Netvox Z808B Manual de usuario

Model：Z808B

Wireless Dimmable Power Plug with Power

Monitoring LCD & USB Port

Wireless Dimmable Power Plug with Power Monitoring

LCD & USB Port

User Manual

Firmware: V5.1

Hardware: V2.4

Table of Content

1. INTRODUCTION......................................................................................................................... 4

2. PRODUCT CHARACTERISTICS..............................................................................................4

3. OPERATION INSTRUCTIONS..................................................................................................4

3.1 POWER ON.................................................................................................................................. 4

3.2 JOIN THE NETWORK.................................................................................................................... 5

3.3 END DEVICE BIND..................................................................................................................... 5

3.4 UNDER CONTROL....................................................................................................................... 6

3.5 ALLOW NETWORK-JOIN FUNCTION............................................................................................. 6

3.7 RESTORE FACTORY SETTINGS..................................................................................................... 7

3.8 ERASE POWER INFORMATION..................................................................................................... 7

3.10 PRODUCT ATTRIBUTES AND CUSTOM INSTRUCTIONS............................................................... 9

4. LOAD CHARACTERISTICS....................................................................................................10

5. RELATED PRODUCTS............................................................................................................. 10

6. INSTALLATION METHODS AND PRECAUTIONS FOR USE.........................................11

7. MAINTENANCE.........................................................................................................................11

Z808B Appearance

Load Socket

Binding Key

LCD Display

Function Key

USB Port 1

USB Port 2

1. Introduction

Z808B (ZigBee Dimmer Control with Power Consumption Display) is used as a

routing device in the network, allowing other devices to be their sub-devices. The

Z808B device can detect the current, voltage, power and energy of the load. At the

same time, the Z808B can be bound to the control device with the switch

function/level control function, and the Z808B switch/level can be controlled by the

bonded device .

ZigBee wireless technology:

ZigBee is an emerging short-range, low-complexity, low-power, low-data-rate,

low-cost wireless network technology. It is a technical proposal between wireless tag

technology and Bluetooth. Mainly used for short-range wireless connections. It

communicates with thousands of tiny sensors in accordance with the 802.15.4

standard. These sensors require very little energy to relay data from one sensor to

another in a relay, and their communication efficiency is very high. In some locations,

the use of ZigBee wireless technology may be limited. Please consult your local

authorities or service provider.

2. Product Characteristics

Fully compatible with IEEE 802.15.4

Use the 2.4GHz ISM band for a total of 16 channels

100-240 VAC 50/60Hz power supply

Communication distance are up to 210 meters

(depending on specific environmental conditions)

Simple operation and setting

3. Operation instructions

3.1 Power on

Connect the Z808B device to the AC 100-240V power supply, power on the device,

and the LCD backlight is always on.

3.2 Join the network

In order to Z808B capable of ZigBee communication to other devices in the network,

it is necessary to Z808B added ZigBee network, the screen operates as follows:

a) Open the allowable screening function of the coordinator or routing device on the

same channel as the Z808B in the network.

b) Z808B is used as a router in the network. It actively searches for the network

immediately after power-on. does not blink before the network is added ,

and the value area displays the power information.

c) The network-joining is successful, and is always on, indicating that the

network-joining is successful; the LCD information area displays the power

information. As shown below

displaying electricity consumption 10.5 kWh.

3.3 End Device Bind

Z808B can bind device such as the client end having ON / OFF cluster with control or

level control cluster such as Netvox Z503/Z501, binding operation is as follows :

a) Press the binding key for 3 seconds till blinks once. At this time, the LCD

value area displays the bind information, and the device issues a binding request.

As shown in the figure ,and operate the bound device

within 16 seconds so that it also issues a binding request. Once the binding

operation is successful, it will show word good and

flash for 3 seconds and return to the main page. Once the binding operation is failure, it

will show word fail and flash for 3 seconds and return to the

main page.

b) Unbind operation: If operating the bound device to be bound again, it will be

unbound.

Note: The device supports only 16 groups, 16 scenes.

3.4 Under control

1. Binding Control: the bound device will send switching / level commands to

control the load connected to Z808B on the switch / level functions.

2. Direct control

Short press the

bind button

External

dimming light

brightness

Short press the

bind button

External dimming

light brightness

1 time 12.5 9 times 87.5

2 times 25 10 times 75

3 times 37.5 11 times 62.5

4 times 50 12 times 50

5 times 62.5 13 times 37.5

6 times 75 14 times 25

7 times 87.5 15 times 12.5

8 times 100 16 times 0

Regardless of the status of the external light, short press the device after power-on and

the dimming level changes according to the above table.

3.5 Allow network-join function

As a router in the network, the Z808B has the function of allowing other devices to

join the network as its sub devices. At the same time, press the binding button and the

function button for 1 second. After 1 second , the icon will flash. After the button

is released, the LCD value field will display JOIN for 1 second and then return to the

power display screen, and the unlock icon will start flashing for 60 times as

shown ;the network-join is allowed to last for one minute

and automatically shut down after one minute. If pressing the binding key and the

function button for 1 second again during the process of allowing the network-join

process, and the device will turn off the function.

3.6 Power, power, voltage, current switching display

In the power display interface, press the function button to switch to voltage (in volts),

current (in amps), power (in watts), and power (in kWh).

3.7 Restore factory settings

After the Z808B joins the network , it will save its assigned network address. If users

want to join a new network, users need to restore the device to the factory settings

first. Press and hold the bind button for 15 seconds ( icon flashes for 3 times). After

releasing the button, press the function button for 2 seconds to restore the factory

settings. The LCD value area display which means

that the factory reset is successful. The device automatically restarts, and the network

can be re-joined.

