Netvox R311DB Manual de usuario

Model：R311DB

Wireless Vibration Sensor , Spring Type

Wireless Vibration Sensor

Spring Type

R311DB

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained

in strict confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX

Technology. The specifications are subject to change without prior notice.

Table of Content

1. Introduction.............................................................................................................................................................2

2. Appearance..............................................................................................................................................................3

3. Main Features..........................................................................................................................................................3

4. Set up Instruction ....................................................................................................................................................4

5. Data Report .............................................................................................................................................................5

6. Installation...............................................................................................................................................................8

7. Important Maintenance Instruction.........................................................................................................................9

1. Introduction

R311DB is a wireless long-distance spring-type vibration device that is a Class A device based on the LoRaWANTM protocol of

NETVOX. It is compatible with the LoRaWAN protocol.

LoRa Wireless Technology:

LoRa is a wireless communication technology famous for its long-distance transmission and low power consumption. Compared

with other communication methods, LoRa spread spectrum modulation technique greatly extend the communication distance. It

can be widely used in any use case that requires long-distance and low-data wireless communications. For example, automatic

meter reading, building automation equipment, wireless security systems, industrial monitoring. It has features like small size,

low power consumption, long transmission distance, strong anti-interference ability and so on.

LoRaWAN:

LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and

gateways from different manufacturers.

2. Appearance

3. Main Features

Compatible with LoRaWAN

2 sections of 3V CR2450 button battery power supply

Voltage and device dumping status detection

Simple operation and setting

Protection level IP30

Compatible with LoRaWANTM Class A

Frequency hopping spread spectrum

Configuration parameters can be configured via a third-party software platform, data can be read and alerts can be set via

SMS text and email (optional)

Applicable to third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne

Low power consumption and long battery life

Note:

Battery life is determined by the sensor reporting frequency and other variables, please refer to

http://www.netvox.com.tw/electric/electric_calc.html

On this website, users can find battery life time for varied models at different configurations.

Indicator

Function Key

4.Set up Instruction

On/Off

Power on

Insert batteries (user may need a screwdriver to open)

Insert 2 x 3V CR2450 button batteries into the battery slot in the correct direction and close the

back cover.

Note: Require 2 button batteries to supply power at the same time.

Turn on Press any function key till the green and red indicator flashes once.

Turn off

(Restore to factory setting)

Press and hold two function keys for 5 seconds and the green indicator flashes 20 times.

Power off Remove Batteries.

Note:

1. Remove and reinsert the battery: the device will remember the previous on/off status by

default.

2. After insert batteries and press the button at the same time, the device will be in engineering

testing mode.

3. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor

inductance and other energy storage components.

Network Joining

Never joined the network

Turn on the device to search the network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Had joined the network

Turn on the device to search the previous network to join.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Fail to join the network

(when the device is on)

Suggest to check the device verification information on the gateway or consult your platform

server provider.

Function Key

Press and hold for 5 seconds

Restore to factory setting / Turn off

The green indicator flashes 20 times: success

The green indicator remains off: fail

Press once The device is in the network: the green indicator flashes once and sends a report

The device is not in the network: the green indicator remains off

Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the reportchange exceeds setting value or the state changes: send a data report according

to Min Interval.

Low Voltage Warning

Low Voltage 2.4V

5. Data Report

Data report configuration and sending period are as following:

Min Interval

(Unit:second)

Max Interval

(Unit:second) Reportable Change Current Change≥

Reportable Change

Current Change＜

Reportable Change

Any number between

1~65535

Any number between

1~65535 Can not be 0. Report

per Min Interval

Report

per Max Interval

When the device is turned on, it will immediately send a version package and an attribute report data.

The device sends data according to the default configuration before any other configuring.

Default setting:

Maximum time: 3600s

Minimum time: 3600s (Default: Every Min Interval will detect the state of the dry contact one time)

BatteryChange: 0x01 (0.1V)

(If there are special customized shipments, the settings will be changed according to customer’s requirement.)

R311DB trigger:

When any way of the sensor senses the vibration and the spring deforms, an alarm message will be reported..

The vibration is “1”.

No vibration is “0”.

Note:

The interval between two reports must be the MinTime.

