A[ 194] slow blink o o on

X003A[ 195] on o o on

X003A[ 196]o fast blink o on

X003A[ 197] fast blink fast blink o on

X003A[ 198] slow blink fast blink o on

X003A[ 199] on fast blink o on

X003A[ 200]o slow blink o on

X003A[ 201] fast blink slow blink o on

X003A[ 202] slow blink slow blink o on

X003A[ 203] on slow blink o on

X003A[ 204]o on o on

X003A[ 205] fast blink on o on

X003A[ 206] slow blink on o on

X003A[ 207] on on o on

X003A[ 208]o o fast blink on

X003A[ 209] fast blink o fast blink on

X003A[ 210] slow blink o fast blink on

X003A[ 211] on o fast blink on

X003A[ 212]o fast blink fast blink on

X003A[ 213] fast blink fast blink fast blink on

X003A[ 214] slow blink fast blink fast blink on

X003A[ 215] on fast blink fast blink on

X003A[ 216]o slow blink fast blink on

X003A[ 217] fast blink slow blink fast blink on

X003A[ 218] slow blink slow blink fast blink on

X003A[ 219] on slow blink fast blink on

X003A[ 220]o on fast blink on

X003A[ 221] fast blink on fast blink on

X003A[ 222] slow blink on fast blink on

X003A[ 223] on on fast blink on

X003A[ 224]o o slow blink on

All content contained herein is subject to change without prior notice.

Nexmosphere

Le Havre 136

5627 SW Eindhoven • The Netherlands

T +31 40 240 7070

Esupport@nexmosphere.com



LED 1 LED 2 LED 3 LED 4

X003A[ 225] fast blink o slow blink on

X003A[ 226] slow blink o slow blink on

X003A[ 227] on o slow blink on

X003A[ 228]o fast blink slow blink on

X003A[ 229] fast blink fast blink slow blink on

X003A[ 230] slow blink fast blink slow blink on

X003A[ 231] on fast blink slow blink on

X003A[ 232]o slow blink slow blink on

X003A[ 233] fast blink slow blink slow blink on

X003A[ 234] slow blink slow blink slow blink on

X003A[ 235] on slow blink slow blink on

X003A[ 236]o on slow blink on

X003A[ 237] fast blink on slow blink on

X003A[ 238] slow blink on slow blink on

X003A[ 239] on on slow blink on

X003A[ 240]o o on on

X003A[ 241] fast blink o on on

X003A[ 242] slow blink o on on

X003A[ 243] on o on on

X003A[ 244]o fast blink on on

X003A[ 245] fast blink fast blink on on

X003A[ 246] slow blink fast blink on on

X003A[ 247] on fast blink on on

X003A[ 248]o slow blink on on

X003A[ 249] fast blink slow blink on on

X003A[ 250] slow blink slow blink on on

X003A[ 251] on slow blink on on

X003A[ 252]o on on on

X003A[ 253] fast blink on on on

X003A[ 254] slow blink on on on

X003A[ 255] on on on on

Otros manuales de Controladores de Nexmosphere

Nexmosphere

Nexmosphere XM-350 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XC-941 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XC-948 Manual de usuario

Nexmosphere

Nexmosphere XC-847 Manual de usuario

Nexmosphere

Nexmosphere XM-350 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XN-135M8L Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XM-350 Manual de usuario

Nexmosphere

Nexmosphere XM-350 Manual de usuario

Nexmosphere

Nexmosphere XC-760 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XC-938 Manual de usuario

Nexmosphere

Nexmosphere XN-135M3 Manual de usuario

Nexmosphere

Nexmosphere SM-125 Manual de usuario

Nexmosphere

Nexmosphere XC-820 Manual de usuario

Nexmosphere

Nexmosphere XN-185 Manual de usuario

Nexmosphere

Nexmosphere XM-350 Manual de usuario

Nexmosphere

Nexmosphere Xperience XN-135M8S Manual de usuario

Nexmosphere

Nexmosphere XC-720 Manual de usuario

Nexmosphere

Nexmosphere XN-180 Manual de usuario

Nexmosphere

Nexmosphere XM-350 Manual de usuario

Nexmosphere

Nexmosphere XC-931 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XN-125 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XC-860 Manual de usuario

Nexmosphere

Nexmosphere XPERIENCE XC-748 Manual de usuario

Nexmosphere

Nexmosphere XY-240 Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