3.8 Erase power information

The power information detected by Z808B will be stored in the eeprom memory.

When the factory value is restored, the power information will not be erased. Users

can erase the power information by the following method. Press and hold the binding

key for 20 seconds ( icon flashes for 4 times). Release and press the function key

within 2 seconds. Z808B will erase power information and the power information is

displayed as 0, the LCD numerical display power information area , as shown in FIG.

3.9 ZigBee Description

1.End Point(s) : 0x01

2.Device ID : Dimmer Light (0x0101 )

3.Cluster ID which the endpoint supports

Cluster ID for Z808B

Server side Client side

EP 0X01 (Device ID: Dimmer Light (0x 0101 )

Basic ( 0x0000 ) None

Identify (0x0003)

Groups (0x0004)

Scenes (0x0005)

On/Off (0x0006)

Level Control (0x0008)

Commissioning ( 0x0015 )

Simple Metering ( 0x0702 )

Electrical Measurement ( 0x0B04 )

Diagnostics (0x0B05)

4. Related attribute definitions for each Cluster :

( 1 ) Attributes of the Basic Device Information attribute set

Identifier Name Type Range Access Default

Mandator

y /

Optional

0x0000 ZCLVersion 8-bit

Unsigned

integer

0x00

–0xff

Read

only

0x0 3 M

0x0001 Application

Versio n

8-bit

Unsigned

integer

0x00

–0xff

Read

only

0x33 O

0x0002 Stack

Version

8-bit

Unsigned

integer

0x00

–0xff

Read

only

0x53 O

0x0003 HWVersion 8-bit

Unsigned

integer

0x00

–0xff

Read

only

0x18 O

0x0004 Manufacture

r Name

Character

string

0 – 32

Bytes

Read

only

Netvox O

0x0005 ModelIdentif

ier

Character

string

0 –

32bytes

Read

only

Z808BE

0x0006 DateCode Character

string

0 – 16

bytes

Read

only

2015012

0x0007 PowerSourc

8-bit

Enumerati

0x00

–0xff

Read

only

0x0 1 M

0x0010 Location

Description

Character

string

0 –

16bytes

Read/wr

ite

-- O

0x0011 Physical

Environment

8-bit

Enumerati

0x00

–0xff

Read/wr

ite

-- O

0x0012 Device

Enabled

Boolean 0x00–0x

0 1

Read/wr

ite

0x01 O

3.10 Product attributes and custom instructions

1. The cluster that Z808B uses is refer to SE in Simple Metering used in the Cluster

ID ( 0x0702 ) and Electrical the Measurement the ClusterID (0x0B04) , and the

Cluster ID ( 0x0702 ) in NETVOX custom current, voltage, power, energy attribute .

Cluster ID (0x0B04):

(1) The current attribute uses the Attribute ID : 0x0508 , voltage attribute 0x0505 .

(2) The power attribute uses the Attribute ID : 0x050B , and the power factor attribute

0x0510.

Cluster ID ( 0x0702 ) :

(1) The current attribute uses the Attribute ID : 0xE000 , voltage attribute 0xE001 .

(2) The power attribute uses the Attribute ID : 0xE002, and the power attribute

0xE003.

(3) The attribute CurrentSummationDeliver that implements the AttributeID of

0x0000 corresponds to the power attribute 0xE003 .

In addition, the attribute InstananouesDemand with the AttributeID of 0x0400 is

implemented corresponding to the power attribute 0xE0002 .

(4)

1 ) The power ATTRID = 0xE003 ( or 0x0000), the unit is Wh ; the power

ATTRID = 0xE002 ( or 0x0400), the unit is W ;

2 ) Current ATTRID=0xE000, the unit is mA;

voltage ATTRID = 0xE001, the unit is V

2 . Custom command

The instruction format for erasing the current battery information is:

CMD=0CE0 LEN ADDRMODE DSTADDR DSTENDPOINT CLUSTER_ID

ACTION

4. Load Characteristics

Rated Load ( AC )

** Remark**

Max. Load with

LEDs *

*Remark**

Max. Surge

Endurable

Surge

Detection

Overload

Protection with

Auto Power

Cutoff

400W/3A/250V 100W/4LEDs 150A Yes Yes

Note: Hardware board V3.0 supports impact, V2.4 does not support impact.

5. Related Products

Z810A : Switch control unit with consumption display

Z800B : Power Socket with Power Consumption Monitoring

Tabla de contenidos

Otros manuales de Accesorios de netvox

netvox

netvox R720FLD Manual de usuario

netvox

netvox R315 Series Manual de usuario

netvox

netvox R718PB15 Manual de usuario

netvox

netvox R718AD Manual de usuario

netvox

netvox R711 Manual de usuario

netvox

netvox R313B Manual de usuario

netvox

netvox R718EA Manual de usuario

netvox

netvox R718N1 Manual de usuario

netvox

netvox RB11E Manual de usuario

netvox

netvox RA0701 Manual de usuario

netvox

netvox R718PE Manual de usuario

netvox

netvox R718N1 Manual de usuario

netvox

netvox RA0711 Manual de usuario

netvox

netvox R718DB Manual de usuario

netvox

netvox RA0708 Manual de usuario

netvox

netvox R311G Manual de usuario

netvox

netvox RA0701 Manual de usuario

netvox

netvox R718DB2 Manual de usuario

netvox

netvox R311DA Manual de usuario

netvox

netvox ZigBee Z801WLS Manual de usuario

netvox

netvox ZigBee ZB11B Manual de usuario

netvox

netvox R718PA4 Manual de usuario

netvox

netvox R718UBD Series Manual de usuario

netvox

netvox R311CB Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario

netvox Z808B Manual de usuario

Manuales populares de Accesorios de otras marcas