The reported data is decoded by the Netvox LoRaWANApplication Command document and

http://loraresolver.netvoxcloud.com:8888/page/index

Example of ConfigureCmd

FPort：0x07

Bytes 1 1 Var (Fix =9 Bytes)

CmdID DeviceType NetvoxPayLoadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

Description Device Cmd

Device

Type NetvoxPayLoadData

ConfigReport

Req

R311

0x01

0xA9

MinTime

(2bytes Unit: s)

MaxTime

(2bytes Unit: s)

BatteryChange

(1byte Unit: 0.1v)

Reserved

(4Bytes, Fixed 0x00)

ConfigReport

Rsp 0x81 Status

(0x00_success)

Reserved

(8Bytes, Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes, Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit: s)

MaxTime

(2bytes Unit: s)

BatteryChange

(1byte Unit: 0.1v)

Reserved

(4Bytes, Fixed 0x00)

(1) Command Configuration:

MinTime = 1min、MaxTime = 1min、BatteryChange = 0.1v

Downlink：01A9003C003C0100000000 // 003C(Hex) = 60(Dec)

Response：

81A9000000000000000000 (Configuration success)

81A9010000000000000000 (Configuration failure)

(2) Read Configuration:

Downlink：02A9000000000000000000

Response：82A9003C003C0100000000 (Current configuration）

Example for MinTime/MaxTime logic:

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V

Max Time Max Time

Sleeping (Min Time) Sleeping (Min Time)

1H 2H 3H

Note:

MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange

value.

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

Sleeping (MinTime) sleeping sleeping sleeping

0H 15th M 30th M 45th M 1H 2H

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

MaxTime

sleeping sleeping ...

0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORT 2.8V

Wakes up and

collects data

REPORTS

2.8V

Wakes up and

collects data

2.7V |2.7-2.8|=0.1

REPORTS 2.7V

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data 2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

REPORTS

2.7V

Wake up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

REPORTS 2.8V

Wakes up and

collects data

2.8V

Does not report

Users push the button,

REPORTS 2.7V.

Recalculate MaxTime.

Wakes up and

collects data

2.8V

Does not report

Wakes up and

collects data

2.8V

Does not report

Note:

1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect

data.

2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value,

the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device

reports according to MaxTime interval.

3)We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up

frequently and the battery will be drained soon.

4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle

of MinTime / MaxTime calculation is started.

6. Installation

(1) The device does not have a waterproof function. After the configuration of joining the network is completed,

please place it indoors.

(2) The dust at the installation location should be wiped clean before paste the device.

(3) The battery installation method is as the figure below. (the battery with the "+" side facing up)

Note: The user may need a screwdriver to open the cover.

7. Important Maintenance Instruction

Kindly pay attention to the following in order to achieve the best maintenance of the product:

•Keep the equipment dry. Rain, moisture and various liquids or water may contain minerals that can corrode

electronic circuits. In case the device is wet, please dry it completely.

•Do not use or store in dusty or dirty areas. This way can damage its detachable parts and electronic components.

•Do not store in excessive heat place. High temperatures can shorten the life of electronic devices, destroy batteries,

and deform or melt some plastic parts.

•Do not store in excessive cold place. Otherwise, when the temperature rises to normal temperature, moisture will form

inside which will destroy the board.

•Do not throw, knock or shake the device. Treating equipment roughly can destroy internal circuit boards

and delicate structures.

•Do not wash with strong chemicals, detergents or strong detergents.

•Do not paint the device. Smudges can make debris block detachable parts up and affect normal operation.

•Do not throw the battery into the fire to prevent the battery from exploding. Damaged batteries may also explode.

All the above suggestions apply equally to your device, batteries and accessories.

If any device is not operating properly.

Please take it to the nearest authorized service facility for repairing.

Tabla de contenidos

Otros manuales de Accesorios de netvox

netvox

netvox R718VA Manual de usuario

netvox

netvox R718PA11 Manual de usuario

netvox

netvox RA0716 Manual de usuario

netvox

netvox R718N3 Manual de usuario

netvox

netvox R718DB2 Manual de usuario

netvox

netvox R72616A Manual de usuario

netvox

netvox R311FA Manual de usuario

netvox

netvox R718E Manual de usuario

netvox

netvox R311D Manual de usuario

netvox

netvox R718CT Manual de usuario

netvox

netvox R809A Manual de usuario

netvox

netvox RA0701 Manual de usuario

netvox

netvox R718UBB Series Manual de usuario

netvox

netvox R711 Manual de usuario

netvox

netvox Contact Sensor Series Manual de usuario

netvox

netvox R718F2 Manual de usuario

netvox

netvox R711 Manual de usuario

netvox

netvox R809A Manual de usuario

netvox

netvox RA0716 Manual de usuario

netvox

netvox R311DA Manual de usuario

netvox

netvox R718PB15 Manual de usuario

netvox

netvox R718VB Manual de usuario

netvox

netvox R718X Manual de usuario

netvox

netvox R718PE01 Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario

netvox R311DB Manual de usuario

Manuales populares de Accesorios de otras marcas
